Cubex Software Overview - 3D Systems CubeX Duo User Manual

2 . Run the CubeX Setup file. (Fig. 52)
3 . Follow the installer wizard. (Fig. 53)
4 . Select a destination for the installation . (Fig . 54)
5 . Click next to begin the installation . A message "if you want to let the
CubeX software make changes to your computer" will appear, select
yes . (Fig . 55 & 56)
6 . The installation is now complete, you can open the CubeX software from the icon located on
your desktop . (Fig . 57)

CUBEX SOFTWARE OVERVIEW

• The CubeX software is used to create the .cubex files that your CubeX will use to
create your parts. The software allows you to orient, scale, re-size and rotate the
part before printing . (Fig . 58)
• When you first open the CubeX software you will be greeted with a message
asking you to configure your printer in the CubeX software. (Fig. 59)
Fig . 55
18
Fig . 52
Fig . 53
Fig . 54
Fig . 56
Fig . 57
Fig . 58
Fig . 59
