AT800 Series User Manual
Headset
To connect the headset:
Connect the RJ‐9 headset to the headset jack on the left side of the phone. The pin sequence of
RJ9 port on the phone is like following picture:
Sip Register
Before using the phone, user have to follow below steps to register it.
To register the phone:
1. Viewing the Network Information:
Press Menu softkey
Enter login password (default: 123)
Scroll to [6.Network] and press select softkey
To view the network information:
Current IP : 172.16.0.110, etc.
Current Net mask:255.255.255.0
2. Access the IP Phone administrator web user interface:
Launch a web browser on a computer that can reach the phone on the network.
Enter the IP address of the phone in web browser address bar. For example:
http://172.16.0.110
