AT800 Series User Manual
3. Configuring the SIP parameters:
Click admin on the right corner of the webpage to login administrator interface
Click Account tab
Under SIP parameters, make the necessary configuration changes to the fields shown in the
following table and click submit:
Enable: yes/no
User ID:
Password:
SIP Server:
SIP Port:
Transport Type:
After that, click submit button to save the configuration. The phone will be restart automatically to make
the changes effect.
Warning: If the parameter remember account is set to yes, the account information will be saved
automatically, user don't have to make a manual login after a restart; if it is set to no, user will have to
enter the User ID and password manually every time restating the phone.
Basic Phone Functions
Place or Answer a call
Press headset button to place or answer a call
If the auto answer parameter is set to yes, the incoming call will be answered automatically.
Enter the Redial list menu, use navigation button to scroll down to highlight an history number, and
press Dial to complete the call.
Use the programmable key to place a call to the pre‐configured number.
For AT800/AT800P, user can place a call as followings:
1. Press headset button, enter number and # (send key) to dial
2. Press headset button, enter a speed dial number, the pre‐configured number will be dialed
3. To hang up the active call, press headset button again.
Note: If setting * as the send key, use * instead of #, If send key is set to none, wait for about 10 seconds,
the number will be dialed automatically.
ATCOM TECHNOLOGY CO., LIMITED
Enable/disable the SIP registration
The username, provided by ISP.
The password, provided by ISP.
The registrar and proxy server (we don't distinguish
between the registrar server and the proxy server right
now).
The default SIP port is: 5060, user can modify it to fit the SIP
server's port.
Optional transport type, can be set as UDP/TCP/TLS
