AT800 Series User Manual
Description of the keys and Screen:
Soft buttons Press to select an feature shown in the soft button features
LCD Screen Display screen for the phone: It shows the date, time, phone number,
incoming caller's ID(if available),line/call status, extension numbers and
the soft button features.
Navigation button 1. Move cursor up and down when pressed in menu reviewing.
2. Adjust output volume when pressed in talking state
3. Adjust ringer volume when pressed in idle state.
1~9,*# For entering numbers, letters or characters
Programmable Key Function key can be defined as Speed dial key, CFWD, Hold, Xfer, ConF,
DND, Redial, Voicemail.
Menu Enter Keypad menu settings
Mute button Mute/un‐mute mic‐phone in talking state
Headset button Pick up phone to make outgoing calls or answer incoming calls.
MWI Message waiting indicator/ Ringing indicator
Login button 1. Press to enter login interface to input SIP account username and
password to register to sip server.
2. Press in login‐ed state to input SIP account password to logout.
