Others; Voice; Echo Cancellation - ATCOM AT800D User Manual

AT800 Series User Manual
when there is no one to pick up the call after the no answer timeout.
After Ring Time (seconds)‐‐‐Set no answer timeout. Default is 5s.

Others

Send key‐‐‐Choose * or # to be the send key to dial out the entered number immediately.
Enable Do Not Disturb‐‐‐Enable or disable Do not disturb. When enabled, all incoming calls will be
rejected. If always call forward or busy call forward is enabled, it will forwards the call to the target
number.
Enable Block Call ID‐‐‐When choosing yes, the phone will call others by an anonymous caller id.
Enable Block Anc Call‐‐‐When choosing yes, the anonymous incoming call will be rejected
Enable Auto Answer‐‐‐When choosing yes, the phone will answer the call automatically right away
when there is an incoming call.
Remember Account‐‐‐When choosing yes, the phone will auto login after a restart every time.
When choosing no, user should login manually via keypad after a restart. For AT800/AT800P, if
choosing remember account to NO, user should login manually on the phone by pressing Login key +
*number*password#. E.G. Sip number is 1234, password is 5678, user should press Login key, and
then press *1234*5678# to login. To logout on the phone, just press Login key + *password#. E.G.
*5678# .
After finishing, click submit button to save changes.
Voice
Echo Cancellation
VAD‐‐‐Voice Activity Detection: when choosing yes, the phone will not send RTP packets at the silent
ATCOM TECHNOLOGY CO., LIMITED www.atcom.cn
