AT800 Series User Manual
a) SIP Qos—Quality of service for SIP (Diffserv)
b) Voice Qos—Quality of service for RTP (Diffserv)
5. Syslog use syslog to output the log of the the device
a) Enable syslog: yes/no, enable/disable syslog service
b) Log level: none, alert, critical, Error, Warning, Notice, Info, Debug
c) Syslog server—syslog server address, e.g. 172.16.0.55
d) Port—syslog server port to receive message, default to 514
Click submit to save changes, and the phone will reboot automatically.
SIP settings
To view and edit SIP and RTP parameters:
Log in to the web interface.
Choose SIP settings
SIP Parameters
1. SIP User Agent Name‐‐‐This name will appear in the header field User‐agent in all SIP
method which is not REGISTER
2. SIP Reg User Agent Name‐‐‐This name will appear in the header field User‐agent in the SIP
method REGISTER
SIP Timer Values
1. SIP T1‐‐‐RFC 3261 T1 value (RTT estimate). Range from 0 to 64 seconds. Defaults to 0.5
seconds
2. SIP T2‐‐‐RFC 3261 T2 value, which is the maximum retransmit interval for non‐INVITE
requests and INVITE responses. Ranges from 0 to 64 seconds. Defaults to 4 seconds
3. SIP T4‐‐‐RFC 3261 T4 value, which is the maximum duration a message remains in the
network. Ranges from 0 to 64 seconds. Defaults to 5 seconds
4. Reg Retry Intvl‐‐‐interval to wait before the phone retries registration after failing during
