Output Format
Format Extract
Format Insert
Format Assign
Output Format Status
Output Filter Configuration
Output Filter Enable
Format Extract
Output Index
Serial Cmd: <K740,output
Options: 1 to 100
Start Location
Serial Cmd: <K740,output
Default: 0
Options: 1 to n (maximum number of characters in the symbol data).
Length
Serial Cmd: <K740,output index,start location,length>
Default: 0 (Disabled; end of format cell array)
Options: 1 to n (maximum number of characters in the symbol data).
Format Insert
Output Index
Output Index refers to the database entry to be modified with this command. A formatted
output is built by extracting data from a symbol's original data output and/or inserting
user-defined characters.
It may be helpful to think of individual indexes as positions in the final formatted output.
Starting with index # 1, enter either an extract or insert command to begin building the
required output string. Then, with the next index number, enter either an extract or insert
command to continue building the output string. Continue this process until the string is
complete.
Serial Cmd: <K741,output
Options: 1 to 100
QX-870 Industrial Raster Scanner User's Manual
<K740,output index,start location,length>
<K741,output index,length,hex string>
<K742,symbol number,status>
<K743,output format status>
<K744,filter number,symbology,length,wildcard,placeholder,
data,decode direction,database index>
<K745,number of filters>
index,start location,length>
index,start location,length>
index,length,hex string>
Appendices
A-71
