Connectors
3.5

LCD glass daughterboard connectors CN6 and CN7

Two 48-pin male headers CN6 and CN7 connect the LCD glass daughterboard (MB979).
GPIOs which act as LCD glass signals and are not on CN5 and CN10 are available on these
two connectors. The space between these two connectors and the position of every LCD
glass signal is defined as a standard which allows development of common daughterboards
for several evaluation boards. The standard width between the CN7 pin1 and CN6 pin1 is
700 mils (17.78 mm).
GPIO signals on these two connectors can be tested on odd pins when the LCD glass board
is absent. Signal assignments are detailed in
Note: If CN6 and CN7 are used as GPIO extension connector on a common daughterboard, do
not connect odd pins and even pins directly onto the daughterboard, and leave Trace
connector (CN11), JTAG connector (CN16) and JP2 open.
Table 24.
Odd pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
30/56
www.BDTIC.com/ST
LCD glass daughterboard connectors CN6 and CN7
CN7
GPIO signal
PA9
PA8
PA10
PB9
PB11
PB10
PB5
PB14
PB13
PB12
PA15
PB8
PB15
PC2
PC1
PC0
PA3
PA2
PB0
PA7
PA6
PB4
PB3
PB1
Doc ID 022868 Rev 1
Table 24.
CN6
Odd pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
UM1521
GPIO signal
PD2
PC12
PC11
PC10
PC3
PC4
PC5
PC6
PC7
PC8
PC9
PD8
PD9
PD10
PD11
PD12
PD13
PD14
PD15
PE0
PE1
PE2
PE3
PA1
