STM32L152D-EVAL I/O assignment
Table 32.
Pin No.
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
52/56
www.BDTIC.com/ST
STM32L152D-EVAL I/O assignment (continued)
Pin name
PA11
PA12
PA13
PH2
VSS_2
VDD_2
PA14
PA15
PC10
PC11
PC12
PD0
PD1
PD2
PD3
PD4
PD5
VSS_10
VDD_10
PD6
PD7
PG9
PG10
PG11
PG12
PG13
PG14
VSS_11
VDD_11
PG15
PB3
PB4
PB5
PB6
PB7
Doc ID 022868 Rev 1
STM32L152D-EVAL I/O assignment
USB_DM
USB_DP
JTMSSWDAT
A22
GND
VDD
JTCKSWCLK
SEG17 / JTDI
COM4 / SEG28/ SEG40 / uSD_D2
COM5 / SEG29 /SEG41 / uSD_D3
COM6 / SEG30 / SEG42 / uSD_CK
D2
D3
COM7 / SEG31 / SEG43 / uSD_CMD
LED1
OEN
WEN
GND
VDD
WAITN
LED2
CS_NOR_EBAR1
CS_RAM_EBAR2
JOYSTICK_UP
LCD_EBAR3
JOYSTICK_SELECT
LED3
GND
VDD
LED4
SEG7 / POT_COMP_INN / JTDO/SWO
SEG8 / LDR_COMP_INP / JTRST
SEG9 / POT_COMP_INP / Temp_SMBAl
Shield_CT_6_3
C_Shield_CT_6_4
