Connectors
Table 26.
Pin
13
15
17
19
3.9

Trace debugging connector CN11

Figure 15. Trace debugging connector CN11 (viewed from above PCB)
Table 27.
Pin
1
3
5
7
9
11
13
15
17
19
3.10

Audio jack CN13

A 3.5 mm stereo audio jack CN13 connected to audio DAC is available on the
STM32L152D-EVAL board.
32/56
www.BDTIC.com/ST
JTAG debugging connector CN16 (continued)
Description
PB3
RESET#
DBGRQ
DBGACK
Trace debugging connector CN11
Description
VDD power
GND
GND
KEY
GND
GND
GND
GND
GND
GND
Doc ID 022868 Rev 1
Pin Description
14 GND
16 GND
18 GND
20 GND
Pin Description
2 TMS/PA13
4 TCK/PA14
6 TDO/PB3
8 TDI/PA15
10 RESET#
12 TraceCLK/PE2
14 TraceD0/PE3 or SWO/PB3
16 TraceD1/PE4 or nTRST/PB4
18 TraceD2/PE5
20 TraceD3/PE6
UM1521
