Hardware layout and configuration
Table 8.
Jumper
PA1 is connected to microphone ( MIC_INP signal) when JP8 is set as shown to
the right: (Default setting)
JP8
PA1 is connected to LCD glass as SEG0 when JP8 is set as shown to the right:
PA2 is connected to microphone (MIC_INN signal)when JP6 is set as shown to
the right: (Default setting)
JP6
PA2 is connected to LCD glass as SEG1 when JP6 is set as shown to the right:
The custom LCD glass on MB979 is model XHO5002B. The signal mapping is shown in
Table 9, Table
Table 9.
Pin 1
COM1 COM1
COM2
COM3
COM4
COM5
COM6
COM7
COM8
Table 10.
Pin 13
COM1 9g
COM2 9h
COM3 9i
COM4 9j
COM5 9d
COM6 9c
COM7 9e
COM8 9f
