Mechanical dimensions
Appendix B
Figure 34. Mechanical dimension

Table 33.
Symbol
A
a1
a2
a3
B
C
D
d
54/56
www.BDTIC.com/ST
Mechanical dimensions

,

D
>
>
Mechanical dimensions
Size (mm) Symbol
68.58 e
2.54 H
2.54 h
2.54 Lx
17.78 Ly
36 Mx
3.5 My
3.2 P1
Doc ID 022868 Rev 1
W
Y
D
y
Size (mm)
72.363
11
12
5.715
5.715
17.145
20.32
18.415
UM1521
Y
W
W
Y
Symbol Size (mm)
P2 84.455
P3 115.247
Q1 24.13
Q2 26.67
Q3 24.792
X 114.3
Y 172.72
