Interpreting The Error Message - GE UTX878 Ultrasonic User Manual

March 2004
Interpreting the Error
Message
3-4
The parameter in the lower right corner, represented by E and a
number (E1, E2, etc.) is an error message that signals a particular
problem with the measurement. To access an explanation of the error,
use the [ ] or [ ] key to highlight the error code and press [ENT].
The screen appears similar to Figure 3-3 below.
E1: LOW SIGNAL
Indicates poor
ultrasonic signal
strenght. Check
transducer cable,
programming and
transducer spacing.
Figure 3-3: A Typical Error Message Explanation
Press [ESC] to return to the display screen. For an explanation of all
error codes, refer to Chapter 6, Error Codes and Diagnostics.
