Troubleshooting

Troubleshooting Reference

WARNING: Electrical shock and burn hazard
Do not disassemble the XM 1800. It does not contain any user-serviceable parts.
Attempting to service the unit yourself could result in an electrical shock or burn.
Table 5-2 Troubleshooting Reference
Problem
Low output voltage
(96 VAC–104 VAC)
No output voltage. The Status
LED and the display are off.
5–4
Possible Cause Solution
You are using a voltmeter Use a true RMS reading voltmeter such as
that cannot accurately the Fluke 87.
read the RMS voltage of a
modified sine wave.
The inverter is off. Turn the inverter on.
No power to the inverter. Check the wiring to the inverter and to the
disconnect/battery selector switch.
The inverter could have The inverter has probably been damaged.
been connected with Return the unit. Damage caused by
reverse DC input polarity. reverse polarity is not covered by the
warranty. Information for returning the
inverter is provided in "Return Material
Authorization Policy" on page WA–3.
No AC power and DC Connect or apply AC shore power and
power. turn the XM 1800 on.
15 A supplementary Reset supplementary circuit breaker and
circuit breaker has turn the XM 1800 on.
tripped.
975-0263-01-01
