Table 5-2 Troubleshooting Reference
Problem
No output voltage. The status
LED is red.
No output voltage with shore
power connected.
No output voltage in inverter
mode.
The problem is not described
in this table.
975-0263-01-01
Possible Cause Solution
Low input voltage (fault Recharge the battery; check the
code E02) connections and cable.
High input voltage (fault Make sure the XM 1800 is connected to a
code E03) 12 V battery.
Check the voltage regulation of the
charging system.
Thermal shutdown (fault Allow the unit to cool off. Reduce the load
code E08) if continuous operation is required.
Improve ventilation. Make sure the
inverter's ventilation openings are not
obstructed.
Reduce the ambient temperature.
Unit overload (fault code Reduce the load. Make sure the load does
E05) not exceed the XM 1800's output rating.
Remove the short circuit.
Unit has a short-circuited
output (fault code E05).
Shore power has dropped Check shore power voltage.
below 90 V. Turn inverter on.
GFCI has tripped. Check load, and reset the GFCI.
15 A supplementary Reset supplementary circuit breaker.
circuit breaker has
tripped.
GFCI has tripped. Check load, and reset the GFCI.
Visit www.xantrex.com/support.asp and
check the FAQs (Frequently Asked
Questions) for your product.
