2. Plug the Ethernet cable into the Speaker Assembly.
3. At this point:
•
•
4. To fasten the speaker:
•
Note
•
Operations Guide
Operational and Linked to the Network"
For drop ceiling mounting, position the VoIP SPEAKER ASSEMBLY in the ceiling so that its
screw holes align with those you prepared.
For drywall mounting, place the three PLASTIC RIBBED ANCHORS in the holes you
prepared, and position the VoIP SPEAKER ASSEMBLY over them, aligning the screw
holes in the assembly with the anchors.
For drop ceiling mounting, use the three 8-32 x 1 1/4" MOUNTING SCREWS, #8 NYLON
THUMB NUTS, and #8 FENDER WASHERS to secure the speaker.
For weak ceiling tile, CyberData offers a reinforcing mount (CyberData part number
010991A).
For drywall mounting, use the three #8 SHEET METAL SCREWS to secure the speaker.
Section 2.2.3, "Confirm that the Speaker is
explains how the Link and Status LEDs work.
930310B
Mount the Speaker
