2.2.2.3 V2 Speaker with Extra Speaker Connection
In Figure
the total speaker wattage is the same, by connecting a low cost analog speaker, additional coverage
can be realized.
Speaker Setup When using the second speaker connection, the analog volume control needs to be disabled (see
the Use Digital Volume Control
"Configure the
Note
Speaker
POWER IN +
(+12VDC 500mA)
POWER GND
RELAY COM
RELAY NO
+5 VDC
BUTTON-SENSE
Operations Guide
2-9, the V2 Speaker supports an amplified audio output for a second analog speaker. While
Device"]).
When using the second Analog speaker in Digital Volume Control Mode, the maximum
recommended volume is a setting of 6.
Figure 2-9. V2 Speaker with Extra Speaker Connection
AUX SPEAKER (-)
AUX SPEAKER (+)
GND
LINE OUT GND
LINE OUT (+)
BUTTON LED (-)
J9
J10
setting on the Device Configuration Page
12 gauge wire and
a maximum length
of 20 feet
*When using the second speaker connection, the analog
volume control needs to be disabled.
*When using the second Analog speaker in Digital
Volume Control Mode, the maximum recommended vol-
ume is a setting of 6.
930274C
Installing the VoIP V2 Speaker
Device Configuration
[see Section 2.3.2,
8 Ohm Analog Speaker
(CD Part Number 011072)
