2. On the Multicast Configuration page, enter values for the parameters indicated in
Web Page Item
Enable Multicast Operation
Device Settings
Priority
Address
Port (range can be from 2000 to 65535)
Multicast Group Name
Operations Guide
Table 2-8. Multicast Configuration Parameters
Description
Enables or disables multicast operation.
Assigns the priority for the multicast group. Priority 9 is the
highest (emergency streams). 0 is the lowest (background
music).
When playing multicast streams, audio on different streams
will preempt each other according to their priority in the list.
An audio stream with a higher priority will interrupt a stream
with a lower priority.
If both SIP and Multicast is enabled, SIP audio streams are
considered priority 4.5. SIP audio will interrupt multicast
streams with priority 0-4 and will be interrupted by multicast
streams with priority 5-9.
During priority 9 multicast streams, the analog volume
control is bypassed and the volume level is set to maximum.
Enter the multicast IP Address for this multicast group (15
character limit).
Enter the port number for this multicast group (5 character
limit).
Assign a descriptive name for this multicast group (25
character limit).
Link to the Home page.
Link to the Device Configuration page.
Link to the Networking page.
Link to go to the SIP Configuration page.
Link to the Multicast Configuration page.
Link to the Audio Configuration page.
Link to the Clock Configuration page.
Link to the Event Configuration page.
Link to the Update Firmware page.
930274C
Installing the VoIP V2 Speaker
Multicast Configuration
Table 2-8.
a
b
