Example Packets For Events - CyberData 11021 Operation Manual

Web Page Item

2.7.1 Example Packets for Events

The server and port are used to point to the listening server and the 'Remote Event Server URL' is
the destination URL (typically the script running on the remote server that's used to parse and
process the POST events).
Note
Here are example packets for every event:
POST xmlparse_engine HTTP/1.1
Host: 10.0.3.79
User-Agent: CyberData/1.0.0
Content-Length: 197
Content-Type: application/x-www-form-urlencoded
<?xml version="1.0" encoding="ISO-8859-1"?>
<cyberdata NAME='CyberData VoIP Device' MAC='0020f70015b6'>
<event>POWERON</event>
</cyberdata>
Operations Guide
Table 2-15. Event Configuration (continued)
a.This page is used only if the CyberData Clock Kit (part number 011023 [wall-mounted version]
or 011024 [flush-mounted version]) is installed.
b.This page is used only if the CyberData Clock Kit (part number 011023 [wall-mounted version]
or 011024 [flush-mounted version]) is installed.
The XML is URL-encoded before transmission so the following examples are not completely
accurate.
Description
Link to the Update Firmware page.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Test Event button to test an event.
Click on the Reboot button to reboot the system.
930274C
Installing the VoIP V2 Speaker
Event Configuration
CyberData Corporation
49
