2.2 Device Configuration

Set up and configure each speaker before you mount it.
CyberData delivers each speaker with the following factory default values:
Parameter
IP Addressing
IP Address
Web Access Username
Web Access Password
Subnet Mask
Default Gateway

2.2.1 Connect Power to the Speaker

Figure 2-4
2.2.1.1 VoIP V2 Speaker to a 802.3af Compliant PoE Switch
Figure 2-4
5 Ethernet cable.
802.3af Compliant PoE Switch
Operations Guide
Table 2-2. Factory Network Default Settings—Default of Network
a
a
a
a. Default if there is not a DHCP server present.
through Figure 2-6
illustrates how to connect the VoIP V2 Speaker to a 802.3af compliant PoE switch via a Cat
Figure 2-4. VoIP V2 Speaker to a 802.3af Compliant PoE Switch
Factory Default Setting
DHCP
10.10.10.10
admin
admin
255.0.0.0
10.0.0.1
illustrates how to connect power to the VoIP V2 Speaker.
930274C
Installing the VoIP V2 Speaker
Device Configuration
Cat 5 Ethernet cable
VoIP V2 Speaker
