On the Audio Configuration page, enter values for the parameters indicated in
Note
Web Page Item
Audio Files
Radio button
(to the right of each input box)
0-9
Dot
Audiotest
Pagetone
Your IP Address is
Rebooting
Restoring default
Ringback Tone
Ring Tone
Downloading files from a tftp
server at
Available Space =
Operations Guide
Each entry on the Audio Configuration page replaces one of the stock audio files on the
board. When the input box displays the word default, the V2 Speaker is using the stock
audio file. If that file is replaced with a user file, it will display the uploaded filename.
Table 2-9. Audio Configuration Parameters
Description
For each entry, if the user selects the radio button to the right of the
input box they have several options:
The Test Audio button will play that audio file.
The Restore Defaults button will delete any user uploaded audio and
restore the stock audio file.
The Download button will download a new user audio file to the board.
It will delete any pre-existing user uploaded audio files.
The name of the audio configuration option is the same as the spoken
audio that plays on the board (24 character limit).
'0' corresponds to the spoken word "zero."
'1' corresponds to the spoken word "one."
'2' corresponds to the spoken word "two."
'3' corresponds to the spoken word "three."
'4' corresponds to the spoken word "four."
'5' corresponds to the spoken word "five."
'6' corresponds to the spoken word "six."
'7' corresponds to the spoken word "seven."
'8' corresponds to the spoken word "eight."
'9' corresponds to the spoken word "nine."
Corresponds to the spoken word "dot." (24 character limit)
Corresponds to the message "This is the CyberData IP speaker test
message..." (24 character limit)
Corresponds to a simple tone that is unused by default
(24 character limit).
Corresponds to the message "Your IP address is..." (24 character limit).
Corresponds to the spoken word "Rebooting" (24 character limit).
Corresponds to the message "Restoring default" (24 character limit).
This is the ringback tone that plays when calling a remote extension
(24 character limit).
This is the tone that plays when set to ring when receiving a call
(24 character limit).
Corresponds to the spoken word "dot" (24 character limit).
Indicates how much space is left in the internal non-volatile memory.
