CyberData 11021 Operation Manual page 38

2. On the SIP Configuration page, you may enter values for the parameters indicated in
Web Page Item
Enable SIP Operation
SIP Settings
SIP Server*
Remote SIP Port*
Local SIP Port*
Outbound Proxy
Outbound Proxy Port
SIP User ID*
Authenticate ID*
Authenticate Password*
Register with a SIP Server*
Re-registration Interval (in seconds)*
Unregister on Reboot*
Dial Out Settings
Dial Out Extension
Extension ID
Operations Guide
Table 2-7. SIP Configuration Parameters
Description
Enables or disables SIP operation.
Type the SIP server represented as either a numeric IP
address in dotted decimal notation or the fully qualified
host name (64 character limit [FQDN]).
Type the Remote SIP Port number (default 5060)
(8 character limit).
Type the Local SIP Port number (default 5060)
(8 character limit).
Type the Outbound Proxy as either a numeric IP address in
dotted decimal notation or the fully qualified host name
(64 character limit [FQDN]).
Type the Outbound Proxy Port number (8 character limit).
Type the SIP User ID (up to 25 alphanumeric characters).
Type the Authenticate ID
(up to 25 alphanumeric characters).
Type the Authenticate Password (up to 25 alphanumeric
characters).
Enable or disable SIP Registration.
Type the SIP Registration lease time in minutes (default is
60 minutes) (8 character limit).
• When selected, the speaker automatically unregisters
when it is rebooted.
• When not selected, the speaker remains registered when
it is rebooted.
Type the dial out extension number (25 character limit).
Type the desired Extension ID (25 character limit).
Link to the Home page.
Link to the Device Configuration page.
Link to the Networking page.
Link to go to the SIP Configuration page.
Link to the Multicast Configuration page.
930274C
Installing the VoIP V2 Speaker
Configure the Speaker Parameters
Table
CyberData Corporation
30
2-7.
