SATEL
Zones – allows to check the status of zones in the partitions accessible to the user and
operated from the keypad. The zone status is presented by means of a symbol. The
numbers placed on the glass allow you to identify the zone numbers. On starting the
function, the status of zones 1-32 is displayed. Use the  and  keys to display the
status of other zones (see also description of the
zone status is shown using the following symbols (which can be changed by the
installer):
b - zone bypass,
l - trouble "long violation",
f - trouble "no violation",
S - tamper alarm,
A - alarm,
- zone tamper,
M - masking,
- zone violation,
s - tamper alarm memory,
m - masking memory,
a - alarm memory,
- zone OK.
Supply voltages – available to the installer. Enables checking of the supply voltage for
individual expansion modules.
Temperatures – allows to check the temperatures measured by ATD-100 wireless
detectors.
Radio devices – allows to check the radio signal level for ABAX system wireless devices
supported by the control panel.
Zone Test – the submenu contains functions which allow to test the detectors connected
to the zones (see: section Z
Battery test – available to the installer. Upon starting the function, the control panel will
generate events to inform about the status of batteries of the control panel and
hardwired expansion modules with power supply. Additionally, the status of 60. T
B
ATTERY LOW
Manual transmission test – generates an event, which starts the procedure of event
transmission to the monitoring station (a code sent with the system identifier).
Monitoring station test (1A, 1B, 2A, 2B) – allows to send a test transmission to the
monitoring station (separate functions for each of the telephone numbers). When
sending the transmission, messages are displayed to inform about the currently
performed operation. The function is useful when starting the reporting or in case of any
reporting trouble.
Messaging test – allows to test the messaging function. Upon starting the function:
1. Enter the number of the telephone (consecutive number on the telephone list).
2. Press the  key.
3. Enter the number of voice message.
4. Press the
message.
Answering test – if this function is started, information on the number of rings and going
off-hook is displayed when answering the telephone call.
Proximity card test – allows to check the number of proximity card and establish to whom
it belongs (if the card belongs to a user of the system).
ONE TESTING
type zones will be analyzed.
key. The control panel will call the indicated number and play back the
INTEGRA Plus
LEDs, p. 7). By factory default, the
p. 32).
19
.-
