Fire alarm control panel
ACSP-402
EN
Firmware version 1.00
PROGRAMMING
acsp-402_p_en 06/23
SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND
tel. +48 58 320 94 00
www.satel.pl

Advertisement

loading
Need help?

Need help?

Do you have a question about the ACSP-402 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Satel ACSP-402

Summary of Contents for Satel ACSP-402

  • Page 1 Fire alarm control panel ACSP-402 Firmware version 1.00 PROGRAMMING acsp-402_p_en 06/23 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
  • Page 2 Before you start programming, please read carefully this manual in order to avoid mistakes that can lead to malfunction or even damage to the equipment. SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.

  • Page 3: Table Of Contents

    CONTENTS 1. Introduction ........................3 2. Addressable elements ....................3 Line elements ........................3 Control panel inputs and outputs ................... 3 Addresses of the system elements ..................4 Verification of addressable elements ..................4 Links between the addressable elements ................4 2.5.1 Link identifier ..........................
  • Page 4 ACSP-402 SATEL 9. Addressable elements ....................35 Dependence ........................37 Detector ..........................37 Remote indicator ......................... 37 Inputs and outputs ....................... 37 9.4.1 Inputs ........................... 37 9.4.2 Outputs ..........................39 Side line module ........................40 Locate device ........................40 9.6.1 Line supply ..........................

  • Page 5: Introduction

    • name of the parameter or option in the service menu of the control panel. 2. Addressable elements The ACSP-402 control panel supports the following addressable elements: • line elements (addressable devices), • inputs and outputs. You can create links (dependences) between the addressable elements. When elements are linked, their operation is dependent on the occurrence of certain events in the fire alarm system (see: “Links between the addressable elements”...

  • Page 6: Addresses Of The System Elements

    ACSP-402 SATEL OUT8 – programmable relay output to control the automatic fire protection equipment (potential-free with control of line continuity). Addresses of the system elements Line elements The addresses are given by the control panel during the identification (see: “Installer manual”) or verification procedure (see: “Verification of addressable elements”).
  • Page 7 SATEL ACSP-402 group or events related to the selected element. If the indicator is not linked with a zone, a group or another element, the indicator will indicate events in the entire system (see: “Remote indicator” p. 37). • Input (of the control panel / MIO-400 input and output module) – depending on the input type (see: “Input type”...

  • Page 8: Link Identifier

    ACSP-402 SATEL Link Linked system Addressable element Type of link element / addressable element Output type: Acknowl. of fire protection equip. activation Linked with “Control of fire protection equipment” Zone Logic control Linked with Group Zone Evacuation Linked with Group...

  • Page 9: Service Mode

    SATEL ACSP-402 – with a control panel / MIO-400 module output. You can check the address of the linked output in the device details (click on the control panel) or in the ACSP Soft program. OUT8 – with the OUT8 control panel output when the output type is “Control of fire protection equipment”.

  • Page 10: Indicating The Service Mode

    ACSP-402 SATEL Indicating the service mode The service mode is indicated by the flashing of the yellow CONTROL LED on the control panel. If the control panel is connected with the ACSP Soft program, the “Service mode: ACSP Soft” message will be displayed.

  • Page 11: Information On System Elements

    SATEL ACSP-402 The cursor shows the submenu you can enter / function you can start / option you can select. Press and hold to scroll faster through the menu. Information on system elements You may notice that names and addresses are displayed when you scroll and edit the list of system elements.

  • Page 12: Programming The Detection Line

    ACSP-402 SATEL Button Characters available after next keystroke " & < > Table 3. Programming the detection line 4.5.1 Adding the detection line elements 1. Start the service mode (see: p. 7). The service menu will be displayed. 2. Keep pressing until the cursor shows the “Elements”...

  • Page 13: Removing The Detection Line Elements

    SATEL ACSP-402 11. Press . The “On a branch?” prompt will be displayed. 12. Press to add the device to the main detection line or press to add the device on a branch (to quit, press 4.5.2 Removing the detection line elements 1.

  • Page 14: Unlinking An Addressable Element

    ACSP-402 SATEL 6. Press to select the function from the list and press . The list of system elements will be displayed. Depending on the selected function, it will be the list of zones, groups or addressable elements. 7. Press to select from the list the zone / group / addressable element with which you want to link the element.

  • Page 15: Function To Verify Line Elements

    SATEL ACSP-402 6. Press . Depending on the detection line type, the “Cut the loop after” or “C. rad. c. A after” information and the list of devices connected to the detection line (loop or radial circuit A) will be displayed.

  • Page 16: Service Menu

    ACSP-402 SATEL if the function detects a single change in the line topology. Press to acknowledge the changes (press to quit). − “Error” – if the function detects more than one change in the line topology. In such a case, start the verification function in the ACSP Soft program (see: “Starting the verification function”...
  • Page 17 SATEL ACSP-402 High Night sensitivity Normal High Delete this zone Add zone [zone selected by number / name] Delete zones [zone selected by number / name] Groups Group list [group selected by number / name] Name Elements Element list [element selected by address / name]...
  • Page 18 ACSP-402 SATEL … Tone 32 Logic control Product Delete this group Add group [group selected by number, max: Group 32] Delete group [group selected by number / name] Lines Detected topology [detected detection lines] Topology change Line 1 [start of the topology change function – see: “Changing the detection line topology”...
  • Page 19 SATEL ACSP-402 Fire damper Routing acknowl. Ext. device fault School bell Ext. fire alarm OUT8 f. p. eq. ack FRE TX f. p. eq. ack F. p. equip. ack. Logic Evacuation Personnel presence F. damper control Closing Opening Input polarity...
  • Page 20 ACSP-402 SATEL Evacuation Options [output type Alarm / Fire p. eq. contr.] Alarm II Alarm I [output type No acknowledgment] Fire routing Fault routing [output type Fault] Power Convent. sounders Routing outputs / Other [output type Disablement] Convent. sounders FRE TX output...
  • Page 21 SATEL ACSP-402 Side lines [line in the MLB-400 module selected by address / name] Name Alarm mode One-stage Two-stage Add to zone [zone selected by number / name] Remove from zone Indicators [indicator selected by address / name] Name Indicated states...
  • Page 22 ACSP-402 SATEL Select device Consecutively [device selected by address / name] By serial number [device selected by serial number] Restore settings Global settings Acknowl. time Verification time X time Y time Personnel By access level According to sched. Attendance schedule Sunday 00:00 –...
  • Page 23 SATEL ACSP-402 Enabling delays Disabling delays WZ indication Activity None Intermittent 1 Intermittent 2 Continuous Disablement None Intermittent 1 Intermittent 2 Continuous Fault None Intermittent 1 Intermittent 2 Continuous Sounder 1 Alarm I(i) or II Alarm I or II Alarm II...
  • Page 24 ACSP-402 SATEL 10 min FLT TX output Transmission Aut. sound restore Earth fault control Clock Set time Set date Clock correction Summer/winter time No time change Acc. to EU rules Acc. to US rules Acc. to dates Summer time from...
  • Page 25 SATEL ACSP-402 INTEGRUM key INTEGRUM addr. INTEGRUM port VAPSP VAPSP app VAPSP password VAPSP serv. passw. VAPSP port Time synchronizat. Time from server NTP server ad. Email messaging Email sending SMTP server SMTP port Encryption SSL/TLS STARTTLS Sender name Authentication...
  • Page 26 ACSP-402 SATEL Alarms Diagnostics Recipient 3 Email address Event types General Tests Disablements Faults Pre-alarms Alarms Diagnostics Recipient 4 Email address Event types General Tests Disablements Faults Pre-alarms Alarms Diagnostics Period 15 min 30 min Diagnostic reports Every month Every quarter...

  • Page 27: Programming In The Acsp Soft Program

    Exit the SM 5. Programming in the ACSP Soft program You can download the ACSP Soft program from www.satel.pl. Description of the ACSP Soft program In the ACSP Soft program, you can configure the fire alarm system and run diagnostics of the system.

  • Page 28: Side Menu

    ACSP-402 SATEL 5.1.2 Side menu The side menu is displayed on the left side of the program window. Click the menu buttons to open the tabs in which you can configure the fire alarm system settings. 5.1.3 Additional menu To open the additional menu, click Open –...

  • Page 29: Establishing Communication With The Control Panel

    SATEL ACSP-402 “Software language” window Fig. 3. “Software language” window. Software language – you can select the program language. Buttons Save click to save changes. Cancel click to close the window without saving changes. Establishing communication with the control panel 1.

  • Page 30: Times

    ACSP-402 SATEL Fig. 4. “Settings” tab. Times Time to acknowledge the alarm [Acknowl. time] – the time used in two-stage alarm. It is counted from the moment the first stage alarm is indicated (after information is received from a detector or an input is activated). If the personnel fails to press ACKNOWLEDGEMENT during this time, the second stage alarm is indicated.

  • Page 31: Events Signaled By Wz-400

    SATEL ACSP-402 alarm will be indicated (depending on the alarm variant). If no fire alarm is generate during the “Time X”, the control panel will not indicate the alarm and will reset it. You can program from 30 to 60 seconds (by default: 60 seconds).

  • Page 32: Attendance Schedule

    ACSP-402 SATEL Presence by L1/L2 level [By access level] – if this option is enabled, the “Personnel present” / “Personnel absent” operating mode of the control panel changes depending on the access level. In the case of the level 1 (the key switch is in the neutral position), the control panel operates in the “Personnel absent”.

  • Page 33: Sounders

    SATEL ACSP-402 Fault routing output (FLT TX) [FLT TX output] – turn on the FLT TX output if the control panel is to indicate faults using the output. Sounders Sounder 1 / Sounder 2 / FRE TX output [Sounder 1 / Sounder 2 / FRE TX output] – mode...
  • Page 34 ACSP-402 SATEL Fig. 5. “RTC clock” tab. Buttons click to download from the control panel the settings displayed in the tab. click to temporarily upload the settings displayed in the tab (if you fail to save the settings to the non-volatile memory, all changes will be undone when you exit the service mode).

  • Page 35: Rs-485 Devices

    SATEL ACSP-402 8. RS-485 devices Fig. 6. “RS-485 devices” tab. APSP-402 repeater panel – if this option is enabled, the control panel supports the APSP-402 repeater panel connected to the communication bus (APSP-402 terminals). ACSP-ETH module ACSP-ETH module [Ethernet module] – if this option is enabled, the control panel supports the ACSP-ETH Ethernet communication module.

  • Page 36: Vapsp Application

    ACSP-402 SATEL MAC [MAC address] – hardware address of the ACSP-ETH module. 8.1.1 VAPSP application VAPSP application [VAPSP app] – if this option is enabled, the connection between the control panel and the VAPSP mobile app can be established via the ACSP-ETH module.

  • Page 37: Recipients

    SATEL ACSP-402 STARTTLS – the STARTTLS protocol is used. NONE – the outgoing mail is not encrypted. Sender’s name [Sender name] – e-mail address included in the outgoing e-mail message as the sender address. If this field is blank, the name of the e-mail account will be treated as the sender address.
  • Page 38 ACSP-402 SATEL Fig. 7. “Addressable elements” tab. Dependence – type of link (dependence) between the addressable element and other fire alarm system element(s) (see: “Links between the addressable elements” p. 4): Belongs to: – zone / group that the element belongs to.

  • Page 39: Dependence

    SATEL ACSP-402 Dependence You can link an addressable element with other fire alarm system element(s). Depending on the element type, you can add it to the zone or group or link it with the zone, group or another element (see: “Links between the addressable elements” p. 4).
  • Page 40 ACSP-402 SATEL Logic control [Logic] – the input status is the input signal for the logical function that controls the “Logic control” type outputs linked with the same group as the input (see: “Logical control” p. 50). Evacuation [Evacuation] – activating the input activates the evacuation indication.

  • Page 41: Outputs

    SATEL ACSP-402 Alarm mode [Alarm mode] – you can select the type of alarm that will be generated when the input is activated: One-stage – second stage alarm will be generated, Two-stage – first stage alarm will be generated. This field is available if the “External fire alarm” input type is selected.

  • Page 42: Side Line Module

    ACSP-402 SATEL 2nd stage alarm sign. [Alarm II] / 1st stage I alarm sign. [Alarm I] – you can select the alarms that are to turn on the output. The fields are available if the “Fire alarm” or the “Control of fire protection equipment” type output is selected.

  • Page 43: Line Supply

    SATEL ACSP-402 Address – address of the device. If the device is linked with another element of the fire alarm system, the link identifier is added to that element’s address (see: “Link identifier” p. 6). Serial no. – serial number of the device.

  • Page 44: Structure And Identification

    ACSP-402 SATEL Structure and identification Fig. 10. “Structure and identification” tab (example structure: Line L1 – loop connected between the 1A and 1B terminals, Line L2 – radial circuit connected to the 2A terminals). You can configure the structure of the control panel addressable detection lines: •...

  • Page 45: Starting The Identification Function

    SATEL ACSP-402 − serial number of the element. Buttons click to start the function of identification / verification of line elements. click to download from the control panel the settings displayed in the tab. click to temporarily upload the settings displayed in the tab (if you fail to save the settings to the non-volatile memory, all changes will be undone when you exit the service mode).

  • Page 46: Removing The Detection Line Elements

    ACSP-402 SATEL 2. Right-click the line element after which you want add a new device. If you want to add a device immediately after the detection line terminals, click 3. In the context menu, click “Add”. The “Add device” window will be displayed.

  • Page 47: Zones

    SATEL ACSP-402 2. Right-click the last element of the A or B radial circuit after which you want to connect the radial circuits. 3. In the context menu, click “Connect with...”. The list of devices connected to the other radial circuit will be displayed.

  • Page 48: Alarm Variants

    ACSP-402 SATEL Day sens. [Day sensitivity] – smoke detection sensitivity of detectors in the zone, when the “Personnel present” mode is active. Available settings: normal, high or low (by default: normal). Night sens. [Night sensitivity] – smoke detection sensitivity of detectors in the zone, when the “Personnel absent”...
  • Page 49 SATEL ACSP-402 by the preset time (see: “Time for alarm recognition”). This gives the personnel the time to verify if the fire alarm is justified. There are 19 alarm variants available in the control panel. This enables you to select such an alarm variant for the zone so that the fire can be detected at the earliest stage of its development while the risk of false alarms can be reduced.
  • Page 50 ACSP-402 SATEL V8: Two-stage, with warning device single reset X[sec]/Y[min] – when a detector generates a fire alarm, the control panel does not indicate it. If another detector generates an alarm within the set time (“Time X”), the control panel indicates the first stage alarm (see: variant V2).

  • Page 51: Signaling Groups

    SATEL ACSP-402 first stage alarm (see: variant V2). If detectors generate a fire alarm simultaneously in subzones A and B, the control panel indicates the second stage alarm. V18: Two-stage, with preliminary zone reset and group coincidence in order to speed up 2nd stage alarm –...
  • Page 52 ACSP-402 SATEL Zones [Activat. from zones] – number(s) of the zones linked with the group (alarm condition in the zone activates devices belonging to the group). Linked elem. [Element list] – reference numbers of addressable system elements that belong to / are linked with the group.

  • Page 53: Names

    SATEL ACSP-402 logical sum – outputs will be turned on after any “Logic control” input is activated, logical product – outputs will be turned on after all “Logic control” inputs are activated simultaneously. Linked devices It is a list of addressable elements that belong to the group and elements that are linked with the group.

  • Page 54: Special Functions

    ACSP-402 SATEL LCD messages ACSP [Message 1A / Message 1 B / Message 2] – text of the messages displayed in the second and third line of the control panel display. APSP [Message 1A / Message 1 B / Message 2] – text of the messages displayed in the second and third line of the APSP-402 repeater panel display.

  • Page 55: Printouts

    SATEL ACSP-402 Buttons click to restore the default settings of the control panel. In the window that will open, you will be asked if you want to restore the control panel default settings. 14. Printouts 14.1 Configuration You can print out the fire alarm system settings. Click “Printouts”, then “Configuration”.

  • Page 56: Restoring The Default Settings
