Definity Quick Reference Manual

Console operations

Basic operation

Console layout

The Attendant Consoles and DXS Selector Console are shown in
Figure 2, and
6
2
1. Lamp test switch
2. Handset
3. Handset cradle
4. Call processing area
5. Outside-line buttons
6. Warning lamps and call waiting lamps
7. Display buttons
Figure 1. Model 302A/B attendant console
4 DEFINITY ECS Console Operations Quick Reference
