Secondary Display; Alternate Display - Oceanic DATA PLUS Owner's Manual

®
FT
Fig. 32 - Main Display (Alt On)
Fig. 33 - Secondary Display
FT
MAX
Fig. 34 - Alternate Display
30
If the Alternate Display is set to 'ON', information includes (Fig. 32):
Current Depth and Dive Time Remaining (and icon). Elapsed Dive Time and
Maximum Depth are 'accessed' in Large Format, as described below.
Secondary Display (access if Alternate is set ON or OFF)
To view water Temperature, Time of Day, and if FO2 was set for a numerical
value, display the current level of PO2 (Fig. 33):
• press the Advance (Left) button 1 time
• the unit will revert to the Main Display after 10 seconds, if the Advance
(Left) button is not pressed again.
Alternate Display (access only if Alternate is set ON)
To view Maximum Depth and Elapsed Dive Time in Large Format in place of
Current Depth and Dive Time Remaining (Fig. 34):
• press the Advance (Left) button 2 times, or -
• press the Advance (Left) button 1 time, if viewing Temp/Time/PO2.
• the unit will revert to the Main Display after 10 seconds, or if the Ad-
vance (Left) button is pressed.
The Graphic Diver Interface (bar graphs) will be active with each display
representing nitrogen loading, oxygen accumulation (if FO2 was set for a value
other than Air), and your ascent rate.
