PRO PLUS 3 OPERATING MANUAL
PRO PLUS 3

DIVE COMPUTER

OPERATING MANUAL
1
© 2002 Design, 2012
Doc. No. 12-5332-r01 (11/19/12)

Advertisement

Table of Contents
loading

Related Manuals for Oceanic PRO PLUS 3

Summary of Contents for Oceanic PRO PLUS 3

  • Page 1: Dive Computer

    PRO PLUS 3 OPERATING MANUAL PRO PLUS 3 DIVE COMPUTER OPERATING MANUAL © 2002 Design, 2012 Doc. No. 12-5332-r01 (11/19/12)

  • Page 2: Table Of Contents

    PRO PLUS 3 OPERATING MANUAL Contents notICes....................3 dIVe.Mode.FeAtURes..............20 BAR.GRAPHs.................21 FeAtURes.And.FUnCtIons..............5 tLBG.(noRM)................21 dIsPLAY.CoMPonents..............6 VARI.(noRM/GAUG)..............21 oVeRVIeW..................6 ALGoRItHM..................21 InteRACtIVe.ContRoL.ConsoLe..........6 ConseRVAtIVe.FACtoR.(CF)............21 MenU.sYsteM.................6 deeP.stoP.(ds)................21 sAFetY.stoP.(ss)................22 sMARtGLo .BACKLIGHt...............7 ® AUdIBLe.ALARM................7 dIVe.tIMe.ReMAInInG.(dtR)............22 PC.InteRFACe.................7 ndC.(no.deco.dtR)..............22 PoWeR.sUPPLY................8 otR.(o2.dtR)................22...

  • Page 3: Notices

    DECOMPRESSION MODEL The programs within the Pro Plus 3 simulate the absorption of nitrogen into the body by using a mathematical model. This model is merely a way to apply a limited set of data to a large range of experiences. The Pro Plus 3 dive computer model is based upon the latest research and experiments in decompres- sion theory.
  • Page 4 PRO PLUS 3 OPERATING MANUAL Welcome OCEANIC THANK YOU for choosing the PRO PLUS 3 © 2002 Design, 2012 Doc. No. 12-5332-r01 (11/19/12)

  • Page 5: Features.and.functions

    PRO PLUS 3 OPERATING MANUAL FEATURES FUNCTIONS © 2002 Design, 2012 Doc. No. 12-5332-r01 (11/19/12)

  • Page 6: Display.components

    • User Upgradable Firmware • Dual Algorithm INTERACTIVE CONTROL CONSOLE The Interactive Control Console utilizes 2 control buttons that allow you to maneuver through the Pro Plus 3's unique system of menus. The buttons are referred to as S and A.

  • Page 7: Smartglo ® Backlight

    • On the Surface during a Conditional Violation. PC INTERFACE Interface with a PC, to allow uploading settings and downloading data, is accomplished by connecting the Pro Plus 3 to a PC USB Port using the special Pro Plus 3 USB Interface Cable.

  • Page 8: Power.supply

    PRO PLUS 3 OPERATING MANUAL POWER SUPPLY • Battery >> (1) 3 vdc, CR2, Lithium battery • Shelf life >> up to 5 years depending on specific battery • Use life >> 50 dive hours if (1) 1 hour dives per dive day to 150 dive hours if (3) 1 hour dives per dive day •...

  • Page 9: Norm.surface.modes

    PRO PLUS 3 OPERATING MANUAL NORM SURFACE MODES © 2002 Design, 2012 Doc. No. 12-5332-r01 (11/19/12)

  • Page 10: Activation

    • At elevations of 3,001 feet (916 meters) or higher, it will adjust depth calibration for the higher altitude. The Pro Plus 3 is configured with contacts located on the stems of the buttons and pins of the PC Data Port that will automatically activate the unit and cause it to enter dive mode when the contacts become wet and it senses depth of 5 FT (1.5 M).

  • Page 11: Fly/Sat.time

    PRO PLUS 3 OPERATING MANUAL FLY/SAT TIME Time to Fly is a countdown timer that begins counting down from 23:50 to 0:00 (hr:min) 10 minutes after surfacing from a dive. Time to Desaturate, also a countdown timer, provides calculated time for tissue desaturation at sea level taking into consideration the Conservation Factor setting.

  • Page 12: Log.mode

    PRO PLUS 3 OPERATING MANUAL LOG MODE (NORM/GAUG) Information from the latest 24 NORM and/or GAUG dives is stored for viewing. > After exceeding 24 dives, the most recent dive is stored while the oldest is deleted. > Dives are numbered from 1 to 24 starting each time NORM (or GAUG) Dive Mode is activated. After the post dive 24 hour period has elapsed and the unit shuts off, the first dive of the next activation period will be #1.

  • Page 13: Set.gas.(Norm.fo2.&.Po2.Alarms)

    Sequence >> Gas 1 >> Gas 2 >> Gas 3 >> FO2 50% Default. With the FO2 50% Default selection set Off, the Pro Plus 3 will remain set at the last FO2 set point for that period of activation.

  • Page 14: Set.fo2.Default

    PRO PLUS 3 OPERATING MANUAL • S (< 2 sec) to save the FO2 setting and flash the PO2 digits if Nitrox, or access Set Gas 3 if OFF or Air. • S (2 sec) to revert to Set Gas Lead-in.

  • Page 15: Set.tlbg.alarm

    PRO PLUS 3 OPERATING MANUAL Set TLBG Alarm, information includes (Fig. 23): TLBG > Graphic OFF (or ON) flashing. > TLBG, last value saved (number of segments). > Graphic TLBG. • A (< 2 sec) to step through selections OFF, ON, and Set, one at a time.

  • Page 16: Set.utilities

    PRO PLUS 3 OPERATING MANUAL SET UTILITIES (NORM/GAUG) Sequence >> Lead-in >> Water Type >> Units >> DS* >> SS* >> Algo* >> CF* >> Glo >> SR. *Items apply to NORM only. Set points remain as set until changed.

  • Page 17: Set.algorithm

    PRO PLUS 3 OPERATING MANUAL Set Algorithm, information includes (Fig. 32): > Graphics SEL and ALGO. > Z+ (or DSAT) icon, flashing. • A (< 2 sec) to toggle Z+ and DSAT. • S (< 2 sec) to save the setting and access Set CF.

  • Page 18: Set.date.format

    PRO PLUS 3 OPERATING MANUAL Set Date Format, information includes (Fig. 37): Date Format establishes the location that the Month (M) digits are displayed relative to the Day (D) digits, on the left or right. > Graphics dAtE FORM. > Graphic M.D (or D.M), flashing.

  • Page 19: History.mode

    > Graphic SN with the factory programmed serial number (up to 199999). > Graphic R1A (or higher), indicating the revision level of the firmware (Pro Plus 3's current operating software). • A (< 2 sec) to revert to Surface Main.

  • Page 20: Dive.mode.features

    PRO PLUS 3 OPERATING MANUAL DIVE MODE FEATURES © 2002 Design, 2012 Doc. No. 12-5332-r01 (11/19/12)

  • Page 21: Bar.graphs

    30 + ALGORITHM The Pro Plus 3 is configured with 2 algorithms which allows you to choose which set of NDLs (No Deco Limits) will be used for nitrogen/oxygen calculations and displays relating to Plan and DTR (Dive Time Remaining).

  • Page 22: Safety.stop.(Ss)

    DTR on the Dive Main (Fig. 50a), identified by the OTR icon. CLEAR (RESET) The Pro Plus 3 is configured with a feature that clears nitrogen and oxygen calculations. This is intended for facilities using the Pro Plus 3 for rental or training activities, not for general use by individual divers.

  • Page 23: Norm.dive.modes

    PRO PLUS 3 OPERATING MANUAL NORM DIVE MODES © 2002 Design, 2012 Doc. No. 12-5332-r01 (11/19/12)

  • Page 24: No.deco.main.and.alts

    PRO PLUS 3 OPERATING MANUAL Dive Mode is activated when a descent is made to 5 FT (1.5 M) for 5 seconds TLBG VARI and continues until ascent is made to 2 FT (0.6 M) for 1 second. NO DECO DIVE MAIN, information includes (Fig. 52A/B) - >...

  • Page 25: Safety.stop.(Ss)

    PRO PLUS 3 OPERATING MANUAL DEEP STOP MAIN, information includes (Fig. 57): TLBG VARI > Current Depth with FT (or M) icon. > NX, DSAT (or Z+), Gas 1 (2, 3), CF, DS icons - those that apply. > Stop Depth with FT (or M) icon.

  • Page 26: Decompression

    PRO PLUS 3 OPERATING MANUAL DECOMPRESSION TLBG VARI Decompression mode activates when theoretical No Decompression time and depth limits are exceeded. Upon entry into Deco, the audible will sound and the alarm LED will flash. The full TLBG, Stop Bar with Up Arrow icon, and graphic DECO will flash (Fig.

  • Page 27: Dv.1.(Delayed.violation.1)

    (Fig. 68), and Current Depth, DTR (NDC), and Max Depth will only display dashes ( - - ) signifying that you are Too Deep. *MOD is the Max Operating Depth at which the Pro Plus 3 can properly perform calculations or provide accurate display information. Refer to the Specifications in the back.

  • Page 28: High.po2

    PRO PLUS 3 OPERATING MANUAL HIGH PO2 (NORM only) TLBG VARI Warning >> at .20 less than the Alarm value set for the Gas in use. Alarm >> at the value set for the Gas in use (1.00 to 1.60), except in Deco then at 1.60 only.

  • Page 29: Digital.gauge.mode

    PRO PLUS 3 OPERATING MANUAL DIGITAL GAUGE MODE © 2002 Design, 2012 Doc. No. 12-5332-r01 (11/19/12)

  • Page 30: Gaug.surf.main.and.alts

    PRO PLUS 3 OPERATING MANUAL GAUG SURF MAIN, information includes (Fig. 77): > Surface Interval time (hr:min) with SURF icon; if no dive yet, this is time since activation. > Dive number with # icon, up to 24 for that operating period; #0 if no dive made yet.

  • Page 31: Reference

    PRO PLUS 3 OPERATING MANUAL REFERENCE © 2002 Design, 2012 Doc. No. 12-5332-r01 (11/19/12)

  • Page 32: Pc.interface

    Instrument Lens Protector. Small scratches will naturally disappear underwater. • Soak and rinse the Pro Plus 3 in fresh water at the end of each day of diving, and check to ensure that the areas around the Low Pressure (Depth) Sensor (Fig.

  • Page 33: Battery.replacement

    • Closely examine the inside of the Battery Compartment for any signs of corrosion indicating entrance of moisture into the unit. • If corrosion is found, return the Pro Plus 3 to an Authorized Oceanic Dealer, and DO NOT attempt to use it until it has re- ceived factory service.

  • Page 34: Altitude.sensing.and.adjustment

    > No adjustments are made during any time that the Wet Contacts are bridged. > When diving in high altitude waters from 3,001 to 14,000 feet (916 to 4,270 meters), the Pro Plus 3 automatically adjusts to these conditions providing corrected Depth, and reduced No Deco and O2 Times at intervals of 1,000 feet (305 meters).

  • Page 35: Z+.Algorithm.ndl.chart

    PRO PLUS 3 OPERATING MANUAL Z+ ALGORITHM >> NDLS (minutes) at ALTITUDE (Imperial) Altitude 3001 4001 5001 6001 7001 8001 9001 10001 11001 12001 13001 (feet) 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000 13000 14000 Depth ( FT )

  • Page 36: Specifications

    PRO PLUS 3 OPERATING MANUAL SPECIFICATIONS CAn.Be.Used.As • Dive Computer (Air or Nitrox). • Digital Depth Gauge/Timer. dIVe.CoMPUteR.PeRFoRMAnCe • Buhlmann ZHL-16c based PZ+, or DSAT based, algorithm. • No Deco limits closely follow PADI RDP. • Decompression in agreement with Buhlmann ZHL-16c and French MN90.
  • Page 37 PRO PLUS 3 OPERATING MANUAL SPECIFICATIONS (CONTINUED) nUMeRIC.dIsPLAYs:. Range: Resolution: • Time of Day 0:00 to 23:59 hr:min 1 minute • Temperature 0 to 99°F (-18 to 60°C) 1° • Altitude Level Sea, EL2 to EL7 1 level • Surface Interval Time...

  • Page 38: Inspection/Service.record

    ___________________________________________________________________________________________________ Pro Plus 3 Firmware Rev: ___________________________________________________________________________________________________ Date of Purchase: ___________________________________________________________________________________________________ Purchased from: ___________________________________________________________________________________________________ Below to be filled in by an Authorized Oceanic Dealer: Date Service Performed Dealer/Technician OCEANIC WORLD WIDE OCEANIC USA 2002 Davis Street San Leandro, CA 94577...
  • Page 39 PRO PLUS 3 OPERATING MANUAL NOTES © 2002 Design, 2012 Doc. No. 12-5332-r01 (11/19/12)
  • Page 40 PRO PLUS 3 OPERATING MANUAL PRO PLUS 3 DIVE COMPUTER OPERATING MANUAL © 2002 Design, 2012 Doc. No. 12-5332-r01 (11/19/12)
