To Set: Sampling Rate - Oceanic DATA PLUS Owner's Manual

®
M
a
Fig. 17 - Set Time
FT
Fig. 18 - Set Sampling Rate
18
• the Time appears with the Hour setting flashing (Fig. 17a)
• press Select (Right) button until the correct Hour appears.
• press Advance (Left) button 1 time to accept the setting displayed
• the Minute setting flashes (Fig. 17b)
• press Select (Right) button until the correct Minute appears.
• press Advance (Left) button to accept the setting displayed, and either -
• revert to Surface Mode (date/time settings changed)
b
• advance to Set: Sampling Rate (Date/Time settings not changed)

TO SET: SAMPLING RATE

Sampling Rate is the Time, or Depth, interval at which data samples will be
recorded for subsequent download to the OceanLog™ PC software program. It
has 'no effect' upon displayed data or data stored in the unit's viewable Log.
Rates available are 2 FT (.5M), 5 FT (1.5 M), 10 FT (3 M), 2 SEC, 5 SEC, 10
SEC, 15 SEC, 20 SEC, 25 SEC, 30 SEC. Lower rates = more samples and
more memory used per dive (e.g., fewer dives stored for download).
• press BOTH buttons simultaneously, while in Surface Mode
• press Advance (Left) button 7 times
• the Rate setting appears flashing (Fig. 18)
