Oceanic Prodigy Owner's Manual

Dive computer
Hide thumbs
Table of Contents

Advertisement

Quick Links

OCEANIC
®
Prodigy
owner's guide
R5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Prodigy and is the answer not in the manual?

Questions and answers

Julie
March 4, 2025

Can I change settings to metric?

0
1 comments:
Mr. Anderson
May 14, 2025

No, the Oceanic Prodigy does not allow switching between metric and imperial settings. It is manufactured as either metric or imperial, and the unit type cannot be changed.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Oceanic Prodigy

Summary of Contents for Oceanic Prodigy

  • Page 1 OCEANIC ® Prodigy owner's guide...
  • Page 2 Adequate Surface Interval Between Each Dive • Adequate Surface Interval Between Each Day Of Diving (12 Hours Or Until Your Computer Clears) • Read And Understand This Owner's Guide Before Using the Prodigy Pay special attention to items marked with this WARNING symbol...
  • Page 3 The programs within the PRODIGY simulate the absorption of nitrogen into the body by using a mathematical model. This model is not magic, merely a way to apply a limited set of data to a large range of experiences. The PRODIGY dive computer model is based upon the latest research and experiments in decompression theory.

  • Page 4: Table Of Contents

    CONTENTS I. THE PRODIGY IS EASY TO USE .......... 1 Introduction ......... 2 II. DETAILED OPERATION GUIDE .......... 10 Operational Modes ......12 The PRODIGY At A Glance ....26 Informational Displays ..... 20 III. HANDLING THE EXTREMES ..........27 Maximum depth ........
  • Page 5 THE PRODIGY EASY TO USE...

  • Page 6: Introduction

    The PRODIGY was designed to be extremely easy to use and understand. This owner’s guide is divided into five sections designed to make it easy to learn how to use the PRODIGY. The first two sections will show you how it performs in most diving situations. Section three describes extreme condition performance such as deep or decompression diving.
  • Page 7 ® Once you enter the water and descend to a depth below 5 feet (1.5 meters), the PRODIGY changes to the “No-decompression Dive Mode” (Fig. 3) signified by the No Decompression Identification Icon (Fig. 3a). This mode displays current depth, elapsed dive time (and Elapsed Dive Time Icon), no- Fig.
  • Page 8 USING THE “GRAPHIC DIVER INTERFACE” To make it easy to check your dive status on the PRODIGY, a color-coded system of graphic displays is used. This “Graphic Diver Interface” is made up of two bar graphs that have green, yellow and red markers to indicate nor- mal, caution, and danger zones, respectively.
  • Page 9 If your depth or bottom time is such that the TLBG enters the red zone, Fig. 4 – Decompression the PRODIGY will switch to the “Decompression Dive Mode” (Fig. 4) signi- Dive Mode fied with the flashing Decompression Dive Identification Icon (Fig. 4a). A decompression stop “ceiling”...
  • Page 10 ceiling depth indicated or risk decompression sickness. Also indicated by digital displays are current depth, decompression time for current stop (Fig. 4d) and total decompression stop time (Fig. 4e). You must stay at or a few feet below the TLBG indicated ceiling depth until the bar graph recedes into the next shallower zone before ascending any further.
  • Page 11 IT’S REALLY JUST THAT SIMPLE! The PRODIGY is designed to help you stay out of trouble with quick visual reference during all modes of operation. Just “keep it in the green” and you’ll greatly reduce your exposure to decompression sickness.
  • Page 12 The PRODIGY follows one of the more conservative of these, cited by Divers Alert Network (DAN); that divers wait at least 12 hours before flying in pressurized commercial aircraft, and at least 24 or more if making repeti- tive multi-day or decompression dives.
  • Page 13 Planning Sequence over again. After the timer reaches zero, 24 hours have elapsed. You may choose when to fly according to the type of diving you have done, consulting your PRODIGY to determine the amount of surface time that has elapsed. To learn more about flying after diving and DAN's guidelines, see page 24.
  • Page 14 This page intentionally left blank...
  • Page 15 DETAILED OPERATIONS GUIDE...

  • Page 16: Operational Modes

    15% of rated voltage all graphic displays will shut off except the Bat- ® tery Icon which will flash 15 final times prior to shutdown of the PRODIGY. WARNING - Never activate the PRODIGY if the computer is under- water.
  • Page 17 WARNING - If a Low Battery condition is indicated immediately upon activation, Oceanic strongly recommends that you DO NOT dive until you have obtained battery replacement, described on pages 47-50. Activating the External Access(EA) mode, described...
  • Page 18 profiles. The PDPS automatically replaces Surface Mode every minute. Information provided includes depths and no-decompression dive times. WARNING – The Pre Dive Planning Sequence predicts only no- decompression times for subsequent dives. Depending on tank size and air consumption, you may have less time available than shown in the PDPS because of air limitations.
  • Page 19 DECOMPRESSION DIVE MODE The PRODIGY will help you to avoid, or easily manage, decompression. Before explaining further, read the following warning. WARNING - Oceanic recommends the application of responsible diving practices and does not recommend decompression diving, or diving deeper than 130 feet, as these practices will greatly increase your risk of decompression sickness.
  • Page 20 Still, you must never ascend shallower than your decompression ceiling! Doing so will place the PRODIGY into a Conditional Violation Mode (see page 30) and greatly increase your risk of decompression sickness. Often while coping with surge and swell, it is difficult to stay at a chosen depth.
  • Page 21 Gauge Mode on subsequent dives. The PRODIGY removes displays that no longer provide correct information because of the violation (see page 35). No dives must be made for 24 hours for the PRODIGY to reset itself. DIVE LOG MODE Dive Log Mode, identified by the Dive Log Icon (Fig.
  • Page 22 When accessing Dive Log Mode, you can choose to either press and release, or press and hold, the button on the face of the PRODIGY. As mentioned, pressing and releasing the button initiates the Automatic Dive Log Sequence, showing previous dives for about four seconds each.
  • Page 23 TELLING THE DIFFERENT MODES APART The PRODIGY’s different operating modes are easy to tell apart. Each is clearly identified with graphic Mode Icons (Fig. 16) which provide quick visual reference during the various modes of operation. You will not see Decompression Dive, Violation, or Gauge Modes unless you dive to extremes.

  • Page 24: Informational Displays

    INFORMATIONAL DISPLAYS Each PRODIGY numeric or graphic display represents a unique piece of information. The following section describes each display in detail. Depth Display The top portion of the LCD (Fig. 17a) contains the current Depth display. The dive number display replaces the depth display in the Surface or Dive Log modes.
  • Page 25 GRAPHIC DIVER INTERFACE Two different bar graphs are located around the perimeter of the PRODIGY LCD (Fig. 18). They are color coded green, yellow, and red to denote normal, caution and danger zones, respectively. The Graphic Diver Interface allows you to make quick status checks underwater of your no- decompression status and ascent rate.
  • Page 26 Ascent Rate Indicator currently holds a U.S. Patent. DIVE TIME REMAINING DISPLAY One of the most important pieces of information on the PRODIGY is the no-decompression dive time remaining display (Fig. 19a). The PRODIGY constantly monitors theoretical loading of twelve different tissue compart- ments and calculates no-decompression time based on the amount of nitrogen ®...
  • Page 27 Over 3,000 feet (915 meters) depth calibration automatically changes to read in feet of freshwater rather than feet of seawater. WARNING - Until it has shut itself off, you must not use the PRODIGY at a different altitude than the altitude where it was originally activated. Doing so will result in an error equal to the difference in barometric pressure, and possibly a false dive mode.
  • Page 28 FLYING AFTER DIVING In 1990 the Undersea and Hyperbaric Medical Society (UHMS) published a set of guidelines aimed at minimizing the possibility of decompression sickness due to flying too soon after diving. The UHMS suggests divers using standard air tanks and exhibiting no symptoms of decompression sickness wait 24 hours after their last dive to fly in aircraft with cabin pressures up to 8,000 ft.
  • Page 29 PRODIGY. ® THE PRODIGY AT A GLANCE Figure 21 on the following page shows the PRODIGY's various displays Fig. 20 – Time to Fly "At-A-Glance" for quick visual reference or review of display features. Display...

  • Page 30: The Prodigy At A Glance

    Surface Mode Pre Dive Planning Sequence No-decompression Dive Time to Fly ® ® ® ® ® ® ® ® Decompression Dive Alt Decom Dive Delayed Violation Dive Log Fig. 21 –The PRODIGY At–A–Glance...
  • Page 31 HANDLING EXTREMES...

  • Page 32: Maximum Depth

    PRODIGY MAXIMUM DEPTH The PRODIGY will display a maximum depth of 250 feet (76 meters). If you exceed that depth, the Depth, Max Depth, and Dive Log readouts will display dashes signifying that you descended out-of-range (Fig. 22). For that dive, you will not see a numeric depth display over 250 feet (76 meters) or a Max Depth indication other than the three dashes.

  • Page 33: Emergency Decompression

    PRODIGY closely because you will enter decompression rapidly. Upon entering decompression the TLBG will enter the red zone and the decompres- sion dive icons will be displayed (Fig. 23). EMERGENCY DECOMPRESSION After entering decompression (especially at deeper depths) the TLBG may fill the 10, 20, 30, and 40 FT (3, 6, 9, and 12 M) STOP decompression zones rapidly.

  • Page 34: Violation Modes

    VIOLATION MODES If you exceed certain limits, the PRODIGY will not be able to tell you how to get back to the surface. These situations will make the PRODIGY enter violation mode and must be avoided at all costs. They push decompression theory to the limits and can result in loss of some PRODIGY functions for 24 hours after the last dive of a day in which a violation occurred.
  • Page 35 The PRODIGY will stay in the Conditional Violation Mode for up to 5 minutes of being shallower than the decompression ceiling. After 5 minutes, it will enter the Delayed Violation Mode (see next section). But, if the Condi- tional Violation is corrected before 5 minutes have elapsed (meaning you ®...

  • Page 36: Permanent Violations

    24 hours after the last dive. DELAYED VIOLATION MODE When the PRODIGY enters Delayed Violation Mode it retains the capac- ity to tell the diver how to get back to the surface. Delayed Violation Mode will be encountered in either of the following decompression situations:...
  • Page 37 PRODIGY. As previously described, you would then need to follow the ceiling toward the surface as the TLBG recedes toward the Caution Zone. Upon...
  • Page 38 After 5 minutes of surface time, the PRODIGY will enter an Immediate Violation and will then revert to the Gauge Mode (see page 35) for 24 hours. IMMEDIATE VIOLATION MODE The PRODIGY enters Immediate Violation Mode when a situation totally exceeds its capacity to predict an ascent procedure.

  • Page 39: Gauge Mode

    “Gauge Mode” up to 24 hours after a dive in which any Immediate or Delayed Dive time avail Violation Mode was entered. Gauge Mode turns the PRODIGY into a digital TLBG instrument without any decompression monitoring functions. Figure 27a All other displays Yes illustrates the changes effected in Gauge Mode.
  • Page 40 WARNING – Never exit the water with the Tissue Loading Bar Graph in the red decompression zone. Doing so greatly increases the risk of decompression sickness, and may result in injury or death. A diver’s metabolism varies from person to person, and even from day to day. If you are feeling slightly less than 100%, or you are in less than perfect physical shape, use the Caution Zone as a visual reference to place a wider margin of protection between you and the no-decompression limit.
  • Page 41 If you ever extend your dive profiles to the maxi- mum limit, Oceanic advises you to bring additional backup instruments with you on your dives, and to log each dive profile during every surface interval.
  • Page 42 (like a car trunk). After the dive, cover the PRODIGY and keep it out of the sun. If inadvertently left in the direct view of the sun, the LCD display may become totally black.
  • Page 43 Oceanic recommends that you carry a backup dive light, in case of primary light failure. SHARING THE PRODIGY The PRODIGY provides information based upon your personal dive profile and therefore must not be “shared” between divers. You should never, under any circumstances, swap your computer with another unit between dives, or share your computer with another diver underwater.
  • Page 44 (This page intentionally left blank)
  • Page 45 CARE & MAINTENANCE...

  • Page 46: Before The Dive

    Many dive computers (and dive trips) are ruined by encounters between carelessly tossed computers and weight belts or tanks. If the PRODIGY is attached to a tank in a rack, tuck Fig. 30 – DataLink high the computer into a B.C.
  • Page 47 (if you have a console version). This allows you to keep the PRODIGY nearby when recording dives in your log book or planning the next dive. DURING THE DIVE Keep the PRODIGY protected from abuse underwater by using the console retainers on your B.C.

  • Page 48: Annual Inspections

    PRODIGY. Therefore, if you are requesting a depth check, it is best to verify that the test chamber’s gauge is accurate to within plus or minus 1% of full scale.
  • Page 49 HOW TO OBTAIN SERVICE Tel: 44-884-84-0001; Fax: 44-884-84-1770 You can obtain service for your PRODIGY by returning it to the Autho- OCEANIC DIVING AUSTRALIA PTY LTD rized Oceanic Dealer where it was purchased. If one is not nearby, or you...
  • Page 50 Authorized Oceanic Dealer, where you may also obtain an annual inspection - even if your PRODIGY is not yet due for one. Whenever it is necessary to replace your own batteries, however, you may do so by follow- Fig.
  • Page 51 The module will slide up the screwdriver and exit the console. 2. Verify that your PRODIGY contains user replaceable batteries by examin- ing the case back to find the battery hatch (Fig. 33a).
  • Page 52 If found, return your PRODIGY to your Authorized Oceanic Dealer or Oceanic Parts & Service, and DO NOT attempt to use until it has received service. You may otherwise proceed to the next step.
  • Page 53 If found, return your PRODIGY to your Authorized Oceanic Dealer or Oceanic Parts & Service, and DO NOT attempt to use until it has received service. You may otherwise proceed to the next step.
  • Page 54 Surface Mode, followed by the Pre Dive Planning Sequence (PDPS). If Low Battery is indicated, return the unit to your Authorized Oceanic Dealer for a complete inspection before attempting to use it. 2. Observe the LCD display to ensure it is consistently clear and sharp in contrast throughout the screen.
  • Page 55 REFERENCE...

  • Page 56: Multiple Tissue Tracking

    Dive Log mode. REPETITIVE DECOMPRESSION DIVING Fig. 33 – Think of the 12 tissues The decompression model used by the PRODIGY is based on the no- as overlaid clear displays decompression multilevel repetitive dive schedules successfully tested by Dr.
  • Page 57 In the event that you must make an emergency decompression dive, you must not make another dive for at least 24 (twenty-four) hours. WARNING – Using the PRODIGY, just as using the U.S. Navy (or other) No-decompression Tables, is no guarantee of avoiding decompression sickness, i.e. “the bends.”...

  • Page 58: No-Decompression Limits

    170 (51) ––* 180 (54) ––* In this example, the PRODIGY was taken to a depth where the No-decom- 190 (57) ––* pression Dive Time Remaining reached three minutes. It was then taken to a shallower depth where it received one minute of no-decompression time * The Pre Dive Planning Sequence will not credit.
  • Page 59 Limit Diving 130 feet (39 meters). lose the assistance of the 160 ft. DO NOT EXCEED the PRODIGY getting back to 160 ft. Limit sport diving limit and the surface, resulting in an unguided ascent that make safety stops on 180 ft.
  • Page 60 The PRODIGY can greatly add to your enjoyment of the underwater world. Learn how to use it. Use it wisely. And have fun with the PRODIGY, your guide to the Oceanic frontier.
  • Page 61 NOTES...

  • Page 62: Specifications

    • Decompression ceilings at 10, 20, 30, & 40 feet (3, 6, 9, & 12 meters) • Tissue Loading Bar Graph (TLBG) Altitude Algorithm No decompression (green) 16 segments 1 segment • Based on National Oceanic & Atmospheric Administration (NOAA) tables Caution Zone (yellow) 4 segments 1 segment Decompression (red) 20 segments 1 segment OPERATIONAL MODES &...
  • Page 63 After counting down from 6 to 0, the • Altitude range 0 - 14,000 feet (4,268 meters) above sea level PRODIGY shifts back to the Surface or PDPS Mode. • Modes Full functions up to 14,000 feet (4,268 meters) Recalibration to fresh water depth readings over 3,000 ft (915 m) elevation * Battery life may vary greatly depending upon age, usage, climate, etc.

  • Page 64: Glossary

    GLOSSARY The following are diving terms that you should become familiar with. Many definitions given below apply specifically to the PRODIGY. Algorithm - A step-by-step mathematical formula designed to accomplish a particular result (i.e. Dive Time Remaining in the PRODIGY)
  • Page 65 Graphic Diver Interface ™ - A feature of Oceanic dive computers. Easily understandable color coded bar graphs that indicate diver status; green = normal, yellow = caution, red = danger. Icon - a small pictorial representation of an operational mode...
  • Page 66 Transducer - An electro-mechanical device in a dive computer that acts as a depth or pressure sensor VARI - Abbreviation for Variable Ascent Rate Indicator ™ Variable Ascent Rate Indicator - A display on the PRODIGY that shows ascent rate as a bar graph alongside a color–coded indicator (part of the Graphic Diver Interface)
  • Page 67 INDEX No aerosols 42 Depth sensor 44 Ceiling 4 Diagnostic Mode 12 Clean dive 14 Displays 20 Computer Accuracy 59 Accuracy 59 Failure 37 Activation 2, 12 Activation 2, 59 Modes 26, 58 Alternate 6 Accidental underwater 12 Sharing 39 Depth 20 How to 12 Conditional Violation Mode 30...
  • Page 68 DSAT 23 Before dive 42 PDPS limits 14 During dive 43 Numeric Displays Obtaining service 45 Listing of 58 Maximum depth 28 Flying after diving 7, 18 Maximum dive profile 54 DAN guidelines 24 Model ii, 23, 58 Obtaining Service ii Modes Off-gassing 31 Alternate dive 3, 14...
  • Page 69 Tables, U.S. Navy 54 Warnings Temperature Decompression sickness 53 Testing depth accuracy 44 Depth sensor damage 43, 45 Time to Fly 7, 18 Don’t decompression dive 15, 21 Tissue Compartment 22 Improper use 2 Tissue half-times 52, 58 PDPS 14 Tissue Loading Bar Repetitive decompression 53 Graph 4, 15, 21, 29, 36...
  • Page 70 RESPONSIBLE DIVER: Date of purchase _____________ AS A RESPONSIBLE DIVER I UNDERSTAND AND ASSUME THE Purchased from ______________ To be filled in by Authorized Oceanic Dealer: RISKS I MAY ENCOUNTER WHILE DIVING RESPONSIBLE DIVING BEGINS WITH: Date Dealer Name & Number Technician Name •...
  • Page 71 If you don't understand the contents of this manual and need assistance in learning how to use this computer, you should seek training from your Autho- rized Oceanic Dealer.
  • Page 72 OCEANIC USA 2002 Davis Street San Leandro, Ca. 94577 Phone: 510/562-0500 Fax: 510/569-5404 Web: http://www.oceanicusa.com © 2002 Design 1995 Doc. No. 12-1880,R5 (11/29/99)
