be displayed flashing (Fig. 30). Depth and Time displays will not appear until
the O2 bar graph recedes into the green (normal) zone (e.g., your daily oxygen
dosage decreases an amount equivalent to the amount accumulated during the
latest dive completed).
NO DECOMPRESSION DIVE MODE
As long as it is activated on the surface, the Data Plus 2 will enter the No De-
compression Dive Mode when you descend deeper than 5 feet (1.5 meters), re-
gardless of the operating mode it is in. If activated below 4 feet (1 meter), the
unit will perform a diagnostic check and shutdown.
To activate the Oceanglo ® backlight underwater, press the Select (Right) but-
ton. The display will be illuminated for button depression time plus 5 seconds.
It will not activate if a Low Battery condition exists.
Main Display (data shown depends on Alternate ON/OFF setting)
If the Alternate Display is set to 'OFF', information includes (Fig. 31) -
Current Depth, Elapsed Dive Time (and icon), Dive Time Remaining (and
icon), and Maximum Depth for that dive (and icon).
Data Plus 2
O
2
Fig. 30 - O2 Limit Exceeded
FT
FT
MAX
Fig. 31 - Main Display
(Alternate Off)
29
