Page 1 PROPLUS X OPERATING MANUAL PROPLUS X DIVE COMPUTER OPERATING MANUAL © Pelagic, 2016 Doc. No. 12-5655-r01 (8/19/16)
Page 2: Table Of Contents
PROPLUS X OPERATING MANUAL CONTENTS NOTICES SET UTILITIES 1: WATER TYPE 2: UNITS GETTING STARTED 3: DEEP STOP BASICS 4: SAFETY STOP POWER 5: ALGORITHM CHARGING THE BATTERY 6: CONSERVATIVE ACTIVATION 7: SAMPLE RATE QUICK DISCONNECT HOSE SET PREVIEW BUTTONS...
Page 3: Notices
DECOMPRESSION MODEL The programs within the ProPlus X simulate the absorption of nitrogen into the body by using a mathematical model. This model is merely a way to apply a limited set of data to a large range of experiences. The ProPlus X dive computer model is based upon the latest research and experiments in decompression theory.
Page 4 PROPLUS X OPERATING MANUAL Welcome OCEANIC THANK YOU for choosing the ProPlus X © Pelagic, 2016 Doc. No. 12-5655-r01 (8/19/16)
Page 6: Basics
The ProPlus X is an easy to use dive computer utilizing a four button interface. Divers may choose between either Dive or Gauge Mode. Though the ProPlus X is easy to use, you will get the most out of your new ProPlus X if you take some time to familiarize yourself with its displays and operation.
Page 7: Quick Disconnect Hose
Removal • Turn the locking collar counterclockwise to loosen. • Then push the hose fitting towards the ProPlus X and turn it counterclockwise ¼ turn. The hose will release from the console. Assembly • Visually inspect the fittings and connection O-ring for damage, corrosion, or deterioration.
Page 8: Display Icons
PROPLUS X OPERATING MANUAL DISPLAY ICONS SYMBOL MEANING BATTERY LEVEL (0 - 100%) 74° BLUETOOTH IS ON SURF SURFACE TIME DEPTH (FEET OR METERS) DIVE DIVE NUMBER GAS PRESSURE GAS TIME REMAINING NO DECOMPRESSION TIME OXYGEN TIME REMAINING ELAPSED DIVE TIME...
Page 9: Buttons
(v) TO MENU - (>) TO COMPASS BUTTONS The ProPlus X utilizes 4 control buttons Up, Down, Left, and Right. They allow you to select mode options and access specific information. They are also used to enter settings and acknowledge the audible alarm.
Page 11: Home Menu
HOME MENU This is a base menu that provides access to general items common to all the operating dive modes. When the ProPlus X is activated manually, this is the first screen you will see after the Welcome screen. When ready to dive, select Norm or Gauge Mode from the menu.
Page 12: Setup Menu
PROPLUS X OPERATING MANUAL SETUP MENU This menu allows you to adjust the Brightness, Bluetooth®, Set Date-Time, Calibrate Compass, and Set Declination features. HOME SETUP MENU BRIGHTNESS BLUETOOTH BRIGHTNESS SET DATE, TIME LEVEL CAL COMPASS SET DECLINATION AUTO DIM FUNCTION (>) TO SET...
Page 13: 2: Bluetooth
B: S While underwater the ProPlus X screen dims after a set time interval from the last button press. This is done to reduce distractions during the dive and to conserve power. The ProPlus X allows you to customize the time interval and degree of dimming. This feature may also be turned off.
Page 14: 3: Date, Time Set Menu
PROPLUS X OPERATING MANUAL 3: DATE, TIME SET MENU Within this menu you can set the formats, date, and time of day. DATE, TIME SET MENU DATE FORMAT DATE TIME FORMAT TIME SELECT ACCESS (<) BACK TO SETUP MENU CONTROLS...
Page 15: 4: Calibrate Compass
You may need to calibrate the compass from time to time to compensate for any magnetic changes (new dive location or other surround- ing changes). Follow the prompts to calibrate the compass. The ProPlus X will then indicate if the calibration passed or failed.
Page 16: 5: Set Declination
PROPLUS X OPERATING MANUAL 5: SET DECLINATION Magnetic declination or variation measures the angle between the Earth's magnetic north and true north. The declination value for any region can be found on current geographical charts. By correcting for declination, you can achieve a more accurate compass reading.
Page 17: History
PROPLUS X OPERATING MANUAL Data 3 NOTE: If the record is a Gauge dive, the message GAUGE DIVE NO DATA will be displayed on the Log Data 3 screen. DATA 3 DATE # LOG FO2 SET 2/14/13 MAX PO2 10/28/12 #2 0.86...
Page 19: Dtr (Dive Time Remaining)
DTR (DIVE TIME REMAINING) The ProPlus X constantly monitors No Decompression status and O2 Accumulation, and will display whichever time is the least amount available as DTR on the No Decompression Dive Main screen. The time being displayed will be identified by the NDC (no decompression) or OTR (Oxygen Time Remaining) icons.
Page 20: Ascent Rate Bar Graph
(915 m) higher than the actual altitude at activation. Refer to the charts in the back of this manual for dive times. DEEP STOP When the DS (Deep Stop) selection is set ON, it will trigger after descending deeper than 80 ft (24 m). The ProPlus X then calculates (continually updating) a Stop Depth equal to ½ the Max Depth.
Page 21: Safety Stop
• There is no penalty if you surface prior to completing the Safety Stop or choose to ignore it. LOW BATTERY WARNING: DO NOT dive with a low battery. Charge the battery before diving if your ProPlus X indicates the Battery Low Warn- ing or Alarm.
Page 22: Audible Alarm
PROPLUS X OPERATING MANUAL AUDIBLE ALARM While operating in Norm or Gauge mode, the audible alarm will emit 1 beep per second for 10 seconds when alarms strike. During that time, the audible alarm can be acknowledged and silenced by pressing the UP button.
Page 24: On The Surface Before A Dive
PROPLUS X OPERATING MANUAL ON THE SURFACE BEFORE A DIVE The Norm Surface Main screen will display the SURF (Surface Time), dive number, gas pressure, any residual nitrogen loading, and the selected of the breathing gas. The surface time displayed is the time since activation or the surface interval after a dive.
Page 25: Last Dive Data
PROPLUS X OPERATING MANUAL LAST DIVE DATA This screen displays essential data from the last dive. If there has been no dive within the current activation cycle, the the max depth and elapsed dive time will be displayed as zero.
Page 26: Set Gas
FO2 Air with no PO2 alarm value for Gas 1, and OFF for Gas 2, 3, and 4. Settings revert to the defaults when 24 hours elapse without conducting a dive. If you save a nitrox mix value for any gas, the ProPlus X will highlight the PO2 alarm value allowing it to be set. Additionally, the ProPlus X allows for each gas (1 - 4) to have individual PO2 alarm settings.
Page 27: 1: Audible
PROPLUS X OPERATING MANUAL 1: AUDIBLE The Audible Alarm allows you to set audible alarms ON or OFF. AUDIBLE ALARM AUDIBLE DEPTH TLBG SETTING TURN PRESS - TOGGLE LOW PRESS - TOGGLE > - SAVE (<) BACK TO MENU CONTROLS...
Page 28: 4: Tlbg (Tissue Loading Bar Graph)
PROPLUS X OPERATING MANUAL 4: TLBG (TISSUE LOADING BAR GRAPH) This feature allows you to set an alarm to go off at a predetermined percentage of Tissue Loading Bar Graph being filled. TLBG ALARM AUDIBLE 80 % DEPTH TLBG Alarm Triggered...
Page 29: 7: Low Press
PROPLUS X OPERATING MANUAL 7: LOW PRESS The Low Pressure Alarm allows you to set an alarm for when you reach a designated end pressure. You may choose from from 300 to 1500 PSI (20 to 105 BAR) in increments of 100 PSI (5 BAR).
Page 30: 2: Units
PROPLUS X OPERATING MANUAL 2: UNITS The Units feature allows you to select whether Imperial (FT, PSI) or Metric (M, BAR) units of measure will be displayed. UNITS OF MEASURE WATER TYPE M, BAR UNITS DEEP STOP (METRIC) SAFETY STOP...
Page 31: 5: Algorithm
PROPLUS X OPERATING MANUAL 5: ALGORITHM This feature allows the choice of using the Z+ or DSAT algorithms, for nitrogen and oxygen calculations. See page 20 for further Dual Algorithm details. NOTE: Changing the algorithm is blocked during 24 hours after NORM dives unless Desat time decreases to 0:00.
Page 32: 7: Sample Rate
7: SAMPLE RATE The Sample Rate controls how frequently the ProPlus X stores a data snapshot for PC Download during a dive. Setting options are 2, 15, 30, or 60 second intervals. Shorter intervals will provide a more precise record of your dives.
Page 33: View Preview
PROPLUS X OPERATING MANUAL VIEW PREVIEW Upon accessing this screen from the Norm Main Menu, the items selected using the Set Preview function previously described will be displayed with the settings last saved. NORM DIVE PREVIEW GAS 1 FO2 PO2 AL...
Page 35: Initiating A Dive
PROPLUS X OPERATING MANUAL INITIATING A DIVE With the ProPlus X in Dive Mode, a dive will commence upon descending to 5 ft (1.5 m) for at least 5 seconds. Below is a diagram to help you navigate Dive Mode functions.
Page 36: Dive Menu
PROPLUS X OPERATING MANUAL DIVE MENU Set Brightness, More Data, Gas Switches, and Deep Stop Preview are all accessed from the Dive Menu. NORM DIVE MENU SET BRIGHTNESS 80 % MORE DATA GAS SWITCH DS PREVIEW SELECT TO ADJUST BY % (>) TO SET...
Page 37: 3: Gas Switch
PROPLUS X OPERATING MANUAL 3: GAS SWITCH WARNING: Historically, many accidents and near misses have occurred by switching to the wrong gas at the wrong depth. DO NOT attempt gas switch decompression dives without proper education and training to do so from an inter- nationally recognized training agency.
Page 38: Earmark
By holding the left button for more than 2 seconds during a dive you can manually record a data snapshot. The snapshot can later be accessed us- ing the ProPlus X's download feature. The message "EARMARK APPLIED" will be displayed for 3 seconds as confirmation after an earmark is made.
Page 39: Decompression
COMPLICATIONS The preceding information has described standard dive operations. Your new ProPlus X is also designed to help you to the surface in less than ideal situations. The following is a description of these situations. Take some time to familiarize yourself with these operations before diving your ProPlus X.
Page 40: Delayed Violation 1
Only dashes will display for Current Depth and NDC (No Decompression) time signifying that you are too deep. * The maximum functional depth (Dive/Gauge = 330 ft / 100 m) is the depth at which the ProPlus X can properly perform calculations or provide accurate display information.
Page 41: Violation Gauge Mode During A Dive
During Dive mode dives, operation will enter VGM when Decompression requires a Stop Depth greater than 70 ft (21 m). Operation would then continue in VGM during the remainder of that dive and for 24 hours after surfacing. VGM turns the ProPlus X into a digital instrument without any decompression or oxygen related calculations or displays.
Page 42: High O 2 2 Sat (Oxygen Saturation)
PROPLUS X OPERATING MANUAL ALARM If PO continues to increase and reaches the alarm set point, the audible alarm sounds again. The PO value, GO UP message, and up arrows will flash during the audible alarm. After the audible alarm is silenced, they alternate with NDC (No Decompression) and EDT (Elapsed Dive Time) until PO decreases below the alarm set point.
Page 43 PROPLUS X OPERATING MANUAL WARNING DURING DECOMPRESSION When O2 SAT reaches the Warning Level, the audible alarm sounds and the O2 SAT value will flash in the middle of the screen. When the audible alarm is silenced, the O2 Sat value will alternate with Decoo Stop/Time.
Page 45: On The Surface Before A Dive
INITIATING A DIVE With the ProPlus X in Gauge Mode, a dive will commence upon descending to 5 ft (1.5 m) for longer than 5 seconds. Below is a diagram to help you navigate Gauge Dive Mode functions. The dive will end and revert to Surface Mode upon ascent to 0.9 m (3 ft) of depth for at least 1 second.
Page 46 PROPLUS X OPERATING MANUAL NOTE: All other Gauge mode dive functions are similar to Norm Mode. See the Norm Dive Mode chapter for further details. © Pelagic, 2016 Doc. No. 12-5655-r01 (8/19/16)
Page 48 PROPLUS X OPERATING MANUAL COMPASS DISPLAY ICONS NORTH 1 56 74° 12:36 SURF 147° 22 sec (<) TO SURF MAIN COMPASS MODE DEPTH OR SURFACE TIME HEADING CORRECTION ARROW HEADING MARKER TIME OUT COUNTDOWN HEADING DEGREES ASCENT RATE DIVER'S DIRECTION (LUBBER LINE) HEADING INDEX ©...
Page 49: Overview
• The ProPlus X reverts back to the previous operation mode after 1 minute unless the Compass Mode is reset by pressing any of the buttons. See the Timeout section at the end of this chapter for further details.
Page 50: Reference/Reverse Reference
PROPLUS X OPERATING MANUAL REFERENCE/REVERSE REFERENCE The Reference modes allow you to select course headings. The heading marker and course correction arrows will aid you in navigating. When first entering this mode the reference heading in the lower left of the screen will be flashing.
Page 52: Uploading/Downloading Data
ProPlus X lens protector. Small scratches will naturally disappear underwater. • Soak and rinse the ProPlus X in fresh water at the end of each day of diving, and check to ensure that the areas around the low pressure (depth) sensor, PC interface data port, and buttons are free of debris or obstructions.
Page 53: Altitude Sensing And Adjustment
• No adjustments are made during any time that the Wet Contacts are bridged. • When diving in high altitude waters from 3,001 to 14,000 feet (916 to 4,270 meters), the ProPlus X automatically adjusts to these conditions pro- vidingcorrected Depth, and reduced No Deco and O2 Times at intervals of 1,000 feet (305 meters).
Page 55 PROPLUS X OPERATING MANUAL DSAT BASED NDLS (HR:MIN) (IMPERIAL) Altitude 3001 4001 5001 6001 7001 8001 9001 10001 11001 12001 13001 (feet) 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000 13000 14000 Depth (FT) 4:20 3:21 3:07 2:55...
Page 56 PROPLUS X OPERATING MANUAL Z+ BASED NDLS (HR:MIN) (IMPERIAL) Altitude 3001 4001 5001 6001 7001 8001 9001 10001 11001 12001 13001 (feet) 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000 13000 14000 Depth (FT) 3:17 2:30 2:21 2:14...
Page 57: Specifications
PROPLUS X OPERATING MANUAL SPECIFICATIONS CAN BE USED AS • Dive Computer (Air or Nitrox) • Digital Depth Gauge/Timer DIVE COMPUTER PERFORMANCE • Buhlmann ZHL-16c based PZ+, or DSAT based, algorithm. • No Decompression limits closely follow PADI RDP. • Decompression in agreement with Buhlmann ZHL-16c and French MN90.
Page 58 PROPLUS X OPERATING MANUAL SPECIFICATIONS (CONTINUED) NUMERIC DISPLAYS: Range: Resolution: • Temperature 0 to 140 F (-18 to 60 C) 1 degree • Altitude Level Sea, EL2 to EL7 1 level • Depth, Max Depth 0 to 330 FT (100 M) 1 FT (0.1 M )
Page 59 PROPLUS X OPERATING MANUAL ABBREVIATIONS/TERMS = Alarm M.D (D.M) = Month.Day (Day.Month) = Ascent Rate MIN (min) = Minutes (time) = Atmospheres Absolute = Meters Per Minute = Audible = No Deco DTR = Metric Unit Of Pressure = No Deco Limit...
Page 60 Serial Number: ___________________________________________________________________________________________________ Firmware Rev: ___________________________________________________________________________________________________ Date of Purchase: ___________________________________________________________________________________________________ Purchased from: ___________________________________________________________________________________________________ Below to be filled in by an Authorized Oceanic Dealer: Date Service Performed Dealer/Technician OCEANIC WORLD WIDE OCEANIC USA 2002 Davis Street San Leandro, CA 94577 Tel: 510/562-0500 Fax: 510/569-5404 Web: www.OceanicWorldwide.com...
Page 61 PROPLUS X OPERATING MANUAL ProPlus X DIVE COMPUTER OPERATING MANUAL © Pelagic, 2016 Doc. No. 12-5655-r01 (8/19/16)
