OPERATIONAL PERFORMANCE (continued)
Altitude:
• Operational from sea level to 14,000 feet (4,267 meters) elevation
• Recalibration of depth readings from 'feet of sea water' to 'feet of fresh water'
when higher than 2,000 feet (610 meters) elevation
Power:
1 - 3.6 volt, 1/2AA TADIRAN ® model TL-2150, .95Ah,
• Battery
1.0ma, Lithium (must be 3.6 v, .95Ah, 1.0ma rating)
• Shelf life Up to 5 years
• Replacement User replaceable (annual recommended)
• Life expectancy 350 dive hours (if 1 - 1 hour dive per dive day) to over
700 dive hours (if 2 or more 1 hour dives per dive day).
Yearly replacement is recommended.
Activation:
• Manual (push button) - cannot be activated by water immersion
• Cannot be activated deeper than 4 feet (1.5 m)
• Cannot be activated at elevations higher than 14,000 feet (4,267 m)
• Needed before first dive.
• Automatically shuts off if no dive is made within 120 minutes after initial
activation. Reactivation required.
• Cannot be shut off manually.
76
SPECIFICATIONS (continued)
Setting FO2:
• Automatically set for 'Air' upon activation
• Remains set for Air unless an FO2 numerical value is set
• Nitrox set points from 21 to 50 %
• If set for 21%, remains set for 21% until changed
• If set for >21%, reverts to 50% 10 minutes after the dive (however,
if the FO2 Default setting is OFF, the previous value set will be
retained)
ACCESSORIES
Optional items available from your Authorized Oceanic Dealer:
• Battery Kit - includes 1 battery, 1 o-ring, silicon grease
• Lens Protector - adheres to lens face, prevents scratches
• OceanLog™ for Data Plus 2 - PC Download Package
(hardware and software program)
