  • Page 1: Data Plus

    OCEANIC ® DATA PLUS ™ owner's guide...
  • Page 2 ®...

  • Page 3: Responsible Computer Diving

    DataPlus RESPONSIBLE COMPUTER DIVING Always Plan Each Dive Always Limit Your Dive to the Level of Your Training and Experience Always Make Your Deepest Dive First Always Make The Deepest Part Of Every Dive First Check Your Computer Often During the Dive Do A Safety Stop On Every Dive Allow Adequate Surface Interval Between Each Dive Allow Adequate Surface Interval Between Each Day...
  • Page 4 • Read and understand this owner’s guide completely before diving with the DataPlus. • If you do not fully understand how to use this dive computer, or if you have any questions, you should seek instruction in its use from your authorized Oceanic dealer before you utilize this product.
  • Page 5 (at Oceanic’s discretion) free of charge excluding shipping and handling charges. This warranty will be considered void if the registration card is not filled out completely at the time of purchase and mailed to Oceanic within 30 days of purchase, and/or if the annual inspection is not done according to this owner’s guide.
  • Page 6 This owner’s guide is copyrighted, all rights are reserved. It may not, in whole or in part, be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine readable form without prior consent in writing from Oceanic / 2002 Design. The Surface Time/Mode, Plan Mode, No Decompression Time, Decompression Stop Time, Dive Log, Low Battery, Bottom Time, Maximum Depth, Ascent Rate, and Caution Zone icons are protected by copyright, and are trademarks of Oceanic.

  • Page 7: Table Of Contents

    DataPlus CONTENTS FEATURES OVERVIEW .............. 1 Introduction ........................2 Regulator Attachment ....................4 Activating the Display ....................4 Programming Nitrox Mixes (FO2) ................6 Making a Dive ....................... 7 After the Dive ......................11 Knowing When to Fly ....................13 Altitude Diving ......................
  • Page 8 ® CONTENTS (CONTINUED) Variable Ascent Rate Indicator™ (VARI) ..............24 Operational Modes ...................... 25 Activation & Diagnostic Mode ................... 26 Surface Mode ......................27 Pre Dive Planning Sequence™ (PDPS) ..............29 No Decompression Dive Mode ................... 31 Decompression Dive Mode ..................33 High PO2 Dive Mode ....................
  • Page 9 DataPlus CONTENTS (CONTINUED) Decompression Dive Mode ..................47 Violation Modes ......................50 Conditional Violation Mode ..................50 Delayed Violation Mode ....................51 Immediate Violation Mode ..................54 Gauge Mode ........................ 55 Permanent Violation ....................55 Exceeding Maximum Operating Depth ..............56 Oxygen Exposure ......................
  • Page 10 ® CONTENTS (CONTINUED) Flooded Battery Compartment .................. 72 Inspection ........................73 Returning the Module To Its Boot ................73 REFERENCE ................75 More About Flying After Diving ................76 More About Altitude Diving ..................77 More About Nitrox Diving ..................78 Multiple Tissue Tracking ...................

  • Page 11: Features Overview

    FEATURES OVERVIEW...

  • Page 12: Introduction

    Welcome to Oceanic and thank you for choosing the DataPlus! Your new DataPlus presents the information that you need before, during, and after your air (or nitrox) dives using Oceanic's intuitive combination of easy to read digital displays and unique identification icons.
  • Page 13 LCD display. If any signs of damage are found, return the unit to an Authorized Oceanic Dealer. DO NOT attempt to use it until it has received factory service.

  • Page 14: Regulator Attachment

    REGULATOR ATTACHMENT If you have purchased the DataPlus in a console version, you will need to have it attached to your regulator first stage by an Authorized Oceanic Dealer. ACTIVATING THE DISPLAY You activate the DataPlus by pressing and releasing the control button located below the display (Fig.
  • Page 15 DataPlus Surface Time display will start counting up from 0:00. If no dive is made within 2 hours (2:00) after activation, the unit will automatically shut off. After displaying the Surface Mode for several seconds, the DataPlus advances to the display FO2 and Air for 5 seconds (Fig. 2) during which time percentage O2 for that dive's nitrox mix can be programmed (set) by pressing and holding DATA PLUS...

  • Page 16: Programming Nitrox Mixes (Fo2)

    ® PROGRAMMING NITROX MIXES WARNING: FO2 must be set 'before each' nitrox dive. The DataPlus can be used either as an Air computer or a Nitrox computer. To program the percentage O2, press and hold the control button when 'FO2' - 'Air' appears during the Surface Sequence.

  • Page 17: Making A Dive

    DataPlus FO2 must be reset for each repetitive nitrox dive, or the value will automatically be 50 and the dives will be calculated based on 50% O2 for oxygen calculations and 21% O2 (79% nitrogen) for nitrogen calculations. Once a dive is made with the DataPlus set as a nitrox computer (FO2 set for a numerical value), the unit cannot be programmed to operate as an 'Air' computer until 24 hours after the last dive.
  • Page 18 ® When underwater, you can quickly focus on the three bar graphs to make sure that they are in the green. You can quickly verify that you’re not getting too close to the no decompression limit, or the oxygen tolerance limit, or ascending too fast.
  • Page 19 DataPlus either per dive allowable O2 or 24 hour period allowable O2. As your exposure, oxygen tolerance dose (OTU), increases during the dive, segments will fill the graph to form an arc along the right perimeter of the LCD. As your OTU level decreases, the bar graph will begin to recede, indicating that additional exposure is allowed for the dive, or 24 hour period.
  • Page 20 ® completing your ascent. Many divers do this to provide a wider zone of caution from the no decompression limit. If your depth or elapsed dive time are such that the TLBG enters the red decom- pression (DECO) zone, the DataPlus will switch to the Decompression Dive Mode (Fig.

  • Page 21: After The Dive

    DataPlus AFTER THE DIVE After reaching 3 feet (1 meter) upon ascent, the Surface Mode display (Fig. 15) will replace the Dive Mode display for 10 minutes. After 10 minutes, the DataPlus advances through the sequence of surface displays - Time to Fly, FO2, PO2, PDPS, then back to Surface Mode.
  • Page 22 ® tions on nitrogen loading, only the TLBG will be displayed, or if calculations are based upon oxygen loading, only the O2 bar graph will be displayed. Immediately after a dive, various information is stored in the DataPlus’ memory and can be viewed by accessing the Dive Log Mode. This gives you a opportu- nity to record data in your log book before it is eventually overwritten by subse- quent data.

  • Page 23: Knowing When To Fly

    DataPlus KNOWING WHEN TO FLY Due to the present lack of a complete data set derived from actual human testing, there are different recommendations cited by various scientific organiza- tions for the amount of time a diver should wait before flying after diving. The DataPlus follows one of the more conservative of these, cited by Divers Alert Network (DAN);...

  • Page 24: Altitude Diving

    The mathematical model within the DataPlus accounts for the reduced No Decompression time available at higher elevations based on NOAA (National Oceanic and Atmospheric Administration) guidelines. When diving in high altitude lakes or rivers from 2,000 to 14,000 feet (610 to 4,268 meters), the DataPlus will adjust automatically, providing corrected depth and reduced No Decompression times.

  • Page 25: Sharing The Dataplus

    DataPlus SHARING THE DATAPLUS WARNING: Never participate in sharing or swapping of a dive computer. Doing so may result in injury or death. The DataPlus provides information based upon a diver’s personal dive profile, and therefore must not be “shared” between divers. You should never, under any circumstances, swap your computer with another unit between dives, or share your computer with another diver underwater.

  • Page 26: Lcd Display Legend

    ® 1a. TLBG - (Green - No Decompression zone) 1b. TLBG - (Yellow - Caution zone) 1c. TLBG - (Red - Decompression zone) 2a. O2 Bar Graph - (Green - safe O2 zone) 2b. O2 Bar Graph - (Yellow - Caution zone) 2c.

  • Page 27: Detailed Operations

    DETAILED OPERATIONS...

  • Page 28: Informational Displays

    ® INFORMATIONAL DISPLAYS Each DataPlus numeric or graphic display represents a unique piece of informa- tion. It is imperative that you understand the formats, ranges, and values of the information represented by the DataPlus' displays to avoid any possible misun- derstanding that could result in error.

  • Page 29: Time Display

    DataPlus indicates the Maximum Depth reached during that dive. In the event that you descend deeper than 330 feet (99.5 meters), this display will only show three dashes (Fig. 21b, page 18) for the remainder of that dive, and as the Max Depth in the Dive Log for that dive.
  • Page 30 ® segments of the LCD include - FO2 set point value, 'EA' (External Access), and 'FLY' (during the first 12 hours). A second time display, located in the center right portion of the LCD (Fig. 23b, page 19), indicates Elapsed Dive Time, or Decompression Stop Time required (Fig.24b) for the current stop ceiling indicated, as identified by the Elapsed Dive Time and Ceiling Stop icons, respectively.

  • Page 31: Graphic Diver Interface

    DataPlus GRAPHIC DIVER INTERFACE ™ NOTE: Displays associated with oxygen and the O2 bar graph will only appear if FO2 has been set at a value other than 'Air'. Three bar graphs referred to as the Graphic Diver Interface™ are located around the perimeter of the DataPlus' LCD (Fig.

  • Page 32: Oxygen Accumulation (O2) Bar Graph

    Pre Dive Planning Sequence™ (PDPS), and no segments of the O2 bar graph are displayed, that next dive is calculated to be controlled by nitrogen loading. WARNING: Oceanic advocates responsible diving practices consistent with your individual level of formal training and experience, and does not recommend decompression diving or diving below 130 feet (39 m).
  • Page 33 DataPlus dive, or 24 hour period, segments will add to the graph in an arc beginning from the lower right. As oxygen loading decreases, the bar graph will begin to recede, indicating that additional oxygen accumulation is allowed for that dive and a subsequent dive during that 24 hour period.

  • Page 34: Variable Ascent Rate Indicator™ (Vari)

    ® VARIABLE ASCENT RATE INDICATOR™ (VARI) Segments = Speed (rate) The Variable Ascent Rate Indicator™ (VARI), located along the bottom of the 0 = 0 - 20 fpm (0 - 6 mpm) LCD screen (Fig. 29), is provided to help you to avoid excessive ascent rates by 1 = 21 - 30 fpm (6.5 - 9 mpm) providing a visual representation of ascent speed, rather than just showing that 2 = 31 - 40 fpm (9.5 - 12 mpm)

  • Page 35: Operational Modes

    DataPlus OPERATIONAL MODES Icon a - Maximum Depth NOTE: Displays associated with oxygen and the O2 bar graph b - Low Battery warning will only appear if FO2 has been set at a value other than 'Air'. c - Dive Log mode d - Temperature The different operating modes of the DataPlus are easy to tell apart.

  • Page 36: Activation & Diagnostic Mode

    DataPlus. See page 69 for more information regarding Low Battery. PLUS WARNING: If a Low Battery condition is indicated immediately upon activation, Oceanic strongly recommends that you DO NOT Fig. 31 - Diagnostic Mode dive until batteries are replaced.

  • Page 37: Surface Mode

    DataPlus If a dive is not made within 2 hours after activation, the DataPlus will shut off automatically to save battery power. Always check your DataPlus before entering the water to ensure that it has been activated. SURFACE MODE Surface Mode (Fig. 32), identified by the Surface Mode icon to the right of the Surface Time display, immediately follows Diagnostic Mode after initial activa- DATA tion.
  • Page 38 ® was a nitrox dive). If you descend during that first 10 minute transition period, time underwater will be considered a continuation of that dive. The time at the surface (if less than 10 minutes) will not be added as elapsed dive time. During the 10 minute transition period, the Log Mode is accessible and will display that dive's data, however, data will not be stored in the unit's memory until the 10 minute period is completed.

  • Page 39: Pre Dive Planning Sequence (Pdps)

    PRE DIVE PLANNING SEQUENCE ™ (PDPS) Prior to every dive, Oceanic strongly recommends that you view the PDPS to review the no decompression limits that will help you plan your dive as required to avoid decompression or oxygen toxicity. This is especially important for repetitive dives, when the PDPS (Fig.
  • Page 40 ® With each depth display you will see either 'predicted' no decompression limits based upon your previous dive profiles (if calculated to be nitrogen controlled), or 'predicted' oxygen tolerance limits based upon either a single dive OTU or your 24 hour accumulation of oxygen (if calculated to be oxygen controlled). The DataPlus will then return to the Surface mode, continuing the sequence for the first 12 hours after surfacing.

  • Page 41: No Decompression Dive Mode

    DataPlus NO DECOMPRESSION DIVE MODE Upon descending deeper than 5 feet (1.5 meters), the DataPlus will enter the No Decompression Dive Mode (Fig. 37), identified by the No Decompression Dive icon (Fig. 37b) located to the right of the Main Time display. Information provided includes Current Depth, Maximum Depth for that dive (and Max Depth icon), Elapsed Dive Time (and Elapsed Dive Time icon), and No Decompression Dive Time Remaining for that depth.
  • Page 42 ® decompression limit, the TLBG will diminish as control shifts to slower compartments. This is a feature of the decompression model that is the basis for multilevel diving, one of the most important advantages the DataPlus offers. (See page 80 in the Reference section for more informa- tion pertaining to tissue tracking.) The no decompression algorithm is based upon Haldane’s theory using maximum allowable nitrogen levels developed by Merrill Spencer.

  • Page 43: Decompression Dive Mode

    DECOMPRESSION DIVE MODE The DataPlus will help you to avoid and manage decompression. WARNING: Oceanic recommends the application of responsible diving practices and does not recommend decompression diving, or diving deeper than 130 feet (39 meters), as these practices will greatly increase your risk of decompression sickness.

  • Page 44: High Po2 Dive Mode

    ® HIGH PO2 DIVE MODE The DataPlus enters the High PO2 Dive Mode (Fig. 41) when partial pressure of oxygen becomes equal to or greater than 1.40 BAR as indicated by the digital display. In the event that this does occur, the value of PO2 (Fig. 41a), and the symbol 'PO2' (Fig.

  • Page 45: Gauge Mode

    DataPlus GAUGE MODE If the DataPlus totally exceeds its capacity to predict an ascent procedure, it enters a Permanent Violation Mode and will operate in Gauge Mode for the remainder of that dive and on subsequent dives, only displaying depth and time (Fig.

  • Page 46: Dive Log Mode

    ® While you cannot provide a guarantee against the occurrence of de- compression sickness, you may choose your own personal zone of caution based upon your individual age, physique, excessive weight, training, experience, etc. to reduce the statistical risk. The Ascent Rate Indicator shows how fast you are ascending. When you exceed the maximum recommended ascent rate of 60 feet per minute (18 meters per minute), the bar graph segments will enter the red (Too Fast) zone and you will DATA...
  • Page 47 DataPlus Dives are displayed in a sequence that starts with the dive most recently re- corded scrolling back to the oldest of the 12 stored for viewing. Thus, your most recent dive will always be the first shown in the log sequence, the second most recent will appear next, etc.

  • Page 48: Time To Fly Mode

    ® • Today you conducted 2 dives. • Your log sequence would be #2, #1, #3, #2, #1. • This relates to #2 (today' most recent dive), #1 (today's first dive), #3 (Last Saturday's last dive), #2 (Last Saturday's second dive), #1 (Last Saturday's first dive), etc.
  • Page 49 DataPlus ended to assist you with deciding when enough surface time has elapsed to fly. It appears once per minute for several seconds during the Surface Sequence showing the word FLY below a countdown display (Fig. 48) that starts at 23:50 (hr : min) and counts down to 12:00 (hr:min).

  • Page 50: External Access (Ea) Mode

    95 operating system. Instructions for performing the interface and download are provided with the hardware and software package that is available separately at your Authorized Oceanic Dealer. Ask for OceanLink™ for DataPlus. The OceanLink™ program provides dive profiles, nitrogen and oxygen loading throughout the dive, and a unique interactive DataPlus Simulator that enables you to view all of the displays and operating modes being described.

  • Page 51: Backlight Feature

    10 seconds after being released. Ambient temperature will be (backlight feature) displayed for the first 2 seconds after the button is depressed. Oceanic recommends that you always carry primary and backup dive lights when conducting dives that could include low light situations. AMBIENT TEMPERATURE DISPLAY...

  • Page 52: Operating Temperature

    ® OPERATING TEMPERATURE The DataPlus will operate in almost any temperature diving environment in the world (Fig. 53) between 32 and 140 F (0 and 60 C). At extremely low tempera- tures, the LCD may become sluggish, but this will not affect it's accuracy. If stored or transported in extremely low temperature areas (below freezing), you should warm the module and its batteries with body heat before diving.

  • Page 53: Handling The Extremes

    HANDLING EXTREMES...

  • Page 54: Emergency Decompression

    ® EMERGENCY DECOMPRESSION There are few legitimate excuses for making unplanned Decompression dives, and the consequences of this type of diving can be severe. Decompression diving requires special training. The DataPlus is intended for use by recre- ational divers not engaged in intentional decompression diving. De- compression features are provided only for emergency situations.
  • Page 55 It should not be considered, however, that these built-in capabilities provide any im- plied approval or consent from Oceanic for individuals to exceed the defined limits of recreational dive profiles, as agreed on by all interna- tionally recognized training agencies.

  • Page 56: Caution Zone (Tlbg)

    ® WARNING: Existing data for making planned decompression dives is extremely limited, and virtually nonexistent for repeti- tive decompression diving. You must therefore avoid decompres- sion diving and allow a surface interval of at least 24 hours before reentering the water in the event a dive requiring decom- pression is made.

  • Page 57: Decompression Dive Mode

    DataPlus nient way to consistently monitor how close you are coming to the No Decom- pression limit. Oceanic suggests always leaving the water with the TLBG in the green No Decompression (NO DECO) zone. WARNING: Never exit the water with the TLBG in the red Decompression (DECO) zone.
  • Page 58 ® decompression dive time/depth limits are exceeded causing the TLBG to pass the yellow caution (C.Z.) zone and enter the red decompression (DECO) zone. Information provided includes current depth, current required decompression ceiling stop depth and time (and Ceiling Stop icon), and total ascent time that includes stop time at all ceilings and vertical ascent time calculated at 60 feet (18 meters) per minute.
  • Page 59 DataPlus ascending any further, or you will increase your risk of decompression sickness. The amount of decompression credit time you receive is dependent on depth, with slightly less credit given the deeper you are. Still, you must never ascend shallower than your decompression ceiling. Doing so will greatly increase your risk of decompression sickness and place the DataPlus into a Conditional Violation Mode described later.

  • Page 60: Violation Modes

    ® VIOLATION MODES WARNING: If you exceed certain limits, the DataPlus will not be able to tell you how to get safely back to the surface. These situations will make the DataPlus enter 'violation modes' and must be avoided at all costs. They exceed tested limits and can result in loss of some DataPlus functions for 24 hours after the dive in which a violation occurred.

  • Page 61: Delayed Violation Mode

    DataPlus The DataPlus will alert you to the Conditional Violation by flashing the Total Ascent Time display until you descend below the required decompression stop ceiling. If you descend below the required decompression ceiling before 5 minutes have elapsed, the DataPlus will continue to function as if no violation had occurred.
  • Page 62 ® would then need to follow the ceiling stop depths and time toward the surface until the TLBG recedes toward the caution (C.Z.) zone. Upon reaching zero Total Ascent Time remaining, you should continue decompressing until the TLBG segments are well inside of the green no decompression (NO DECO) zone.
  • Page 63 DECO) zone, unless a low air condition requires you to surface. 3. You descend deeper than 330 feet (99.5 meters). Oceanic reminds you that the DataPlus is intended for no decompres- sion diving at depths within 130 feet (39 meters). Expanded capabili- ties of the DataPlus are provided as safety features to assist you with emergency situations.

  • Page 64: Immediate Violation Mode

    These dives represent gross excursions into decom- pression that are beyond the boundaries and spirit of the DataPlus design. If you are following these dive profiles, Oceanic advises you not to use a DataPlus dive computer. Immediate Violation Mode occurs when a Decompression Stop depth much greater than 60 feet (18 meters) is required.

  • Page 65: Gauge Mode

    DataPlus GAUGE MODE Underwater the Gauge Mode is a continuation of the Immediate Violation Mode that turns the DataPlus into a digital instrument without any decompression or oxygen monitoring functions (Fig. 64). After surfacing, Gauge Mode does not provide the Time to Fly, FO2, PO2, and PDPS features.

  • Page 66: Exceeding Maximum Operating Depth

    130 feet (39 meters). Any deeper dive should be avoided. Special training, equipment and support are necessary for this type of diving. Oceanic does not advocate diving to depths below 130 feet (39 meters), the basis for which is purely theoretical.

  • Page 67: Oxygen Exposure

    DataPlus dives, the DataPlus will allow a maximum of 7 minutes no decompression dive time available at 160 feet (48 meters). Since part of the 7 minutes is used during descent, the actual time available upon reaching 160 feet (48 meters) can be a very short amount of time.
  • Page 68 It should not be considered, however, that these built-in capabilities provide any implied approval or consent from Oceanic for individuals to exceed the defined limits of oxygen exposure, as agreed on by all internationally recognized nitrox training agencies.

  • Page 69: High O2 Accumulation

    DataPlus Oceanic strongly recommends that you avoid exceeding oxygen expo- sure limits, and reminds you that nitrox diving requires special train- ing and understanding of the effects of oxygen toxicity. WARNING: In the event that you exceed the maximum per dive allowable O2 exposure (dose), it is recommended that you allow a surface interval of at least 2 hours before reentering the water.

  • Page 70: High Po2 Dive Mode

    (dose) decreases during your surface interval, the bar graph will gradually receed into the yellow caution (C.Z.) zone and green (normal) zone. Oceanic suggests always keeping the O2 Bar Graph in the green (safe) zone. WARNING: DO NOT allow the O2 Bar Graph to enter the red (Danger) zone.

  • Page 71: Unexpected Loss Of Displayed Information

    This is an important reason to avoid pushing the no decompression and oxygen tolerance limits, and a critical reason to avoid entering decompression. Regardless of your diving habits, Oceanic advises you to dive with additional backup instrumentation that can provide the DATA data necessary to properly surface if and when your primary instruments fail.
  • Page 72 Before diving with the DataPlus, be sure you thoroughly understand its functions and displays. Contact your local Authorized Oceanic Dealer if you have a question. Above all remember, technology is not a...

  • Page 73: Care & Maintenance

    CARE & MAINTENANCE...

  • Page 74: Care And Cleaning

    (actually transparent) scratches and attack by strong chemicals. If the face does become scratched, Oceanic can replace it, although small scratches will naturally disappear under- water. For even more convenience and additional protection against scratches, place a transparent Oceanic Instrument Lens Protector on the gauge face.
  • Page 75 BC. Keep it off the deck and protected from undue shock. Better yet, if you have a console version, attach an Oceanic DataLink™ quick disconnect on the high pressure hose that connects your pressure gauge to your regulator first stage.

  • Page 76: Annual Dealer Inspections & Factory Service

    ANNUAL DEALER INSPECTIONS & FACTORY SERVICE As with all Oceanic instrumentation, the DataPlus should be inspected annually by an Authorized Oceanic Dealer who will perform a factory prescribed function check and inspection for damage or wear. To keep the two year limited warranty in effect, this annual inspection must be completed one year after purchase ( 30 days).

  • Page 77: Obtaining Factory Service

    OCEANIC EUROPE Pomezia, Italy Tel: 39-6-910-4148; Fax: 39-6-910-4163 If your local Authorized Oceanic Dealer does not have the special tools or facili- ties to follow the procedures described above, have the dealer send your OCEANIC SW, LTD DataPlus directly to Oceanic, or an Oceanic regional distribution center for Devon, England service (Fig.

  • Page 78: Battery Life

    • If you have any questions regarding DataPlus service, call Oceanic’s Parts & Service Department at (510) 562-0500. • Allow two to four weeks for service, plus travel time to and from Oceanic, when estimating your down time. 50 Activation Periods...

  • Page 79: Low Battery Condition

    DATA PLUS Oceanic strongly advises that you replace all of the batteries and DO NOT attempt to dive with the DataPlus when the Battery icon remains on display, and that you replace the batteries with new prior to any...
  • Page 80 • Closely check the threads of the battery hatch and the housing for any signs of damage which might impair proper threading. If found, return your Fig. 74 - Battery Hatch DataPlus to your Authorized Oceanic Dealer, and DO NOT attempt to use until it has received factory service.

  • Page 81: Battery Installation

    (bending or breakage), and for any signs of corrosion indicat- Fig. 75 - Outer Case Ring ing entrance of moisture into the unit. If found, return your DataPlus to an Authorized Oceanic Dealer, and DO NOT attempt to use the unit until it Battery has received factory service.

  • Page 82: Flooded Battery Compartment

    Instead, stretch it slightly to work it down over the slotted end of the battery hatch and into the groove at the base of the threads. NOTE: This o-ring must be a genuine Oceanic Part that can be purchased from your Authorized Oceanic Dealer. Use of any other o-ring will void the warranty.

  • Page 83: Inspection

    Surface Mode, followed by FO2 and the PDPS. • If a Low Battery condition is indicated, return the unit to your Authorized Oceanic Dealer for a complete inspection before attempting to use it. • Observe the LCD display to ensure it is consistently clear and sharp in contrast throughout the screen.
  • Page 84 ® • Correct the alignment of the module as needed so that it is straight. • Press the module completely into place with your thumbs, watching the alignment, until it snaps into place. SUMMARY Care and maintenance is simple and easy, and with a small investment of your time you will help keep your DataPlus in top condition for many years of diving enjoyment.

  • Page 85: Reference

    REFERENCE...

  • Page 86: More About Flying After Diving

    ® MORE ABOUT FLYING AFTER DIVING In 1990 the Undersea and Hyperbaric Medical Society (UHMS) published a set of guidelines aimed at minimizing the possibility of decompression sickness due to flying too soon after diving. The UHMS suggests* divers using standard air cylinders and exhibiting no symptoms of decompression sickness wait 24 hours after their last dive to fly in aircraft with cabin pressures up to 8,000 feet.

  • Page 87: More About Altitude Diving

    WARNING: Diving at high altitude requires special knowledge of the variations imposed upon divers, their activities, and their Responsible equipment by the decrease in atmospheric pressures. Oceanic recommends completion of a specialized Altitude training course by a recognized training agency prior to diving in high altitude...
  • Page 88 ® Atmospheric pressure decreases as altitude increases above sea level. Weather systems and ambient temperature also affect barometric pressures. Conse- quently, depth reading instruments that do not compensate for the decrease in pressure indicate depth readings shallower than the depth they are actually at. The DataPlus automatically compensates for decreased ambient pressure when activated at high altitudes up to 14,000 feet (4,267 meters).

  • Page 89: More About Nitrox Diving

    Maximum upon divers, their activities, and their equipment by the increase Exposure Time in percentage of oxygen. Oceanic recommends completion of a specialized Nitrox training course by a recognized training Per Dive Per 24hr...

  • Page 90: Multiple Tissue Tracking

    ® recognized training agency to teach diving with nitrox. The DataPlus is not intended for use by military or commercial divers. WARNING: In the event that you exceed the maximum per dive allowable O2 exposure (dose), it is recommended that you allow a surface interval of at least 2 hours before reentering the water.
  • Page 91 DataPlus Display Seen by the Diver Display Seen by the Diver NO. OF TISSUE SEGMENTS HALF–TIME TISSUE NO. OF SEGMENTS HALF–TIME etc. Fig. 78 - Tissue Fig. 79 - Tissue Compartment Compartment Control Control Hand Over...

  • Page 92: No Decompression Limits

    ® basis of multilevel diving, one of the most important contributions DataPlus U.S. the DataPlus offers you. Take advantage of this feature and make Depth NDL-mins. Navy all of your dives multilevel dives. feet (meters) Eng (Metric) NDL -mins. 280 (283) - - - NO DECOMPRESSION LIMITS - - -...
  • Page 93 DataPlus Navy theory. Therefore, pay special attention to the following warnings: WARNING: Oceanic advocates responsible diving practices and does not recommend decompression diving, or diving below 130 feet (39 meters). The decompression capabilities of the DataPlus are intended strictly for emergency use. Decompression diving is...

  • Page 94: Responsible Computer Diving

    ® RESPONSIBLE COMPUTER DIVING Since the advent of dive computers, it is a common mistake to assume that the old traditional rules of diving no longer apply, but the truth is just the opposite. Before you dive using your DataPlus, keep these rules in mind: •...

  • Page 95: Specifications

    0 - 9 Altitude Algorithm: • Depth 0 - 330 ft. (99.5 m) 1 ft. (.5 m) • Based on National Oceanic & Atmospheric Administration (NOAA) • Maximum Depth 330 ft. (99.5 m) 1 ft. (.5 m) tables • FO2 Set Point 21 - 50 % •...
  • Page 96 ® SPECIFICATIONS (cont'd) GRAPHIC DIVER INTERFACE OPERATIONAL PERFORMANCE Tissue Loading Bar Graph (TLBG) Function: Accuracy: segments • Depth 1% of full scale No Decompression zone (green) • Timers 1 second per day Caution zone (yellow) Decompression zone (red) Dive Counter: •...
  • Page 97 DataPlus SPECIFICATIONS (cont'd) OPERATIONAL PERFORMANCE (cont'd) PARTS & ACCESSORIES Activation: • P/N 04.9006 Battery Kit (with 2 batteries, o-ring, & grease) • Manual activation is required (water immersion does not activate unit). • P/N 2.023 Battery hatch o-ring • Cannot be activated deeper than 4 feet (1.5 m) •...

  • Page 98: Glossary

    ® GLOSSARY The following are diving terms that you should become familiar with. Some apply specifically to the DataPlus. Air Dive - A dive conducted using air (approximately 21% oxygen & 79% nitrogen) as the breathing gas. Algorithm - A step-by-step mathematical formula designed to accomplish a particular result (i.e. Dive Time Remaining in the DataPlus).
  • Page 99 ™ Graphic Diver Interface - A feature of Oceanic dive computers. Easily understandable color coded bar graphs that indicate diver status; green = normal, yellow = caution, red = danger. Icon - A small pictorial representation of an operational mode.
  • Page 100 O2 Bar Graph - A visual representation of oxygen accumlation on a dive computer display. Oceanglo ® - An Oceanic name for an instrument backlight feature. OceanLink™ - An Oceanic name for a high pressure hose quick disconnect device. OTU - Abbreviation for oxygen tolerance unit. A Hamilton's Repex method term for oxygen dose.
  • Page 101 Square Wave Dive - A type of dive profile where the entire dive is spent at one depth between descent and ascent. Surface Sequence - An Oceanic term for the sequence of information displayed during surface operation. Tissue - See Compartment Tissue Compartment - See Compartment ™...

  • Page 102: Index

    ® INDEX External Access Mode 40, 87 Accuracy Data Base Factory Service Activation 4, 26,87 DataLink 65, 87 Flooded Battery Compartment Algorithm vi, 85 Decompression Dives 44, 83 Flying After Diving 13, 38, 76 Alternate Deco Mode 10, 33, 48 Decompression Mode 10, 33, 47 FO2 Display...
  • Page 103 Variable Ascent Rate Indicator 9, 24, 36, 86 O2 Bar Graph 8, 22, 59, 86 Safety Stop 17, 49, 66 Violation Modes 34, 50 O2 Limits 59, 85 Service Record Oceanglo 4, 41 Sharing Computers Oceanic Facilities Warranty v, 66 Specifications OceanLink...

  • Page 104: Dataplus Service Record

    AS A RESPONSIBLE DIVER I UNDERSTAND AND ASSUME Purchased from THE RISKS I MAY ENCOUNTER WHILE DIVING. To be filled in by Authorized Oceanic Dealer: RESPONSIBLE DIVING BEGINS WITH: Date Service Performed Dealer / Technician • DIVING WITHIN THE LIMITS OF MY ABILITY AND TRAINING •...
  • Page 105 DataPlus...
  • Page 106 © 2002 Design 1996 Doc. No. 12-1968,R3 (7/99)
