To access a specific dive's log, press the Advance (Left) button repeatedly.
To view the second screen (Nitrogen Log) for that dive (Fig. 48):
• press the Select (Right) button 1 time
• Log Mode icon
• Dive number
• Maximum Depth reached for the dive (and icon)
• Elapsed Dive Time (and icon)
• Surface Interval prior to that dive (and icon)
• Variable Ascent Rate Indicator - showing the maximum ascent rate
maintained for 4 consecutive seconds during the dive
• Tissue Loading Bar Graph - showing tissue nitrogen loading at the
end of the dive
To view the third screen (Oxygen Log) for that dive Fig. 49):
• press the Select (Right) button 1 time
• Log Mode icon
• FO2 value - set for that dive (and 'FO2' symbol)
• Maximum PO2 level - reached during that dive (and 'PO2' symbol)
• O2 bar graph - showing oxygen loading at the time you surfaced.
• If FO2 was set for 'Air', the O2 screen will only display 'FO2' and 'Air'.
• press the Select (Right) button 1 time to view the first screen of the previ-
ous dive's log, or press the Advance (Left) button repeatedly to revert to
the Surface Mode.
Data Plus 2
FT
Fig. 48 - Log Mode
(second screen - nitrogen)
O
2
Fig. 49 - Log Mode
(third screen - oxygen)
