ATCOM AT-323 IP Net Phone User Manual (V Released 1.25)
Upgrade Program: Click this button to update the program of IP phone.
Before updating, please fill IP address of FTP server into upgrade addr
field, and then click this button. Then the phone will read the
corresponding bin files from the server and then load into the phone.
Update Digitmap: Click this button to update the digitmap of the phone.
Before updating, please fill IP address of FTP server into upgrade addr
field, and then click this button. Then the phone will read the
corresponding map files from the server and then load into the phone.
Note Please refer to PalmTool User Guide to learn how to write digitmap or just
download TXT file from our site. Then please save it as "phone type.map" file,
such as ATCOM.map.

Configured by PalmTool

PalmTool is a tool designed especially to configure and upgrade the ATCOM
IP phone. You
Program/PalmTool.zip
please unzip the downloaded file and save them.
a) On a PC connecting with the phone or at the same segment of the phone,
double click
will popup.
b) Input the IP address of the phone into Local IP field (such as
192.168.1.100), and then click ¡ ° Phone Settings¡ ±
From Version1.24, use PalmTool to set the IP phone, please set debug as
output or output all firstly, or PalmTool cannot connect IP phone. The
parameters of PalmTool is same as the parameters in HTTP, so please refer
Shenzhen ATCOM Co., Ltd.
Fig 3.8 Phone Book Illustration
can visit http://www.comm.com/solutions/Download/
to download the latest version of PalmTool. Then
icon to open the PalmTool. The index page of PalmTool
button.
29
