AT-320 H323 Phone User Manual (V1.39)
Upgrade Program: Click this button to update the program of IP phone. Before
updating, please fill IP address of FTP server into upgrade addr field, and then click
this button. Then the phone will read the corresponding bin files from the server and
then load into the phone.
Update Digitmap: Click this button to update the digitmap of the phone. Before
updating, please fill IP address of FTP server into upgrade addr field, and then click
this button. Then the phone will read the corresponding map files from the server and
then load into the phone.
Note Please refer to PalmTool User Guide to learn how to write digitmap or just
download TXT file from our site. Then please save it as "phone type.map" file,
such as pa168S.map.

Configured by PalmTool

PalmTool is a tool designed especially to configure and upgrade the PA168 IP phone. On a PC
connecting with the phone or at the same segment of the phone, double click
PalmTool. The index page of PalmTool will popup.
a) Input the IP address of the phone into Local IP field (such as 192.168.1.100), and
then click "Phone Settings" button.
From Version1.24, use PalmTool to set the IP phone, please set debug as output or
output all firstly, or PalmTool cannot connect IP phone. The parameters of PalmTool is
same as the parameters in HTTP, so please refer to HTTP set chapter to learn how to
set IP phone.

Telnet Configuration

● On the PC choose Start>Run, and then type telnet 192.168.1.100 into Run
field in popuping Run dialog. Or input telnet 192.168.1.100 in the DOS
window. Then the following information will be displayed.
AT-320 V1.39 settings
Password :
Then please type password. With debug is set as 0[disable], if type ordinary password
(default one is 1234), after Retun, you will see
Fig 3.8 Phone Book Illustration
icon to open the
22
