ATCOM AT-323 IP Net Phone User Manual (V Released 1.25)
With H323 protocol used, please enter a number from 1024 through
65535 into this field.
With MGCP protocol used, please enter 2427 here.
With SIP protocol used, please enter 5060 here.
With Net2phone protocol used, this port could be any number.
● signal port: With H323 protocol used, signal port is Q.931 port using
TCP protocol. It is arranged from 1024-65535.
● control port: With H323 protocol used, this port is H.245 port using
TCP protocol. Please enter a number from 1024 through 65535.
● local type: With H323 protocol used, this parameter refers to how
IP phone log in gatekeeper. The meaning of each item is as follow:
phone number: Use phone number as E.164 and H323 ID to login the
GK.
account: Use phone number as E.164 and designated H323 ID filled
in account field as H323 ID to login GK.
mac: Use phone number as E.164 and MAC address of IP phone as H323
ID to login GK.
md5 account: With H323 protocol used, according to the log in
gatekeeper,
selecting/diselecting this item. With this item selected, please
fill the user name and password into account and pin fields
respectively.
cat account: Select this item to use cat£ ¨ Cisco Access Talk£ ©
authentication. With this item selected, please fill the user name
and password into account and pin fields respectively.
Shenzhen ATCOM Co., Ltd.
enable/disable H235 encryption by
