Figure 5: Sample Port Numbering

#
Port Number
1
IN 1, IN 2, IN 3, IN 4
2
IN 5, IN 6
3
IN 9, IN 10, IN 11, IN 12
Note: There is no IN 7, IN 8, OUT 11 or OUT 12 because these slots contain DVI
dual link cards.
VS-3232DN - Connecting the VS-3232DN
#
Port Number
4
OUT 1, OUT 2, OUT 3, OUT 4
5
OUT 5, OUT 6, OUT 7, OUT 8
6
OUT 9, OUT 10
13
