6

Connecting the VS-3232DN

The configuration of DVI input/output cards shown in
representation and different I/O cards may be mixed as required (for limitations,
see page 12
types.
i

Figure 4: Connecting the VS-3232DN 32x32 Digital Matrix Switcher

VS-3232DN - Connecting the VS-3232DN
). Exactly the same principles apply to installations using other card
Always switch off the power to all devices before connecting them to
your VS-3232DN. After connecting your VS-3232DN, connect its
power and then switch on the power to each device.
Figure 4 is a sample
11
