10.4.1
Testing the Projector Output
Signal path: c to d; d to projector
To test the projector output:
1. Configure Input 33 to Output 33 (see
2. Connect Output 33 to the projector.
3. Set the generated video resolution (see
4. Set the pattern for the generated video (see
5. Verify that the projector output is as expected.
10.4.2
Testing the Output Signal Path to the Projector
Signal path: a to b; b to projector
To test the output signal path to the projector:
1. Configure Input 33 to Output 1 (see
2. Connect Output 1 to the projector.
3. Set the generated video resolution (see
4. Set the pattern for the generated video (see
5. Verify that the projector output is as expected.
10.4.3
Testing the Input and Output Signal Path to the Projector
Signal path: c to e; e to f; f to b; b to projector
To test the input and output signal path to the projector:
1. Configure Input 33 to Output 33 (see
2. Connect Output 33 to Input 1.
3. Configure Input 1 to Output 1.
VS-3232DN - Installing and Using the Test Module to Troubleshoot Video Problems
Section 7.4
).
Section 10.2
).
Section 10.3
Section 7.4
).
Section 10.2
).
Section 10.3
Section 7.4
).
).
).
47
