Defining The Vs-3232Dn 32X32 Digital Matrix Switcher; Figure 1: Vs-3232Dn Front Panel Numeric Keypad - Kramer VS-3232DN User Manual

4 Defining the VS-3232DN 32x32 Digital Matrix
Switcher
Figure 1,

Figure 1: VS-3232DN Front Panel Numeric Keypad

# Feature
◄ (Backwards)
1
2 1, 2, 3, 4, 5, 6, 7, 8, 9, 0
► (Forward)
3
VS-3232DN - Defining the VS-3232DN 32x32 Digital Matrix Switcher
Figure 2 and Figure 3
Front Panel Numeric Keypad Labels
define the VS-3232DN.
Function
Press to shift the sliding window to the right (The
LCD display is large enough to show only 13
cross-points out of a total of 32)
Numeric keypad, 1 to 0
Press to shift the sliding window to the left
5
