When the unit is powered-on, the last matrix setup that was used is loaded. Use
either the recall setup (see
Section
7.4.5
Records a stored configuration from a preset. For quick retrieval, you can program a default
setup that is commonly used.
7.1.1
Viewing the Display
Figure 9
show 13 out of the 32 available matrix combinations at once. To view any of the
matrix combinations use the ◄ or the ► buttons on the front panel to shift the
sliding window to the right or left.
This sliding window functionality is enabled when:
The switcher is in between operations
Waiting for its next operation while all previous operations are complete or cancelled.
Recalling a setup using the ◄ or ► buttons
i
7.2

Using the Selector Buttons

For numbers between 1 and 9, the VS-3232DN can handle two digit numbers as
well as single digit numbers. When entering a single digit number (for example 5),
you can either press 0 followed by 5, or 5 followed by ENT.
Pressing 00 (or 0, ENT) is only relevant for an input selection and is used to
disconnect the currently entered output number from the input.
For example, the following display indicates that inputs 8 and 12 are disconnected
from any output (note that in the second line representing these inputs the display
is blank):
06 07 08 09 10 11 12 13
12 08
VS-3232DN - Operating Your Video Matrix Switcher
Section
) functions to retrieve other setups.
shows the output-input matrix on the LCD display. The LCD display can
When entering an output/input combination, the contents of the LCD
display automatically shift to indicate the current status of the
selected output.
10 14 13 06
8.1.6) or default setup recall (see
19
