GEQ rack

Each scope screen has up to five eight-slot racks in the Graphic EQs section, which can
contain a maximum of 36 GEQs (as shown below). The number of racks and GEQs are
configuration dependent.
Graphic EQs represented on the Recall Scope screen. Racks are always shown fully
populated, regardless of how many GEQs are configured. This example is taken from a
PRO9.
Note: A rack slot in the Graphic EQs section in equivalent to a the All

Patching

The following diagram details the scoped patching parameters of the GEQs, which are
shown on the Graphic GEQs screen (below).
1
Item Parameter
1 Bus assignment/type
Appendix K: Parameters Affected By Scope
A B C
N/A No N/A
D E F
N/A N/A N/A
