Page 1 1050/1050e Operator Manual • Copier • POD Administrator • Security...
Page 3: Table Of Contents
Table of Contents Safety Information Safety Information ................1-3 1.1.1 Warning and Precaution Symbols ..........1-3 1.1.2 Meaning of Symbols ..............1-3 Regulation Notices ................. 1-10 1.2.1 Laser Safety ................. 1-10 1.2.2 Ozone Release ................1-12 1.2.3 Electromagnetic Interference ............1-12 1.2.4 For European Users ..............
Page 4 To Use Machine When Power Save LED Lights ......2-26 2.3.1 Auto Low Power ................2-27 2.3.2 Auto Shut-Off ................2-27 2.3.3 Using Power Save Manually ............2-28 2.3.4 When Weekly Timer Is Activated ..........2-30 Making User Authentication ............2-33 Paper and Original Information Paper Information ................3-3 3.1.1 Paper Weight ..................3-3 3.1.2...
Page 5 Before Making Copies Copy Screen ..................5-3 5.1.1 Machine Status Screen ..............5-5 Features of the bizhub PRO 1050/1050e ........5-7 How to Make a Basic Copy ............5-12 Positioning Originals ..............5-16 5.4.1 Positioning Originals in ADF ............5-16 5.4.2 Positioning Original on Original Glass ..........
Page 6 Making Double-Sided Copies Using Original Glass .....6-40 6.8.1 Making Single-Sided Copies from Double-Sided Originals ..6-44 Paper Tray Setting ................6-46 6.9.1 To Select Paper Size Automatically (APS) ........6-47 6.9.2 To Specify Desired Paper Size (AMS) ...........6-49 6.9.3 Rotation ..................6-51 6.9.4 Using Paper Not Specified for Any Tray (Paper Presetting) ..6-53 6.10 Reserve Job Setting ................6-64 Job Management...
Page 7 8.14 Repeat Automatically or Select Repeat Times (Repeat: Auto Detect/ Repeat Mode) ..........8-50 8.15 Eliminating Black Copy Marks Along Borders (Frame/Fold Erase) ................. 8-54 8.16 Copying Image in the Centre of Copy Paper (Image Centering) ................8-58 8.17 Printing Images Fully to the Edges (All-Image Area) ....8-60 8.18 Adjusting Position of Copy Image (Image Shift) ......
Page 8 9.11 Using Two Copiers in Tandem ............9-67 9.11.1 To Stop Scanning/Printing ............9-73 9.11.2 Troubleshooting ................9-74 10 Advanced Information 10.1 Checking Feature Selections by Proof Copying ......10-3 10.2 Checking Feature Selections Before Copying (Check Mode) ..10-5 10.3 Interrupt Copying ................10-9 10.4 Storing and Recalling Job Conditions (Mode Memory) .....10-11 10.4.1 Storing Job Conditions ...............10-11...
Page 9 13.7 02 Multi Folder (Punch) Adjustment ..........13-31 13.8 03 Multi Folder (Fold) Adjustment ..........13-36 13.9 04 Stacker Adjustment ..............13-53 13.10 05 Saddle Stitcher Adjustment ............ 13-57 13.11 06 Perfect Binder Adjustment ............. 13-76 13.12 07 Trimmer Count Adjustment ..........13-105 14 Controller Setting 14.1 Function Overview ................
Page 10 16.2.7 04 Image Density Selection ............16-31 16.2.8 04 Preset Zoom ................16-33 16.2.9 05 Tandem Setting ..............16-34 16.2.10 06 User Paper Selection .............16-38 16.3 03 Copy Setting ................16-39 16.3.1 01 Reset Setting .................16-39 16.3.2 02 Each Function Setting ............16-46 16.4 04 Scanner Setting ................16-49 16.4.1 01 Default Address Setting ............16-49 16.4.2...
Page 11 17.6 05 Copy/Printer Setting .............. 17-128 17.6.1 01 JOB Offset Operating ............17-128 17.6.2 02 Continuation Print(Print) ............17-129 17.6.3 03 Page No. Position (Booklet) ..........17-130 17.6.4 04 Fixing Prerotation Set ............17-131 17.6.5 05 Image Auto Rotation ............17-133 17.6.6 06 Interruption Suspend ............
Page 12 18.10 Administrator Mode – System Tab ..........18-44 18.10.1 Administrator Password .............18-44 18.10.2 Device Information ..............18-45 18.10.3 ROM Version ................18-46 18.10.4 Online Assistance ...............18-46 18.10.5 Import/Export ................18-48 18.10.6 Maintenance ................18-49 18.10.7 E-Mail Alert .................18-51 18.11 Administrator Mode – Print Tab ...........18-52 18.11.1 Interface ..................18-52 18.11.2...
Page 13 19.2 Security Strengthen Mode ............. 19-6 19.2.1 Description of Security Strengthen mode ........19-6 19.2.2 Data protected by Security Strengthen mode ......19-7 19.2.3 Data that is not protected in Security Strengthen mode ..... 19-7 19.3 Protect and Delete Data After Use ..........19-8 19.4 User Authentication in Security Strengthen Mode ......
Page 14 21 Maintenance 21.1 Cleaning Image Scanning Section ..........21-3 21.1.1 Cleaning the ADF Scanning Glass ..........21-3 21.1.2 Cleaning the Original Glass ............21-3 21.1.3 Cleaning the ADF Guide Cover .............21-4 21.2 Precautions for Paste Pellets and the Perfect Binder ....21-5 21.3 Checking Copy Count ..............21-6 21.4 Preventive Maintenance ..............21-9 22 Machine Specifications...
Page 15: Bizhub Pro 1050/1050E
® NERGY Program The ENERGY STAR Program has been established to encourage the wide- spread and voluntary use of energy-efficient technologies that reduce energy consumption and prevent pollution. As an ENERGY STAR Partner, we have determined that this product meets the ENERGY STAR guidelines for energy efficiency, based on the following features.
Page 16: Safety Information
Acknowledgements - KONICA MINOLTA, KONICA MINOLTA Logo and The essentials of imag- ing are registered trademarks or trademarks of KONICA MINOLTA HOLDINGS, INC. - PageScope and bizhub PRO are registered trademarks of KONICA MI- NOLTA BUSINESS TECHNOLOGIES, Inc. Copyright © 2006 KONICA MINOLTA BUSINESS TECHNOLOGIES, Inc.
Page 17: Safety Information
Safety Information...
Page 19: Bizhub Pro 1050/1050E
Safety Information Safety Information Safety Information This section contains detailed instructions on the operation and maintenance of this machine. To achieve optimum utility of this device, all operators should carefully read and follow the instructions in this manual. Please read the following section before connecting the machine to the sup- ply.
Page 20 Safety Information Disassemble and modification WARNING • Do not attempt to remove the covers and panels which have been fixed to the product. Some products have a high-voltage part or a laser beam source inside that could cause an electrical shock or blindness.
Page 21: Bizhub Pro 1050/1050E
Safety Information Power source CAUTION • The outlet must be near the equipment and easily accessible. Oth- erwise you can not pull out the power plug when an emergency oc- curs. Power plug WARNING • Do not unplug and plug in the power cord with a wet hand, as an electrical shock could result.
Page 22 Safety Information Installation WARNING • Do not place a flower vase or other con- tainer that contains water, or metal clips or other small metallic objects on this product. Spilled water or metallic objects dropped inside the product could result in a fire, electrical shock, or breakdown.
Page 23: Bizhub Pro 1050/1050E
Safety Information Actions in response to troubles WARNING • Do not keep using this product, if this product becomes inordinately hot or emits smoke, or unusual odor or noise. Immediately turn OFF the power switch, unplug the power cord from the power outlet, and then call your authorized service representative.
Page 24 Safety Information Before successive holidays CAUTION • Unplug the product when you will not use the product for long pe- riods of time. Paste pellet CAUTION • Do not put paste pellets close to fire. Paste pellets are flammable and easy to catch on fire. •...
Page 25: Safety Information 1
Safety Information Perfect Binder CAUTION • Do not use the Perfect Binder without ventilation for an extended period of time. Ensure to ventilate the room on a regular basis. It is recommended that the Perfect Binder should be installed in a place with a local exhaust system.
Page 26: Regulation Notices
Safety Information Regulation Notices 1.2.1 Laser Safety This product employs a Class 3B laser diode having maximum power of 15 mW and wavelength of 770 - 800 nm. This product is certified as a Class 1 laser product. Since the laser beam is concealed by protective housings, the product does not emit hazardous la- ser radiation as long as the product is operated according to the instructions in this manual.
Page 27 Safety Information For Finland, Sweden Users LUOKAN 1 LASERLAITE KLASS 1 LASER APPARAT 6 VAROITUS! Laitteen käyttäminen muulla kuin tässä käyttöohjeessa mainitulla tav- alla saattaa altistaa käyttäjän turvallisuusluokan 1 ylittävälle näkymät- tömälle lasersäteilylle. Tämä on puolijohdelaser. Laserdiodin suurin teho on 15 mW ja aallon- pituus on 770 - 800 nm.
Page 28: Ozone Release
Safety Information 1.2.2 Ozone Release During print operation, a small quantity of ozone is released. This amount is not large enough to harm anyone adversely. However, be sure the room where the machine is being used has adequate ventilation, especially if you are printing a high volume of materials, or if the machine is being used con- tinuously over a long period.
Page 29: Caution Labels And Indicators
Safety Information Caution Labels and Indicators The caution labels and indicators are attached to the machine areas, as shown below, where you are advised to pay special attention to avoid any dangerous situations or serious injury. (Entrance of the reversal output unit) CAUTION (Right side of the fixing unit) DO NOT INSERT your finger...
Page 30 Safety Information CAUTION The paste tank unit is very hot. To avoid getting burned DO NOT TOUCH. 1-14 bizhub PRO 1050/1050e...
Page 31: Installation Space
Safety Information Installation Space Allow sufficient space for facilitating copy operation, replenishing consuma- bles, changing parts, and periodic inspection. The whole machine may weigh approx. 1,065 kg at maximum, depending on the combination of options. Be sure to choose a level and solid floor for the installation place. Unit: mm Unit: mm Main body + DF-603 + PF-701 + FS-503...
Page 32 Safety Information Unit: mm Unit: mm Main body + DF-603 + PF-701 + LS-501 + LS-502 Main body + DF-603 + PF-701 + FD-501 + FS-503 Main body + DF-603 + PF-701 + LS-502 (×2) + FS-503 1-16 bizhub PRO 1050/1050e...
Page 33 Safety Information Unit: mm Main body + DF-603 + PF-701 + FD-501 + SD-501 + FS-503 Main body + DF-603 + PF-701 + FD-501 + SD-501 Main body + DF-603 + PF-701 + SD-501 bizhub PRO 1050/1050e 1-17...
Page 34 Safety Information Unit: mm Main body + DF-603 + PF-701 + SD-501 (Side view) Main body + DF-603 + PF-701 + FD-501 + SD-501 + PB-501 Main body + DF-603 + PF-701 + SD-501 + PB-501 1-18 bizhub PRO 1050/1050e...
Page 35 Safety Information Unit: mm Main body + DF-603 + PF-701 + FD-501 + SD-501 + PB-501 Main body + DF-603 + PF-701 + LS-501 + PB-501 Main body + DF-603 + PF-701 + PB-501 bizhub PRO 1050/1050e 1-19...
Page 36 Safety Information For EU member states only This symbol means: Do not dispose of this product together with your household waste! Please refer to the information of your local community or contact our dealers regrad- ing the proper handling of end-of-life elec- tric and electronic equipments.
Page 37: Preparation For Use
Preparation for Use Copier...
Page 39: Machine Configuration
Preparation for Use Preparation for Use Machine Configuration 2.1.1 External Machine Items Part name Description ADF (Automatic Docu- automatically feeds multiple originals one at a time to the ment Feeder) original glass for copying. Touch Panel displays interactive operation screens. Sub power switch turns machine power ON/OFF when pressed.
Page 40 Preparation for Use Part name Description Tray left side door opens to allow removal of mishandled paper. Tray 1 (universal tray) is user-adjustable and holds 1,500 sheets from A3 to A5. Tray 2 (universal tray) is user-adjustable and holds 1,500 sheets from A3 to A5.
Page 41: Internal Machine Items
Preparation for Use 2.1.2 Internal Machine Items Part name Description Total counter indicates the total number of copies and prints made. Conveyance fixing unit passes the paper through the drum unit, and fuses the toner onto the copy paper, and is to be withdrawn for re- moval of mishandled paper.
Page 42: Control Panel Layout
Preparation for Use 2.1.3 Control Panel Layout 13 12 11 10 Part name Description Sub power switch turns machine power on/off when pressed. Keypad enters numeric values. Reset restores copier to the initial settings. Interrupt stops copying/printing/scanning in progress to allow a simple copying job.
Page 43 Preparation for Use Part name Description Mode Check displays a screen showing all settings that are selected for the current job. Utility/Counter displays the Utility Menu Screen / Counter Screen or ac- cesses programming modes for setting special functions. Mode Memory displays screens for selecting job store/job recall func- tions.
Page 44: Folding Unit Fd-501
Preparation for Use 2.1.4 Folding Unit FD-501 FD-501 FD-503 Part name Description Lower cover feed tray holds cover sheets. Lower cover feed tray hold cover sheets to fix the position. guide plates Upper cover feed tray holds cover sheets. Upper cover feed tray hold cover sheets to fix the position.
Page 45 Preparation for Use Part name Description Inlet lever opens leftward to remove mishandled paper. Post inserter convey- (behind the inlet lever) opens leftward to remove mishan- ance lever dled paper. Trash basket holds waste paper punched out. Upper/Lower convey- opens rightward to remove mishandled paper. ance lever Folding unit handle withdraws the unit to allow removal of mishandled paper.
Page 46 Preparation for Use Part name Description Upper/Middle/Lower can be turned clockwise to ease removal of mishandled knob paper. Left side lever (right/ opens leftward to remove mishandled paper. left) Upper lever opens upward to remove mishandled paper. Conveyance knob/2 can be turned clockwise to ease removal of mishandled cover paper.
Page 47 Preparation for Use 2.1.5 Large Capacity Stacker LS-501/LS-502 Part name Description Secondary (Sub) tray holds sets output in Non-sort mode. Top cover handle (left) opens to remove mishandled paper. Top cover handle opens to remove mishandled paper. (right) Paper removal indica- lights while the stacker goes down in order to allow takeout of printed sheets.
Page 48 Preparation for Use Part name Description Paper removal button is pressed to take out printed sheets from the stacker. Large capacity stacker opens to take out printed sheets from the stacker. door Outlet cover lever opens to remove mishandled paper. Secondary (Sub) tray opens to remove mishandled paper.
Page 49: Saddle Stitcher Sd-501
Preparation for Use 2.1.6 Saddle Stitcher SD-501 bizhub PRO 1050/1050e 2-13...
Page 50: Internal View
Preparation for Use Internal View Part name Description Secondary (Sub) tray holds non-sorted sets output from Saddle Stitcher. of Saddle Stitcher SD-501 Multi-folding mode opens the cover to remove mishandled paper when using outlet cover handle multi-folding mode. Multi-folding mode holds sets output in multi-folding mode.
Page 51: External View
Preparation for Use External View Part name Description Upper cover lever of opens the upper cover to remove paper misfed inside the Folding unit Folding unit. Secondary (Sub) tray opens downward to remove mishandled paper. conveyance lever (middle) Folding unit drawer opens the drawer to remove paper misfed inside the handle Folding unit.
Page 52: Perfect Binder Pb-501
Preparation for Use 2.1.7 Perfect Binder PB-501 2-16 bizhub PRO 1050/1050e...
Page 53 Preparation for Use Internal View Part name Description Glue hopper cover opens for supply of glue pellet. Secondary (Sub) tray holds sets output without being processed by the perfect binder. Front door of Perfect opens for manual binding operation or to remove mishan- Binder PB-501 dled paper and waste trimmings.
Page 54 Preparation for Use External View Part name Description Body set releasing can be turned clockwise to take out the body set fixed in knob in clamp unit the clamp unit. Clamp unit convey- can be turned clockwise to feed the body set for removal ance knob of mishandled paper.
Page 55: Finisher Fs
Preparation for Use 2.1.8 Finisher FS-503 Part name Description Finisher door opens to the internal Finisher to allow clearing mishan- dled paper and replenishing staples. Primary (Main) tray holds sets output in Non-sort mode, Collated mode (off- set), or Staple mode. Secondary (Sub) tray holds sets output in Non-sort mode.
Page 56: Standard/Optional Equipment
Preparation for Use 2.1.9 Standard/Optional Equipment Finisher FS-503 Finisher FS-503 + Folding Unit FD-501 Saddle Stitcher SD-501 + Folding Unit FD-501 Main Body + Paper Feeder Unit PF-701 + Reverse Automatic Document Feeder DF-603 Finisher FS-503 + Saddle Stitcher SD-501 + Folding Unit FD-501 Large Capacity Stacker LS-502 + Folding Unit FD-501...
Page 57 Preparation for Use Perfect Binder PB-501 + Folding Unit FD-501 Perfect Binder PB-501 + Saddle Stitcher SD-501 + Folding Unit FD-501 Saddle Stitcher SD-501 Main Body + Paper Feeder Unit PF-701 + Reverse Automatic Document Feeder DF-603 Finisher FS-503 + Saddle Stitcher SD-501 Perfect Binder PB-501 + Saddle Stitcher SD-501 Perfect Binder PB-501...
Page 58 Preparation for Use Large Capacity Stacker LS-502 Finisher FS-503 Large Capacity Stacker LS-501 Saddle Stitcher SD-501 + Large Capacity Stacker LS-501 Main Body + Paper Feeder Unit PF-701 + Reverse Automatic Document Feeder DF-603 Perfect Binder PB-501 + Large Capacity Stacker LS-501 Large Capacity Stacker LS-502 + Large Capacity Stacker LS-501 Finisher FS-503...
Page 59: Turning On/Off The Power Switch
Preparation for Use Turning On/Off the Power Switch The machine has two power switches, namely, main power switch and sub power switch. 2.2.1 To Turn On the Power Turn ON the main power switch. The main power switch is located inside the machine.
Page 60 Preparation for Use A few seconds after the Wake-up Screen appears in the touch panel, the Machine Status Screen with four types of warm-up image will be displayed in succession for approx. 6.0 minutes. Details You can set reserve jobs while the machine is warming up. Touch the LCD screen to change the Machine Status Screen with warm- up image to the screen with the job list, then check that the message “Ready to copy reserve”...
Page 61: To Turn Off The Power
Preparation for Use 2.2.2 To Turn Off the Power Turn OFF the sub power switch. The sub power switch is located on the right side of the control panel. The touch panel and all the LEDs on the control panel other than the Power LED will go out, and the Power LED will turn red from green.
Page 62: To Use Machine When Power Save Led Lights
Preparation for Use To Use Machine When Power Save LED Lights If you find the Power Save LED lit on the control panel, the machine cannot be operated due to the Power Save or Weekly Timer function. Press [Power Save] on the control panel. If Power Save has been activated, the machine will become available for copying operation.
Page 63: Auto Low Power
Preparation for Use 2.3.1 Auto Low Power This function conserves energy by lowering the power consumption to 413W or less in standby mode. Auto Low Power activates automatically after a specified period (initially 15 minutes) of copier inactivity with the Power Save LED lit, touch panel gone off, and all other LEDs except Start LED on the control panel turned off.
Page 64: Using Power Save Manually
Preparation for Use 2.3.3 Using Power Save Manually Follow the procedure below to operate Power Save function (Low Power or Shut-Off) manually. Note The machine is initially set to activate the Shut-Off function manually. For details, refer to “Lists of the function settings” on page 15-5. Press [Power Save] for one second or longer, then release it.
Page 65 Preparation for Use Details Be sure to press [Power Save] for one second or longer, otherwise the following message will be displayed and the Shut-Off (Low Power) mode will not be activated. Press POWER SAVER more than one second, then release it for shut off mode Press POWER SAVER continuously more than one second for low power mode Power Save will be activated.
Page 66: When Weekly Timer Is Activated
Preparation for Use 2.3.4 When Weekly Timer Is Activated The Weekly Timer function turns a copier on and off at the time specified by the machine manager. Note For details, refer to “Lists of the function settings” on page 15-5. When a machine is in OFF condition under control of Weekly Timer, the [Power Save] LED is lit and machine operation is unavailable.
Page 67 Preparation for Use Enter the Timer Interrupt password, then press [Start]. Enter a 4-digit Timer Interrupt password using the control panel keypad. Timer interrupt mode Please input password #### Press [Start]. Note The Timer Interrupt password is to be specified in the machine manager setting.
Page 68 Preparation for Use When the machine operation is finished, press [Power Save] for one second or longer, then release it. The machine returns to OFF condition. 2-32 bizhub PRO 1050/1050e...
Page 69: Making User Authentication
Preparation for Use Making User Authentication This machine can prohibit its operation until the user name, user password, section name, and/or section password specified by the machine manager are verified. Copy quantity limit for each section can also be set. When the machine is turned on, one of the following User Authentication screen will be displayed according to the authentication setting.
Page 70 Preparation for Use Copying will be available by the following procedure. Enter the user name, user password, section name, and/or section password, as required. Touch the desired item key to display the keypad screen. Enter your user name (max. 64 characters), user password (max. 64 characters), section name (max.
Page 71: Paper And Original Information
Paper and Original Information Copier...
Page 73: Paper Information
Paper and Original Information Paper and Original Information Paper Information This machine is equipped with the following trays for loading copy paper. - Tray 1 and 2 (Main body trays) - Tray 3, 4, and 5 (Paper Feeder Unit PF-701) Also, the following equipment is provided for conveying/delivering copies.
Page 74 Paper and Original Information Equipment Weight 60 ~ 244 g/m Finisher • Primary (main) tray: 40 ~ 244 g/m Secondary (sub) tray: 40 ~ 300 g/m Folding unit • Punch: 50 ~ 209 g/m Folding, Letter fold-in, Letter fold-out, Z-fold: 50 ~ 130 g/m Double parallel, Gate: 50 ~ 91 g/m...
Page 75: Tray/ Exit Tray Capacity
Paper and Original Information 3.1.2 Tray/ Exit Tray Capacity Paper Trays Capacity Tray 1 and 2 (Main body trays) 1,500 sheets (80 g/m paper) Tray 3, 4 and 5 (PF-701 trays) 2,000 sheets (80 g/m paper) Equipment Capacity Unlimited Finisher Secondary (sub) Max.
Page 76 Paper and Original Information Equipment Capacity 2 : 50 or 49 sheets +1 (200 g/m 2 Cover) Saddle stitcher Fold & Staple • 50 ~ 81 g/m 2 : 30 or 29 sheets +1 (200 g/m 2 Cover) (fine paper) •...
Page 77 Paper and Original Information The Full load detection function on Perfect binder counts one column to be full when the following amount is reached in order to prevent the piled sets from collapsing. 10 ~ 30-sheet-bound set: 50 sets 31 ~ 150-sheet-bound set: 35 sets or until detected as full load 151 ~ 300-sheet-bound set: until detected as full load Details The following table shows the standard height of folded and stapled...
Page 78: Paper Size
Paper and Original Information 3.1.3 Paper Size Paper Trays Available Sizes Tray 1 to 5 • STD size: A3, B4, F4, A4, A4R, B5, B5R, A5, 12"x18", 11"x17", 8.5"x14", 8.5"x11" Available to detect 5.5”x8.5” instead of A5, 8.5"x11"R instead of A4R, 8K instead of B4, 16K instead of B5, 16KR instead of B5R •...
Page 79: To Store Copy Paper
Paper and Original Information Equipment Available Sizes Saddle stitcher Saddle stitcher A3, B4, A4R, B5R, F4*, 12"x18", 11"x17", 8.5"x14", tray 8.5"x11"R, 8K, 16KR, Wide size paper Max. 12.76" x 18.11" (324 mm x 460 mm) F4 indicates the following four sizes: 8"x13", 8.125"x13.26", 8.5"x13", 8.25"x13"...
Page 80: Original Information
Paper and Original Information Original Information Use the original glass or document feeder to position originals to copy. 3.2.1 Using Original Glass Use the original glass when originals are not suitable for use with the docu- ment feeder, e.g., when size is incompatible, or when originals are folded, stapled, torn, or in generally poor condition.
Page 81 Paper and Original Information 7 CAUTION Do not place too heavy originals, or do not press strongly when thick original is placed and is under pressure of ADF; otherwise the glass may be broken and you may be injured. bizhub PRO 1050/1050e 3-11...
Page 82: Adf Originals
Paper and Original Information 3.2.2 ADF Originals Following four modes are provided when using the document feeder (ADF) to scan originals. - Normal mode - Mixed Original mode - Z-Folded Original mode - SDF mode Specifications for each mode are described as follows. Note Detectable paper size can be changed from only A series to Inch series, AB series, or AB series and Inch series mixed by the machine manager.
Page 83 Paper and Original Information Details See below for the guide width of each combination. Guide Guide Guide width width width Z-Folded Original mode Use Z-Folded Original mode to scan folded originals without using the size detection sensor of the ADF. For details, refer to “Copying Z-Folded Origi- nals (Z-Folded)”...
Page 84 Paper and Original Information 3-14 bizhub PRO 1050/1050e...
Page 85: Supplies & Handling
Supplies & Handling Copier...
Page 87: Loading Paper
Supplies & Handling Supplies & Handling Loading Paper A paper indicator is shown on each tray key of the Machine Status Screen and of the Copy Screen to indicate the paper level of the tray. Six levels are provided. When paper in a tray becomes empty, the indicator blinks on the tray key.
Page 88: Loading Paper In Main Body Trays And Paper Feeder Unit Trays
Supplies & Handling 4.1.1 Loading Paper in Main Body Trays and Paper Feeder Unit Trays Withdraw the tray to be supplied with paper. Details Be sure that the machine is powered ON before withdrawing the tray. Only one tray can be withdrawn at a time. Reminder Do not withdraw the tray forcibly;...
Page 89 Supplies & Handling Place paper on the tray with any curl turning up, then move the side guide plates and rear edge guide to the edge of the paper. Paper holding lever Tray 1 and 2 Limit lever Paper holding lever Tray 3, 4, and 5 Limit lever Load paper aligning it to the paper feed roller side of the tray.
Page 90 Supplies & Handling When paper is seated properly, close the paper feed roller. bizhub PRO 1050/1050e...
Page 91 Supplies & Handling Push in the tray until it locks into place. The indicator on the Machine Status Screen or Copy Screen will change. Reminder Do not bump the tray into the main body; otherwise machine trouble may be caused. bizhub PRO 1050/1050e...
Page 92: Loading Cover Paper In Cover Feeding Tray Of Perfect Binder Pb-501
Supplies & Handling 4.1.2 Loading Cover Paper in Cover Feeding Tray of Perfect Binder PB-501 Withdraw the cover feeding tray. Open the paper feed roller. Load cover paper in the tray. Place cover paper faceup, with the top to be rear in the tray. When making the book bound on the right side, the front side in the tray will be the top.
Page 93 Supplies & Handling Reminder Do not load above the limit level, and carefully load the paper to be seat- ed under the paper holding lever at the air nozzle. Align the side guide plates and rear edge guide to cover paper. Press the release knob of the front side guide plate to move the side guide plates, and also move the rear edge guide to the edge of cov- er paper.
Page 94 Supplies & Handling Push in the tray until it locks into place. The indicator on the Machine Status Screen or Copy Screen will change. Do not bump the tray into the perfect binder; otherwise machine trou- ble may be caused. 4-10 bizhub PRO 1050/1050e...
Page 95: Loading Tabbed Sheets In Tray
Supplies & Handling 4.1.3 Loading Tabbed Sheets in Tray Tabbed sheets can be used if the tray paper size is specified as tabbed sheets in the Tray Setting or Paper Presetting. Follow the procedure below to supply the tray with tabbed sheets. Example: 9 Tabbed sheets loaded in position for 3 finished sets.
Page 96 Supplies & Handling Details The machine can be set to discharge the oddments of a set of tabbed sheets automatically if the tabbed original count is less than the number of tabbed sheets in a set. See the next page for detail. Move the side guide plates to the edge of the paper.
Page 97 Supplies & Handling Details Needless Tab Paper Exit This function sets the machine to discharge the oddments of a set of tabbed sheets automatically if the tabbed original count is less than the number of tabbed sheets in a set, so that the next copy job can be started afresh with the 1st tabbed sheet.
Page 98: Adding Toner
Supplies & Handling Adding Toner This machine is equipped with a toner storage for keeping a bottle stock of toner. When toner supply from the toner bottle becomes low, the message “Toner Bottle can be exchanged” will be displayed on the touch panel. When toner supply runs out from both toner bottle and toner storage, the message “Toner will be used up / Exchange Toner Bottle”...
Page 99 Supplies & Handling Add toner according to the procedure as follows. Open the toner unit door. Pull the toner unit lever forward to withdraw the bottle holder until it stops. Remove the empty toner bottle. Shake the new toner bottle several times to loosen toner.
Page 100 Supplies & Handling Remove the cap from the new toner bottle, then put it to the used one. Used Set the new toner bottle into the bottle holder. Details Be sure to set the label of the toner bottle upward, then fit its bottom to the hollow part of the bottle holder;...
Page 101: Inserting A New Staple Cartridge Into Finisher Fs-503
Supplies & Handling Inserting a New Staple Cartridge into Finisher FS-503 When the staple cartridge of the Finisher is empty, the Cartridge indicator lights in red in the option status area of the Machine Status Screen. Follow the procedure below to set the staple roll into the staple cartridge. Open the Finisher door.
Page 102 Supplies & Handling Remove the staple cartridge. Pull down the handle of the staple cartridge to draw it downward. Set the staple roll into the staple cartridge. Open the staple cartridge cover, then set the staple roll into the cartridge. Close the cover, then remove the lock tape pulling it in horizontal direction.
Page 103 Supplies & Handling Return the stapler unit to its original position. Close the Finisher door. bizhub PRO 1050/1050e 4-19...
Page 104: Inserting A New Staple Cartridge Into Saddle Stitcher Sd-501
Supplies & Handling Inserting a New Staple Cartridge into Saddle Stitcher SD-501 When the staple cartridge of the Saddle Stitcher SD-501 is empty, the Car- tridge indicator lights in red in the option status area of the Machine Status Screen. If printing job is in progress, a message will be displayed on the Copy Screen.
Page 105 Supplies & Handling Details The machine is mounted with two staple cartridges. Be sure to remove the empty one. Set the new cartridge. Reminder Check that the top side of the staple cartridge is up, otherwise it cannot be inserted. Close the left side door of the Saddle Stitcher.
Page 106: Adding Paste Pellets To Perfect Binder Pb-501
Supplies & Handling Adding Paste Pellets to Perfect Binder PB-501 If the Perfect Binder PB-501 is out of paste pellets, the machine warmup cannot be completed with the following message displayed on the Machine Status Screen, and consequently the binding operation is unavailable. When the paste pellets run out during the binding operation, the machine stops the job immediately and the binding operation also becomes unavail- able.
Page 107 Supplies & Handling Loosen the paste pellets inside the bag. Open the paste hopper cover. Supply the paste hopper with paste pellet. Reminder Do not add the paste pellet above the limit level indicated inside the paste hopper. bizhub PRO 1050/1050e 4-23...
Page 108 Supplies & Handling Close the paste hopper cover. 4-24 bizhub PRO 1050/1050e...
Page 109: Empty Trash Basket Of Folding Unit Fd-501
Supplies & Handling Empty Trash Basket of Folding Unit FD-501 When the trash basket becomes full, the Punch Dust indicator lights in red in the option status area of the Machine Status Screen. Follow the procedure below to empty the trash basket. Open the Finisher door.
Page 110 Supplies & Handling Empty the trash basket. Return the trash basket to its original position. Close the Finisher door securely. 4-26 bizhub PRO 1050/1050e...
Page 111: Empty Dust Box Of Saddle Stitcher Sd-501
Supplies & Handling Empty Dust Box of Saddle Stitcher SD-501 When the dust box of the Saddle Stitcher SD-501 becomes full, the Trim Dust indicator lights in red in the option status area of the Machine Status Screen. If printing job is in progress, a message will be displayed on the Copy Screen. Follow the procedure below to empty the dust box.
Page 112 Supplies & Handling Open the top cover of the dust box. Take waste paper out of the dust box. Close the top cover of the dust box, then return it to its original position. Reminder Be sure to return the dust box to its original position, otherwise the trim- ming function cannot be performed.
Page 113: Empty Dust Box Of Perfect Binder Pb-501
Supplies & Handling Empty Dust Box of Perfect Binder PB-501 When the dust box of the Perfect Binder PB-501 becomes full, the Trim Dust indicator lights in red in the option status area of the Machine Status Screen. If printing job is in progress, a message will be displayed on the Copy Screen. Follow the procedure below to empty the dust box.
Page 114 Supplies & Handling Withdraw the dust box. Take waste paper out of the dust box. Return the dust box to its original po- sition. Then close the front door of the per- fect binder. 4-30 bizhub PRO 1050/1050e...
Page 115: Removing Finished Sets From Large Capacity Stacker
Supplies & Handling Removing Finished Sets from Large Capacity Stacker LS-501/502 Large Capacity Stacker LS-501/502 can hold 5,000 output sheets (2,000 sheets for B5 and A5) at maximum. Follow the procedure below to take out paper from the stacker. Press the Paper removal button. The stacker unit will move down to the carriage.
Page 116 Supplies & Handling Remove the sheets from the car- riage. The stacker unit can be removed from the carriage. Reminder Once lowering the stacker unit for the purpose of removing mishandled paper or checking output sheets, be sure to remove all the sheets from the carriage.
Page 117: Before Making Copies
Before Making Copies Copier...
Page 119: Copy Screen
Before Making Copies Before Making Copies Copy Screen The Copy Screen is used to select the desired copy conditions when setting a new copy job and also reserve jobs. Part name Description COPY tab is touched to display the Copy Screen. Original Setting key is touched to specify the condition of originals to be scanned.
Page 120 Before Making Copies Part name Description Auto Zoom key is touched to activate AMS (Automatic Magnification Se- lection). Set Number indicator indicates the print quantity entered from the control panel keypad. Output indicator indicates the print count on the left of the set count while printing.
Page 121: Machine Status Screen
Before Making Copies 5.1.1 Machine Status Screen The Machine Status Screen displays when copying operation becomes available after warm-up, or when any copying job has been completed. Part name Description COPY tab is touched to display the Copy Screen. JOB LIST tab is touched to display the Job List Screen.
Page 122 Before Making Copies Part name Description Paper Set key is touched to make paper setting for each tray. Maintenance & supply lights in red when staple supply is required or when trash indicator basket is full. Toner message displays the current status of toner supply. Machine status display prompts you if any door or cover is open.
Page 123: Features Of The Bizhub Pro 1050/1050E
Before Making Copies Features of the bizhub PRO 1050/1050e All-Image Area Makes copies printed completely to the edges of the paper to avoid im- age loss. AE - Automatic Exposure Automatically adjusts exposure to compensate for quality of the original. AMS - Automatic Magnification Selection Automatically selects an appropriate magnification ratio when paper size is selected manually.
Page 124 Before Making Copies Copy Mode Selects the desired simplex mode (1-1 or 2-1); or duplex mode (1-2 or 2- Custom Size for Original Identifies the special original size which the machine cannot detect, in or- der to select the optimal paper size for copying or printing. Density Shift Shifts each of nine density levels in four enhance modes (Text &...
Page 125 Before Making Copies Mixed Original Copies mixed size originals from the document feeder in APS or AMS mode. APS automatically selects the paper size of each original. AMS mode allows you to select one paper size for all originals. Mode Memory Programs up to 30 jobs and recalls each job by job number, as needed.
Page 126 Before Making Copies Overlay Memory Same as for “Overlay” except the overlay image is stored in memory. Paper Capacity Total 9,000 sheets, including two 1,500-sheet trays (Tray 1 and 2) and three 2,000 sheet trays (Tray 3, 4, and 5). Power Save Automatically turns off all but nominal power supply after a specified pe- riod of copier inactivity, for optimal efficiency.
Page 127 Before Making Copies Text/Photo Enhance Enhances photo image in Photo mode, regular image in Text/Photo mode, text image in Text mode, lighter image in Low Contrast mode. Weekly Timer Can be set according to the needs of each work environment. Turns main body power Off/On daily or weekly, during lunch time, on holidays, and also enables the Timer Interrupt mode, which allows temporary use of the machine even when the machine is in the daily, weekly, or holiday Off...
Page 128: How To Make A Basic Copy
Before Making Copies How to Make a Basic Copy Follow the procedure below to make a basic copy. Use Function key to recall the job setting previously registered using Mode Memory. Up to five settings can be recalled. Details The following procedure is basic and not always applicable to the oper- ation of selected copy conditions.
Page 129 Before Making Copies Enter the desired print quantity from the control panel keypad. Entered quantity will be displayed on the touch panel. For details, refer to “Setting Print Quantity” on page 5-20. Position originals FACE UP in the document feeder, or FACE DOWN on the original glass.
Page 130 Before Making Copies Press [Start] on the control panel. When the machine starts scanning originals, the current job status will be displayed on the popup menu. The reserve job setting is available from this popup menu. Touch [Yes] or [Close] to return to the Copy Screen. For details, refer to “Reserve Job Setting”...
Page 131 Before Making Copies If [No] is touched, the Machine Status Screen will be restored. The current job will be displayed in the job list, with the count/set quan- tity indicated at the upper right corner of the screen. bizhub PRO 1050/1050e 5-15...
Page 132: Positioning Originals
Before Making Copies Positioning Originals 5.4.1 Positioning Originals in ADF The document feeder (ADF) automatically feeds up to 100 originals directly to the original glass area, starting with the top sheet. The ADF should only be used for unstapled, smooth, flat originals. Positioning originals in Normal mode Arrange originals in order.
Page 133 Before Making Copies Positioning originals in Mixed Original mode Mixed size originals can be copied together from the document feeder. Note For details, “Copying Mixed Size Originals (Mixed Original)” on page 6-14 Arrange originals in order. Arrange the mixed size originals as illustrated below. To the To the left depth...
Page 134 Before Making Copies Adjust paper guides. Positioning originals in Z-Folded original mode Z-Folded original mode detects the folded original size without using the size detection sensor of the ADF. Note For details, refer to “Copying Z-Folded Originals (Z-Folded)” on page 6-16. Arrange originals in order.
Page 135: Positioning Original On Original Glass
Before Making Copies 5.4.2 Positioning Original on Original Glass Use the original glass when originals are not suitable for use with the docu- ment feeder, e.g., when size is incompatible, or when originals are folded, stapled, torn, or in generally poor condition. Raise the document feeder.
Page 136: Setting Print Quantity
Before Making Copies Setting Print Quantity This section describes how to set or change print quantity. 5.5.1 To Set Print Quantity The copier is initially set to copy the original set in amounts determined by the print quantity setting, then outputs sorted sets. Enter the desired print quantity from the control panel keypad.
Page 137: To Change Print Quantity
Before Making Copies 5.5.2 To Change Print Quantity Follow the procedure below to change the print quantity that has been al- ready entered. Press [C] (clear quantity). The quantity displayed on the touch panel will return to 1. Enter the correct quantity. Entered quantity will be displayed on the touch panel.
Page 138: Setting Job During Warm-Up
Before Making Copies Setting Job During Warm-up While the copier is warming up after power is turned on, select copy condi- tions and start scanning so that the copier may start printing immediately the copier engine is ready. This function can be disabled by service. Contact your service representa- tive, if desired.
Page 139 Before Making Copies Position original(s) FACE UP in the ADF or FACE DOWN on the original glass. Note For details, refer to “Positioning Originals” on page 5-16. Press [Start]. When scanning the original for the job is started, the popup menu will appear on the Copy Screen.
Page 140 Before Making Copies If [No] is touched, the Machine Status Screen will be restored. The current job will be displayed in the job list, with the count/set quan- tity indicated at the upper right corner of the screen. 5-24 bizhub PRO 1050/1050e...
Page 141: To Stop Scanning/Printing
Before Making Copies To Stop Scanning/Printing Follow the procedure below to stop scanning or printing. Note This procedure is effective only for the job in progress. To stop the re- served jobs on standby, operate on the Job List Screen. For details, refer to “Overview of Job List Screen”...
Page 142 Before Making Copies Both scanning and printing are in progress Touch [Stop Job] to cancel the job, or touch [Continue] to complete the job. Details Touching [Stop Job] will delete all the scanned data. Scanning the job in Memory Scan mode Touch [Stop Job] to cancel the job, or touch [Continue] to complete the job.
Page 143 Before Making Copies Batch printing is in progress Touch [Stop Job] to cancel the job, or touch [Continue] to complete the job. Details Touching [Stop Job] will delete all the scanned data. Scanning and printing the job using Program Job Touch [Stop Job] to cancel the job, or touch [Continue] to complete the job.
Page 144 Before Making Copies Scanning reserve job while printing Select to stop scanning, printing, or to stop both operation. Start scanning the reserve job while printing. The following popup menu will be displayed. Touch [NO] to restore the Machine Status Screen. If machine has been set to display the Copy Screen as the initial screen, touch [MACHINE] tab to restore the Machine Status Screen.
Page 145 Before Making Copies Select the job to cancel. Touch Scan to stop scanning the reserve job and continue printing. Touch Print to stop printing and continue the scanning job. Touch Scan/Print to cancel both scanning and printing jobs. Touch Continue to complete both jobs. Details All the data scanned for stopped job will be deleted.
Page 146 Before Making Copies 5-30 bizhub PRO 1050/1050e...
Page 147: Basic Job Settings
Basic Job Settings Copier...
Page 149: Copy Conditions Incompatible With Basic Settings
Basic Job Settings Basic Job Settings Copy Conditions Incompatible with Basic Settings Copy Conditions Incompatible Copy Mode/Magnification Special Image Original Setting with Basic Settings Memory Scan Mode (Glass) Memory Scan Mode (ADF) 1.000 Magnification ZOOM Preset Magnification Rotation Manual Density Preset Density Text &...
Page 150 Basic Job Settings Application / File Edit Application / Image Edit bizhub PRO 1050/1050e...
Page 151 Basic Job Settings Copy Conditions Incompatible with Output Application Basic Settings Memory Scan Mode (Glass) Memory Scan Mode (ADF) 1.000 Magnification ZOOM Preset Magnification Rotation Manual Density Preset Density Text & Photo (Enhance) Low Contrast Photo (*5) Text Background Adjust (+) Background Adjust (-) Mixed Original Z-Folded Original...
Page 152 Basic Job Settings Output Application bizhub PRO 1050/1050e...
Page 153 Basic Job Settings Description None Compatible Grayed out (including automatic release) Output message Originally incompatible but selectable (Function last selected has priority.) Released automatically Overlay cannot be selected in Program Job. Selecting Auto in Repeat, Non-Image Area Erase will also be selected automati- cally and cannot be released.
Page 154: Function Key
Basic Job Settings Function Key The Function key allows you to assign up to five job settings previously stored using Mode Memory. This section describes how to make a copy by simply touching the Function key to recall the desired job setting. Details For storing job settings using Mode Memory, refer to “Storing and Recall- ing Job Conditions (Mode Memory)”...
Page 155 Basic Job Settings Touch the desired Function key. The copy conditions of Mode Memory assigned to that key will resume on the screen. bizhub PRO 1050/1050e...
Page 156: Original Setting
Basic Job Settings Original Setting 6.3.1 Specifying Original Direction Specify the direction of the originals placed on ADF or original glass. This setting is required to obtain copy results as expected when making dou- ble-sided copies with binding position specified or when staple position is specified.
Page 157 Basic Job Settings Touch to highlight the desired original direction key. Touch [OK] to complete the setting and return to the Copy Screen. Details Touch [Recall STD] to restore the initial setting, or touch [Cancel] to resume the previous setting. bizhub PRO 1050/1050e 6-11...
Page 158: Selecting Binding Direction Of Originals
Basic Job Settings 6.3.2 Selecting Binding Direction of Originals When copying double-sided originals in 2-1 or 2-2 mode, the copied sets will be exactly the same in page arrangement as the originals. Use this function to obtain the single- or double-sided copies having the same edge as page top, from double-sided originals printed upside down on the reverse side.
Page 159 Basic Job Settings Touch [Upper Binding] to highlight it. Touch [OK] to complete the setting and return to the Copy Screen. bizhub PRO 1050/1050e 6-13...
Page 160: Copying Mixed Size Originals (Mixed Original)
Basic Job Settings 6.3.3 Copying Mixed Size Originals (Mixed Original) Use the Mixed original mode with the document feeder to copy mixed size originals. Each original in the mixed set will be copied to paper of the same size (APS mode) or to paper of desired size with appropriate ratio automatically select- ed (AMS mode).
Page 161 Basic Job Settings APS mode Automatically select the paper of the same size as that of the original. AMS mode Automatically select magnification ratio to copy onto the same paper in size. Touch [Original Setting] on the Copy Screen. The Special Original popup menu will be displayed. Touch [Mixed Original] to highlight it.
Page 162: Copying Z-Folded Originals (Z-Folded)
Basic Job Settings 6.3.4 Copying Z-Folded Originals (Z-Folded) Use the Z-Folded mode with the document feeder to copy Z-folded originals. Otherwise, the size detection sensor of the ADF may function incorrectly. Specifications for Z-Folded Original: - Use ADF. - This mode requires more scanning time to detect the original size. Z-folded original Touch [Original Setting] on the Copy Screen.
Page 163 Basic Job Settings Touch [OK] to return to the Copy Screen. Details Touch [Recall STD] to restore the initial setting, or touch Cancel to resume the previous setting. Position Z-folded original(s) FACE UP in the document feeder. Normal originals can be set together with the Z-folded original. Note For details, refer to “Positioning originals in Z-Folded original mode”...
Page 164: Feeding Single Original From Adf (Single Feed)
Basic Job Settings 6.3.5 Feeding Single Original from ADF (Single Feed) Use the Single Feed mode to copy thick originals or paste-ups to be fed one sheet at a time in the document feeder. Copying usually starts after the [Start] key is pressed, however, the machine manager can set the machine to automatically feed the original one second after placing the original in the document feeder.
Page 165 Basic Job Settings Position Single Feed original FACE UP in the document feeder. Position a sheet of the original in the document feeder, then align the paper guides to the original. Reminder Never set more than one thick original or paste up, otherwise machine trouble may be caused.
Page 166 Basic Job Settings Select additional copy conditions, as desired. Adjust the ADF paper guides. Without setting the original, adjust the ADF paper guides according to the original size to be set. Position a sheet of original FACE UP in the document feeder. The set original will be automatically fed and scanned.
Page 167: Copying Non-Standard Size Originals (Custom Size / Tab Paper)
Basic Job Settings 6.3.6 Copying Non-Standard Size Originals (Custom Size / Tab Paper) The copier usually detects the standard size of originals fed through ADF or positioned on the original glass (Standard Size mode). Use Custom Size mode to specify the scanning area manually for copying or printing special size originals.
Page 168 Basic Job Settings Touch [Custom Size] or [Tab Paper]. The popup menu will appear for Custom Size or Tab Paper size setting. Touch the desired size key. 6-22 bizhub PRO 1050/1050e...
Page 169 Basic Job Settings Touch [OK] on the popup menu. The popup menu will disappear. Touch [OK] to complete the setting and return to the Copy Screen. Details Touch [Recall STD] to restore the initial setting, or touch [Cancel] to resume the previous setting. bizhub PRO 1050/1050e 6-23...
Page 170: Memory Scan Mode
Basic Job Settings Memory Scan Mode Use Memory Scan mode to scan more than 100 originals into memory then to start a continuous printing job, or to combine images scanned from ADF and original glass. Specification for Memory Scan Mode: - Memory Scan mode is necessarily used in the following functions: Mak- ing double-sided copies using original glass, Image Insert, Book Copy, Program Job, Storing image in Overlay Memory...
Page 171 Basic Job Settings Details Memory indicator under the message area of the LCD screen allows you to check the remaining memory. To delete the scanned data without printing, press [Stop]. For details, “Scanning the job in Memory Scan mode” on page 5-26. When scanning is completed, touch Memory Scan to exit the Memory Scan mode.
Page 172: Special Image
Basic Job Settings Special Image 6.5.1 Selecting Exposure Level and Adjusting Background Whiteness Automatic Exposure (AE) operates with the default settings. It detects the density of the original image and automatically selects the appropriate expo- sure for the copy. Select manual copy density to adjust exposure (density) when originals are too light or too dark.
Page 173 Basic Job Settings This setting can be made by the machine manager, and will also be ap- plied to Density Shift for Enhance Mode. For details, refer to “04 Image Density Selection” on page 16-31. Touch [Darker] to darken, or [Lighter] to lighten the copy image. Highlight the desired exposure level indicator.
Page 174 Basic Job Settings Select the desired background adjustment level. Touch [Special Image]. The Special Image popup menu will be displayed. Touch [Darker] or [Lighter] in the Background Adjust area to move the highlighted indication to the desired adjustment level. Or, touch [Normal] to resume the standard level. Touch [OK].
Page 175 Basic Job Settings Details Touch [Recall STD] to restore the initial setting, or touch [Cancel] to resume the previous setting. bizhub PRO 1050/1050e 6-29...
Page 176: Making Copy Quality Closer To Originals (Text/Photo Enhance)
Basic Job Settings 6.5.2 Making Copy Quality Closer to Originals (Text/Photo En- hance) Use this function to enhance the reproducibility of half tones so that the copy quality more closely matches to that of the original. Text & Photo Mode Use this mode to copy an original including both text and photo image.
Page 177 Basic Job Settings Touch [Special Image] on the Copy Screen. The Special Image popup menu will be displayed. Touch the desired mode key to highlight it. Touch [OK] to return to the Copy Screen. Details Touch [Recall STD] to restore the initial setting, or touch [Cancel] to resume the previous setting.
Page 178: Zoom
Basic Job Settings Zoom In the initial settings on the Copy Screen, the magnification is automatically set at “1.000” (full size). This section describes how to change the magnification ratio. 6.6.1 To Copy in 1.000 Magnification Mode Follow this procedure to make a 100% copy of the original image. Close the ADF securely, then press [Reset].
Page 179: To Change Magnification Ratio
Basic Job Settings 6.6.2 To Change Magnification Ratio The following four modes are provided. - Manual Zoom (proportional): 0.250 to 4.000 in 0.001 (0.1%) increments - Manual Zoom (individual): Vertical and horizontal dimensions can be specified individually from 0.250 to 4.000 in 0.001 (0.1%) increments. - Enlarge/Reduce: Select from the eight ratios (0.500, 0.647, 0.772, 0.785, 1.214, 1.294, 1.545, 2.000) provided on the screen.
Page 180 Basic Job Settings Specify the desired magnification. Manual Zoom (proportional) Touch the key at the upper left corner in the Manual Zoom area. Use the screen keypad to enter the desired magnification ratio. The entered ratio will be displayed on the Copy Screen. Details If wrong number is entered, continue by entering the correct number.
Page 181 Basic Job Settings Use the screen keypad to enter the desired vertical magnification ratio. The entered ratio will be displayed on the Copy Screen. Touch the horizontal zoom key (the third one in the left side line) in the Manual Zoom area. Use the screen keypad to enter the desired horizontal magnification ratio.
Page 182 Basic Job Settings Touch [OK] to return to the Copy Screen. Details Touch [Cancel] to resume the previous setting. 6-36 bizhub PRO 1050/1050e...
Page 183: Copy Mode
Basic Job Settings Copy Mode The Copy Screen is initially set to 1-1 copy mode to make single-sided cop- ies from single-sided originals. Follow the procedure below to make double-sided copies from the originals scanned from the document feeder or from the original glass, and also to make single-sided copies from double-sided originals.
Page 184 Basic Job Settings Touch [1-2] or [2-2] on the Copy Screen to highlight it. Specify other conditions for making double-sided copies. Selecting the original set direction Touch [Original Setting] on the Copy Screen to display the Special Original popup menu. Touch the desired original direction key to highlight it.
Page 185 Basic Job Settings Details Touch [OK] to return to the Copy Screen. For details, refer to “Specifying Original Direction” on page 6-10. For details, “Selecting Binding Direction of Originals” on page 6-12. Selecting the binding mode Touch [Output Application] on the Copy Screen to display the Out- put Application popup menu.
Page 186: Making Double-Sided Copies Using Original Glass
Basic Job Settings Making Double-Sided Copies Using Original Glass Use the original glass to scan originals unsuitable for the document feeder. Specifications for Making Double-Sided Copies Using Original Glass: - Use the Memory Scan mode. - Position originals according to the original direction icon on the Copy Screen.
Page 187 Basic Job Settings Selecting the binding mode Touc opy Screen to display the h [Output Application] on the C Output Application popup menu. Touch the desired binding direction key to highlight it. To make double-sided copies arranged upside down on the back pages, touch [Upper].
Page 188 Basic Job Settings Touch [1-2] on the Copy Screen to highlight it. The [Memory Scan] key will be automatically highlighted on the screen. Reminder DO NOT press [Reset] at this point, otherwise the Memory Scan mode will be released to disable the copier from scanning the original placed on the original glass.
Page 189 Basic Job Settings Details Press [Stop] to suspend the printing job. For details, “Batch printing is in progress” on page 5-27. bizhub PRO 1050/1050e 6-43...
Page 190: Making Single-Sided Copies From Double-Sided Originals
Basic Job Settings 6.8.1 Making Single-Sided Copies from Double-Sided Originals Use ADF and select 2-1 copy mode to make single-sided copies from dou- ble-sided originals. Specifications for Making Single-Sided Copies from Double-Sided Originals: - Position originals according to the original direction icon on the Copy Screen.
Page 191 Basic Job Settings Specify copy conditions for making copies from double-sided origi- nals. Selecting the original set direction and binding direction ch [Original Setting] on the Co py Screen to display the Spe- cial Original popup menu. Touch the desired original direction key to highlight it. To make normal double-sided copies (having the same edge as page top) from double-sided originals printed upside down on the back pages, touch [Upper Binding] to highlight it.
Page 192: Paper Tray Setting
Basic Job Settings Paper Tray Setting Each paper tray has been preset with paper size, paper type/weight, and air assist on/off by machine manager. Paper Size The machine manager has been set each tray to detect the standard paper size when loaded or exclusively to accommodate a specific size. (non-stand- ard size, wide size, or tabbed paper size) The tray specified as standard size or tabbed paper size allows APS (Auto- matic Paper Selection), AMS (Automatic Magnification Selection), and Rota-...
Page 193: To Select Paper Size Automatically (Aps)
Basic Job Settings 6.9.1 To Select Paper Size Automatically (APS) APS detects the original size placed on the ADF or original glass and auto- matically selects and feeds copy paper of the same size, or selects an ap- propriate size according to the magnification ratio selected. Details The original sizes to be detected from the ADF or original glass are pre- viously determined.
Page 194 Basic Job Settings Press [Start]. Scanned image will be printed on the paper size automatically select- If the appropriate copy paper is not loaded in any tray, no copying will be performed, and a message will prompt you to load the appropriate paper.
Page 195: To Specify Desired Paper Size (Ams)
Basic Job Settings 6.9.2 To Specify Desired Paper Size (AMS) When a paper size is specified on the touch panel, an appropriate reduction or enlargement ratio will be selected automatically according to the original size detected from the ADF or the original glass. Specifications for AMS: - AMS is incompatible with APS, however, Rotation is available.
Page 196 Basic Job Settings Press [Start]. Scanned image will be printed on the specified paper size in the mag- nification ratio automatically selected. See the table below for the original size, copy paper size, and magnifi- cation ratio automatically selected. Original size 6-50 bizhub PRO 1050/1050e...
Page 197: Rotation
Basic Job Settings 6.9.3 Rotation This function allows you to utilize APS or AMS and copy the original docu- ments onto size A4 or B5, irrespective of the copy paper feeding direction. Details The machine manager can set this function ON, or to operate when APS, AMS or reduce functions.
Page 198 Basic Job Settings Touch [Rotation Off] on the Copy Screen to highlight it. When Rotation is released, the Rotation icon on the Copy Screen will disappear to indicate that this function is cancelled. Touch to deselect [Rotation Off] to resume this function. When Rotation is resumed, the Rotation icon will be displayed on the screen.
Page 199: Using Paper Not Specified For Any Tray (Paper Presetting)
Basic Job Settings 6.9.4 Using Paper Not Specified for Any Tray (Paper Presetting) Each paper tray has been preset with paper size, paper type/weight, and air assist on/off by machine manager. If you want to use another paper than any loaded in the trays, follow the pro- cedure below to temporarily change the setting of the tray to be used.
Page 200 Basic Job Settings Touch Paper Presetting. The Paper Presetting popup menu will be displayed. Select the tray to change the setting temporarily. Touch the desired tray key on the popup menu. 6-54 bizhub PRO 1050/1050e...
Page 201 Basic Job Settings Change the paper size. Select one of the following four items. Standard Size, Custom Size, Wide Size Paper, Tab Paper Setting Standard Size Touch [Size Setting], then touch [Standard Size]. Touch the desired size key. Touch [OK] to complete the setting. Setting Custom Size Touch [Size Setting], then touch [Custom Size].
Page 202 Basic Job Settings sion, 140 mm ~ 460 mm in horizontal dimension. Touch [Lead Edge], [Rear Edge], or [Centre] to specify the desired image position. Touch [OK] to complete the setting Details The smallest size of the custom size can be changed. Contact your serv- ice representative for details.
Page 203 Basic Job Settings Details When setting wide size, be sure to specify the precise dimensions of pa- per to be used. The dimensions of the wide size selected in step (2) are not correctly set in the initial setting. Touch [Select Size] to return to the Select Size Screen. Touch [OK] to complete the setting.
Page 204 Basic Job Settings Setting Tab Paper Touch [Size Setting], then touch [Tab Paper]. Touch the desired tabbed paper size key to highlight it. If setting the custom tabbed paper size, touch [Custom Size] to dis- play the Size Setting Screen. Touch the vertical/horizontal/index size key, then use the screen keypad or arrow keys + and , to enter the desired size.
Page 205 Basic Job Settings Change the paper setting. Change the paper setting of the tray either by selecting the one previ- ously registered or by programing a new setting. Selecting the paper setting Touch [Type/Weight]. Use [Next] or [Previous] to scroll to the desired paper type/weight from the list, then touch the key to highlight it.
Page 206 Basic Job Settings Programing a new setting Touch [Change]. Touch [Type], then select the desired paper type key. Touch [OK] to complete the setting. Details For details, refer to “Paper Setting Outlines” on page 12-3. 6-60 bizhub PRO 1050/1050e...
Page 207 Basic Job Settings Touch [Weight]. Touch the desired paper weight key, then touch [OK]. Touch [Coloured Paper]. bizhub PRO 1050/1050e 6-61...
Page 208 Basic Job Settings Touch the desired colour key, then touch [OK]. Touch [Hole-Punch]. Touch [With Punch Hole] if the paper has punch holes, or touch [Non Punch Holes] if not, then touch [OK]. Touch [Both Sides Adj]. Touch [Front or Back] to select the printed side, select the adjustment item (vertical zoom, horizontal zoom, vertical shift, or horizontal shift), and then touch + <-->...
Page 209 Basic Job Settings Note For details,refer to “Paper Setting Outlines” on page 12-3. Touch [Close] on the Paper Presetting popup menu. The tray with the paper setting changed will be selected on the screen, and all paper level indicators will disappear from the tray keys. However, the name indicated on the tray key will not be changed.
Page 210: Reserve Job Setting
Basic Job Settings 6.10 Reserve Job Setting The Reserve function allows you to set up a new job while a current job is in process. When the current job is finished, the Reserve job starts printing im- mediately. Service can set the machine to disable this function. Contact your service representative, if desired.
Page 211 Basic Job Settings While printing job is in progress: The message “Printing in progress” is displayed in the message area of the Machine Status Screen. Touch [COPY] tab to display the Copy Screen with the message “Ready to set reserve Job”. Select copy conditions for the reserve job as desired, position origi- nal(s), then press [Start].
Page 212 Basic Job Settings If paper setting has been changed for a reserve job, a popup menu will be displayed, prompting you to replace copy paper in the designated tray. Load copy paper specified for that reserve job into the designated tray, touch [Change], then press [Start].
Page 213: Job Management
Job Management Copier...
Page 215: Overview Of Job List Screen
Job Management Job Management Overview of Job List Screen The Job List Screen allows you to check/operate the following items. - Reserved job - Output History - Send History - Incomplete - Suspended (The letters on the key turn red if any suspended job remains.) - Spool Details The jobs referred here include printer jobs and scanner jobs.
Page 216: Job Operation On Job List Screen
Job Management Job Operation on Job List Screen 7.2.1 To Check/Control Reserved Jobs Use this function to display all the reserve jobs as a list. The list includes following information. - Job No.: consecutive numbers of both copy and print jobs - User Name: user who transmitted the job - Mode: Copy or Printer - Status: Printing or Reserved (current status of the job)
Page 217 Job Management Select the desired job, then select the job operation. To specify the next job to be printed: Touch to highlight the desired reserve job key, then touch [Print Nex]t. The highlighted reserve job will be moved just under the current print job.
Page 218: To Display Output History
Job Management 7.2.2 To Display Output History Use this function to display output history as a list. The list includes following information. - Job No.: consecutive numbers of both copy and print jobs - User Name: user who transmitted the job - Mode: Copy or Printer - Sheets: max.
Page 219: To Display Send History
Job Management 7.2.3 To Display Send History Use this function to display send history as a list. The list includes following information. - Job No.: consecutive numbers of both copy and print jobs - User Name: user who transmitted the job - Mode: E-Mail / FTP / PC / HDD - Address: address to which the data was transmitted - Result: Complete or Cancel...
Page 220: To Check Incomplete Jobs
Job Management 7.2.4 To Check Incomplete Jobs Use this function to display incomplete jobs as a list. The list includes following information. - Job No.: consecutive numbers of both copy and print jobs - User Name: user who transmitted the job - Cause: Memory Full, Cancel, etc.(cause for which the job was not com- pleted) Follow the procedure below to check the settings of noncomplete jobs.
Page 221: To Check/Operate Suspended Jobs
Job Management 7.2.5 To Check/Operate Suspended Jobs Use this function to display all suspended jobs as a list. The list includes following information. - Job No.: consecutive numbers of both copy and print jobs - User Name: user who transmitted the job - Mode: Copy or Printer - Status: Suspended or Printing (current status of the job) - Sheets: max.
Page 222 Job Management Select the desired job, then select the job operation. To output suspended job: Touch to highlight the desired job key, then touch [Release]. The selected job will be output according to the current printing order. Details To check the printing order, touch [Reserved Job] to display the reserved job list.
Page 223: To Check/Control Spool Jobs
Job Management 7.2.6 To Check/Control Spool Jobs Use this function to display spool jobs as a list. The list includes following information. - Job No.: consecutive numbers of both copy and print jobs - Mode: Wait for RIP or Receiving (current status of the spool job) Follow the procedure below to change the output order or delete the spool jobs.
Page 224 Job Management To change the order of jobs: Touch to highlight the desired job key, then touch Priority. The highlighted job will be advanced by one in printing order unless the job preceding the selected one is already in progress. Details If printing order cannot be changed for the selected job, a message will be displayed for information.
Page 225: Applications
Applications Copier...
Page 227: Copy Conditions Incompatible With Applications
Applications Applications Copy Conditions Incompatible with Applications Copy Conditions Incompatible Copy Mode/Magnification Special Image Original Setting with Applications Program Job (First job) Sheet Insertion Insertion using PI Front Cover Back Cover Front PI (Upper/Lower) Back PI (Upper/Lower) Chapter Chapter (Print Insertion) Combination Booklet Adhesive Binding...
Page 228 Applications Application / File Edit Application / Image Edit bizhub PRO 1050/1050e...
Page 229 Applications Output Application Copy Conditions Incompatible with Applications Program Job (First job) Sheet Insertion Insertion using PI Front Cover Back Cover Front PI (Upper/Lower) Back PI (Upper/Lower) Chapter Chapter (Print Insertion) Combination Booklet Adhesive Binding OHP Interleave Image Insert Book Copy Neg.
Page 230 Applications Output Application bizhub PRO 1050/1050e...
Page 231 Applications Description None Compatible Grayed out (including automatic release) Output message Originally incompatible but selectable (Function last selected has priority.) Released automatically 2 in 1 and 2 Repeat are available. (Grayed out if not.) Limited to Job Store function in Copy mode. Overlay cannot be selected in Program Job.
Page 232: To Use Application Function
Applications To Use Application Function Follow the procedure below to display the Application popup menu and se- lect the desired copying features. Touch [COPY] tab on the Machine Status Screen to display the Copy Screen. Touch [Application] on the Copy Screen. The Application popup menu will be displayed on the touch panel.
Page 233 Applications Details When a function key is touched, it becomes highlighted. If you touch a function key, another screen or two will display to enable you to enter the appropriate settings. If one function on the menu is incompatible with another, it will appear dimmed.
Page 234: Inserting Sheets And Covers (Sheet Insertion)
Applications Inserting Sheets and Covers (Sheet Insertion) Use Sheet Insertion in print mode or blank mode to insert chapter sheets or separator sheets into the finished set, as well as front and back covers. The covers and insertions can be fed from different tray source for each, and also available from Post inserter if Folding unit FD-501 option is installed.
Page 235 Applications FRONT COVER PRINTED FRONT COVER BLANK 9 10 9 10 9 10 SURVEYOR S SURVEYOR S SURVEYOR S REPORT REPORT REPORT SURVEYOR S REPORT Copies Copies Originals Originals BACK COVER PRINTED BACK COVER BLANK 9 10 9 10 9 10 SURVEYOR S SURVEYOR S SURVEYOR S...
Page 236 Applications Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. Touch [Sheet Insertion] on the Application popup menu. The Sheet Insertion Screen will be displayed. Select the desired cover mode. If no cover is desired, proceed to the next step.
Page 237 Applications To insert a front cover: Touch [Front Cover]. The Front Cover Screen will be displayed. Select the desired front cover mode, copy mode (Simplex/Duplex), and tray paper to be used. To use covers loaded in the Post inserter, touch [Cover] and select the tray to be used.
Page 238 Applications To use covers loaded in the Post inserter, touch [Cover] and select the tray to be used. If both tray cover and post inserter cover are specified, the post inserter back cover will be the last page. Touch [OK] to complete the setting and return to the previous screen. To insert the insertion sheets: Touch [Insertion Sheets].
Page 239 Applications Enter the page number. Touch [Insert Page Setting], then use the touch panel keypad to enter the page number of insertion location. Use “, (comma)” between pag- es, or “- (hyphen)” for consecutive pages. To delete the last entered number, touch [Delete]. To clear all the page entry, touch [Clear].
Page 240 Applications Details If the same page number has been entered in Set 02 and Set 03 for ex- ample, the setting of later number (Set 03) will take priority. When all settings are completed, touch [OK] on the Sheet Insertion Screen.
Page 241: Locating Title Pages On The Right Side (Chapter)
Applications Locating Title Pages on the Right Side (Chapter) Chapter is used with ADF in 1-2 mode for the purpose of locating title pages on the right side, rather than reverse side, of a duplex copy to improve the presentation of double-sided copies. To effectively locate the title page on the right, a blank sheet will be automat- ically created on the reverse side of a sheet, if required.
Page 242 Applications Touch [Chapter] on the Application popup menu. The Chapter Screen will be displayed. Use the control panel keypad to enter the page number of each title page. Touch [Set] after each entry to move to the next key. To set more than 15 locations, touch the arrow key to move to the next page.
Page 243 Applications Details Entering “0” or the same page number twice will be ignored on the screen. Chapter insertions occur in sequence even if original page numbers are entered out of sequence. When a page number is larger than the total original page count, insertion oc- curs as the last page of the document.
Page 244: Lay Out Several Pages Onto One Sheet (Combination)
Applications Lay Out Several Pages onto One Sheet (Combination) Use this function to lay out and copy a fixed number (2, 4, or 8) of pages onto one sheet of copy paper (2 in 1, 4 in 1, or 8 in 1). Specifications for Combination: - Use ADF.
Page 245 Applications The Combination Screen will be displayed. Select the desired Combination mode. Touch [2 in 1], [4 in 1] or [8 in 1] in the desired order area, referring to the illustration on the following page. Touch [OK]. The Application popup menu will be restored. Details To cancel the setting, touch [Cancel].
Page 246 Applications Select the desired original direction. Touch [Original Setting] on the Copy Screen to display the Special Original popup menu. Touch to select the desired original direction key, then touch [OK] to return to the Copy Screen. Enter the desired print quantity from the control panel keypad. Position originals FACE UP in the document feeder.
Page 247: Making A Multiple Page Signature Booklet (Booklet)
Applications Making a Multiple Page Signature Booklet (Booklet) Use the Booklet to make a multiple page signature booklet on both sides of paper. Original images are scanned into memory and automatically arranged in booklet format in correct order. If the machine is equipped with Saddle stitcher SD-501 option, folded, sta- pled, and/or trimmed booklets can be made.
Page 248 Applications Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. Touch [Booklet] on the Application popup menu. Touch to highlight the desired Booklet mode key. When a cover sheet is required, touch [Cover Tray Select] to select the cover sheet tray source.
Page 249 Applications Touch [OK]. The Application popup menu will be restored. Details To cancel the setting, touch [Cancel]. To cancel the function without clearing the setting made, touch [Function OFF]. Note The Utility Menu Screen provides the setting to position the page num- bers automatically on the outside edges of the copy when using Booklet with Page Numbering in Stamp.
Page 250: Copying Onto Transparent Films (Ohp Interleave)
Applications Copying onto Transparent Films (OHP Interleave) Use the OHP Interleave function in 1-1 or 2-1 mode to copy onto overhead projection transparent films, and output a blank or copied interleaf sheet with each copied transparent film. In the Interleave Blank mode, a blank interleaf sheet is output with each transparent film to keep the film material from sticking together.
Page 251 Applications Touch [Application] on the Copy Screen. Touch [OHP Interleave] on the Application popup menu. Select the desired OHP Interleave mode, then touch [OK]. Details To cancel the setting, touch [Cancel]. To cancel the function without clearing the setting made, touch [Function OFF].
Page 252 Applications Touch [OK] on the Application popup menu. The Copy Screen will be restored. Details AMS is selected automatically. To release AMS, select the desired magnification. Print quantity is already set to 1. You cannot enter any other quantity. Touch to select the tray loaded with transparent films. Position original(s) FACE UP in the document feeder or FACE DOWN on the original glass.
Page 253: Inserting Images Into Printed Sets (Image Insert)
Applications Inserting Images into Printed Sets (Image Insert) Use the Image insert mode to combine images scanned from the original glass, such as photos, paste-ups, newspaper articles, graphs, etc., with im- ages scanned from the document feeder. Then, output the combined images as a finished set.
Page 254 Applications Touch [Image Insert] on the Application popup menu. The Image Insert Screen will be displayed. Use the control panel keypad to enter the page number. Touch [Set] after each entry to move to the next key. When setting more than 15 locations, touch the arrow key to move to the next page.
Page 255 Applications Details Entering Page Numbers For example, if insertion locations are [2/2/6], scanned images will be in- serted as follows: The first scanned image will be inserted after page 2. The second scanned image will be inserted directly after the first scanned Image insertion.
Page 256 Applications Press [Start]. The originals positioned in the document feeder will be scanned into memory. Scan the original glass images. Open the document feeder. Position an original FACE DOWN on the original glass, then close the document feeder. Reminder PLACE AND SCAN THE ORIGINALS ACCORDING TO PAGINATION. Press [Start].
Page 257: Dividing An Image Into Right And Left Pages (Book Copy)
Applications Dividing an Image into Right and Left Pages (Book Copy) The Book Copy mode performs image division on the original image. Use this function to copy an open book or a ledger sheet onto two sheets in 1-1 or 2- 1 mode, or onto the front and back sides of one sheet in 1-2 or 2-2 mode.
Page 258 Applications Touch [Book Copy] on the Application popup menu. The Book Copy Screen will be displayed. Select the desired Book Copy mode. Touch to highlight the desired mode key. Touch [Left Binding] or [Right Binding] to select the output order ac- cording to the original pagination.
Page 259 Applications Touch [OK]. The Application popup menu will be restored. Details To cancel the setting, touch [Cancel]. To cancel the function without clearing the setting made, touch [Function OFF]. Touch [OK] on the Application popup menu. The Copy Screen will be restored. APS and AMS are automatically released, and the Memory Scan key appears highlighted to show that the Memory Scan mode is automati- cally selected.
Page 260 Applications Repeat steps 9 and 10 for all originals. Reminder When using original glass, No Image Area Erase and Image Centering are automatically selected. DO NOT CLOSE the document feeder throughout the scanning job. Touch [Memory Scan] to exit the Memory Scan mode. Press [Start].
Page 261 Applications Scanning Original for Cover Use original glass for scanning original for cover. 1. Open the document feeder. 2. Position original for front cover FACE DOWN on the original glass. 3. Press [Start] to start scanning. 4. When Front/Back Cover + Full scan is selected, scan original for back cover according to the above steps 2 and 3.
Page 262 Applications Note Memory overflow may occur during scanning. When using original glass, No Image Area Erase and Image Centering are automatically selected. DO NOT CLOSE the document feeder throughout the scanning job. 8-38 bizhub PRO 1050/1050e...
Page 263: Programming Different Settings For An Output Job (Program Job)
Applications 8.10 Programming Different Settings for an Output Job (Program Job) In the ordinary Memory Scan mode, the combined features selected for the job are applied to all originals to be scanned. In the Program Job mode, you may scan multiple sets of originals and apply different settings on each set (referred to as JOB), then output them all as a complete set.
Page 264 Applications Touch [Program Job] on the Application popup menu. The incompatible function keys will be dimmed to show inactivity. Touch [OK] on the Application popup menu. The Copy Screen will be restored. The Memory Scan key on the Copy Screen appears highlighted to show that the Memory Scan mode is automatically selected.
Page 265 Applications Press [Start]. The paper size determined at this time will be applied to all subsequent JOBs. When scanning for the current JOB is completed, the popup menu will be displayed in the Copy Screen. Touch [Confirm]. The current JOB images will be stored. To delete the images, touch [Cancel].
Page 266: Erasing Outside Of The Original (No Image Area Erase)
Applications 8.11 Erasing Outside of the Original (No Image Area Erase) The No Image Area Erase mode is used to copy non standard or special orig- inals, such as books, magazines, paste-ups, graphs, thick or thin materials, etc. from the original glass. The exposed glass area outside the borders of the original will not be copied.
Page 267 Applications Touch [OK] on the Application popup menu. The Copy Screen will be restored. Select magnification and paper size, as desired. Details APS and AMS are automatically released. Copy mode is automatically set to 1-1. When selecting 1-2 mode, Mem- ory Scan mode will function automatically.
Page 268 Applications Having Any Problem? This function may perform incorrectly if the lighting in the work place is di- rectly over the original glass. In this case, consult your service representative about an appropriate place for installation. 8-44 bizhub PRO 1050/1050e...
Page 269: Reversing Colour In Black And White Image (Neg. Pos. Reverse)
Applications 8.12 Reversing Colour in Black and White Image (Neg. Pos. Reverse) Use Neg. Pos. Reverse to reverse the image from black-on-white to white- on-black, and vice versa. This is very good for copying white-on-black orig- inals and reversing them to fax. Original Neg.
Page 270 Applications Touch [OK] on the Application popup menu. The Copy Screen will be restored. 8-46 bizhub PRO 1050/1050e...
Page 271: Repeating Selected Image Area (Repeat: Vert./Horiz. Mode)
Applications 8.13 Repeating Selected Image Area (Repeat: Vert./Horiz. Mode) Use this function to repeat the selected image area of 10mm ~ 150mm in both vertical and horizontal widths measured from the rear left corner of the A3 original area indicated on the left edge of the original glass. Vertical/Horizontal Width Setting Mode Specifications: - Use the original glass.
Page 272 Applications Touch [Manual], then specify the vertical and horizontal widths of the scanning area. Use up/down arrow key to enter the width from 10 to 150 mm in 1 mm increments. Keep touching the key to increase/decrease the value con- tinuously.
Page 273 Applications Touch [OK] on the Application popup menu. The Copy Screen will be restored. Select the desired magnification and paper size. Details APS and AMS are automatically released, and 1.000 (100%) is selected as a magnification ratio. Copy mode is automatically set to 1-1. When selecting 1-2 mode, Mem- ory Scan mode will function automatically.
Page 274: Repeat Automatically Or Select Repeat Times (Repeat: Auto Detect/ Repeat Mode)
Applications 8.14 Repeat Automatically or Select Repeat Times (Re- peat: Auto Detect/ Repeat Mode) Auto Detect mode will automatically set the equal repeat area to the size of the original placed onto the original glass by activating No Image Area Erase. Repeat mode will scan the image area specified by the selected paper size and mode (2 Repeat, 4 Repeat, or 8 Repeat), then arrange the image by specified times in one copy sheet.
Page 275 Applications Touch [Repeat] on the Application popup menu. The Repeat Screen will be displayed. Touch to highlight the desired mode key. Touch [Auto] to select the Auto Detect mode. Touch [2 Repeat], [4 Repeat], or [8 Repeat] to select the desired Re- peat mode.
Page 276 Applications Details No Image Area Erase is automatically selected on the Application popup menu when Auto Detect mode is selected. Note When 2 Repeat mode is selected, Page space function of Image Shift can be used to make the desired amount of blank space between the two im- ages on a page.
Page 277 Applications Position original. For Auto Detect mode original, open the document feeder, then posi- tion the original FACE DOWN on the original glass. For 2 Repeat, 4 Repeat or 8 Repeat mode original, ADF is also availa- ble. Reminder When Auto Detect mode is selected, No Image Area Erase functions au- tomatically.
Page 278: Eliminating Black Copy Marks Along Borders (Frame/Fold Erase)
Applications 8.15 Eliminating Black Copy Marks Along Borders (Frame/ Fold Erase) Use Frame/Fold Erase to eliminate black copy marks along borders to clean up and improve the presentation of the copy. Frame erasure Frame erasure Frame Fold Frame Set original erasure erasure erasure...
Page 279 Applications Touch [Frame/Fold Erase] on the Application popup menu. The Frame/Fold Erase Screen will be displayed. Touch to highlight the desired mode key. Touch [All sides], [Each side], or [Fold Erasure] to highlight it. Either Frame erasure mode and Fold erasure can be selected in combination.
Page 280 Applications Specify the erasure amount in the selected mode. To specify Frame Erasure (All sides) amount: Touch to highlight [Frame], if not highlighted, then use the touch panel keypad or up/down arrow key to enter the desired erasure amount of the Up, Down, Right, and Left sides collectively, from 1 to 300 mm in 1 mm increments.
Page 281 Applications To specify Fold Erasure amount: Touch to highlight [Fold], if not highlighted, then use the touch panel keypad or up/down arrow key to enter the desired erasure amount, from 1 to 99 mm in 1 mm increments. Touch [OK]. The Application popup menu will be restored.
Page 282: Copying Image In The Centre Of Copy Paper (Image Centering)
Applications 8.16 Copying Image in the Centre of Copy Paper (Image Centering) Use this function to detect the image area of the original and centre the whole image on the copy paper making it easy to copy small pieces of paper. Specifications for Image Centering: - No Image Area Erase is automatically selected.
Page 283 Applications Details No Image Area Erase will be selected automatically. When using ADF to scan the original, touch to deselect this function. When using the Book Copy with this function, the original smaller than the selected paper size will be printed in the centre of the copy paper without image division performed.
Page 284: Printing Images Fully To The Edges (All-Image Area)
Applications 8.17 Printing Images Fully to the Edges (All-Image Area) Use this function to make copies printed completely to the edges. Original Normal copy All-Image Area copy Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset].
Page 285: Adjusting Position Of Copy Image (Image Shift)
Applications 8.18 Adjusting Position of Copy Image (Image Shift) Use Image Shift to adjust the position of copy images, e.g. for the purpose of creating a new binding margin on originals to make it easier for filing pur- poses. Page Space function is available only when Booklet or 2 Repeat mode of Re- peat has been already selected.
Page 286 Applications Select the copy mode and paper size from the Copy Screen, as re- quired. Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. Touch [Image Shift] on the Application popup menu. Touch [Image Shift] on the Image Shift Screen, then specify the shift di- rection and amount.
Page 287 Applications Touch [Front] or [Back] to specify the shift direction and amount indi- vidually; or touch [Both Sides] to specify collectively. The [Back] and [Both Sides] keys function only for duplex copying. Touch to highlight the desired shift direction key in the upper right area, then use the touch panel keypad or up/down arrow key to enter the de- sired shift amount, from 0 to 250 mm in 1 mm increments.
Page 288 Applications Details Page space function is available only when Booklet or 2 Repeat mode of Image Repeat has been already selected. Use this function to increase/decrease the blank space between the two images on a page. See the illustration below for details. Page space Booklet Original...
Page 289 Applications Details Creep Adjustment function is available only when Booklet (except Adhe- sive Binding mode) has been already selected. Use this function in combination with Page space to make space be- tween the two images two images widening gradually from the inner pag- es to the outer pages in a folded/ folded&stapled and trimmed booklet, so that the outer margin should be uniform on all pages through.
Page 290: Reducing Images To Create Binding Margin (Reduce&Shift)
Applications 8.19 Reducing Images to Create Binding Margin (Re- duce&Shift) Use Reduce & Shift instead of regular Image Shift to prevent image loss when creating a binding margin. Specifications for Reduce & Shift: - AMS is automatically selected and cannot be released. - Shift amount: 0 to 250 mm in 1 mm increments - Setting in 0.1 mm increments using up/down arrow key is also available.
Page 291 Applications Select the copy mode and paper size, as required. Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset]. Touch [Image Shift] on the Application popup menu. Touch [Reduce &...
Page 292 Applications Touch to highlight the desired shift direction key, then use the touch panel keypad or up/down arrow key to enter the desired shift amount, from 0 to 250 mm in 1 mm increments. The image display on the screen allows you to view the shift direction and amount to be printed on the printed sheets.
Page 293: Printing Stamp, Page, Date/Time Onto Copies (Stamp)
Applications 8.20 Printing Stamp, Page, Date/Time onto Copies (Stamp) This function allows you to print onto output copies the desired type of stamp, page number, numbering, and date/time at the location designated on the screen. The four stamp types and watermark (described in the next subsection) pro- vided on the Stamp/Overlay Selection Screen can be used individually or in multiple combinations.
Page 294 Applications Touch [Stamp/Overlay] on the Application popup menu. The Stamp/Overlay Screen will be displayed. Touch to select the desired key in the Stamp area. The subsequent screen will be displayed to allow you to specify the se- lected stamp type. 8-70 bizhub PRO 1050/1050e...
Page 295 Applications When selecting Stamp: Specify the stamp type, printing position, character size and printed page. Touch to highlight the desired stamp key and printing position key on the screen. If fine adjustment is required, touch [Fine Adjust- ment] to display the Fine Adjustment Setting Screen. For details, re- fer to p.
Page 296 Applications Touch to highlight the desired numbering type key and printing po- sition key on the screen. If fine adjustment is required, touch [Fine Adjustment] to display the Fine Adjustment Setting Screen. For de- tails, refer to p. 8-74. Touch [Character Size] to select 20 point or 30 point. Touch [Printed Page] to designate whether to print the selected stamp on the cover only or on all pages.
Page 297 Applications When selecting Date/Time: Specify the date/time type, printing position, character size and type, printed page, and date & time. Touch to highlight the desired date, time, and printing position keys on the screen. If fine adjustment is required, touch [Fine Adjust- ment] to display the Fine Adjustment Setting Screen.
Page 298 Applications Details Fine Adjustment Setting Screen When [Fine Adjustment] is touched, the Fine Adjustment Setting Screen will be displayed. Touch [UP SIDE], [DOWN SIDE], [RIGHT SIDE], or [LEFT SIDE] to specify the direction, then use the touch panel keypad or up/down arrow key to enter the desired amount, from 0 to 50 mm.
Page 299 Applications Start Number Setting Screen: Available from Page Numbering When Chapter is already selected, the chapter start number can also be specified on the Start Number Setting Screen.To enter the start number, touch [Start Number] to highlight it, then use the touch panel keypad or up/down arrow key to enter the desired start number for each.
Page 300 Applications When [Change Character] is touched, the Change Printing Charac- ter Screen will be displayed. Touch to select the desired key, then touch [OK] to return to the previous screen. Cover/Insert Print Setting Selection Screen: from Page Numbering When copied/blank insertion mode of Sheet Insertion has been al- ready selected, this screen allows you to specify whether to print the page number on insertions, or skip them from the page count.
Page 301 Applications Date & Time Setting Screen: from Date/Time When [Date & Time] is touched, the Date & Time Setting screen will be displayed. To print the present time, touch [Present Time] to highlight it. To print hte setting time, touch [Setting Time], then use the touch panel keypad to enter the desired date and time.
Page 302: Printing Watermark Onto Copies (Stamp)
Applications 8.21 Printing Watermark onto Copies (Stamp) Use this function to print the desired letter type obliquely in the centre of the page (Watermark), or the numbers in the specified form repeatedly over the scanned image (Watermark Numbering). Watermark Watermark Numbering Touch [Application] on the Copy Screen.
Page 303 Applications Touch [Watermark] or [Watermark Numbering], as desired. The subsequent screen will be displayed to allow you to specify the se- lected watermark type. When selecting Watermark: Specify the desired watermark type and density. Touch to highlight the desired watermark key and density key on the screen.
Page 304 Applications When selecting Watermark Numbering: Specify the desired watermark numbering type, density, character size and start number. Touch to highlight the desired watermark key and density key on the screen. Touch [Character Size] to select 20 point. or 30 point. Touch [Start Number] to designate the start number, if required.
Page 305: Print Words, Date/Time, Annotation Number Onto Copies (Annotation)
Applications 8.22 Print Words, Date/Time, Annotation Number onto Copies (Annotation) This function allows you to register words, current date/time, and annotation number as a set and to print it onto output copies at the location designated on the screen. The setting previously made for annotation number in the Utility setting can be changed temporarily on the Annotation Screen.
Page 306 Applications 3 sets Upper Upper Upper Left Middle Right Originals Copies Middle Middle Middle Left Right Ex. Lower Right Lower Lower Lower Left Middle Right Date/time Annotation number Type in Printing position Touch [Application] on the Copy Screen. Reminder When starting a new copying job, be sure to close the ADF securely, then press [Reset].
Page 307 Applications Touch [Annotation]. The Annotation Screen will be displayed. Select the desired Annotation type, then specify its printing position. Touch [Next] or [Previous] to display the desired Annotation setting key on the screen, then touch to highlight it. Up to 40 setting keys are available on the screen.
Page 308 Applications Details If [Temp. No. Set] key appears on the annotation, the serial number set- ting has been changed temporarily. See the next step. To change the annotation number setting temporarily, touch [Temp. No. Set]. The Temporary Number Setting Screen will be displayed. Touch the alphanumerical screen keys to enter the desired number or word.
Page 309 Applications Touch [OK] on the Stamp/Overlay Selection Screen. The Application popup menu will be restored. Touch [OK] on the Application popup menu. The Copy Screen will be restored. bizhub PRO 1050/1050e 8-85...
Page 310: Overlay An Image Onto Each Page Copied In The Job (Overlay)
Applications 8.23 Overlay an Image onto Each Page Copied in the Job (Overlay) Use this function to scan an image, then overlay the image onto each page copied in the job. Specification for Overlay: - Memory Scan mode is automatically selected. 1st scanned original Originals scanned Copies in Overlay mode...
Page 311 Applications Touch [Overlay]. Touch [OK] on the Stamp/Overlay Screen. The Application popup menu will be restored. Touch [OK] on the Application popup menu. The Copy Screen will be restored. The Memory Scan mode is automatically selected. Select the desired paper size and magnification on the Copy Screen. APS and AMS are automatically released, and 1.000 (100%) is selected as a magnification ratio.
Page 312 Applications Touch [Memory Scan] on the Copy Screen to exit the Memory Scan mode, then press [Start] to print. 8-88 bizhub PRO 1050/1050e...
Page 313: Store Image In Hdd / Overlay Stored Image (Overlay Memory)
Applications 8.24 Store Image in HDD / Overlay Stored Image (Overlay Memory) Use Overlay Memory to scan and store several images in HDD, then recall the desired image from the HDD to overlay onto each page copied in the job. Image Store Store in HDD Overlaying image...
Page 314 Applications Touch [Stamp/Overlay] on the Application popup menu. The Stamp/Overlay Screen will be displayed. Touch [Overlay Memory]. The Store Image Screen will be displayed. Proceed to step 9, when recalling only the stored image. 8-90 bizhub PRO 1050/1050e...
Page 315 Applications Touch [Store Image] to display the Image Name Entry Screen. Enter the desired image name. Use the touch panel keypad to enter the desired name up to 8 charac- ters. The date when you made this entry will be stored automatically. To correct an entry, touch [Del] repeatedly to delete each character, then enter the correct name.
Page 316 Applications Press [Start] to scan. The Store Image Screen will be displayed. Details To stop scanning, press [STOP]. The machine automatically starts to store the overlaying image data in the HDD. The Overlaying Image Selection Screen will resume when the storing function is completed.
Page 317 Applications Details Popup Menu for Name Duplication If the popup menu with [Yes] and [No] keys is displayed instead of the Copy Screen, the entered name is duplicated. Touch Yes to enter a new name, or No to create a duplicate name. If the popup menu with [OK] key is displayed, the entered name is dupli- cated.
Page 318 Applications 8-94 bizhub PRO 1050/1050e...
Page 319: Setting Output Methods
Setting Output Methods Copier...
Page 321: Copy Conditions Incompatible With Output Modes
Setting Output Methods Setting Output Methods Copy Conditions Incompatible with Output Modes Copy Conditions Incompatible Copy Mode/Magnification Special Image Original Setting with Output Modes Collated (Offset) Uncollated Collated (Rotation) Uncollated (Rotation) 1 Stapling (Upper Left) 1 Stapling (Upper Right) 2 Stapling (Top) 2 Stapling (Left) 2 Stapling (Right) Z-Fold...
Page 322 Setting Output Methods Application / File Edit Application / Image Edit bizhub PRO 1050/1050e...
Page 323 Setting Output Methods Copy Conditions Incompatible with Output Application Output Modes Collated (Offset) Uncollated Collated (Rotation) Uncollated (Rotation) 1 Stapling (Upper Left) 1 Stapling (Upper Right) 2 Stapling (Top) 2 Stapling (Left) 2 Stapling (Right) Z-Fold Folding (Inside Print) Folding (Outside Print) Letter Fold-in (Inside Print) Letter Fold-in (Outside Print) Letter Fold-out (Inside Print)
Page 324 Setting Output Methods Output Application bizhub PRO 1050/1050e...
Page 325 Setting Output Methods Description None Compatible Grayed out (including automatic release) Output message Originally incompatible but selectable (Function last selected has priority.) Released automatically Limited to Job Store function in Copy mode. Overlay cannot be selected in Program Job. Available only when Booklet is selected. Selecting Auto in Repeat, Non-Image Area Erase will also be selected automatically and cannot be released.
Page 326: Selecting An Output Tray
Setting Output Methods Selecting an Output Tray This section describes how to select an output tray. Touch [Output Application] on the Copy Screen. The Output Application Screen appears. Trays that can output paper will be have keys on the front image of the machine, and the tray that is currently set to output paper is shown with a depressed key.
Page 327 Setting Output Methods Touch [Output Tray]. An Output Tray Selection Screen reflecting the combination of optional devices will appear. Select the desired output tray. Touch the desired tray position key to select it. bizhub PRO 1050/1050e...
Page 328 Setting Output Methods Machine with Large Capacity Stacker LS-502 (1 unit), or with Large Capacity Stacker LS-501 + Finisher FS-503: In addition to the tray position key , the [Pile Setting] key is shown. If you touch [Pile Setting], a popup screen will appear. Touch [Permit] if you want to allow paper from several jobs to pile up in the large ca- pacity stacker, or touch [Prohibit] if you do not.
Page 329 Setting Output Methods Machine with Large Capacity Stacker LS-501+ LS-502, or with Large Capacity Stacker LS-501 + LS-502 + Finisher FS-503: In addition to the tray position key and the [Pile Setting] key, the [Stacker Auto] key is shown. If you touch [Stacker Auto], in case the selected output tray and the large capacity stacker become full or if problems occur, paper will be automatically output to another large capacity stacker.
Page 330 Setting Output Methods Touch [OK] on the Output Application Screen. It will return to the Copy Screen. Withdraw the Saddle stitcher tray, if selected as an output tray. Open the tray stand when fully withdrawn. Reminder Never return the Saddle stitcher tray to its original position with the tray stand opened.
Page 331: Setting Binding Direction For Duplex Copies
Setting Output Methods Setting Binding Direction for Duplex Copies When setting duplex mode (simplex % duplex / duplex % duplex), a binding direction must be selected. It should be set when making duplex copies with upper binding (front and back sides have the opposite side up) from simplex or duplex originals of right/left binding (front and back sides have the same side up).
Page 332 Setting Output Methods Touch [Output Application] on the Copy Screen. The Output Application Screen appears. Touch [Upper] to select it. Touch [OK]. 9-14 bizhub PRO 1050/1050e...
Page 333: Using Finisher Fs-503
Setting Output Methods Using Finisher FS-503 The Finsiher FS-503 has a primary (main) tray and a secondary (sub) tray, each of which has the following output modes. Output to the Primary (Main) Tray: Non-sort: Non-sort mode simply means that the offset-stacker finisher modes are not selected.
Page 334 Setting Output Methods Output to the Secondary (Sub) Tray Collated: Collated mode outputs multiple copies of the original set. No offset out- put is available. Uncollated: Uncollated mode groups together multiple copies of each original. No offset output is available. Combined with the output modes above, you can also choose to output face up or face down, and output front to back or back to front.
Page 335: Non-Sort / Collated / Uncollated Output To The Primary (Main) Tray
Setting Output Methods 9.4.1 Non-sort / Collated / Uncollated Output to the Primary (Main) Tray A machine with Finisher FS-503 installed is set to collate output to the prima- ry (main) tray by default, regardless of whether or not other optional devices are attached.
Page 336 Setting Output Methods Note Changing output trays is described separately. For details, refer to “Se- lecting an Output Tray” on page 9-8. Select an output mode. For non-sort output, cancel both [Collated] and [Uncollated]. For collated output, touch [Collated] to select it. For uncollated output, touch [Uncollated] to select it.
Page 337: Stapling Output To The Primary (Main) Tray
Setting Output Methods 9.4.2 Stapling Output to the Primary (Main) Tray Copies will be stapled in this mode. Follow the procedures below to select stapling position and number of staples: upper left/upper right 1 stapling, left/up/right 2 stapling. Specifications for Stapling Output to the Primary (Main) Tray - Paper size: A3, B4, F4, A4, A4R, B5, A5, 8K, 16K, 12"x18", 11"x17", 8.5"x14", 8.5"x11", 8.5"x11"R, 5.5"x8.5"...
Page 338 Setting Output Methods Touch [Output Application]. The Output Application Screen appears. Touch [Stapling] and select stapling style and position. The Stapling Selection Screen appears. Touch any stapling position key to select it. Details If you touch [Cancel], it returns to the previous setting. If you touch [Function Off], stapling output will be turned off but the sta- pling position will be kept in memory.
Page 339 Setting Output Methods Touch [OK]. It will return to the Output Application Screen. Touch [OK] on the Output Application Screen. The icon of the specified output application appears on the Copy Screen. Reminder The primary (main) tray gradually goes down while printed materials out- put.
Page 340: Collated / Uncollated Output To The Secondary (Sub) Tray
Setting Output Methods 9.4.3 Collated / Uncollated Output to the Secondary (Sub) Tray A machine with Finisher FS-503 installed is set to collate output to the prima- ry (main) tray by default, regardless of whether or not other optional devices are attached.
Page 341 Setting Output Methods Select the secondary (sub) tray as the output tray. Touch [Output Tray] to open the Output Tray Selection Screen. Touch the tray position key of the secondary (sub) tray to select it. Touch [OK]. Select an output mode. For collated output, touch Collated to select it.
Page 342 Setting Output Methods Touch [OK] on the Output Application Screen. The icon of the specified output application appears on the Copy Screen. Details Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused. 9-24 bizhub PRO 1050/1050e...
Page 343: Using Large Capacity Stacker Ls-501/Ls-502
Setting Output Methods Using Large Capacity Stacker LS-501/LS-502 The Large Capacity Stacker LS-501/LS-502 has a stacker (on the carriage) and a secondary (sub) tray, each of which has the following output modes. Output to the Stacker Non-sort: Non-sort mode simply means that the offset-stacker finisher modes are not selected.
Page 344 Setting Output Methods - The stacker's specifications are described separately. For details, refer to “Paper Information” on page 3-3. Secondary (sub) tray - Paper size: A3, B4, F4, A4, A4R, B5, B5R, A5, A5R, B6R, 8K, 16K, 16KR, 12"x18", 11"x17", 8.5"x14", 8.5"x11", 8.5"x11"R, 5.5"x8.5", standard tab paper, wide size paper (maximum 324 x 460 mm) - Paper weight: 50 - 300 g/ - Loading capacity: Maximum 200 sheets...
Page 345 Setting Output Methods Select an output mode. For unsorted output, cancel both [Collated] and [Uncollated]. For collated output, touch [Collated] to select it. For uncollated output, touch [Uncollated] to select it. Select output face (Face Down / Face Up), and output order (1 to N / N to 1) as needed.
Page 346: Using Folding Unit Fd-501
Setting Output Methods Using Folding Unit FD-501 There are three elements for output settings: - Intermediary processing - Output mode - Output tray position The Folding Unit FD-501 does the intermediary processing, while Finisher FS-503/Saddle Stitcher SD-501/Perfect Binder PB-501 sets an output mode and changes output tray position.
Page 347: Punching File Holes In Copies
Setting Output Methods 9.6.1 Punching File Holes in Copies Copies will be punched in this mode. Follow the procedures below to select 2- or 4-hole punch and punch position. Specifications for Punching Copies: - Punch holes: 2 / 4 - Punch hole diameter: 2-hole 6.5 mm / 4-hole 8.0 mm - Punch hole pitch: 80 mm - Hole position adjustment range: ±4 mm (error 0.2mm) - Paper size:...
Page 348 Setting Output Methods Touch [Output Application]. The Output Application Screen appears. Touch [Punch] and select the number of punch holes and position. The Hole-Punch Screen appears. Touch any punch key to select it. 9-30 bizhub PRO 1050/1050e...
Page 349 Setting Output Methods Touch [OK]. It will return to the Output Application Screen. Details If you touch [Cancel], it returns to the previous setting. If you touch [Function Off], punch output will be turned off but the select- ed punch settings will be kept in memory. Touch [OK] on the Output Application Screen.
Page 350: Folding Copies
Setting Output Methods 9.6.2 Folding Copies Copies will be folded in this mode. Follow the procedures below to select from six folding types. Specifications for Folding Copies: - Folding types: Z-Fold, Letter Fold-in, Letter Fold-out, Double Parallel, Gate, Folding - Paper size: A3, B4, A4R, 8K, 12"x18", 11"x17", 8.5"x14", 8.5"x11"R - Paper weight: - Z-Fold / Letter Fold-in / Letter Fold-out / Folding: 50 - 130g/ - Double Parallel / Gate: 50 - 130 g/...
Page 351 Setting Output Methods Touch [Folding] to select a folding type. The Folding Mode Screen appears. Touch any punch key to select it. Touch [OK]. It will return to the Output Application Screen. Details If you touch [Cancel,] it returns to the previous setting. If you touch [Function Off], folding output will be turned off but the select- ed folding settings will be kept in memory.
Page 352: Using Saddle Stitcher Sd-501
Setting Output Methods Using Saddle Stitcher SD-501 9.7.1 Making Folded Booklet Machine with the Saddle Stitcher SD-501 installed provides Fold & Staple mode in combination with Booklet feature to make two-sided signature booklet, folded and stapled at two positions (saddle stitched) in the centre. Use Trimming mode to trim the edge that opens the booklet, if desired.
Page 353 Setting Output Methods Touch Output Application on the Copy Screen. The Output Application Screen appears. Touch [Fold&Staple], then select to use Trimming or not. The Fold&Staple Screen will be displayed. Touch [Trimming] or [Non Trimming] to select it. Touch [OK]. The Output Application Screen will be restored.
Page 354 Setting Output Methods Details If you touch [Cancel], the previous setting will be restored. Touching Function Off will deselect the Fold&Staple (and Trimming) mode, however, the specified setting will be kept in memory. Touch [OK] on the Output Application Screen. The output icon of the selected output mode will be displayed on the Copy Screen.
Page 355 Setting Output Methods Details The folded and stapled (and trimmed) sets will be delivered into the Sad- dle stitcher tray. If the tray is not fully withdrawn, the machine will detect that the tray is filled up, even with less number of finished sets than that specified in specifications.
Page 356: Folding Copied Set
Setting Output Methods 9.7.2 Folding Copied Set Machine with the Saddle Stitcher SD-501 installed provides Multi Centre mode to double-fold up to 5 sheets of copied set, or Multi Letter mode to fold it inside in three. Using Multi Letter, the print side can be specified on the screen. Specifications for Multi Centre / Multi Letter - Paper weight: Multi Centre 50 - 244 g/ , Multi Letter 50 - 130 g/...
Page 357 Setting Output Methods Touch [Output Application] on the Copy Screen. The Output Application Screen appears. Touch [Multi Centre] or [Multi Letter] to select it. If [Multi Centre] is selected, the [Multi Centre Screen] will be dis- played to specify whether or not to trim the edge of the folded sheets.
Page 358 Setting Output Methods If [Multi Letter] is selected, the Multi Letter Screen will be displayed to specify the print side. Touch [Outside Print] or [Inside Print] to select it. Touch [OK]. The Output Application Screen will be restored. Details If you touch [Cancel], the previous setting will be restored. Touching [Function Off] will deselect the mode, however, the specified setting will be kept in memory.
Page 359 Setting Output Methods If [Multi Centre] is selected, withdraw the Saddle stitcher tray. Open the tray stand when fully withdrawn. Details The double-folded sets will be delivered into the Saddle stitcher tray. If the tray is not fully withdrawn, the machine will detect that the tray is filled up, even with less number of finished sets than that specified in specifi- cations.
Page 360: Using Post Inserter On Folding Unit Fd-501
Setting Output Methods Using Post Inserter on Folding Unit FD-501 This function uses the post inserter on Folding Unit FD-501 to attach a cover. Using Sheet Insertion function, cover sheets loaded in the top/bottom tray of the post inserter can be attached as a front cover, back cover or insertion sheet to output copies.
Page 361 Setting Output Methods Covers and insertion sheets Copied set with Copied set with covers attached in covers and staple mode insert sheets attached Cover sheet Body set with cover attached in perfect binding mode Place paper on the upper and lower Upper tray trays of the post inserter.
Page 362 Setting Output Methods Use the sheet insertion or booklet function to place a cover sheet. Reminder Copies will be delivered to the primary (main) tray of Finisher FS-503. Be careful not to exceed the finisher tray capacity when selecting the print quantity, otherwise unexpected trouble may be caused.
Page 363 Setting Output Methods To prevent small cover sheet from skewing The small cover sheet may be skew, when loading it in the upper/lower tray of the post inserter. Three paper rollers are attached to the upper/lower tray respectively. To lock the roller both sides, prevent paper from skewing. Push the both roller lock levers to inside to lock them.
Page 364: Using Folder/Finisher Functions Manually
Setting Output Methods Using Folder/Finisher Functions Manually If the optional Folding Unit FD-501 and the Finisher FS-503 / Saddle Stitcher SD-501 are installed, you can load paper in the lower tray of the post inserter and manually punch, fold, and/or staple copies. Specifications for Using Folder/Finisher Functions Manually: - When using folder/finisher functions manually, paper should be placed only in the upper tray of the post inserter.
Page 365 Setting Output Methods Multi-Feed Detection Function 1 Stapling 2 Holes Punch Z-Fold Letter Fold-in Gate Letter Double Function 2 Stapling 3 Holes Punch Folding Fold out Parallel Multi-Feed Punch selection Start/Stop button Detection button button Staple Selection Fold Selection button button Place paper in the upper tray of the Upper tray...
Page 366 Setting Output Methods Select a mode. Staple Selection Fold Selection button button Punch selection button When selecting 1 or 2 stapling / fold/staple, press the Staple selec- tion button to turn on the desired mode lamp. When selecting 2- or 4-hole punching, press the Punch selection button to turn on the desired mode lamp.
Page 367 Setting Output Methods Press the [Start/Stop] button. Start/Stop button If multi-feeding is detected and the machine stops even if single sheet is fed, press the Multi-Feed Detection button to turn on the lamp below. Multi-Feed Detection button Details To interrupt the operation, press the Start/Stop button again. Note Using Fold&Staple mode, the finished sets will be delivered to the saddle stitcher tray of Saddle stitcher SD-501.
Page 368: Using Perfect Binder Pb-501
Setting Output Methods 9.10 Using Perfect Binder PB-501 The machine with the optional Perfect Binder PB-501 installed automatically attaches a copied set with a cover sheet to make a perfect-bound book, ap- plying a dab of glue in the centerline of the cover sheet to fix the spine. In the Perfect Binding mode, both simplex and duplex copying are available for the body set, and also the cover sheet can be blank, simplex-printed or duplex-printed, and even trimmed to match with the thickness of the body...
Page 369 Setting Output Methods Even number originals Body set: simplex, Cover print: Off Blank Blank Blank Blank Body set: duplex, Cover print: Off Blank Blank Blank Blank Body set: duplex, Cover print: On, copver print side: simplex Blank Blank Body set: duplex, Cover print: On, copver print side: duplex Body set Cover bizhub PRO 1050/1050e...
Page 370 Setting Output Methods Odd number originals Body set: simplex, Cover print: Off Blank Blank Blank Blank Body set: duplex, Cover print: Off Blank Blank Blank Blank Body set: duplex, Cover print: On, copver print side: simplex Blank Blank Blank Body set: duplex, Cover print: On, copver print side: duplex Blank Body set Cover...
Page 371 Setting Output Methods Specifications for Using Perfect Binder PB-501 - Warm-up/Low Power/Shut-Off The perfect binder requires longer warm-up time than that required for the main body, while the Low Power/Shut-Off mode activates at the same time on main body and perfect binder. We recommend you to specify the time to activate the Low Power/Shut- Off mode in view of the frequency to use the perfect binder.
Page 372 Setting Output Methods - Use Cover Trimming function to trim the cover by the amount automati- cally estimated from the following formula, in the range from 3 mm to 40 mm in 0.1 mm increments. – (Cover width) – (Body width × 2) – (Spine width) - For specifications of the secondary (sub) tray, see p.
Page 373 Setting Output Methods Load paper for body sets and covers in each tray to be used. Load paper for body sets in one of the tray 1 to 5. When printing on covers, also load cover sheets in one of the tray 1 to 5.
Page 374 Setting Output Methods Touch [COPY] tab to display the Copy Screen, select the tray loaded with paper for body sets, and change the paper setting as required. The paper size will be detected automatically. If paper weight specified for the tray loaded with paper for body sets is inadequate, the binding operation cannot be performed.
Page 375 Setting Output Methods Touch [Output Application], then touch [Perfect Bind]. The Perfect Binding Screen will be displayed. bizhub PRO 1050/1050e 9-57...
Page 376 Setting Output Methods Select the tray loaded with covers, then specify the paper setting. Touch Cover Tray to display the Cover Tray Screen. Touch the tray loaded with covers in step 1 to highlight it. Details If any other tray than tray 1 to 5, the Cover Print setting in step 5 will be limited to Cover Print Off.
Page 377 Setting Output Methods Touch [Change Paper Set] to display the Tray Setting Screen. Enter the cover paper dimensions. Touch [Size Setting] to display the Size Setting Screen. Use the screen keypad or arrow keys + and , to enter the dimen- sions of the covers loaded in step 1, then touch [OK].
Page 378 Setting Output Methods Specify the paper type and weight. Touch [Change] to display the Change Setting Screen. Touch [Type] to select the desired paper type, then touch [OK]. 9-60 bizhub PRO 1050/1050e...
Page 379 Setting Output Methods Touch [Weight] to select the desired paper weight, then touch [OK]. If unsuitable selection is made, the binding operation will not be performed. Select the desired one from 72-91g, 92-130g and 131-161g. Details The binding operation may not be performed even if one of the paper weight mentioned above is specified.
Page 380 Setting Output Methods Touch [OK] on the Cover Tray Screen. Specify the cover print setting. This setting is available when one of the tray 1 to 5 is specified as the cover tray source. Select [On] to print on covers, or [Off] to attach blank covers. Also select [Simplex] to print only on the front side, or [Duplex] to have both front and back sides printed.
Page 381 Setting Output Methods Specify the spine width. Touch [Spine Width (1-30 mm)] to display the Spine Width Screen. Use the screen keypad, arrow keys + and ,, or the control panel keypad to enter the desired value, then touch [OK]. Specify the cover trimming setting.
Page 382 Setting Output Methods Make fine adjustments for the lead edge, trimming width, and image position of the cover. Touch Fine Adjustment to display the Fine Adjustment Screen. To adjust the lead edge of the cover, touch [Cover Lead Edge Adj.] Use [+5–] to select positive/negative, then use the screen keypad, arrow keys + and ,, or the control panel keypad to enter the de- sired value.
Page 383 Setting Output Methods Enter the desired print quantity from the control panel keypad. Proof copy is recommended before making multiple sets. After proof copying, the thickness of body set will be displayed on the Perfect Binding Screen. Use this information if making any adjustment. Position originals.
Page 384 Setting Output Methods Take out the perfect-bound books from the perfect binder tray, press the feeding button to move them for- ward. Open the perfect binder tray cover. Details The perfect binder tray cover will not open while the machine operation is in process, and also the feeding button will not function.
Page 385: Using Two Copiers In Tandem
PRO 1050P printer. - The combination of the two copiers can be either the two bizhub PRO 1050e copiers, two bizhub PRO 1050eP printers, or bizhub PRO 1050e copier and bizhub PRO 1050eP printer. - Two copiers should have the same optional configuration.
Page 386 Setting Output Methods - To use the User Authentication function on the two copiers in tandem mode, the same user/section setting is required on both copiers. In this case, copying will be available by entering the user/section password in the master machine only. The password will be transmitted to the tandem machine automatically so as to enable the copying operation.For details, refer to “03 Use Auth./Volume Track”...
Page 387 Setting Output Methods The copier with [Tandem] highlighted will become the master machine; the other copier will function as the tandem machine. The Master icon displays on the Copy Screen of the master machine to indicate that the two units are ready to work in tandem mode. Details The Tandem icon will display on the Copy Screen of the tandem machine when [Start] is pressed on the master machine to start the tandem print-...
Page 388 Setting Output Methods Select the desired copying conditions on the master machine. Details Ordinary copying operation is still available on the tandem machine dur- ing the tandem mode setting. Reminder Corresponding tray sizes on the master and tandem machines should be the same when using multiple trays for a single job.
Page 389 Setting Output Methods Press [Start] on the control panel of the master machine. The Tandem icon will display on the Copy Screen of the tandem ma- chine to indicate that the two copiers will start working in tandem. The tandem mode will be released automatically when the tandem mode copying is completed, and the Master and Tandem icons on each Copy Screen will disappear.
Page 390 Setting Output Methods If Auto shut-off is activated on the tandem machine during the tandem job setting, the tandem mode will be released automatically. Selected tandem mode will be released automatically when the master machine activates Auto low power/Auto shut-off. Press [Power Save] to release Auto shut-off if required, then select the tandem mode again to restart the procedure.
Page 391: To Stop Scanning/Printing
Setting Output Methods 9.11.1 To Stop Scanning/Printing To cancel the tandem copying job Press [Stop] on the control panel of the master machine. The scanning/printing job stops immediately, and the popup menu ap- pears on the Copy Screen of the master machine to ask you whether to continue or terminate the job.
Page 392: Troubleshooting
Setting Output Methods 9.11.2 Troubleshooting When a paper jam, SC-code (E-code, F-code) trouble or unloaded paper occurs on either the master or tandem machine Remove the mishandled paper, take the appropriate troubleshooting meas- ures to correct the problem, or add paper. When the trouble is cleared, the machine will restart printing for the remain- ing print quantity.
Page 393: Advanced Information
Advanced Information Copier...
Page 395: Checking Feature Selections By Proof Copying
Advanced Information Advanced Information 10.1 Checking Feature Selections by Proof Copying Use Proof copy to produce a sample of the copied set before making multi- ple copies. This is a convenient and cost effective way of viewing the results of the copying selections. Specifications for Proof Copy: - Proof copy is available when using ADF, or when using Memory Scan mode for multiple originals or originals to be scanned from original glass.
Page 396 Advanced Information The screen for checking the job settings will be displayed. Touch [Close]. The Copy Screen will be restored. Change the settings or print quantity, as required. The setting keys that cannot be changed or released will appear dimmed to show inactivity. Details If the desired setting cannot be changed, press [Stop] to delete all the data in memory.
Page 397: Checking Feature Selections Before Copying (Check Mode)
Advanced Information 10.2 Checking Feature Selections Before Copying (Check Mode) Display the Check Screen to check the feature selections you made, and use Proof Copy to make a sample copy if needed, before making multiple copies. This is a convenient and cost effective way of viewing the results of the cop- ying selections.
Page 398 Advanced Information Check the job settings on the screen. If [Next] is active on the screen, touch it to proceed to the next page. If making any setting change from the Check Screen, proceed to the next step. If releasing any application function from the Check Screen, pro- ceed to step 4.
Page 399 Advanced Information If making a set or sample copy, proceed to step 5. To start printing without proof copying, proceed to step 7. Release Application functions. Touch the desired application function key on the Check Screen to highlight it, then touch [Release Setting]. The confirmation screen will appear on the Check Screen.
Page 400 Advanced Information Make a sample copy. Position originals in the ADF. Or, use Memory Scan mode to scan all originals. Press [Proof Copy] on the control panel or touch [Proof Copy] on the Check Screen. A sample copy will be output. Details Press [Stop] to suspend the proof copying.
Page 401: Interrupt Copying
Advanced Information 10.3 Interrupt Copying Use the Interrupt mode to interrupt copying in progress to perform a simple job. When interrupt copying is completed, the settings for the previous job restore automatically and the Copy Screen displays. Specification for Interrupt Mode: - The Interrupt mode cannot be selected with the following copier condi- tions: –...
Page 402 Advanced Information The Copy Screen for Interrupt copying will be displayed. Set copy conditions, as desired. All copy conditions except Reserve mode can be specified. Position original(s), then press [Start] to start the interrupt copying. When Interrupt copying is completed, press [Interrupt] again. The [Interrupt] LED turns out and the settings of the initial job will be re- stored.
Page 403: Storing And Recalling Job Conditions (Mode Memory)
Advanced Information 10.4 Storing and Recalling Job Conditions (Mode Memory) Use Mode Memory to store up to 30 frequently used copy job settings, which can be recalled at any time. The stored jobs can be given alphabetical names. 10.4.1 Storing Job Conditions Follow the procedure below to store the copy job setting.
Page 404 Advanced Information Touch [Store]. The Job Store Check Screen will be displayed. Review the settings, then touch [OK]. The Mode Memory Screen will be restored. Details If any correction is required, touch [Cancel] to return to the Copy Screen. Make new selections, then restart the operation from step 2. 10-12 bizhub PRO 1050/1050e...
Page 405 Advanced Information Touch the desired job key, then touch [OK]. The job keys numbered from 01 to 18 are displayed on the screen. Touching [Next] will display the keys from 19 to 30. A blank keys without a lock icon indicate that no job is stored under that key, and a named job without a lock icon displayed...
Page 406 Advanced Information Touch [OK]. The Mode Memory Screen will be restored. Check that the job name has been correctly entered. Details If you do not wish to enter a name, simply touch [OK]. The key displays 16 asterisks (*) in place of a name. Touch [OK] to complete the setting and return to the Copy Screen.
Page 407: Recalling Stored Job Settings
Advanced Information 10.4.2 Recalling Stored Job Settings Follow the procedure below to recall jobs that are already stored. Specifications for Recalling Job Conditions: - The Mode Memory Screen can be displayed only from the Copy Screen. If any other screen such as Machine Status Screen is displayed, pressing [Mode Memory] will be ignored.
Page 408 Advanced Information The job keys numbered from 01 to 18 are displayed on the screen. Touching [Next] will display the keys from 19 to 30. The desired job can also be selected by entering two-digit number from the control panel keypad. Touch [Job Check].
Page 409: Recalling Previous Job Settings
Advanced Information 10.5 Recalling Previous Job Settings Follow the procedure below to copy with a previous job settings. Specifications for Recalling Previous Job Settings: - Only the last-completed output job settings can be recalled as the previ- ous job settings. Non-completed job or reserve job settings cannot be re- called, even if the setting operations have been made last.
Page 410 Advanced Information Touch Pre-Job Recall. The [Job Check] key will appear on the screen. Touch [Job Check] to review the settings. The Job Recall Check Screen will be displayed. Check the settings of the previous job on the screen. Note Recalled settings can be altered from this screen.
Page 411: Displaying Screen For Operation Guide (Help Mode)
Advanced Information 10.6 Displaying Screen for Operation Guide (Help Mode) The Help Screen provides you with the information about copy job setting procedure, toner and paper supply, and control panel and touch panel key operation. Help Screen comprises the following menu items. 01 Copy provides information on function and operation of the keys on Copy Screen.
Page 412: To Display Help Screen
Advanced Information 10.6.1 To Display Help Screen Pressing [Help] when Machine Status Screen is displayed: Pressing [Help] when Copy Screen is displayed: 10-20 bizhub PRO 1050/1050e...
Page 413 Advanced Information Top Page of the Help Screen: This screen appears when [Top Menu] on the subordinate Help Screen is touched. bizhub PRO 1050/1050e 10-21...
Page 414: Adjusting Response Time Of Touch Keys (Accessibility)
Advanced Information 10.7 Adjusting Response Time of Touch Keys (Accessibility) This machine can sets the desired interval between touching the screen key and machine response in advance. Pressing the Accessibility key on the control panel will select this interval, so that the machine will respond to the touch key operation only when the key is kept touched for a specified period of time.
Page 415 Advanced Information To deactivated this function, press [Accessibility] for one second or longer. The Accessibility LED goes off, and normal response time will be re- stored in touch key operation. bizhub PRO 1050/1050e 10-23...
Page 416 Advanced Information 10-24 bizhub PRO 1050/1050e...
Page 417: Machine Status Screen Setting
Machine Status Screen Setting POD Administrator...
Page 419: Machine Status Screen Setting Outlines
Machine Status Screen Setting Machine Status Screen Setting 11.1 Machine Status Screen Setting Outlines The [Paper Set], [Adjustment], and [Controller] keys are located at the bottom of the Machine Status Screen, to display each setting screen. Paper Set The Paper Set popup screen is displayed. Specify each tray size, register/delete paper type/weight setting, and also set air assist function on/off from this screen.
Page 420 Machine Status Screen Setting Details You may set the other settings on another screen while specifying the pa- per setting. Press the tab key to switch the screens. 11-4 bizhub PRO 1050/1050e...
Page 421 Machine Status Screen Setting Adjustment The Adjustment mode menu screen is displayed. Adjust the settings of Image Control and Output options. For the details, refer to “Machine Adjustment Outlines” on page 13-3. After completing the Adjustment mode settings, touch [Return] to exit the Adjustment mode.
Page 422 Machine Status Screen Setting 11-6 bizhub PRO 1050/1050e...
Page 423: Paper Setting
Paper Setting POD Administrator...
Page 425: Paper Setting Outlines
Paper Setting Paper Setting How to operate Paper Setting to be designated for paper tray 12.1 Paper Setting Outlines This machine provides the optimum print result according to each character- istics of copy paper by specifying paper size, paper type/weight, and air as- sist function for each tray (Tray Setting).
Page 426 Paper Setting 3. Coloured Paper Select one of the following six types. White, Transparent, Yellow, Pink, Blue, Green 4. Hole-Punch Select either condition. With Punch Hole or No Punch Hole 5. Both Sides Adjustment Specify the Vertical zoom, Horizontal zoom, Up/Down shift amount, and Right/Left shift amount for both front and back pages.
Page 427 Paper Setting Coated B Specify [Coated B] when overlay printing on the offset printed coated paper. If a trouble occurs in feeding the coated paper when [Coated A] is specified, select [Coated B]. Details When using the overlay printed paper, you are required to specify specific settings besides [Coated B] to the tray to which this type of coated paper is load.
Page 428 Paper Setting Specify [OHP] to a tray to which transparent films are loaded. Weight is classified into eight types as shown in the following table. 12-6 bizhub PRO 1050/1050e...
Page 429: Paper Type And Weight
Paper Setting Paper type and weight Coated A Coated B Fine Normal Book/ Embossed News 40 ~ 49 g/m² (Disable) (Disable) 50 ~ 61 g/m² 62 ~ 71 g/m² 72 ~ 91 g/m² 92 ~ 130 g/m² 131 ~ 161 g/m² 162 ~ 209 g/m²...
Page 430 Paper Setting Paper Weight Conversion Chart Inch Paper type, Basic size Bond Cover Index Bristol Book 17x22 20x26 25.5x30.5 22.5x28.5 24x36 25x38 432x559 508x660 648x775 572x724 610x914 635x965 g/m² 50.0 13.3 18.5 27.7 22.8 30.8 33.8 52.3 13.9 19.4 29.0 23.9 32.2 35.4...
Page 431 Paper Setting Inch Paper type, Basic size Bond Cover Index Bristol Book 17x22 20x26 25.5x30.5 22.5x28.5 24x36 25x38 432x559 508x660 648x775 572x724 610x914 635x965 g/m² 240.0 63.9 88.9 132.9 109.6 147.7 162.4 250.0 66.6 92.6 138.5 114.2 153.8 169.1 260.0 69.2 96.3 144.0...
Page 432: Recommended Setting Of Paper Type/Weight
Paper Setting 12.1.2 Recommended Setting of Paper Type/Weight It is recommended that paper type/weight should be registered for each pa- per to be used, so that the setting change can be made according to the en- vironment (temperature, humidity, paper condition, etc.) on the basis of registered settings for each tray.
Page 433: Register Paper Type/Weight
Paper Setting 12.2 Register Paper Type/Weight Follow the procedure below to register paper type/weight according to the paper type to be used. Procedure Touch [Paper Set] - [Register Type/Weight]. bizhub PRO 1050/1050e 12-11...
Page 434 Paper Setting Touch the key to be registered. The Input Condition Screen will be dis- played. 12-12 bizhub PRO 1050/1050e...
Page 435 Paper Setting Touch [Type] to display the Type popup menu, then select the desired paper type. Details For details, refer to “Paper Type Specifications” on page 12-4. Touch [OK] to complete the setting. Touch [Name] on the Input Condition Screen, then enter the name of the paper to be used.
Page 436 Paper Setting Details The same name as the paper type specified is displayed on the screen. To alter it, enter the new paper type name. For details on entering texts in the field, see the appendix. Touch [OK] to complete the setting. Touch [Weight] on the Input Condition Screen, then select the desired paper weight.
Page 437 Paper Setting Touch [OK] to complete the setting. Touch [Hole-Punch] on the Input Condition Screen, then touch [With Punch Hole] if the paper has punch holes. Touch [OK] to complete the setting. bizhub PRO 1050/1050e 12-15...
Page 438 Paper Setting Touch [Both Sides Adj.] on the Input Condition Screen, then enter the adjustment value as follows. Touch [Front] or [Back] on the Front and Back Page Adjustment Screen to select the printed side. Select the adjustment item (vertical zoom, horizontal zoom, vertical shift, and horizontal shift.) Touch [+ 5 -] to specify the value to be positive or negative.
Page 439: Delete Paper Type/Weight
Paper Setting 12.3 Delete Paper Type/Weight Follow the procedure below to delete the paper type/weight previously reg- istered. Procedure Touch [Paper Set] - [Delete Type/Weight]. bizhub PRO 1050/1050e 12-17...
Page 440 Paper Setting Use [Next] or [Previous] to scroll to the desired paper type/weight from the list, then touch the key to highlight it. Touch [OK]. The popup menu will appear to confirm that the selected key is to be deleted. Touch [Yes] to delete it, or touch [No] to cancel.
Page 441: Set Paper Size, Conditions, Air Assist Function For A Tray
Paper Setting 12.4 Set Paper Size, Conditions, Air Assist Function for a Tray Specify the paper sizes, programmed paper type/weight, air assist function for each tray. bizhub PRO 1050/1050e 12-19...
Page 442 Paper Setting Procedure Touch [Paper Set] - [Tray Setting]. Touch the tray key (Tray 1 to 5) to be specified. Touch [Size Setting]. The Size Setting Screen will be displayed. Follow the procedure for each setting. 12-20 bizhub PRO 1050/1050e...
Page 443 Paper Setting Setting Standard Size 1. Touch [Standard Size] to highlight it. 2. If selected tray will be loaded with one of the following sizes, touch [Search Size Set] to display the Search Size Set Screen, then touch the desired size key. 5.5x8.5, 8.5x11R, 8x13, 8.12x13.2, 8.25x13, 8.5x13 Details If 5.5x8.5 is selected on the Search Size Set Screen, the machine will au-...
Page 444 Paper Setting 3. Touch [OK] to complete the setting. The Tray Setting Screen will be re- stored. 4. Touch [OK] on the Size Setting Screen to complete the setting. 5. Proceed to step 5. (p. 12-27) Setting Custom Size 1. Touch [Custom Size] to highlight it. 2.
Page 445 Paper Setting Setting Wide Size Paper 1. Touch [Wide Size Paper] to highlight it. 2. Touch the desired wide size key to highlight it. 3. Touch [Lead Edge], [Rear Edge], or [Centre] to specify the desired image position. 4. Touch [Input Size] to display the Size Input Screen. 5.
Page 446 Paper Setting Details When setting wide size, be sure to specify the precise dimensions of pa- per to be used. The dimensions of the wide size selected in step 2 are not correctly set in the initial setting. 7. Touch [Select Size] to return to the Select Size Screen. 8.
Page 447 Paper Setting Setting Tab Paper 1. Touch [Tab Paper] to highlight it. 2. Touch the desired tabbed paper size key to highlight it. 3. If setting the custom tabbed paper size, touch [Custom Size] to display the Size Setting Screen. bizhub PRO 1050/1050e 12-25...
Page 448 Paper Setting 4. Touch the vertical/horizontal/index size key, then use the touch panel keypad or arrow keys (+) and (,) to enter the desired size. 5. Touch [Number of Tabs] to display the Number of Tabs Screen, then use the touch panel keypad or arrow keys (+) and (,) to enter the number of tabs.
Page 449 Paper Setting Touch [Type/Weight] on the Tray Setting Screen. Use [Next] or [Previous] to scroll to the desired paper type/weight from the list, then touch the key to highlight it. bizhub PRO 1050/1050e 12-27...
Page 450 Paper Setting Touch [OK] to complete the setting. The Tray Setting Screen will be re- stored. Touch [Air Assist ]on the Tray Setting Screen. Touch [Auto,] [On], or [Off] to highlight it. Touch [OK] to complete the setting. The Tray Setting Screen will be re- stored.
Page 451: Change Paper Type/Weight Specified For A Tray
Paper Setting 12.5 Change Paper Type/Weight Specified for a Tray The paper size and air assist function can be changed with the same proce- dure as setting. To change paper type/weight already designated for a tray, follow the proce- dure below. Details Front and Back Page Adjustment is required to execute every time the paper type is changed or as daily maintenance, because a shrinkage ratio...
Page 452 Paper Setting Procedure Touch [Paper Set] - [Tray Setting]. Touch [Change] to display the Change Setting Screen. 12-30 bizhub PRO 1050/1050e...
Page 453 Paper Setting Touch the key of the setting item to be changed. bizhub PRO 1050/1050e 12-31...
Page 454 Paper Setting 12-32 bizhub PRO 1050/1050e...
Page 455 Paper Setting To change it, follow the same procedure as registering the paper con- ditions. For details, refer to “Register Paper Type/Weight” on page 12-11. To output a chart for the Front and Back Page Adjustment, proceed to the next step. To output a chart for the Front and Back Page Adjustment, touch [Both Sides Adj.] on the Change Setting Screen.
Page 456 Paper Setting – With Back side selected: Measure the positional gap between the front side and back side. – Setting range: X (horizontal) - 10 (left) to + 10 (right), Y (vertical) - 10 (top) to + 10 (bot- tom), 1 step = 0.1 mm 4.
Page 457 Paper Setting If selected key has already been named, that name will be displayed. Change it in this step, if desired. For details of entering texts in the field, see the appendix. Touch [OK]. To restore the previous setting, touch [Cancel]. Touch [OK] to complete the setting.
Page 458 Paper Setting 12-36 bizhub PRO 1050/1050e...
Page 459: Adjustment
Adjustment POD Administrator...
Page 461: Machine Adjustment Outlines
Adjustment Adjustment 13.1 Machine Adjustment Outlines The following adjustments for image control are included in the Machine Ad- justment functions. 01 Magnification Adjustment Provide controls for image magnification. 02 Timing Adjustment Provide controls for image timing. 03 Centering Adjustment Provide the centering control to the direction of paper feed. bizhub PRO 1050/1050e 13-3...
Page 462: Magnification Adjustment
Adjustment 13.2 01 Magnification Adjustment 01 Printer Drum Clock Adjustment <SIDE1> In the printer control, perform this adjustment to control the magnification for Side 1 to the direction of paper feed. Details This adjustment is a baseline for both sides adjustment enabled in Tray Setting and Register Type/Weight.
Page 463 Adjustment Procedure Touch [Adjustment] - [01 Machine Adjustment] - [01 Magnification Ad- justment]. Touch [01 Printer Drum Clock Adjustment <SIDE1>] to display the Printer Drum Clock Adjustment <SIDE1> Screen. Touch the [COPY] tab to display the Copy Screen. Load A3 paper into the tray, then press [Start] to output the sample pat- tern (No.
Page 464 Adjustment Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -10 (short) to +10 (long), 1 step = 0.05%. Repeat steps 3 to 7 until the desired result is obtained. Touch [Return] to restore the Magnification Adjustment Menu Screen. 13-6 bizhub PRO 1050/1050e...
Page 465 Adjustment 02 Printer Drum Clock Adjustment <SIDE2> In the printer control, perform this adjustment to control the magnification for Side 2 to the direction of paper feed. Details This adjustment is a baseline for both sides adjumstment enabled in Tray Setting and Register Type/Weight.
Page 466 Adjustment Procedure Touch [Adjustment] - [01 Machine Adjustment] - [01 Magnification Ad- justment]. Touch [02 Printer Drum Clock Adjustment <SIDE2>] to display the Printer Drum Clock Adjustment <SIDE2> Screen. Select the required paper size using [Next] or [Back]. With [Next] select- ed each time, the display will switch as follows: Tray1 –...
Page 467 Adjustment 03 Printer Horizontal Adjustment <SIDE1> In the printer control, perform this adjustment to control the magnification for Side 1 perpendicular to the direction of paper feed. bizhub PRO 1050/1050e 13-9...
Page 468 Adjustment Procedure Touch [Adjustment] - [01 Machine Adjustment] - [01 Magnification Ad- justment]. Touch [03 Printer Horizontal Adjustment <SIDE1>] to display the Print- er Horizontal Adjustment <SIDE1> Screen. Touch the [COPY] tab to display the Copy Screen. Select A3 paper, then press [Start] to output the sample pattern (No. 16).
Page 469 Adjustment 04 Printer Horizontal Adjustment <SIDE2> In the printer control, perform this adjustment to control the magnification for Side 2 perpendicular to the direction of paper feed. bizhub PRO 1050/1050e 13-11...
Page 470 Adjustment Procedure Touch [Adjustment] - [01 Machine Adjustment] - [01 Magnification Ad- justment]. Touch [04 Printer Horizontal Adjustment <SIDE2>] to display the Print- er Horizontal Adjustment <SIDE2> Screen. Select the required paper size using [Next] or [Back]. With [Next] select- ed each time, the display will switch as follows: Tray1 –...
Page 471: Timing Adjustment
Adjustment 13.3 02 Timing Adjustment 01 Printer Restart Timing Adjustment <SIDE1> Perform this adjustment to control the restart timing for Side 1. Reminder Perform this adjustment after completing Printer Drum Clock Adjustment <SIDE1>. bizhub PRO 1050/1050e 13-13...
Page 472 Adjustment Procedure Touch [Adjustment] - [01 Machine Adjustment] - [02 Timing Adjust- ment]. Touch [01 Printer Restart Timing Adjustment <SIDE1>] to display the Printer Restart Timing Adjustment <SIDE1> Screen. Select the required tray using [Next] or [Back]. With [Next] selected each time, the display will switch as follows: All –...
Page 473 Adjustment If the desired result cannot be obtained, touch the [ADJUSTMENT] tab to return to the Adjustment Screen. Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -30 (short) to +30 (long), 1 step = 0.1 mm. Repeat steps 3 to 8 until the desired result is obtained.
Page 474 Adjustment 02 Printer Restart Timing Adjustment <SIDE2> Perform this adjustment to control the restart timing for Side 2. Reminder Perform this adjustment after completing Printer Drum Clock Adjustment <SIDE2>. 13-16 bizhub PRO 1050/1050e...
Page 475 Adjustment Procedure Touch [Adjustment] - [01 Machine Adjustment] - [02 Timing Adjust- ment]. Touch [02 Printer Restart Timing Adjustment <SIDE2>] to display the Printer Restart Timing Adjustment <SIDE2> Screen. Select the required tray using [Next] or [Back]. With [Next] selected each time, the display will switch as follows: All –...
Page 476 Adjustment 03 Scanner Restart Timing Adjustment Perform this adjustment to control the restart timing in scanning the original with the original glass. 13-18 bizhub PRO 1050/1050e...
Page 477 Adjustment Procedure Touch [Adjustment] - [01 Machine Adjustment] - [02 Timing Adjust- ment]. Touch [03 Scanner Restart Timing Adjustment] to display the Scanner Restart Timing Adjustment Screen. Touch the [COPY] tab to display the Copy Screen. Select A3 paper, place the original of which a misalignment can be eas- ily monitored on the original glass, then press [Start].
Page 478 Adjustment 04 ADF Restart Timing Adjustment Perform this adjustment to control the restart timing in scanning the original with ADF. 13-20 bizhub PRO 1050/1050e...
Page 479 Adjustment Procedure Touch [Adjustment] - [01 Machine Adjustment] - [02 Timing Adjust- ment]. Touch [04 ADF Restart Timing Adjustment] to display the ADF Restart Timing Adjustment Screen. Select the desired paper side using [Next] or [Back]. Each time [Next] is selected, the display will switch as follows: SIDE 1 - SIDE 2 Note "SIDE 1"...
Page 480: Centering Adjustment
Adjustment 13.4 03 Centering Adjustment 01 Printer Centring Adjustment Perform this adjustment to control image centring to the direction of paper feed. 13-22 bizhub PRO 1050/1050e...
Page 481 Adjustment Procedure Touch [Adjustment] - [01 Machine Adjustment] - [03 Centring Adjust- ment]. Touch [01 Printer Centring Adjustment] to display the Printer Centring Adjustment Screen. Select A3 paper, then press [Start] to output the sample pattern (No. 16). Fold the output sheet at the centre to the direction of paper feed and measure the distance between the lines on both sides.
Page 482: Finisher Adjustment Outlines
Adjustment 13.5 Finisher Adjustment Outlines Use this function to make fine adjustments on Finisher options. Details The target adjustment items vary depending upon the configuration of in- stalled options. 01 Stapler Position Adjustment Adjust the dislocation of sheets delivered to the tray and centre position of staples processed by the Staple Finisher FS-503.
Page 483: Stapler Position Adjustment
Adjustment 13.6 01 Stapler Position Adjustment 01 Stapling Centre Position Adjustment Perform this adjustment for the centre position of copied/printed sheets and of staples processed by the Staple Finisher FS-503. The paper width adjustment is supposed to be completed before this adjust- ment.
Page 484 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [01 Stapler Position Adj.]. Touch [01 Stapling Center Position Adjustment] to display the Stapling Centre Position Adjustment Screen. Touch the [COPY] tab to display the Copy Screen. Press [Start]. A sample copy will be output. Use the touch panel keypad to enter the desired adjustment value, then touch [Set].
Page 485 Adjustment 02 Paper Width Adjustment Perform this adjustment if stapled sheets are not aligned neatly processed when Straight/Staple mode is selected on the Staple Finisher FS-503. bizhub PRO 1050/1050e 13-27...
Page 486 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment ]- [01 Stapler Position Adj.]. Touch [02 Paper Width Adjustment] to display the Paper Width Adjust- ment Screen. Touch [Straight Mode] or [Staple Mode] to select the adjustment mode. Touch the [COPY] tab to display the Copy Screen. Load the desired size of paper to be adjusted on a tray.
Page 487 Adjustment Check misalignment (a), in which misalignment occurs if the paper width setting is larger than the actual width, or paper curving (b), in which a sample set is curved if the paper width setting is smaller than the actual width has occurred. [Straight Mode] [Staple Mode] If the desired result cannot be obtained, touch the [ADJUSTMENT] tab.
Page 488 Adjustment Remove the output paper, then close the finisher door. If desired adjustment result cannot be obtained, touch the [ADJUST- MENT] tab, then repeat the adjustment steps from 3 to 12 until the de- sired result is obtained. Touch [Return] to restore the Stapler Position Adjustment Mode Menu Screen.
Page 489: Multi Folder (Punch) Adjustment
Adjustment 13.7 02 Multi Folder (Punch) Adjustment 01 Paper Width Adjustment Perform this adjustment for the specific paper size if punch holes processed by the Folding Unit FD-501 dislocate largely. bizhub PRO 1050/1050e 13-31...
Page 490 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [02 Multi Folder (Punch) Adj.]. Touch [01 Paper Width Adjustment] to display the Paper Width Adjust- ment Screen. Touch the [COPY] tab to display the Copy Screen. Load the desired size of paper to be adjusted on a tray, specify the set number to 10, then press [Start].
Page 491 Adjustment 02 Hole-Punch Vertical Position Adjustment Perform this adjustment for the position of punch holes to the direction of pa- per feed. bizhub PRO 1050/1050e 13-33...
Page 492 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [02 Multi Folder (Punch) Adj.]. Touch [02 Hole-Punch Vertical Position Adjustment] to display the Hole-Punch Vertical Position Adjustment Screen. Touch the [COPY] tab to display the Copy Screen. Load the desired size of paper to be adjusted on a tray, specify [Punch], then press [Start].
Page 493 Adjustment If adjustment in any other hole type or paper size is required, repeat steps from 3 to 10. Touch [Return] to restore the Multi Folder (Hole-Punch) Adjustment Mode Menu Screen. bizhub PRO 1050/1050e 13-35...
Page 494: Multi Folder (Fold) Adjustment
Adjustment 13.8 03 Multi Folder (Fold) Adjustment 01 Folding Position Adjustment Perform this adjustment for the folding position processed by theFolding Unit FD-501. 13-36 bizhub PRO 1050/1050e...
Page 495 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [03 Multi Folder (Fold) Adj.]. Touch [01 Folding Position Adjustment] to display the Folding Position Adjustment Screen. Touch the [COPY] tab to display the Copy Screen. Load the desired size of paper to be adjusted on a tray, specify [Fold- ing], then press [Start].
Page 496 Adjustment 02 Letter Fold-in Position Adjustment Perform this adjustment for the folding positions in Letter Fold-in mode proc- essed by the Folding Unit FD-501. Reminder When adjusting both Single Fold and Double Fold, be sure to start with the Double Fold adjustment. The baseline of Single Fold is calculated from the edge of the sheet, while that of Double Fold is calculated from the position of the first fold line, therefore a distance (b) in step 5 will be altered by changing the position...
Page 497 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [03 Multi Folder (Fold) Adj.]. Touch [02 Letter Fold-in Position Adjustment] to display the Letter Fold-in Position Adjustment Screen. Touch the [COPY] tab to display the Copy Screen. Load the desired size of paper to be adjusted on a tray, specify [Letter Fold-in], then press [Start].
Page 498 Adjustment Touch [Next] or [Back] to select the paper size to be adjusted. Touching [Next] continuously will change the paper size as follows: All - 11x17 - A3 - B4 - 8.5x14 - A4R - 8.5x11R - 8K - 12x18 Touch [Double Fold].
Page 499 Adjustment 03 Letter Fold-out Position Adjustment Perform this adjustment for the folding positions in Letter Fold-out mode processed by the Folding Unit FD-501. Details The baseline of Single Fold is calculated from the edge of the sheet, while that of Double Fold is calculated from the position of the first fold line, therefore a distance (b) in step 5 will be altered by changing the position of either Single Fold or Double Fold.
Page 500 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [03 Multi Folder (Fold) Adj.]. Touch [03 Letter Fold-out Pos. Adjustment] to display the Letter Fold- out Position Adjustment Screen. Touch the [COPY] tab to display the Copy Screen. Load the desired size of paper to be adjusted on a tray, specify [Letter Fold-out], then press [Start].
Page 501 Adjustment Touch [Next] or [Back] to select the paper size to be adjusted. Touching [Next] continuously will change the paper size as follows: All - 11x17 - A3 - B4 - 8.5x14 - A4R - 8.5x11R - 8K - 12x18 Touch [Single Fold].
Page 502 Adjustment 04 Double Parallel Position Adjustment Perform this adjustment for the folding positions in Double Parallel folding mode processed by the Folding Unit FD-501. Reminder When adjusting both Single Fold and Double Fold, be sure to start with the Single Fold adjustment. The baseline of Single Fold is calculated from the edge of the sheet, while that of Double Fold is calculated from the position of the first fold line, therefore a distance (b) in step 5 will be altered by changing the position...
Page 503 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [03 Multi Folder (Fold) Adj.]. Touch [04 Double Parallel Position Adjustment] to display the Double Parallel Position Adjustment Screen. Touch the [COPY] tab to display the Copy Screen. Load the desired size of paper to be adjusted on a tray, specify [Double Parallel], then press [Start].
Page 504 Adjustment Touch [Next] or [Back] to select the paper size to be adjusted. Touching [Next] continuously will change the paper size as follows: All - 11x17 - A3 - B4 - 8.5x14 - A4R - 8.5x11R - 8K - 12x18 Touch [Single Fold].
Page 505 Adjustment 05 Z-Fold Position Adjustment Perform this adjustment for the folding positions in Z-Fold mode processed by the Folding Unit FD-501. Reminder When adjusting both Single Fold and Double Fold, be sure to start with the Single Fold adjustment. The baseline of Single Fold is calculated from the edge of the sheet, while that of Double Fold is calculated from the position of the first fold line, therefore a distance (b) in step 5 will be altered by changing the position of either Single Fold or Double Fold.
Page 506 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [03 Multi Folder (Fold) Adj.]. Touch [05 Z-Fold Position Adjustment] to display the Z-Fold Position Adjustment Screen. Touch the [COPY] tab to display the Copy Screen. Load the desired size of paper to be adjusted on a tray, specify [Z- Fold], then press [Start].
Page 507 Adjustment Touch [Next] or [Back] to select the paper size to be adjusted. Touching [Next] continuously will change the paper size as follows: All - 11x17 - A3 - B4 - 8.5x14 - A4R - 8.5x11R - 8K - 12x18 Touch [Single Fold].
Page 508 Adjustment 06 Gate Position Adjustment Perform this adjustment for the folding positions in Gate folding mode proc- essed by the Folding Unit FD-501. Reminder When adjusting Single Fold, Double Fold and Triple Fold at a time, be sure to start with the Single Fold adjustment. The baseline of Single Fold is calculated from the edge of the sheet, while that of Double Fold is calculated from the position of the first fold line, and that of Triple Fold is calculated from the position of the second fold line,...
Page 509 Adjustment Procedure Touch [Adjustment ]- [02 Finisher Adjustment] - [03 Multi Folder (Fold) Adj.]. Touch [06 Gate Position Adjustment] to display the Gate Position Ad- justment Screen. Touch the [COPY] tab to display the Copy Screen. Load the desired size of paper to be adjusted on a tray, specify [Gate], then press [Start].
Page 510 Adjustment Touch [Next] or [Back] to select the paper size to be adjusted. Touching [Next] continuously will change the paper size as follows: All - 11x17 - A3 - B4 - 8.5x14 - A4R - 8.5x11R - 8K - 12x18 Touch [Single Fold].
Page 511: Stacker Adjustment
Adjustment 13.9 04 Stacker Adjustment 01 Paper Width Adjustment Perform this adjustment when output sheets are not aligned in a perpendic- ular position to the direction of paper feed processed by the Large Capacity Stacker LS-501/502. bizhub PRO 1050/1050e 13-53...
Page 512 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [04 Stacker Adj.]. Touch [01 Paper Width Adjustment] to display the Paper Width Adjust- ment Screen. Touch the [COPY] tab to display the Copy Screen. Specify [A3] then press [Start]. A sample pattern (No. 16) will be output. If output sheets are misaligned, touch the [ADJUSTMENT] tab.
Page 513 Adjustment 02 Paper Length Adjustment Perform this adjustment when output sheets are not aligned to the direction of paper feed processed by the Large Capacity Stacker LS-501/502. bizhub PRO 1050/1050e 13-55...
Page 514 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [04 Stacker Adj.]. Touch [02 Paper Length Adjustment] to display the Paper Length Ad- justment Screen. Touch the [COPY] tab to display the Copy Screen. Specify [A3] then press [Start]. A sample pattern (No. 16) will be output. If output sheets are misaligned, touch the [ADJUSTMENT] tab.
Page 515: Saddle Stitcher Adjustment
Adjustment 13.10 05 Saddle Stitcher Adjustment 01 Stapling Centre Adjustment Perform this adjustment for the centre (folding) position of copied/printed sheets and of staples processed by the Saddle Stitcher SD-501. The paper width adjustment (06) and folding position adjustment (04) are supposed to be completed before this adjustment.
Page 516 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [05 Saddle Stitcher Adj.]. Touch [01 Stapling Centre Adjustment] to display the Stapling Centre Position Adjustment Screen. Touch the [COPY] tab to display the Copy Screen. Select the Fold&Staple mode, then press [Start]. A sample copy will be output.
Page 517 Adjustment Use the touch panel keypad to enter the desired adjustment value, then touch [Set]. Available range: -20 (forward) to +20 (backward), 1 step = 0.1 mm Repeat the adjustment steps from 3 to 7 until the desired result is ob- tained.
Page 518 Adjustment 02 Stapling Paper Width Adjustment Perform this adjustment if stapled sheets are not aligned neatly processed by the Saddle Stitcher SD-501. 13-60 bizhub PRO 1050/1050e...
Page 519 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [05 Saddle Stitcher Adj.]. Touch [02 Stapling Paper Width Adjustment] to display the Staple Pa- per Width Adjustment Screen. Touch the [COPY] tab to display the Copy Screen. Load the desired size of paper to be adjusted on a tray, select Fold&Staple and then press [Start].
Page 520 Adjustment Details The following limitation is put on the paper width setting according to the actual paper width. Actual paper width Minimum value Maximum value ~ 222 mm 91 mm Actual width minus 91 mm 222 mm ~ 290 mm Not limited Not limited 290 mm ~...
Page 521 Adjustment 03 Staple Pitch Adjustment Perform this adjustment for the staple pitch processed by Saddle Stitcher SD-501. bizhub PRO 1050/1050e 13-63...
Page 522 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [05 Saddle Stitcher Adj.]. Touch [03 Staple Pitch Adjustment] to display the Staple Pitch Adjust- ment Screen. Touch the [COPY] tab to display the Copy Screen. Load the desired size of paper to be adjusted on a tray, specify Fold&Staple, then press [Start].
Page 523 Adjustment 04 Folding Position Adjustment Perform this adjustment for the double-folding position processed by the Saddle Stitcher SD-501. bizhub PRO 1050/1050e 13-65...
Page 524 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [05 Saddle Stitcher Adj.]. Touch [04 Folding Position Adjustment] to display the Folding Position Adjustment Screen. Touch the [COPY] tab to display the Copy Screen. Load the desired size of paper to be adjusted on a tray, specify Multi Centre, then press [Start].
Page 525 Adjustment Touch [Return] to restore the Saddle Stitcher Adjustment Mode Menu Screen. bizhub PRO 1050/1050e 13-67...
Page 526 Adjustment 05 Three-Fold Position Adjustment Perform this adjustment for the three-folding positions processed by the Saddle Stitcher SD-501. Reminder When adjusting both Single Fold and Double Fold, be sure to start with the Double Fold adjustment. The baseline of Single Fold is calculated from the edge of the sheet, while that of Double Fold is calculated from the position of the first fold line, therefore a distance (b) in step 5 will be altered by changing the position of either Single Fold or Double Fold.
Page 527 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [05 Saddle Stitcher Adj.]. Touch [05 Three-Fold Position Adjustment] to display the Three-Fold- ing Position Adjustment Screen. Touch the [COPY] tab to display the Copy Screen. Load the desired size of paper to be adjusted on a tray, specify Multi Letter, then press [Start].
Page 528 Adjustment Touch[Next] or [Back] to select the paper size to be adjusted. Touching [Next] continuously will change the paper size as follows: All Size - A4R - 8.5x11R Touch [Double Fold]. Use the touch panel keypad to enter the desired adjustment value, then touch [Set].
Page 529 Adjustment 06 Fold Paper Width Adjustment Perform this adjustment if folding position processed by the Saddle Stitcher SD-501 dislocates in the folded set. bizhub PRO 1050/1050e 13-71...
Page 530 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [05 Saddle Stitcher Adj.]. Touch [06 Fold Paper Width Adjustment] to display the Fold Paper Width Adjustment Screen. Touch the [COPY] tab to display the Copy Screen. Load the desired size of paper to be adjusted on a tray, specify the number of sheets to 5, then press [Start].
Page 531 Adjustment 07 Trimming Adjustment Perform this adjustment to increase/decrease the trimming width. bizhub PRO 1050/1050e 13-73...
Page 532 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [05 Saddle Stitcher Adj.]. Touch [07 Trimming Adjustment] to display the Trimming Adjustment Screen. Touch the [COPY] tab to display the Copy Screen. Load the desired size of paper to be adjusted on a tray, specify Fold&Staple, then press [Start].
Page 533 Adjustment Details Enter the value so that the cover should be cut more than 2.0 mm. If “All Size” is selected as paper size, the entered adjustment value will be applied to all sizes. If specific paper size is selected, adjustment value will be the sum of the entered value and the value previously specified for “All Size”.
Page 534: Perfect Binder Adjustment
Adjustment 13.11 06 Perfect Binder Adjustment 01 Cover Trimming Adjustment Perform this adjustment to increase/decrease the trimming width of the right cover page determined in Perfect Binding mode. Reminder Be sure to perform 02 Cover Lead Edge Adjustment before this adjust- ment.
Page 535 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [06 Perfect Binder Ad- justment]. Touch [01 Cover Trimming Adjustment] to display the Cover Trimming Adjustment Screen. Touch [Next] or [Back] to select the tray (Main Tray or PB Tray) to feed the cover.
Page 536 Adjustment Use the touch panel keypad to enter the desired adjustment value, then touch [Set]. Available range: -128 (short) to +127 (long), 1 step = 0.1 mm Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained.
Page 537 Adjustment 02 Cover Lead Edge Adjustment Perform this adjustment for the position of left cover page determined in Per- fect Binding mode. bizhub PRO 1050/1050e 13-79...
Page 538 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [06 Perfect Binder Ad- justment]. Touch [02 Cover Lead Edge Adjustment] to display the Cover Lead Edge Adjustment Screen. Touch [Main Tray] or [PB Tray] to select the tray to feed the cover. Touch [Next] or [Back] to select the paper size of the body set to be at- tached with the cover.
Page 539 Adjustment Touch [Return] to restore the Perfect Binder Adjustment Mode Menu Screen. Details If “All Size” is selected as paper size, the entered adjustment value will be applied to all sizes. If specific paper size is selected, adjustment value will be the sum of the entered value and the value previously specified for “All Size”.
Page 540 Adjustment 03 Spine Corner Forming Position Adjustment Perform this adjustment to regulate the position when forming the spine cor- ner of the cover. 13-82 bizhub PRO 1050/1050e...
Page 541 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [06 Perfect Binder Ad- justment]. Touch [03 Spine Corner Forming Position Adjustment] to display the Spine Corner Forming Position Adjustment Screen. Touch the [COPY] tab to display the Copy Screen. Select the PB tray or desired main body tray, then press [Start]. A sample pattern of perfect-bound book will be output.
Page 542 Adjustment 04 Pasting Start Position Adjustment Perform this adjustment for the position to start pasting on the body set. 13-84 bizhub PRO 1050/1050e...
Page 543 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [06 Perfect Binder Ad- justment]. Touch [04 Pasting Start Position Adjustment] to display the Pasting Start Position Adjustment Screen. Touch [Go Ahead] or [Go Back] to select the direction to start pasting. Touch [Next] or [Back] to select the paper size of the body set.
Page 544 Adjustment Touch [Return] to restore the Perfect Binder Adjustment Mode Menu Screen. Reminder If “All Size” is selected as paper size, the entered adjustment value will be applied to all sizes. If specific paper size is selected, adjustment value will be the sum of the entered value and the value previously specified for “All Size”.
Page 545 Adjustment 05 Pasting Finish Position Adjustment Perform this adjustment for the position to finish pasting on the body set. bizhub PRO 1050/1050e 13-87...
Page 546 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [06 Perfect Binder Ad- justment]. Touch [05 Pasting Finish Position Adjustment] to display the Pasting Finish Position Adjustment Screen. Touch [Go Ahead] or [Go Back] to select the direction to finish pasting. Touch [Next] or [Back] to select the paper size of the body set.
Page 547 Adjustment Touch [Return] to restore the Perfect Binder Adjustment Mode Menu Screen. Details If “All Size” is selected as paper size, the entered adjustment value will be applied to all sizes. If specific paper size is selected, adjustment value will be the sum of the entered value and the value previously specified for “All Size”.
Page 548 Adjustment 06 Paste Formation Finish Position Adjustment Perform this adjustment for the position to finish equalizing the paste applied on the body set. 13-90 bizhub PRO 1050/1050e...
Page 549 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [06 Perfect Binder Ad- justment]. Touch [06 Paste Formation Finish Position Adjustment] to display the Paste Formation Finish Position Adjustment Screen. Touch [Next] or [Back] to select the paper size of the body set. Touching [Next] continuously will change the paper size as follows.
Page 550 Adjustment 07 Temperature Adjustment Perform this adjustment to control the condition of paste to be dried by set- ting the temperature on the following sensors inside the melt tank. - Melt Tank -Top: Melt tank temperature sensor/ Up (TH2) - Melt Tank -Mid: Melt tank temperature sensor/ Md (TH3) - Melt Tank -Low: Melt tank temperature sensor/ Lw (TH4) - Pasting Roller: Pasting roller temperature sensor (TH1) Reminder...
Page 551 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [06 Perfect Binder Ad- justment]. Touch [07 Temperature Adjustment] to display the [Temperature Ad- justment Screen]. Touch the [COPY] tab to display the Copy Screen. Select the PB tray or desired main body tray, then press [Start]. A sample pattern of perfect-bound book will be output.
Page 552 Adjustment Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained. Touch [Return] to restore the Perfect Binder Adjustment Mode Menu Screen. 13-94 bizhub PRO 1050/1050e...
Page 553 Adjustment 08 Sub Compile CD Width Adjustment Perform this adjustment for the width in horizontal scanning direction of the body set. Details Use this adjustment if the horizontal scanning direction is unequal on all pages of the body set. If unequalness appears mainly on the latter half of body pages, use 09 Clamp CD Width Adjustment instead.
Page 554 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [06 Perfect Binder Ad- justment]. Touch [08 Sub Compile CD Width Adjustment] to display the Sub Com- pile CD Width Adjustment Screen. Touch [Next] or [Back] to select the paper size of the body set. Touching [Next] continuously will change the paper size as follows.
Page 555 Adjustment Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained. Touch [Return] to restore the Perfect Binder Adjustment Mode Menu Screen. Details If “All Size” is selected as paper size, the entered adjustment value will be applied to all sizes.
Page 556 Adjustment 09 Clamp CD Width Adjustment Perform this adjustment for the width in horizontal scanning direction of the body set. Details Use this adjustment if the horizontal scanning direction is unequal on the latter half of body pages. If unequalness appears on all pages, use 08 Sub Compile CD Width Adjustment instead.
Page 557 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [06 Perfect Binder Ad- justment]. Touch [09 Clamp CD Width Adjustment] to display the Clamp CD Width Adjustment Screen. Touch [Next] or [Back] to select the paper size of the body set. Touching [Next] continuously will change the paper size as follows.
Page 558 Adjustment Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained. Touch [Return] to restore the Perfect Binder Adjustment Mode Menu Screen. Details If “All Size” is selected as paper size, the entered adjustment value will be applied to all sizes.
Page 559 Adjustment 10 Cover Up/Down CD Width Adjustment Perform this adjustment for the horizontal scanning position of the body set and cover. bizhub PRO 1050/1050e 13-101...
Page 560 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [06 Perfect Binder Ad- justment]. Touch [10 Cover Up/Down CD Width Adjustment] to display the Cover Up/Down CD Width Adjustment Screen. Touch [Next] or [Back] to select the tray (Main Tray or PB Tray) to feed the cover.
Page 561 Adjustment 11 Clamp FD Position Adjustment Perform this adjustment for the width in vertical scanning direction of the body set. bizhub PRO 1050/1050e 13-103...
Page 562 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [06 Perfect Binder Ad- justment]. Touch [11 Clamp FD Position Adjustment] to display the Clamp FD Po- sition Adjustment Screen. Touch [Next] or [Back] to select the paper size of the body set. Touching [Next] continuously will change the paper size as follows.
Page 563: Trimmer Count Adjustment
Adjustment 13.12 07 Trimmer Count Adjustment Very often used, the trimmer receiver of the Saddle Stitcher SD-501 may be worn out sooner than expected, with the result that the trimming mode may not function properly. Perform this adjustment to select the count of the trimmer receiver from 300, 500, and 700 times, so that the machine could slightly change the position of trimmer receiver after the set count has passed in order to improve its functionability.
Page 564 Adjustment Procedure Touch [Adjustment] - [02 Finisher Adjustment] - [06 Trimmer Count Ad- justment] to display the Trimming Receiver Count Screen. Touch the display count key to highlight it. Touch [OK] to complete the setting and return to the Finisher Adjust- ment Screen.
Page 565: Controller Setting
Controller Setting POD Administrator...
Page 567: Function Overview
Controller Setting Controller Setting 14.1 Function Overview Setting change concerning the printer controller is available from the Con- troller Setting Menu Screen. Touch [Controller] on the Machine Status Screen. The Controller Setting Menu Screen will be displayed. The menu comprises the following settings. 01 Report Type Use this function to print out the report type selected from the screen.
Page 568: Printer Setting
Controller Setting 02 Printer Setting Various printer settings are available from this screen. For details, refer to “02 Printer Setting” on page 14-10. It may not operate properly depending upon the combination of settings selected. Menu Items Description Setting Options (default is high- lighted) Specify the default output setting 1-6 (...
Page 569 Controller Setting Menu Items Description Setting Options (default is high- lighted) 14 Paper Size Select the paper size to be initially A3, B4, A4, B5, A5, 8x13, 8.25x13, used. 8.125x13, 12x18, 11x17, 8.5x14, When specifing tabs, select the 8.5x13, 8.5x11, 5.5x8.5, A3W, number of tabs as well.
Page 570: Select Printer Setting
Controller Setting Menu Items Description Setting Options (default is high- lighted) 07 CR/LF Mapping Select the line feed code. , CR, LF, CRLF 03 PS Setting(Option) 01 Print PS Error Select to print the error report OFF, when an error occurs while raster- izing PostScript data.
Page 571 Controller Setting 05 Interface Setting Set the timer to terminate the interface. For details, refer to “05 Interface Set- ting” on page 14-7. Menu Items Description Setting Options Parallel Timeout Set the timer to terminate the par- 10 to 300 seconds ( allel port.
Page 572: Report Type
Controller Setting 14.2 01 Report Type Use this function to print out the report type selected from the screen. Procedure Touch [Controller] - [01 Report Type]. Touch the desired report type key to select it. Touch [Execute]. The Controller Setting Menu Screen will be restored, and the Data LED on the control panel blinks to indicate that the printing operation is in progress.
Page 573 Controller Setting If further changes are required, touch the desired key. Touch the [MACHINE] tab to complete the setting and restore the Ma- chine Status Screen. bizhub PRO 1050/1050e 14-9...
Page 574: Printer Setting
Controller Setting 14.3 02 Printer Setting Use this function to register the desired output form. Six types can be spec- ified at maximum. Specify the setting number (1 to 6) first, then specify the following four printer settings for that number. 01 Basic Setting specifies basic settings for printer.
Page 575 Controller Setting Use the touch screen keypad to enter the setting number for your set- ting. Available range is from 1 to 6. Touch [Set] to complete the setting. If wrong number is entered, touch [Reset] to reenter the correct number. Perform the Basic Setting.
Page 576 Controller Setting Touch [01 Basic Setting]. The Basic Setting Menu Screen will be dis- played. Make the desired setting. Touch [Next] or [Forward] to scroll to the de- sired item. The following settings are used unless otherwise specified by the print- er driver.
Page 577 Controller Setting 20 Booklet: Select to use the Booklet function. 21 Adhesive Binding: Select to use the Adhesive binding mode. 22 Print Position: Select the initial print position. 23 Pile Permission: Select to permit piling up the output sheets. Touch [Return] to complete the setting and restore the Printer Setting Screen.
Page 578 Controller Setting 02 Font Number: Specify the font number available from the font source. 03 Symbol Set: Specify the symbol set. 04 Form lines: Specify the number of lines per page. 05 Font point size: Specify the font size by point. 06 Font pitch: Specify the font pitch.
Page 579 Controller Setting Make the desired setting. 01 Print PS Error Select to print the error report when an error occurs while rasteriz- ing PostScript data. 02 PDF PS Conversion error control Select [OK] to stop printing error pages resulted from the memory overflow.
Page 580 Controller Setting Make the desired setting. 01 Auto Paper Select: Select to use APS function. 02 Image Position: Select the image position to be printed on a page. Touch [OK] to complete the setting. The TIFF Setting Menu Screen will be restored.
Page 581: Select Printer Setting
Controller Setting 14.4 03 Select Printer Setting Select the default port number, and specify the output format for each port. Procedure Touch [Controller] - [03 Select Printer Setting]. Touch the key to be specified, then use the touch screen keypad to en- ter the desired number.
Page 582 Controller Setting If further changes are required, touch the desired key. Touch the [MACHINE] tab to complete the setting and restore the Ma- chine Status Screen. 14-18 bizhub PRO 1050/1050e...
Page 583: Spool
Controller Setting 14.5 04 Spool Select to enable, disable, or automatically perform the spool function. Procedure Touch [Controller] - [04 Spool]. Touch the desired key to select it. Touch [OK] to complete the setting. The Controller Setting Menu Screen will be restored. If further changes are required, touch the desired key.
Page 584: Interface Setting
Controller Setting 14.6 05 Interface Setting Set the time for Parallel Timeout and Network Timeout. Procedure Touch [Controller] - [05 Interface Setting]. Touch [Parallel Timeout] or [Network Timeout]. Use the touch screen keypad to enter the time, then touch [Set]. The available range is from 10 to 300.
Page 585 Controller Setting If further changes are required, touch the desired key. Touch the [MACHINE] tab to complete the setting and restore the Ma- chine Status Screen. bizhub PRO 1050/1050e 14-21...
Page 586 Controller Setting 14-22 bizhub PRO 1050/1050e...
Page 587: Utility Screen Settings
Utility Screen Settings POD Administrator...
Page 589: Utility Screen Setting Outlines
Utility Screen Settings Utility Screen Settings 15.1 Utility Screen Setting Outlines Press [Utility/Counter] on the control panel to display the Utility Menu Screen. The Utility Screen includes two types of setting items: one in which a user can set and the other in which a machine manager is required to enter a password.
Page 590 Utility Screen Settings Details The machine manager setting can be established by the user in the initial setting. It is recommended to assign the machine manager who will be the sole person to control the machine manager setting. Please contact your service representative to set up your password.
Page 591 Utility Screen Settings Lists of the function settings 01 System Setting Setting options (default is highlighted) English 01 Language Setting Select the language used in the LCD. 02 Buzzer Setting , Big/Small 01 Buzzer On/Off, Volume Setting Set the buzzer sound (the touch key sound) as touch- ing the screen.
Page 592 Utility Screen Settings 02 Function Setting Setting options (default is highlighted) 01 Feed Tray Setting ATS/APS Switch (Trays 1 to 5): 01 Feed Tray Auto Selection Select ATS for each tray and the priority of the detec- Tray Priority: Tray1/Tray2/Tray3/ tion when ATS functions.
Page 593 Utility Screen Settings 02 Function Setting Setting options (default is highlighted) 05 Tandem Setting /OFF 01 Tandem Machine One Time Data Read Set the tandem machine to receive all the data tran- mitted from the master machine before starting to print.
Page 594 Utility Screen Settings 03 Copy Setting Setting options (default is highlighted) 01 Reset Setting Copy Initial Setting (Original Setting/ 01 Initial Setting Set the initial setting when the machine is reset. Special Image/Zoom/Output Appli- cation/Copy Mode/Paper Preset- ting/Rotation/ADF) 02 Reset Function Setting 01 AUTO RESET Key Setting Full Auto /Initial Setting...
Page 595 Utility Screen Settings 03 Copy Setting Setting options (default is highlighted) 02 Each Function Setting Auto Select /Not Auto Select Auto select of Booklet copy Set the machine to automatically select the Booklet mode when Stapling & Folding or Folding mode is se- lected.
Page 596 Utility Screen Settings 04 Scanner Setting Setting options (default is highlighted) 01 Default Address Setting E-Mail /HDD/FTP/SMB Select the default destination to be displayed when se- lecting the Scanner Screen. 02 Each Function Setting Package PDF File Form Setting (E-Mail) /Division PDF/Pack- Select the default file form when transmitting in E- age TIFF/Division TIFF...
Page 597 Utility Screen Settings 06 Machine Manager Setting 01 System Setting Auto Low Power: 5 min. to 240 min.: 01 Power Save Setting Auto Low Power/ Auto Shut Off 15 min ., Auto Shut Off: OFF to 240 Set the interval time of Auto Low Power and Auto min.: OFF/90 min.
Page 598 Utility Screen Settings 06 Machine Manager Setting 05 Operation Prohibit Set Permit /Prohibit Lock/Delete Mode Memory Lock/unlock or Delete a mode memory that has been programmed. Change Send Address Permit/ Prohibit Permit/prohibit to enter send address manually on the Scanner Screen. Permit/ Prohibit Change Preset Zoom...
Page 599 Utility Screen Settings 06 Machine Manager Setting 09 Perfect Binding Setting P. B. Body 62-71 72-91 01 Useful Paper Weight Select Specify the paper weight available for each of body Cover 72-91 92-130 /131-161 and cover when using Perfect Binder. 02 Paper Count Limit for Perfect Binding 62-71 g Minimjm 10, Maximum 300 Specify the minimum and maximum paper count to...
Page 600 Utility Screen Settings 06 Machine Manager Setting 04 Network Setting IP Address/Subnet Mask/Gateway 01 Machine NIC Setting (For details, p. 17-68) Set the NIC settings. Address/IP Address (Server PC)/ Line Speed Setting 02 Controller NIC Setting (For details, p. 17-70) 01 TCP/IP (For details, p.
Page 601 Utility Screen Settings 06 Machine Manager Setting 05 Copy/Printer Setting 01 JOB Offset Operating Set the machine to offset the copies/printouts of dif- ferent jobs. 02 Continuation Print (Print) Set the machine to output multiple reserve jobs in succession. On(Outside Page Print)/ 03 Page No.
Page 602 Utility Screen Settings 06 Machine Manager Setting 07 Security Setting 00000000 01 Machine Manager Password Change the machine manager password which is reg- istered in the Service mode menu. 02 HDD Management Setting 01 Folder Box List/Delete List and delete the details. List the details of the folder box, and delete it.
Page 603: User Setting
User Setting POD Administrator...
Page 605: System Setting
User Setting User Setting 16.1 01 System Setting 16.1.1 01 Language Setting Select the language used in the touch panel. The initial setting is American English. Procedure Touch [01 System Setting] - [01 Language Setting]. Select the desired English mode. Touch [OK] to complete the setting and return to the Utility Menu Screen.
Page 606: Buzzer Setting
User Setting 16.1.2 02 Buzzer Setting 01 Buzzer ON/OFF, Volume Setting Set the buzzer sound (the touch key sound) as touching the screen, and also select the buzzer volume. 16-4 bizhub PRO 1050/1050e...
Page 607 User Setting Procedure Touch [01 System Setting] - [02 Buzzer Setting]. Touch [01 Buzzer On/Off, Volume Setting]. Touch [On] to highlight it. Adjust the Buzzer volume, as desired. Touch [Small] or [Big] to regulate the buzzer volume of the touch keys. Touch [Off] to highlight it.
Page 608 User Setting 02 Buzzer for Job Stop Setting Select the duration of the buzzer sound when the machine stops. 16-6 bizhub PRO 1050/1050e...
Page 609 User Setting Procedure Touch [01 System Setting] - [02 Buzzer Setting]. Touch [02 Buzzer for Job Stop Setting]. Select the desired time to highlight it. Touch [OK] to complete the setting and return to the Buzzer Setting Screen. Touch [Return] to restore the Utility Menu Screen. bizhub PRO 1050/1050e 16-7...
Page 610: 1Shot Indication Time
User Setting 16.1.3 03 1SHOT Indication Time Select the SHOT indication time to be displayed in the message indication area of the touch panel, such as “Original size A4.” Procedure Touch [01 System Setting] - [03 1 SHOT Message Indication Time]. Touch [3 seconds] or [5 seconds] to highlight it.
Page 611: Default Screen Setting
User Setting 16.1.4 04 Default Screen Setting Select the initial screen to be displayed when the power switch is turned on. Procedure Touch [01 System Setting] - [04 Default Screen Setting]. Select the desired initial screen to highlight it. Touch [OK] to complete the setting and return to the Utility Menu Screen.
Page 612: Auto Reset Setting
User Setting 16.1.5 05 Auto Reset Setting Set the reset interval starting from the completion of a copying job until the machine returns to the initial screen, without selecting any key on the touch panel or the control panel. Procedure Touch [01 System Setting] - [05 Auto Reset Setting].
Page 613: Key Response Time
User Setting 16.1.6 06 Key Response Time Select the response time between touching the key and the machine re- sponses to it. Procedure Touch [01 System Setting] - [06 Key Response Time]. Select the desired time to highlight it. Touch [OK] to complete the setting and return to the Utility Menu Screen.
Page 614: Change User Password
User Setting 16.1.7 07 Change User Password Change a user password which the user has registered for user authentica- tion. Details The changed password is reflected to the user authentication setting de- scription. 16-12 bizhub PRO 1050/1050e...
Page 615 User Setting Procedure Touch [01 System Setting] - [07 Change User Password]. Enter the user name and the password then touch [OK]. Enter a new user password in [New Password]. Reenter the new user password in [Check Input]. Touch [OK] to complete the setting and return to the Utility Menu Screen.
Page 616: Function Key Setting
User Setting 16.1.8 08 Function Key Setting Assign up to five job settings previously stored using Mode Memory. The registered settings can be recalled simply by touching the corresponding function key. Details The job setting to be registered to a function key should firstly be regis- tered using Mode Memory.
Page 617 User Setting Procedure Touch [01 System Setting] - [08 Function Key Setting]. On the left side of the Function Key Setting Screen, touch to highlight the function key (F1 - F5) to be registered or deleted. Register or delete Mode Memory job settings. To register a job setting: Touch the arrow keys (,) and (+) to display the desired Mode Mem- ory item key.
Page 618 User Setting To delete a job setting: Touch [Delete]. A popup menu appears to confirm that the Mode Memory job set- ting will be deleted from the selected function key. Even though deleted from the function key, the job setting still re- mains in Mode Memory.
Page 619: Function Setting
User Setting 16.2 02 Function Setting 16.2.1 01 Feed Tray Setting 01 Feed Tray Auto Selection Select the tray size setting to be detected when ATS functions. You may also select the priority of the detection for each tray. bizhub PRO 1050/1050e 16-17...
Page 620 User Setting Procedure Touch [02 Function Setting] - [01 Feed Tray Setting]. Touch [01 Feed Tray Auto Selection]. Touch to highlight the desired tray key under [ATS/APS Switch]. The selected tray is automatically detected when ATS functions. The trays not selected will not be detected even when ATS functions. The selected tray will be displayed under [Tray Priority] as the tray key.
Page 621: Ats Permit
User Setting 16.2.2 02 ATS Permit Set ATS On or Off. bizhub PRO 1050/1050e 16-19...
Page 622 User Setting Procedure Touch [02 Function Setting] - [01 Feed Tray Setting]. Touch [02 ATS Permit]. Select [On] when ATS is used, and [Off] when ATS is not used. Touch [OK] to complete the setting and return to the Feed Tray Setting Menu Screen.
Page 623: Auto Paper Type
User Setting 16.2.3 03 Auto Paper Type Select the paper type setting of the tray which is automatically selected when ATS functions. When the paper type that is not specified with this function is designated to the tray that is automatically selected by ATS, the machine in- dicates the paper type unmatched.
Page 624 User Setting Procedure Touch [02 Function Setting] - [01 Feed Tray Setting]. Touch [03 Auto Paper Type]. Select the paper type of the tray which is automatically selected when ATS functions. Touch to highlight the desired type of keys under [Paper Type], [Weight], [Colored Paper], and [Hole-Punch].
Page 625: Each Function Setting
User Setting 16.2.4 02 Each Function Setting Use this function to make the following four settings. - Select to enter a decimal point for image shift. - Select the interval time that printing via PC is prohibited after touching a touch key on the touch panel.
Page 626 User Setting Touch [Decimal On] or [Decimal Off] to specify image shift in decimal point or not. Select the desired interval time key of the right side of [Printer Prohibit Timer] to set the timer. Touch [On] or [Off] for each of Needless Tab Paper Exit and Auto Image Shift (Tab Print) to specify whether or not to use those functions.
Page 627: Density Setting
User Setting 16.2.5 03 Density Setting 01 Density Shift for Enhance Mode Select the desired copy density level manually from nine levels on the Copy Screen, and also shift each of nine density levels to three levels lighter or three levels darker. Density shift can be applied to each Enhance modes: Auto (Text/photo), Low Contrast, Photo, and Text.
Page 628 User Setting Procedure Touch [02 Function Setting] - [03 Density Setting]. Touch [01 Density Shift for Enhance Mode]. Touch the desired numeric key (from 0 to 5) for each Enhance mode to specify the desired Density shift. Touch [OK] to complete the setting and return to the Density Setting Menu Screen.
Page 629 User Setting 02 User Density Setting The copy density level is divided into 16 levels between Darker and Normal, and between Normal and Lighter, respectively. Select and preset two levels from the 32 levels. The preset density level setting can be recalled from Spe- cial Image on the Copy Screen.
Page 630 User Setting Procedure Touch [02 Function Setting] - [03 Density Setting]. Touch [02 User Density Setting]. Touch [User Density 1] or [User Density 2]. Touch [Darker] or [Lighter] to select the desired density level to preset either between the darkest and normal or between normal and the lightest.
Page 631: Photo Mode Density Setting
User Setting 16.2.6 03 Photo Mode Density Setting Set the density level of Photo Mode to be specified in AE. bizhub PRO 1050/1050e 16-29...
Page 632 User Setting Procedure Touch [02 Function Setting] - [03 Density Setting]. Touch [03 Photo Mode Density Setting]. Select the desired density key from [Lighter], [Normal] and [Darker]. Touch [OK] to complete the setting and return to the Density Setting Menu Screen. Touch [Return] to restore the Utility Menu Screen.
Page 633: Image Density Selection
User Setting 16.2.7 04 Image Density Selection Select the image density on the Copy Screen. Adjust the image density of any dark part of the original to darker (maximum dark) or lighter, just like off- set printing. Similar to printing materials such as books, this feature is useful to make texts lighter in order to ease the eye strain.
Page 634 User Setting Procedure Touch [02 Function Setting] - [03 Density Setting]. Touch [04 Image Density Selection]. Touch the desired density key to highlight it. Touch [OK] to complete the setting and return to the Density Setting Menu Screen. Touch [Return] to restore the Utility Menu Screen. 16-32 bizhub PRO 1050/1050e...
Page 635: Preset Zoom
User Setting 16.2.8 04 Preset Zoom Set three types of the preset zoom on the Preset Zoom Screen. The initial setting for Preset Zoom1 is 4.000, Preset Zoom2 is 2.000, and Preset Zoom3 is 0.500. Procedure Touch [02 Function Setting] - [04 Preset Zoom]. Touch the desired preset key (from 1 to 3) and display the desired zoom ratio on the right side of the keys using the touch panel keypad.
Page 636: Tandem Setting
User Setting 16.2.9 05 Tandem Setting The following settings are provided for the tandem output mode, which is specified on the master machine and used to distribute plural number of print quantity among two machines (master and tandem). 01 Tandem Machine One Time Data Read: On/Off Select [Off] so that both master and tandem machines start printing at the same time, while the master machine continues scanning the image data.
Page 637 User Setting bizhub PRO 1050/1050e 16-35...
Page 638 User Setting 16-36 bizhub PRO 1050/1050e...
Page 639 User Setting Procedure Touch [02 Function Setting] - [05 Tandem Setting]. Touch the item key (from 01 to 04) and make a selection for each. Touch [01 Tandem Machine One Time Data Read], select [On] or [Off], then touch [OK]. Touch [02 Tandem Machine Wait/Proof], select [Permit ]or [Prohib- it], then touch [OK].
Page 640: User Paper Selection
User Setting 16.2.1006 User Paper Selection Select the user paper setting to be used when “User” is specified as paper type. Details For details of three types of user paper setting previously registered, con- tact your service representative. Procedure Touch [02 Function Setting] - [06 User Paper Selection]. Touch the desired User Paper key (from 1 to 3) to highlight it.
Page 641: Copy Setting
User Setting 16.3 03 Copy Setting 16.3.1 01 Reset Setting Set the copying condition as desired when the machine is reset. Also select whether to reset the machine or not when inserting a key counter or a copy card under the following reset conditions. Resetting the machine: - when the power is turned off - when Auto Reset is on...
Page 642 User Setting 16-40 bizhub PRO 1050/1050e...
Page 643 User Setting Procedure Touch [03 Copy Setting] - [01 Reset Setting]. Touch [01 Initial Setting]. Set the following setting items in initial conditions: Original Setting, Special Image, AES On/Off, Zoom, Output Application, Copy Mode, Auto Paper Select/Paper Presetting, and Rotation On/Off. Follow the same procedure as setting it on the Copy Screen.
Page 644 User Setting 02 Reset Function Setting When the machine is reset, select the copying conditions from the factory default setting (Full Auto), Initial Set which is set at “03 Copy Setting - 01 Re- set Setting - 01 Initial Setting”, or the copying condition which is preset to Mode Memory 30.
Page 645 User Setting Procedure Touch [03 Copy Setting] - [01 Reset Setting]. Touch [02 Reset Function Setting]. Select the copying conditions when resetting the machine. AUTO RESET Key Setting: Touch [Full Auto] to set to the factory default setting (Full Auto). Touch [Initial Setting] to set as “03 Copy Setting - 01 Reset Setting - 01 Initial Setting”.
Page 646 User Setting 03 Initial by Key Counter Insert Select to reset or not when inserting the key counter and the copy card. 16-44 bizhub PRO 1050/1050e...
Page 647 User Setting Procedure Touch [03 Copy Setting] - [01 Reset Setting]. Touch [03 Initial by Key Counter Insert]. Touch [On] to reset and [Off] not to reset, when inserting the key coun- ter or the copy card. Touch [OK] to complete the setting and return to the Reset Setting Menu Screen.
Page 648: Each Function Setting
User Setting 16.3.2 02 Each Function Setting The following features can be provided by switching the setting. Auto select of Booklet copy Set the machine with SD-501 mounted to automatically select the Book- let mode when Stapling & Folding or Folding mode is selected. Original Glass AMS The machine detects the size of the original and selects the appropriate magnification ratio to correspond to the selected paper size.
Page 649 User Setting bizhub PRO 1050/1050e 16-47...
Page 650 User Setting Procedure Touch [03 Copy Setting] - [02 Each Function Setting]. Select On/Off or touch the desired key to each item on the left side of the screen. There are two setting screens. Touch [Next] and [Previous] to switch between the screens.
Page 651: Scanner Setting
User Setting 16.4 04 Scanner Setting 16.4.1 01 Default Address Setting Select the default destination of the image scanned when selecting the Scanner Screen. Select one from the following four destinations: - E-Mail (E-Mail address) - HDD (Box No.) - FTP (FTP server address) - SMB bizhub PRO 1050/1050e 16-49...
Page 652 User Setting Procedure Touch [04 Scanner Setting] - [01 Default Address Setting]. Touch the desired key for the destination. Touch [OK] to complete the setting and return to the Utility Menu Screen. 16-50 bizhub PRO 1050/1050e...
Page 653: Each Function Setting
User Setting 16.4.2 02 Each Function Setting Select the default settings for the file form, resolution, and original density/ image type when selecting the Scanner Screen. File Form Setting (E-Mail) Select the data form for transmitting scanned data attached to an e-mail, from Package PDF, Division PDF, Package TIFF, and Division TIFF.
Page 654 User Setting Procedure Touch [04 Scanner Setting] - [02 Each Function Setting]. Touch the desired key to each item on the left side of the screen. Touch [OK] to complete the setting and return to the Utility Menu Screen. Details When transmitting simultaneously to multiple destinations, the file form setting cannot be specified individually.
Page 655: Touch Screen Adjustment
User Setting 16.5 05 Touch Screen Adjustment Use this function to check the touch screen and realign the position of the touch sensor that may have shifted. Details The Touch Screen Adjustment Screen can be accessed also by pressing [5] of the control panel keypad with the Utility Menu Screen displayed. Service can set the machine to forbid users to access this function from the menu and to display the Touch Screen Adjustment Screen only when pressing [5] with the Utility Menu Screen displayed.
Page 656 User Setting If the coordinates fall out of the range of the standard value in step 3, or the buzzer tone does not sound in step 4, repeat the adjustment pro- cedure from steps 2 to 4 or contact your service representative. Press [1] of the control panel keypad to return to the screen before pressing [Utility/Counter] on the control panel.
Page 657: Machine Manager Setting
Machine Manager Setting POD Administrator...
Page 659: Machine Manager Setting Outlines
Machine Manager Setting Machine Manager Setting 17.1 Machine Manager Setting Outlines This section describes the items which the machine manager can set on the Utility/Counter Screen, and the procedure of setting these items. In the initial condition, the machine manager setting can be specified without entering the machine manager password.
Page 660 Machine Manager Setting How to access the Machine Manager Setting Menu Press [Utility/Counter] on the control panel to display the Utility Menu Screen. 17-4 bizhub PRO 1050/1050e...
Page 661 Machine Manager Setting Touch [06 Machine Manager Setting]. The Machine Manager Setting Menu is displayed. When the Password Input Screen is displayed, enter the eight-digit ma- chine manager password then touch [OK]. Set each function items. Touch [Return] to restore the Utility Menu Screen. bizhub PRO 1050/1050e 17-5...
Page 662: System Setting
Machine Manager Setting 17.2 01 System Setting 17.2.1 01 Power Save Setting Specify Auto Low Power or Auto Shut Off when setting the Power Save mode manually, and select the interval of time that must elapse before Auto Low Power and Auto Shut Off. Procedure Touch [01 System Setting] - [01 Power Save Setting].
Page 663 Machine Manager Setting Select the interval of time that must elapse before turning to Auto Low Power automatically. Touch the arrow keys (,) and (+) in each area to select a specific waiting period before activating Auto Low Power. The initial setting is 15 minutes. Note The period of time selected for Auto Low Power cannot exceed the Auto Shut Off setting.
Page 664: Time And Date Setting
Machine Manager Setting 17.2.2 02 Time and Date Setting Set the current date and time, the summer time, and also the time difference. The default setting for the summer time is off. Procedure Touch [01 System Setting] - [02 Time and Date Setting]. Adjust the time.
Page 665 Machine Manager Setting Set the summer time. The summer time is initially deactivated. To activate the summer time (Daylight Savings Time) function, touch [Summer Time] to highlight it. The Present time will gain one hour. The Difference in time setting is provided in order to give the time dif- ference information at the same time when an e-mail is received.
Page 666: Weekly Timer Setting
Machine Manager Setting 17.2.3 03 Weekly Timer Setting This function can be accessed only by the machine manager. The Weekly Timer is a machine management function that shuts down power to the machine on a daily or hourly basis, and can be programmed specifi- cally for lunch breaks, weekends and holidays, or any time the copier is not required.
Page 667 Machine Manager Setting 01 Weekly Timer On/Off Setting Enable and disable the Weekly Timer function. bizhub PRO 1050/1050e 17-11...
Page 668 Machine Manager Setting Procedure Touch [01 System Setting] - [03 Weekly Timer Setting] - [01 Weekly Timer On/Off Setting]. Touch [Weekly timer On] to activate Weekly Timer, or touch [Weekly timer Off] to deactivate Weekly Timer. The default setting is [Weekly Timer Off].
Page 669 Machine Manager Setting 02 Timer Setting Use this function to set the On/Off times in hours and minutes for each day of the week or set the collective time for the entire week, i.e., the same On/ Off time for a certain day of the week. bizhub PRO 1050/1050e 17-13...
Page 670 Machine Manager Setting Procedure Touch [01 System Setting] - [03 Weekly Timer Setting] - [02 Timer Set- ting]. When the Timer Setting Screen is displayed, the On-time of Monday is always highlighted. Enter a two-digit On-hour (ex. 8 a.m. is 08) and a two-digit On-minute (ex.
Page 671 Machine Manager Setting When this screen is displayed, the On and Off times are always set at 00:00~00:00. Touch to highlight the day(s) of the week to be set. More than one can be selected at a time. Enter the On-time and Off-time using the touch panel keypad, and then touch [Set] after each entry.
Page 672 Machine Manager Setting 03 Timer Action On/Off Setting Use this function to set the timer On/Off for a given day of a given month. Set the On-Off condition for specific days individually or collectively for all Mon- days through Sundays of the given month. Note The default setting is collective: On for Mondays through Saturdays, and Off for Sundays.
Page 673 Machine Manager Setting Procedure Touch [01 System Setting] - [03 Weekly Timer Setting] - [03 Timer Ac- tion On/Off Setting]. Use the arrow keys (,) and (+) to scroll to the desired month. Touch the key for the desired day to activate the timer on the calendar dis- played on the centre of the screen.
Page 674 Machine Manager Setting 04 Lunch Hour Off Setting The Weekly Timer function turns the machine On and Off once a day. Use the Lunch Hour Off Setting to shut down the power during the lunch break and then turn it on again according to the Weekly Timer function setting. Only one off-time interval can be programmed.
Page 675 Machine Manager Setting Procedure Touch [01 System Setting] - [03 Weekly Timer Setting] - [04 Lunch Hour Off Setting]. Touch [Function Valid] to activate the Lunch hour off function. Set Off- time and Restart time using the touch panel keypad, and then touch [Set] after each entry.
Page 676 Machine Manager Setting 05 Set Password for Timer Interrupt Use this password setting mode to establish a four-digit password required for using the Timer Interrupt function. The default password of 0000 allows the timer function to be interrupted without entering the password. 17-20 bizhub PRO 1050/1050e...
Page 677 Machine Manager Setting Procedure Touch [01 System Setting] - [03 Weekly Timer Setting] - [05 Set Pass- word for Timer Interrupt]. Use the touch panel keypad to enter a four-digit password. Note When the password setting is 0000, Timer Interrupt can be used simply by turning the machine off, then on.
Page 678: Management List Print
Machine Manager Setting 17.2.4 04 Management List Print Use this function to print out the list selected from the following items. Mode memory list Programmed contents of Mode memory User management list Home position settings selected by user 17-22 bizhub PRO 1050/1050e...
Page 679 Machine Manager Setting Use management list Information controlled by user authentication or division authentication Font pattern list Font patterns used in the machine bizhub PRO 1050/1050e 17-23...
Page 680 Machine Manager Setting Audit log report Audited log 17-24 bizhub PRO 1050/1050e...
Page 681 Machine Manager Setting Procedure Touch [01 System Setting] - [04 Management List Print]. Touch any key to print the list. Press the [COPY] tab to display the Copy Screen. Press [Start] on the control panel to start printing the selected list. To suspend printing, press [Stop].
Page 682: Operation Prohibit Set
Machine Manager Setting 17.2.5 05 Operation Prohibit Set Use this function to permit or prohibit programmed contents of Mode mem- ory. Lock/Delete mode memory: Lock/unlock or delete a mode memory that has been programmed. The settings of a locked mode memory cannot be changed. Change send address: Permit/prohibit to enter send address manually on the Scanner Screen.
Page 683 Machine Manager Setting Procedure Touch [01 System Setting] - [05 Operation Prohibit Set]. Select [Permit] or [Prohibit] of Mode memory. Touch [Lock/Delete Mode Memory]. The programmed name is displayed on the right side of the Mode memory number, when the setting is already programmed. Touch the key on the left side of the desired Mode memory number.
Page 684 Machine Manager Setting Touch the Mode memory number you want to delete. Use the arrow keys to scroll to the desired Job number, if required. Touch [Delete]. Selected programs and the name will be deleted from the Mode memory. Note Locked Mode memory is deleted and a lock is canceled.
Page 685: Expert Adjustment
Machine Manager Setting 17.2.6 06 Expert Adjustment 01 Original Scan Area Setting Select to delete or not the outside area of the original from the following three ways: Erase Outside of Original: Set the machine any time to delete the outside area of the original. On –...
Page 686 Machine Manager Setting Procedure Touch [01 System Setting] - [06 Expert Adjustment] - [01 Original Scan Area Setting]. Touch the desired key to highlight it. Touch [OK] to complete the setting and return to the Expert Adjustment Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. 17-30 bizhub PRO 1050/1050e...
Page 687 Machine Manager Setting 02 ADF Frame Erasure Setting Set Frame Erasure to function anytime when copying in ADF mode, and set the amount of the outside area to be deleted. bizhub PRO 1050/1050e 17-31...
Page 688 Machine Manager Setting Procedure Touch [01 System Setting] - [06 Expert Adjustment] - [02 ADF Frame Erasure Setting]. Touch the desired amount of outside area to be deleted. Touch [None] if deleting the outside area is not necessary. Touch [OK] to complete the setting and return to the Expert Adjustment Menu Screen.
Page 689 Machine Manager Setting 03 Non Image Area Erase Setting Use this function to select the erase mode, and set the density level of the original (five levels). The default setting is [Auto]. bizhub PRO 1050/1050e 17-33...
Page 690 Machine Manager Setting Procedure Touch [01 System Setting] - [06 Expert Adjustment] - [03 Non Image Area Erase Setting]. Select the erase mode and the density level of the original. Touch [Auto] to automatically select the appropriate settings for the original placed on the original glass for either mode.
Page 691: Size Setting
Machine Manager Setting 17.2.7 07 Size Setting Use this function to select the detected paper type of the original and the minimum size of the original placed on the original glass. Procedure Touch [01 System Setting] - [07 Size Setting]. Select the paper type to be detected in ADF mode or when the original is placed on the original glass.
Page 692: Annotation Setting
Machine Manager Setting 17.2.8 08 Annotation Setting Use this function to newly register, edit, or delete annotations. For setting an annotation, the following items are provided: Title: Enter the title of annotation within 12 alphanumerical characters. Item1, 2, and 3: Specify the contents of each item in printing order, from among Type In, Date/Time, and Annotation No.
Page 693 Machine Manager Setting bizhub PRO 1050/1050e 17-37...
Page 694 Machine Manager Setting 17-38 bizhub PRO 1050/1050e...
Page 695 Machine Manager Setting bizhub PRO 1050/1050e 17-39...
Page 696 Machine Manager Setting 17-40 bizhub PRO 1050/1050e...
Page 697 Machine Manager Setting Procedure Touch [01 System Setting] - [08 Annotation Setting]. Register an annotation. Touch a non-registered title key on the Annotation Setting Screen, then touch [New Register]. The Annotation New Register Screen will be displayed. Details If selected title key has already been registered, New Register remains dimmed and cannot be touched.
Page 698 Machine Manager Setting When [Annotation No.] is selected: The Annotation Number Setting Screen will be displayed. Touch [On] or [Off] on the right side of Type In indication to select whether to print Type In words or not. To specify the Type In words, touch [Set] on the right side of Type In indication to display the Input Type In Screen, enter the desired words, then touch [OK].
Page 699: Perfect Binding Setting
Machine Manager Setting 17.2.9 09 Perfect Binding Setting 01 Useful Paper Weight Select Use this function to specify the paper weight available for each of body and cover when using Perfect Binder. bizhub PRO 1050/1050e 17-43...
Page 700 Machine Manager Setting Procedure Touch [01 System Setting] - [09 Perfect Binding Setting] - [01 Useful Paper Weight Select]. Touch the desired paper weight key for each of P.B. Body and Cover to highlight it. Note If one of the paper weight selected here is not specified for the tray to be used in the perfect binding mode, the binding operation will become un- available with an “unsuitable”...
Page 701 Machine Manager Setting 02 Paper Count Limit for Perfect Binding Use this function to specify the minimum and maximum paper count to be bound each for paper weight. bizhub PRO 1050/1050e 17-45...
Page 702 Machine Manager Setting Procedure Touch [01 System Setting] - [09 Perfect Binding Setting] - [02 Paper Count Limit for Perfect Binding]. Touch the desired minimum and maximum count limit keys for each paper weight to highlight it. Touch [OK] to complete the setting and return to the Perfect Binding Setting Menu Screen.
Page 703 Machine Manager Setting 03 Stop Setting for P. B. Cover Unfit Length Use this function to stop/continue the current job when the cover width is not suitable for the body paper size and thickness. bizhub PRO 1050/1050e 17-47...
Page 704 Machine Manager Setting Procedure Touch [01 System Setting] - [09 Perfect Binding Setting] - [03 Stop Set- ting for P. B. Cover Unfit Length]. Touch [Temporary Stop] or [Not Temporary Stop] to highlight it. Touch [OK] to complete the setting and return to the Perfect Binding Setting Menu Screen.
Page 705: Manager/Machine Register
Machine Manager Setting 17.3 02 Manager/Machine Register 17.3.1 01 Machine Manager Register Use this function to register the machine manager name and the extension number which are displayed on the left side of the Utility Menu Screen. bizhub PRO 1050/1050e 17-49...
Page 706 Machine Manager Setting Procedure Touch [02 Manager/Machine Register] - [01 Machine Manager Regis- ter]. Touch [Name Input] to display the Machine Manager Name Input Screen. Use the touch panel keypad to register the machine manager name. The eight characters including a hyphen (-) can be entered. Touch [OK] to complete the setting to return to the previous screen.
Page 707: Use Auth./Volume Track
Machine Manager Setting 17.4 03 Use Auth./Volume Track 17.4.1 01 Authentication Method Use this function to select any function of User Authentication and Volume Track. Authentication settings can be altered according to the user authen- tication and volume track settings. 01 Authentication Setting Establish the authentication settings by combining the following six ele- ments.
Page 708 Machine Manager Setting 17-52 bizhub PRO 1050/1050e...
Page 709 Machine Manager Setting Procedure Touch [03 User Auth./Volume Track] - [01 Authentication Method] - [01 Authentication Setting]. Select [On] or [Off] on the right side of [User Authentication], [Section Authentication], [Section Name Input], and [User/Section Auth. Con- nect]. Select [At Auto Reset] or [At JOB Complete] on the right side of [Pass- word Input Timing].
Page 710 Machine Manager Setting 02 Section Management Setting Use this function to set Copy/Printer or Scanner jobs managed by the sec- tion, and select the machine condition in which the machine stops due to reaching the copy limit. Details If [Copy/Printer] or [Scanner] is set to Off when Section Authentication is set to On on the Authentication Method Setting Screen, the section pass- word is not required to enter for authentication.
Page 711 Machine Manager Setting Procedure Touch [03 User Auth./Volume Track] - [01 Authentication Method] - [02 Section Management Setting]. Select [On] or [Off] on the right side of [Copy/Printer] and [Scanner], re- spectively. Select [Immediately], [After Print], or [Warning Only] on the right side of [Limit Reached Stop Setting].
Page 712: Volume Track
Machine Manager Setting 17.4.2 02 Volume Track Use this function to assign a number to each section, and set a section name, password and limit value to each number. The registered section management setting is listed on the screen. Select the section management setting from the list and change, reset or delete the setting.
Page 713 Machine Manager Setting bizhub PRO 1050/1050e 17-57...
Page 714 Machine Manager Setting 17-58 bizhub PRO 1050/1050e...
Page 715 Machine Manager Setting Procedure Touch [03 User Auth./Volume Track] - [02 Volume Track]. Follow the instructions below for adding, changing and deleting the section setting, and also resetting the copy count. To change section settings: Touch [Next] or [Previous] to display the section name to be changed and touch to highlight it.
Page 716 Machine Manager Setting Touch [Password] to display the input screen. Enter the password and touch [OK]. You may enter eight digits for the password. For the details on entering texts in the input screen, see the appendix. Touch [Limit] to display the input screen. Enter the copy limit value and touch [OK].
Page 717: User Authentication Set
Machine Manager Setting 17.4.3 03 User Authentication Set Use this function to assign a number to each user, and set a user name, password and limit value to each number. The registered user setting is listed on the screen. Select the user setting from the list and change, reset or delete the setting.
Page 718 Machine Manager Setting 17-62 bizhub PRO 1050/1050e...
Page 719 Machine Manager Setting bizhub PRO 1050/1050e 17-63...
Page 720 Machine Manager Setting Procedure Touch [03 User Auth./Volume Track - [03 User Authentication Set. Follow the instructions below for adding, changing and deleting the user setting, and also resetting the copy count. To change user settings: Touch [Next] or [Previous] to display the user name to be changed and touch to highlight it.
Page 721 Machine Manager Setting Touch [Belong Section] to display the screen to select a section be- long to. Touch [Next] or [Previous] to display the desired section name, touch to highlight it, then touch [OK]. Details When [User/Section Auth. Connect] is set to On on the Authentication Method Setting Screen, [Belong Section] can be specified.
Page 722 Machine Manager Setting To reset user count: Touch [Next] or [Previous] to display the user name to reset the count and touch to highlight it. Touch [Count Reset] to display the Reset Confirmation popup screen. Touch any key to reset. Touch [Cancel] when not resetting. To reset all count: Touch [All Count Reset] to display the Reset Confirmation popup screen.
Page 723: Non Register/Output Set
Machine Manager Setting 17.4.4 04 Non register/Output Set Use this function to limit the output setting of an unregistered user or section. When this function is set to On, only the initial output setting can be set to any job under a condition of which user authentication and/or section au- thentication is set to Off.
Page 724: Network Setting
Machine Manager Setting 17.5 04 Network Setting 17.5.1 01 Machine NIC Setting Control the NIC settings such as the IP address and line speed of the ma- chine. 17-68 bizhub PRO 1050/1050e...
Page 725 Machine Manager Setting Procedure Touch [04 Network Setting] - [01 Machine NIC Setting]. Specify the following items. Enter numeric values using the touch panel keypad. After entering a value, touch [Set]. The next item becomes highlighted for setting. Con- tinue in this manner. IP Address Enter the IP address of the machine.
Page 726: Controller Nic Setting
Machine Manager Setting 17.5.2 02 Controller NIC Setting Specify the controller settings. Various default settings or network settings can be customized as required. List of the Network Settings Specify the settings for connecting a network printer and network scanner, and the settings for TCP/IP, RAW port numbers, IP Filter (permission/denial), and ping.
Page 727 Machine Manager Setting Specific setting and Description Setting options (highlighted: de- fault) TCP/IP Filter denial settings * Specify to use the denial settings or not, and the range in which to deny connections. 0.0.0.0 - 0.0.0.0 (0 - 255) Network Test Ping Address Max.
Page 728 Machine Manager Setting Specific setting and Description Setting options (highlighted: de- fault) Max. 191 characters combining NDS Context Name If Novell Directory Service (NDS) is used, specify a symbols and alphanumerics can priority NDS context name. It should be specified as be used.
Page 729 Machine Manager Setting Specify the settings for connecting network printer and the IPP settings. For details, refer to “03 IPP” on page 17-91. Specific setting and Description Setting options (highlighted: de- fault) 03 IPP Specify to use IPP or not. /Not Use IPP Print Job Accept Specify to accept IPP print jobs.
Page 730 Machine Manager Setting Specify to use Scan to HDD/Scan to FTP for transmission, the proxy server setting, and the passive function. For details, refer to “04 FTP” on page 17-94. Specific setting and Description Setting options (highlighted: de- fault) 04 FTP Server * Specify to use the machine as an FTP server.
Page 731 Machine Manager Setting Specify the SNMP settings. For details, refer to “05 SNMP” on page 17-96. Specific setting and Description Setting options (highlighted: de- fault) 05 SNMP SNMP * Specify to use SNMP or not. /Not Use public Read Community Name Specify a Read Community Name.
Page 732 Machine Manager Setting Specify the settings for connecting network printer and the AppleTalk settings. For details, refer to “07 AppleTalk” on page 17-100. Specific setting and Description Setting options (highlighted: de- fault) 07 AppleTalk AppleTalk Selecting enables AppleTalk as the print server Use/ Not Use protocol.
Page 733 Machine Manager Setting Specify the settings for an e-mail send/receive, division for transmitted data and authentication, and save the template of titles and bodies frequently used. For details, refer to “08 E-Mail” on page 17-102. Specific setting and Description Setting options (highlighted: de- fault) 08 E-Mail E-Mail Send Setting...
Page 734 Machine Manager Setting Specific setting and Description Setting options (highlighted: de- fault) 08 E-Mail E-Mail Receive Setting 0.0.0.0 POP Server Address Specify an address of the POP server that is used to Max. 255 characters combining receive e-mail. symbols and alphanumerics can be used.
Page 735 Machine Manager Setting Specify the Alert Mail settings. For details, refer to “10 Alert Mail” on page 17-110. Specific setting and Description Setting options (highlighted: de- fault) 10 Alert Mail E-Mail Transmission Specify to use e-mail transmission for alert notification. Max.
Page 736 Machine Manager Setting Specific setting and Description Setting options (highlighted: de- fault) Max. 15 characters combining Password Specify a password. symbols and alphanumerics can be used. Realm Max. 255 characters combining Specify a realm (domain name). If the SMTP server symbols and alphanumerics can with which to communicate requires a realm, this be used.
Page 737 Machine Manager Setting Specify the settings for third party applications. For details, refer to “12 AP I/F” on page 17-117. Specific setting and Description Setting options (highlighted: de- fault) 12 AP I/F AP I/F Specify to use AP I/F . /Not Use AP I/F over SSL If SSL is used for PSWC communication, this setting is...
Page 738 Machine Manager Setting Specify the SNMP Trap setting. For details, refer to “15 SNMP Trap” on page 17-123. Specific setting and Description Setting options (highlighted: de- fault) 15 SNMP Trap SNMP Trap Tranmission Specify to transmit SNMP Trap or not. Authentication Failure Trans Specify to transmit by SNMP in the case taht any au- thentication failure in Read Community Name or Write...
Page 739 Machine Manager Setting 01 TCP/IP Specify the settings for connecting a network printer and network scanner, and the settings for TCP/IP, RAW port numbers, IP Filter (permission/denial), and ping. bizhub PRO 1050/1050e 17-83...
Page 740 Machine Manager Setting 17-84 bizhub PRO 1050/1050e...
Page 741 Machine Manager Setting Procedure Touch [04 Network Setting] - [02 Controller NIC Setting] - [01 TCP/IP]. For each item, select or enter a required value. Use [Previous] or [Next] as required. TCP/IP Select [Enable] or [Disable]. DHCP Select [Enable] or [Disable]. IP Address Touch [IP Address] to display an address input screen.
Page 742 Machine Manager Setting Network Speed Select an appropriate key. TCP/IP RAW port settings Touch an appropriate RAW port number to display a touch panel keypad input screen. After entering in the field, touch [OK]. To specify to use individual ports or not, select [Use] or [Not Use] to the right of each RAW port key.
Page 743 Machine Manager Setting 02 NetWare Specify the settings for connecting network printer, and the NetWare set- tings. Where Novell NetWare is not used, make sure that [Not Use] is selected. bizhub PRO 1050/1050e 17-87...
Page 744 Machine Manager Setting Procedure Touch [04 Network Setting] - [02 Controller NIC Setting] - [02 NetWare]. For each item, select or enter a required value. Use [Previous] or [Next] as required. 17-88 bizhub PRO 1050/1050e...
Page 745 Machine Manager Setting NetWare Setting NetWare Select [Use]. Frame Type Select a frame type. Operation Mode Select an appropriate operation mode. NetWare Pserver Setting Print Server Name Touch [Print Server Name] to display an input screen. After entering in the field, touch [OK]. Print Server Password Touch [Print Server Password] to display an input screen.
Page 746 Machine Manager Setting After you have changed the settings, turn off the sub power, then turn off and on the main power. Details When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly.
Page 747 Machine Manager Setting 03 IPP Specify the settings for connecting network printer and the IPP settings. bizhub PRO 1050/1050e 17-91...
Page 748 Machine Manager Setting 17-92 bizhub PRO 1050/1050e...
Page 749 Machine Manager Setting Procedure Touch [04 Network Setting] - [02 Controller NIC Setting] - [03 IPP]. For each item, select or enter a required value. Use [Previous] or [Next] as required. IPP Setting Specify to use IPP or not. IPP Print Job Accept Specify to accept IPP print jobs or not.
Page 750 Machine Manager Setting 04 FTP Specify to use Scan to HDD/Scan to FTP for transmission, the proxy server setting, and the passive function. 17-94 bizhub PRO 1050/1050e...
Page 751 Machine Manager Setting Procedure Touch [04 Network Setting] - [02 Controller NIC Setting] - [04 FTP]. For each item, select or enter a required value. Server Select to use an FTP server. Client Select to use a client. Proxy Server Address Touch [Proxy Server Address] to display an input screen.
Page 752 Machine Manager Setting 05 SNMP Specify the SNMP settings. 17-96 bizhub PRO 1050/1050e...
Page 753 Machine Manager Setting Procedure Touch [04 Network Setting] - [02 Controller NIC Setting] - [05 SNMP]. For each item, select or enter a required value. SNMP Select to use SNMP. Read Community Name Touch [Read Community Name] to display an input screen. After entering in the field, touch [OK].
Page 754 Machine Manager Setting 06 SMB Specify the SMB printing setting, and to use Scan to SMB for transmission. 17-98 bizhub PRO 1050/1050e...
Page 755 Machine Manager Setting Procedure Touch [04 Network Setting] - [02 Controller NIC Setting] - [06 SMB]. For each item, select or enter a required value. Print Select [Use] or [Not Use]. Net BIOS Name Specify if required. Touch [Net BIOS Name] to display an input screen.
Page 756 Machine Manager Setting 07 AppleTalk Specify the settings for connecting network printer and the AppleTalk set- tings. 17-100 bizhub PRO 1050/1050e...
Page 757 Machine Manager Setting Procedure Touch [04 Network Setting] - [02 Controller NIC Setting] - [07 Apple- Talk]. For each item, select or enter a required value. AppleTalk Selecting [Use] enables AppleTalk as the print server protocol. Printer Name Touch [Printer Name] to display an input screen. After entering in the field, touch [OK].
Page 758 Machine Manager Setting 08 E-Mail Specify the settings for an e-mail send/receive, division for transmitted data and authentication, and save the template of titles and bodies frequently used. 17-102 bizhub PRO 1050/1050e...
Page 759 Machine Manager Setting bizhub PRO 1050/1050e 17-103...
Page 760 Machine Manager Setting 17-104 bizhub PRO 1050/1050e...
Page 761 Machine Manager Setting Procedure Touch [04 Network Setting] - [02 Controller NIC Setting] - [08 E-Mail]. Touch [01 E-Mail Send Setting] on the E-Mail Setting Menu Screen to display the E-Mail Send Setting Screen. Specify the following items, using [Previous] or [Next] as required. Touch [OK] to complete the set- tings and return to the E-Mail Setting Menu Screen.
Page 762 Machine Manager Setting Touch [02 E-Mail Receive Setting] on the E-Mail Setting Menu Screen to display the E-Mail Receive Setting Screen. Specify the following items. Touch [OK] to complete the settings and return to the E-Mail Setting Menu Screen. POP Server Address Touch [POP Server Address] to display an input screen.
Page 763 Machine Manager Setting Details When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. bizhub PRO 1050/1050e 17-107...
Page 764 Machine Manager Setting 09 HDD Specify the duration for which Scan to HDD data are stored in the printer controller HDD before they are automatically deleted. 17-108 bizhub PRO 1050/1050e...
Page 765 Machine Manager Setting Procedure Touch [04 Network Setting] - [02 Controller NIC Setting] - [09 HDD]. Touch an appropriate key to specify the duration for which data are stored in HDD before they are automatically deleted. Touch [OK] to complete the settings and return to the Controller NIC Setting Menu Screen.
Page 766 Machine Manager Setting 10 Alert Mail Specify the settings for e-mail error notification. 17-110 bizhub PRO 1050/1050e...
Page 767 Machine Manager Setting Procedure Touch [04 Network Setting] - [02 Controller NIC Setting] - [10 Alert Mail]. Specify to use e-mail notification, and a destination address to which to notify. Select [On] or [Off] to the right of [E-Mail Transmission] to specify to use e-mail notification.
Page 768 Machine Manager Setting 11 CSRC CS Remote Care includes service tools, which you do not necessarily have to set. Contact your service representative for details. 17-112 bizhub PRO 1050/1050e...
Page 769 Machine Manager Setting bizhub PRO 1050/1050e 17-113...
Page 770 Machine Manager Setting Procedure Touch [04 Network Setting] - [02 Controller NIC Setting] - [11 CSRC]. Touch [01 CSRC Send Setting] on the CSRC Setting Menu Screen to display the CSRC Send Setting Screen. Specify the following items, using [Previous] or [Next] as required. Touch [OK] to complete the settings and return to the CSRC Setting Menu Screen.
Page 771 Machine Manager Setting Connection Time Out Time Touch [Connection Time Out Time] to display an input screen. After entering in the field, touch [OK].The range to be used is between 30 and 300 seconds. Machine Manager From Address Touch [Machine Manager From Address] to display an input screen.
Page 772 Machine Manager Setting Connection Time Out Time Touch [Connection Time Out Time] to display an input screen. After entering in the field, touch [OK]. The range to be used is between 30 and 300 seconds. Auto Check Select [On] or [Off]. If [On] is selected, the interval must be specified.
Page 773 Machine Manager Setting 12 AP I/F Specify the settings for AP I/F. bizhub PRO 1050/1050e 17-117...
Page 774 Machine Manager Setting Procedure Touch [04 Network Setting] - [02 Controller NIC Setting] - [12 AP I/F]. For each item, select or enter a required value. AP I/F Select [Use] or [Not Use]. AP I/F over SSL Select [Use] or [Not Use]. AP I/F Authentication Select [On] or [Off].
Page 775 Machine Manager Setting 13 PSWC Specify to use PageScope Web Connection (PSWC). bizhub PRO 1050/1050e 17-119...
Page 776 Machine Manager Setting Procedure Touch [04 Network Setting] - [02 Controller NIC Setting] - [13 PSWC]. Touch [Use] or [Not Use] to specify whether you want to use PSWC or not. Touch [OK] to complete the settings and return to the Controller NIC Setting Menu Screen.
Page 777 Machine Manager Setting 14 Network Setting Clear Recover the initial network settings specified at the time of shipment. bizhub PRO 1050/1050e 17-121...
Page 778 Machine Manager Setting Procedure Touch [04 Network Setting] - [02 Controller NIC Setting] - [14 Network Setting Clear]. Touch [Initialize Execute] to recover the initial setting specified at the time of shipment. Touch [OK] to complete the settings and return to the Controller NIC Setting Menu Screen.
Page 779 Machine Manager Setting 15 SNMP Trap Specify the SNMP Trap settings. Details Before setting the SNMP Trap, specify to use SNMP in [04 Network Set- ting] - [02 Controller NIC Setting] - [05 SNMP]. bizhub PRO 1050/1050e 17-123...
Page 780 Machine Manager Setting 17-124 bizhub PRO 1050/1050e...
Page 781 Machine Manager Setting Procedure Touch [04 Network Setting] - [02 Controller NIC Setting] - [15 SNMP Trap]. Specify to use the SNMP Trap transmission and authentication failure transmission functions. SNMP Trap Transmission Select [On] or [Off] to transmit SNMP Trap or not. Authentication Failure Trans Select [On] or [Off] to transmit by SNMP in the case that any au- thentication failure in Read Community Name or Write Community...
Page 782 Machine Manager Setting Trans Community Name Touch [Trans Community Name] to display an input screen. After entering in the field, touch [OK]. Report Items Select the desired report items. More than one item can be select- Touch [Clear All] if none of them are required. Note The authentication failure transmission will be performed even if all report items are cleared.
Page 783 Machine Manager Setting After you have changed the settings, turn off the sub power, then turn off and on the main power. Details When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly.
Page 784: Copy/Printer Setting
Machine Manager Setting 17.6 05 Copy/Printer Setting 17.6.1 01 JOB Offset Operating Set the machine to offset the copies/printouts of different jobs. Procedure Touch [05 Copy/Printer Setting] - [01 JOB Offset Operating]. Touch [On] or [Off] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen.
Page 785: Continuation Print(Print)
Machine Manager Setting 17.6.2 02 Continuation Print(Print) Set the machine to output multiple reserved print jobs in succession. Procedure Touch [05 Copy/Printer Setting] - [02 Continuation Print(Print)]. Touch [On] or [Off] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen.
Page 786: Page No. Position (Booklet)
Machine Manager Setting 17.6.3 03 Page No. Position (Booklet) Set the machine to position the page numbers automatically on the outside edges of the copy when using Booklet with Page Numbering in Stamp. Procedure Touch [05 Copy/Printer Setting] - [03 Page No. Position (Booklet)]. Touch [On Outside Page Print)] or [Off] to highlight it.
Page 787: Fixing Prerotation Set
Machine Manager Setting 17.6.4 04 Fixing Prerotation Set The fixing heat adjustment may be necessary as altering the paper type and the weight. The machine rotates the fixing roller before printing starts in order to print at the appropriate temperature for the specific paper type and the weight.
Page 788 Machine Manager Setting Note If pressing [Start] after altering the paper type and weight when [Rotation On] is selected, the message “Machine is warming up.” Is displayed. Please wait until copying is enabled. 17-132 bizhub PRO 1050/1050e...
Page 789: Image Auto Rotation
Machine Manager Setting 17.6.5 05 Image Auto Rotation Set this function to activate always, only when APS or AMS is activated, or only when APS, AMS or reduce is activated. Procedure Touch [05 Copy/Printer Setting] - [05 Image Auto Rotation]. Touch the desired key to highlight it.
Page 790: Interruption Suspend
Machine Manager Setting 17.6.6 06 Interruption Suspend Select the timing to stop the job in progress when [Interrupt] is pressed. The timing can be set either to suspend on completing the job in progress or to suspend by interrupting the job in progress. Procedure Touch [05 Copy/Printer Setting] - [06 Interruption Suspend].
Page 791: Copy Reserve Operation
Machine Manager Setting 17.6.7 07 Copy Reserve Operation Set the timing for the reserve job setting. The timing can be set to either when specifying on the Copy Reserve Confirmation Screen navigated from the Ma- chine Status Screen, or when displaying the Copy Screen as placing the original in the ADF.
Page 792 Machine Manager Setting Details Copy Reserve by placing the original on the original glass When the Machine Status Screen is displayed, the screen can altered to the Copy Screen by placing the original in the ADF. 17-136 bizhub PRO 1050/1050e...
Page 793: Scan Stop (Pull Out Tray)
Machine Manager Setting 17.6.8 08 Scan Stop (pull out tray) Select to stop scanning when pulling out the tray during scanning the origi- nal. Procedure Touch [05 Copy/Printer Setting] - [08 Scan Stop (pull out tray)]. Touch [On] or [Off] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen.
Page 794: Continuation Print (Copy)
Machine Manager Setting 17.6.9 09 Continuation Print (Copy) Select the machine to output multiple reserve jobs in succession. Procedure Touch [05 Copy/Printer Setting] - [09 Continuation Print (Copy)]. Touch [On] or [Off] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen.
Page 795: Original Glass Sdf
Machine Manager Setting 17.6.1010 Original Glass SDF Select to set the exit direction when copying one set of the original placed on the original glass. Procedure Touch [05 Copy/Printer Setting] - [10 Original Glass SDF]. Touch [Face Up] or [Face Down] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen.
Page 796: Sdf Auto Setting
Machine Manager Setting 17.6.1111 SDF Auto Setting Set the machine to feed a single document automatically as placing it in the ADF in the Memory Scan mode, or feed it by pressing [Start]. Procedure Touch [05 Copy/Printer Setting] - [11 SDF Auto Setting]. Touch [On] or [Off] to highlight it.
Page 797: System Connection
Machine Manager Setting 17.7 06 System Connection 17.7.1 01 User Call Use this function to call your service representative for maintenance. Your service representative is monitoring the machine status as needed basis. The monitored information will be useful for maintenance. Procedure Touch [06 System Connection] - [01 User Call].
Page 798: Security Setting
Machine Manager Setting 17.8 07 Security Setting 17.8.1 01 Machine Manager Password Set the new machine manager password. 17-142 bizhub PRO 1050/1050e...
Page 799 Machine Manager Setting Procedure Touch [07 Security Setting] - [01 Machine Manager Password]. Touch [Input Manager Password] to display the Input Manager Pass- word Screen. Enter the new password. Touch [OK]. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen.
Page 800: Hdd Management Setting
Machine Manager Setting 17.8.2 02 HDD Management Setting 01 Folder Box List/Delete The user can create a folder or a box when saving images in a personal, pub- lic or secure folder. The machine manager can refer to the name, password, number or creation time of the folder created by the user, and delete the fold- er or box if necessary.
Page 801 Machine Manager Setting bizhub PRO 1050/1050e 17-145...
Page 802 Machine Manager Setting 17-146 bizhub PRO 1050/1050e...
Page 803 Machine Manager Setting Procedure Touch [07 Security Setting] - [02 HDD Management Setting] - [01 Fold- er Box List/Delete]. Refer the detailed information of the folder and the box. Touch [Personal Folder], [Public Folder], or [Secure Folder] to refer to the details of the desired folder or box. Touch the desired folder to highlight it.
Page 804 Machine Manager Setting 02 HDD Data Auto Delete Period Setting Specify the period of time (12 hours to 30 days) to keep data so that it will be deleted automatically when specified period has passed. The initial setting is Not Delete. 17-148 bizhub PRO 1050/1050e...
Page 805 Machine Manager Setting Procedure Touch [07 Security Setting] - [02 HDD Management Setting] - [02 HDD Data Auto Delete Period Setting]. Touch the desired period to highlight it. Touch [Not Delete] to highlight it when not setting the automatically de- leting period.
Page 806 Machine Manager Setting 03 Change HDD Lock Password Change the HDD lock password. Note The HDD Lock Password cannot be changed unless the Security Strengthen mode is set to On. 17-150 bizhub PRO 1050/1050e...
Page 807 Machine Manager Setting Procedure Touch [07 Security Setting] - [02 HDD Management Setting] - [03 Change HDD Lock Password]. Touch [Current Password] to display the Password Input Screen. Enter the current password and touch [OK]. Touch [New Password] to display the Password Input Screen. Enter the new password and touch [OK].
Page 808: Security Strengthen Mode
Machine Manager Setting 17.8.3 03 Security Strengthen mode Set the Security Strengthen mode On/Off. Note In order to set the Security Strengthen mode to On, it is required by your service representative to set a CE password and a machine manager password to your machine.
Page 809 Machine Manager Setting Procedure Touch [07 Security Setting] - [03 Security Strengthen mode]. Touch [On] when activating this mode, or touch [Off] when deactivating this mode. Touch [OK] at the lower right side of the screen to display the Confir- mation popup screen.
Page 810: Scanner Address Register
Machine Manager Setting 17.9 08 Scanner Address Register 17.9.1 01 Send Address Edit/Delete Change or delete the destination of the scanned image. The following four addresses can be registered: - E-Mail (mail address) - HDD (box No.) - FTP (FTP server address) - SMB The Group of registered E-Mail addresses can be deleted.
Page 811 Machine Manager Setting bizhub PRO 1050/1050e 17-155...
Page 812 Machine Manager Setting Procedure Touch [08 Scanner Address Register] - [01 Send Address Edit/Delete]. Note In order to delete the group or registered e-mail addresses, touch Group. Touch the name of the group to be deleted, then touch Delete. The popup message “Delete this destination address?”...
Page 813 Machine Manager Setting To change/delete the HDD destination address: Touch [HDD]. Display the Register Name of the destination address using the search key or the arrow keys (,) and (+). Touch the Register Name to highlight it. To change, touch [Change] to display the HDD Description Screen. Select the changing item from [Profile], [Reference Name], [Host Address], [File Path, [Login Name] and [Password], and change it in the input screen.
Page 814 Machine Manager Setting 17-158 bizhub PRO 1050/1050e...
Page 815 Machine Manager Setting To change/delete the FTP destination address: Touch [FTP]. Display the Register Name of the destination address using the search key or the arrow keys (,) and (+). Touch the Register Name to highlight it. To change, touch [Change] to display the FTP Description Screen. Select the changing item from [Profile], [Reference Name], [Host Address], [File Path], [Login Name] and [Password] ,and change it in the input screen.
Page 816 Machine Manager Setting To change/delete the SMB destination address: Touch [SMB]. Display the Register Name of the destination address using the search key or the arrows keys (,) and (+). Touch the Register Name to highlight it. To change, touch [Change] to display the SMB Description Screen. Select the changing item from [Profile], [Reference Name], [Host Address], [File Path], [Login Name] and [Password], and change it in the input screen.
Page 817 Machine Manager Setting To delete Group: Touch [Group]. Display the Register Name of the destination address using the search key or the arrow keys (,) and (+). Touch the Register Name to highlight it. Touch [Delete]. Touch [Yes] on the Delete Confirmation popup screen.
Page 818 Machine Manager Setting Touch [Return] to restore the Machine Manager Setting Menu Screen. 17-162 bizhub PRO 1050/1050e...
Page 819: Browser Control Setting
Browser Control Setting POD Administrator...
Page 821: Web Utilities
Browser Control Setting Browser Control Setting 18.1 Web Utilities When the machine is connected with a PC over a network, the web browser activated on the PC provides the following functions. Account Track Setting Make the account track settings concerning the administrator setting us- ing the web browser on a PC.
Page 822 Browser Control Setting To cancel adding a new account track data, click on [Back] or any Ad- ministrator Setting menu item to jump to the desired window. Follow the procedure below to access the Web Utilities of the machine using the web browser.
Page 823: Setting Account Track Data
Browser Control Setting 18.2 Setting Account Track Data Make the account track settings concerning the administrator setting using the web browser on a PC. Details A duplicate password or name will be rejected with an error message. However, duplicating a password is possible using the administrator set- ting.
Page 824: Adding Account Track
Browser Control Setting 18.2.1 Adding Account Track Add a new account track data (password, name, and limit value). Procedure Open the Web Utilities window. Click on [Machine Manager Setting]. The Enter Network Password dialog box will be displayed. Enter "admin" in the User Name text box, and an 8-digit administrator in the password text box, then click on [OK].
Page 825 Browser Control Setting Click on [Volume Track setting]. The Volume Track Setting menu will be displayed. Click on [Volume Track data add]. The Volume Track Data Add window will be displayed. Enter a new account track data. Section Name (Account Name) : 8 characters max. Password: 8 digits max.
Page 826 Browser Control Setting Click on [ Apply The registered content will be displayed in the window. The new account track data will be transmitted to the machine imme- diately so that is valid for the user operations. Click on [Back] to return to the Volume Track Setting menu or any menu item to jump to the desired window.
Page 827: Editing Account Track Data
Browser Control Setting 18.2.2 Editing Account Track Data Change or delete the account track data (password, section name, or limit value, or reset the counters). Procedure Open the Web Utilities window. Click on [Machine Manager Setting]. The Enter Network Password dialog box will be displayed. Enter "admin"...
Page 828 Browser Control Setting Click on [Volume Track setting]. The Volume Track Setting menu will be displayed. Click on [Volume Track data list]. The Volume Track List will be displayed. 18-10 bizhub PRO 1050/1050e...
Page 829 Browser Control Setting Change the Section Name (Account Name), Password, and Limit Val- Click on the number of the data to be edited. The Volume Track Add Data window will be displayed. Change the section name (account name), password, or limit value, as desired.
Page 830 Browser Control Setting Reset Counter. Click on the check box(es) to select the account track data of the counter to be cleared. If all the counters are to be cleared, click on [SelectAll]. Click on the radio button (a white circle) heading the "Copy/Printer Count reset."...
Page 831 Browser Control Setting Click on [Back] to return to the Account Track Data List or any menu item to jump to the desired window. Delete Counter. Click on the check box(es) to select the account track data to be deleted. If all the data are to be cleared, click on [SelectAll]. Click on the radio button (a white circle) heading the "Delete (Ex- cept for Another user count)".
Page 832 Browser Control Setting Click on [Apply] to immediately delete the data. The message "Setting was deleted" will be displayed. Click on [Back] to return to the Volume Track Data List or any menu item to jump to the desired window. 18-14 bizhub PRO 1050/1050e...
Page 833 Browser Control Setting Save Counter. Click on [Save this table as a file]. Click on [Save]. bizhub PRO 1050/1050e 18-15...
Page 834 Browser Control Setting In the dialog box, designate the folder for saving the data, then click on [Save]. Details The account track data will be stored in CSV format. The data cannot be saved while the machine is in operation. In this case, try this procedure again after the machine starts idling.
Page 835 Browser Control Setting Example: Account track data list stored as a file The "Another user count" will be stored by the name of "UNKNOWN" in the last line. bizhub PRO 1050/1050e 18-17...
Page 836: Setting Scan Transmission Function
Browser Control Setting 18.3 Setting Scan Transmission Function Follow the procedure below to register, change, or delete the address for the transmission of the scanned image data using the web browser. For details of the Scan Transmission Setting, contact your service representative. Prerequisites - The Scan Transmission Setting is not used in the machine.
Page 837 Browser Control Setting Enter "admin" in the User Name text box, and an 8-digit administrator password in the password text box, then click on [OK]. The Administrator Setting menu will be displayed. Click on [Scan transmission setting]. The Scan Transmission Setting window will be displayed. bizhub PRO 1050/1050e 18-19...
Page 838 Browser Control Setting Register the E-Mail, HDD, FTP, and SMB, as required. 18-20 bizhub PRO 1050/1050e...
Page 839 Browser Control Setting Click on [Registration] to complete the entry. The registered content will be displayed. Click on [Back] to return to the Scan Transmission Setting window. Display the Entry List. Click on [Entry List] of the desired item under the entry box to dis- play the Entry List.
Page 840 Browser Control Setting Change the registered contents. Display the Entry List of the desired item as described in step 7. Click on the entry name to be changed. The window for changing the selected item will be displayed. Change the contents as desired, then click on [Registration]. The registered content will be displayed.
Page 841 Browser Control Setting Delete the registered contents. Display the Entry List of the desired item as described in step 7. Click on the check box in the Delete column of the item to be delet- ed, then click on [Delete]. If all the data are to be cleared, click on [SelectAll].
Page 842: Transmitting Machine Setting File
Browser Control Setting 18.4 Transmitting Machine Setting File Follow the procedure below to transmit the following setting file from the ma- chine to a PC (export) using the web browser, edit the setting data on the PC, then return the file to the machine (import). Account track data (max.
Page 843 Browser Control Setting Procedure Open the Web Utilities window. Click on [Machine Manager Setting]. The Enter Network Password dialog box will be displayed. Enter "admin" in the User Name text box, and an 8-digit administrator password in the password text box, then click on [OK]. The Machine Manager Setting menu will be displayed.
Page 844 Browser Control Setting Click on [Setting data Import/Export]. The Setting Data Import/Export window will be displayed. Export the machine setting file. Select the desired file type from the pull-down menu, then click on [Export..] 18-26 bizhub PRO 1050/1050e...
Page 845 Browser Control Setting The File Download dialog box will be displayed. Click on [OK]. In the dialog box, designate the folder for saving the machine set- ting file, then click on [Save]. A dialog box will be displayed when the saving operation is completed. Click on [Close].
Page 846 Browser Control Setting Edit the machine setting file. The machine setting file transmitted to a PC is a TAB separated text file which can be edited using an application software such as Text Editor or Table Editor. A new setting file can also be created according to the specifications for each file type.
Page 847 Browser Control Setting Details The file cannot be accessed when the machine is operating. If an error message is displayed, try again to save the file after the current machine operation is completed. If the registration cannot be completed successfully, error messages will be displayed as follows.
Page 848 Browser Control Setting To Edit the Machine Setting File - Save the file as a text. - Begin the file with a specified tag. (ex. #EKC_TAB) - A line should be 300 bytes or less. - The file size should be 100,000 bytes or less. - The line that begins with "#"...
Page 849 Browser Control Setting - REFERENCE should be 250 bytes or less. - Mark DAILY USE with "1" or DAILY NOT USE with "0" in each column. HDD data setting file: - Begin the file name with #IP_HDD. - A line should include NAME, NUMBER, REFERENCE, or DAILY, separat- ed by a tab.
Page 850: Box Edit
Browser Control Setting 18.5 Box Edit Use the web browser to change the name of the box or file created in the HDD, or to display the thumbnail of the top page of the file. Prerequisites This function is available only when the following conditions are satisfied on the machine.
Page 851 Browser Control Setting The Machine Manager Setting menu will be displayed. Click on [Box edit]. The Box Edit window will be displayed. Click on the desired user name. Selected user name will be marked with an asterisk (*) at its head. The user name marked with “L”...
Page 852 Browser Control Setting Click on the desired box name. Selected box name will be marked with an asterisk (*) at its head. The box name marked with “L” is locked and cannot be selected. To change the box name, proceed to the next step. To change the file name or check the thumbnail, proceed to step 8.
Page 853 Browser Control Setting Click on the desired file name to display the thumbnail. Selected file name will be marked with an asterisk (*), and the thumbnail of the top page of selected file will be displayed in the File Name area. To change the file name, proceed to the next step.
Page 854 Browser Control Setting Change the file name. Clicking on the desired file name (as in step 8), a text box will appear at the top of the File Name area. Enter the new name within 30 alphanumeric characters. Click on [Change] on the right side of the text box. The new name will be registered and enabled immediately.
Page 855: Pagescope Web Connection
PageScope Web Connection PageScope Web Connection is a device control utility program provided by the HTTP server built into the image controller of the KONICA MINOLTA bizhub PRO 1050/1050e. This utility can be used with a Web browser to dis- play the status of the bizhub PRO 1050 printer, scanner, and network, and to change default and network settings.
Page 856 Browser Control Setting Cookies Cookies must be active. For setting cookies, see the following procedure. - Internet Explorer Select [Internet Options] under [Tools]. Select the [Privacy] tab and then move the slider to the [High] privacy setting. - Netscape Navigator Select [Preferences] under [Edit].
Page 857: Access
Browser Control Setting 18.7 Access PageScope Web Connection can be accessed directly from a Web browser. Procedure Start the Web browser. In the Address bar, enter the IP address of the image controller as shown below. Then press the [Enter] key. http://IP address of the image controller/ (Example) When the IP address of the image controller is 192.168.0.10:...
Page 858: Screen Configuration
If user authentication is set, the user name and password entry screen will appear. KONICA MINOLTA PageScope Web Connection Logo Click the KONICA MINOLTA logo to jump to the Konica Minolta web site. http://konicaminolta.jp Click the PageScope Web Connection logo to jump to the About Screen, providing the version information and the copyright description.
Page 859 Browser Control Setting Logs into Administrator Mode. For details, refer to “Logging in Using Ad- ministrator Mode” on page 18-42. Language Sets the display language for the browser. [Auto] indicates the same lan- guage as the operating system being used and the other options indicate the same language as displayed on the control panel.
Page 860: Logging In Using Administrator Mode
Browser Control Setting 18.8.1 Logging in Using Administrator Mode By logging into PageScope Web Connection in Administrator Mode, you can configure or confirm the image controller system. Procedure Click the [Admin Mode] button in the upper left corner of the screen. Enter the password for Administrator Mode and click the [Login] but- ton.
Page 861 Browser Control Setting In order to ensure the security against data used in Administrator Mode, set SSL. SSL can be set on the [Network] tab of Administrator Mode. For details, “SSL/TLS” on page 18-77. bizhub PRO 1050/1050e 18-43...
Page 862: Administrator Mode
Browser Control Setting 18.9 Administrator Mode By logging into PageScope Web Connection in Administrator Mode, you can configure or confirm the image controller system. For the details on the login procedure for Administrator Mode, refer to “Log- ging in Using Administrator Mode” on page 18-42. 18.10 Administrator Mode –...
Page 863: Device Information
Browser Control Setting 18.10.2Device Information This screen appears when you click [Device Information] on the [System] tab. The screen is used to enter the device name, device place, and the adminis- trator name. Device Name: Enter the name of the device. Maximum 255 alphanumeric characters can be used.
Page 864: Rom Version
Browser Control Setting 18.10.3ROM Version This screen appears when you click [ROM Version] on the [System] tab. It shows the ROM version of the copier, the firmware version of the controller, and other information. 18.10.4Online Assistance This screen appears when you click [Online Assistance] on the [System] tab. You can use the screen to enter information concerning product support.
Page 865 Online Help URL: Enter the online manual URL. Maximum 127 alphanumeric characters can be used. There are two choices: – Accessing the manual on the Internet posted on the Konica Minolta web- site: Enter: http://pagescope.com/download/webconnection/onlinehelp/ pro1050/help.html. – Accessing the manual over the LAN: Enter: http://(IP address for the PC)/pswc_help/****.pswc_help.html.
Page 866: Import/Export
Browser Control Setting 18.10.5Import/Export This screen appears when you click [Import/Export] on the [System] tab. You can use the screen to import a setting file from a PC to the device, and to export a setting file from the device to a PC. Details See appendix for exportable data.
Page 867: Maintenance
Browser Control Setting 18.10.6Maintenance This screen appears when you click [Maintenance] on the [System] tab. You can use the screen to operate maintenance of the machine. You can initialize the network settings (reset to factory default settings) or restart the network only to enable new parameters.
Page 868 Browser Control Setting Reset This screen appears when you click [Reset] under the [Maintenance] menu. Restart on the controller to enable new parameters. In this case, the control- ler will be initialized, however the main body will not. Details If you want to initialize the main body after resetting the network, wait un- til the controller restarts (about 2 minutes) and turn the main switch OFF.
Page 869: E-Mail Alert
Browser Control Setting 18.10.7E-Mail Alert This screen appears when you click [E-Mail Alert] on the [System] tab. You can use the screen to set sending notices to the selected e-mail addresses when an alert occurs to your system. The alert items that are checked their check boxes will be sent as alert by e-mail.
Page 870: Administrator Mode - Print Tab
Browser Control Setting 18.11 Administrator Mode – Print Tab The [Printer] tab is used to configure the image controller. 18.11.1Interface This screen appears when you click [Interface] on the [Print] tab. The screen is used to set information concerning the interface timeout. Parallel Timeout: Set parallel port timeout (10-300 seconds).
Page 871: Port Settings
Browser Control Setting 18.11.2Port Settings This screen appears when you click [Port Settings] on the [Print] tab. You can use the screen to see the list of port settings. RAW port number List the RAW port numbers 1 to 6 that are set in [TCP/IP] on the [Network] tab.
Page 872: Default Settings
Browser Control Setting 18.11.3Default Settings General Settings This screen appears when you click [General Settings] under the [Default Settings] menu of the [Print] tab. The screen is used to set default values for printer settings, that are not associated with PDL. If there is no command from the driver, this setting will be applied.
Page 873 Browser Control Setting PCL Settings This screen appears when you click [PCL Settings] under the [Default Set- tings] menu. The screen is used to set PCL. These settings also appear if you select Controller Settings on the touch pan- el's Device Status screen - 02 Printer Settings - 03 PCL Settings. [Apply] button: Click the button to apply the new settings.
Page 874 Browser Control Setting PS Settings (Option) This screen appears when you click [PS Settings] under the [Default Settings] menu. The screen is used to set PS. These settings also appear if you select Controller Settings on the touch pan- el's Device Status screen - 02 Printer Settings - 03 PS Settings. Print To PS Error: Select whether or not to print the error report when an error occurs while rasterizing PostScript data.
Page 875 Browser Control Setting TIFF Settings This screen appears when you click [TIFF Settings] under the [Default Set- tings] menu. The screen is used to set default values for TIFF settings. These settings also appear if you select Controller Settings on the touch panel's Device Status screen - 02 Printer Settings - 04 TIFF Settings.
Page 876: Administrator Mode - Scan Tab
Browser Control Setting Administrator Mode – 18.11.4 Scan Tab The [Scan] tab is used to enter, edit, or delete subject and body text for e- mail. 18.11.5Subject Registration This screen appears when you click [Subject] on the [Scan] tab. You can use the screen to enter, edit, or delete the subject for e-mail.
Page 877 Browser Control Setting To Enter / Edit Subjects Check the number of the subject to enter or edit, and click the [Edit] button. Enter the subject on the Subject Registration screen, and click the [Ap- ply] button. You can use maximum 64 characters. Click the [OK] button on the Completed screen.
Page 878 Browser Control Setting To Delete Subjects Check the number of the subject to delete, and click the [Delete] but- ton. Click the [OK] button on the Subject Deletion screen. Click the [OK] button on the Completed screen. It will take you back to the subject list screen.
Page 879: Body Registration
Browser Control Setting 18.11.6Body Registration This screen appears when you click [Body] on the [Scan] tab. You can use the screen to enter, edit, or delete the body text for e-mail. [Apply] button: Click the button to apply the new settings. [Edit] button: Click the button to open the editing screen.
Page 880 Browser Control Setting To Enter / Edit Body Check the number of the body text to enter or edit, and click the [Edit] button. Enter the text on the Body Registration screen, and click the [Apply] button. You can use maximum 255 characters. Click the [OK] button on the Completed screen.
Page 881 Browser Control Setting To Delete Bodies Check the number of the body text to delete, and click the [Delete] but- ton. Click the [OK] button on the Body Deletion screen. Click the [OK] button on the Completed screen. It will take you back to the body text list screen.
Page 882: Administrator Mode - Network Tab
Browser Control Setting 18.12 Administrator Mode – Network Tab The [Network] tab shows settings concerning the printer controller network. 18.12.1TCP/IP TCP/IP This screen appears when you click [TCP/IP] on the [Network] tab. The screen is used to set a summary of the image controller interface (TCP/IP settings).
Page 883 Browser Control Setting Enter for individual items. Access Permission Addresses and their ranges, Access Refusal Ad- dresses and their ranges. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were selected. bizhub PRO 1050/1050e 18-65...
Page 884: Netware
Browser Control Setting 18.12.2NetWare NetWare This screen appears when you click [NetWare] on the [Network] tab. The screen is used to enter and confirm various settings concerning NetWare. When NetWare is set to disable, you still need to set parameters. Make sure to enter parameters correctly.
Page 885 Browser Control Setting [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were selected. NetWare Status This screen appears when you click [NetWare Status] under the [NetWare] menu on the [Network] tab. This screen is used to confirm NetWare status. bizhub PRO 1050/1050e 18-67...
Page 886: Ipp
Browser Control Setting 18.12.3IPP This screen appears when you click [IPP] on the [Network] tab. This screen is used to enter and confirm settings concerning IPP. When IPP Print is set to disable, you still need to set parameters. Make sure to enter parameters correctly.
Page 887: Ftp
Browser Control Setting 18.12.4FTP FTP Client This screen appears when you click [FTP] on the [Network] tab, then click [Client] under the [FTP] menu. The screen is used to enter and confirm vari- ous settings concerning the FTP client. When FTP Client is set to disable, you still need to set parameters. Make sure to enter parameters correctly.
Page 888 Browser Control Setting FTP Server This screen appears when you click [FTP] on the [Network] tab, then click [Server] under the [FTP] menu. The screen is used to enter and confirm var- ious settings concerning the FTP server. FTP Server: Select enable or disable.
Page 889: Snmp
Browser Control Setting 18.12.5SNMP This screen appears when you click [SNMP] on the [Network] tab. The screen is used to enter and confirm settings concerning SNMP. SNMP: Select enable or disable. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered.
Page 890: Smb
Browser Control Setting 18.12.6SMB SMB Scan This screen appears when you click [SMB] on the [Network] tab, then click [Scan] under the [SMB] menu. The screen is used to enter and confirm set- tings concerning SMB scan. SMB Scan: Select enable or disable. [Apply] button: Click the button to apply the new settings.
Page 891 Browser Control Setting Print This screen appears when you click [Print] under the [SMB] menu. The screen is used to enter and confirm settings concerning SMB printing. When SMB Print is set to disable, you still need to set parameters. Make sure to enter parameters correctly.
Page 892: Apple Talk
Browser Control Setting 18.12.7Apple Talk This screen appears when you click [Apple Talk] on the [Network] tab. The screen is used to enter and confirm settings concerning Apple Talk. When Apple Talk is set to disable, you still need to set parameters. Make sure to enter parameters correctly.
Page 893: E-Mail
Browser Control Setting 18.12.8E-Mail E-Mail Receive (POP) Configuration This screen appears when you click [E-Mail] on the [Network] tab, then click [E-Mail Receive] under the [E-Mail] menu. The screen is used to enter and confirm settings concerning receiving e-mail. When E-Mail Receive is set to disable, you still need to set parameters. Make sure to enter parameters correctly.
Page 894 Browser Control Setting E-Mail Send (SMTP) Configuration This screen appears when you click [E-Mail] on the [Network] tab, then click [E-Mail Send] under the [E-Mail] menu. The screen is used to enter and con- firm settings concerning sending e-mail. When E-Mail Send is set to disable, you still need to set parameters. Make sure to enter parameters correctly.
Page 895: Ssl/Tls
Browser Control Setting 18.12.9SSL/TLS This screen appears when you click [SSL/TLS] on the [Network] tab. The screen is used to enter and confirm settings concerning SSL/TLS. You can configure them separately depending whether or not certificates are in- stalled. Creating a self-signed certificate bizhub PRO 1050/1050e 18-77...
Page 896 Browser Control Setting Click [Setting]. The SSL/TLS Setting screen appears. Check [Create a Self-Signed Certificate] and click [Next]. The Self-Signed Certificate Setting screen appears. Note Only [Create a Self-Signed Certificate], [Request a Certificate], and [In- stall a Certificate] can be selected. If you click [Cancel], it will take you back to the SSL/TLS Setting screen.
Page 897 Browser Control Setting Requesting a certificate to install bizhub PRO 1050/1050e 18-79...
Page 898 Browser Control Setting 18-80 bizhub PRO 1050/1050e...
Page 899 Browser Control Setting Click [Setting]. The SSL/TLS Setting screen appears. Check [Request a Certificate] and click [Next]. The Request a Certificate screen appears. Note Only [Create a Self-Signed Certificate], [Request a Certificate], and [In- stall a Certificate] can be selected. If you click [Cancel], it will take you back to the SSL/TLS Setting screen.
Page 900 Browser Control Setting Click [OK]. It will take you back to the SSL/TLS Information screen. 18-82 bizhub PRO 1050/1050e...
Page 901 Browser Control Setting Requesting a certificate to switch information bizhub PRO 1050/1050e 18-83...
Page 902 Browser Control Setting 18-84 bizhub PRO 1050/1050e...
Page 903 Browser Control Setting Click [Setting]. The SSL/TLS Setting screen appears. Note Initially [Request a Certificate] is checked. Remove an already installed certificate first before requesting a new one. For details, refer to “Removing a certificate” on page 18-90. Click [Next]. Enter necessary information, and click [Next].
Page 904 Browser Control Setting Changing mode settings Changing encryption strength setting 18-86 bizhub PRO 1050/1050e...
Page 905 Browser Control Setting Click [Settings]. The SSL/TLS Setting screen appears. Check [Set a Encryption Strength], and click [Next]. The Encryption Strength Setting screen appears. Select a discretionary value. Click [Create]. The completion screen appears. Click [OK]. It will take you back to the SSL/TLS Information screen. bizhub PRO 1050/1050e 18-87...
Page 906 Browser Control Setting Changing mode using SSL/TLS 18-88 bizhub PRO 1050/1050e...
Page 907 Browser Control Setting Click [Settings]. The SSL/TLS Setting screen appears. Check [Mode using SSL/TLS], and click [Next]. The Mode using SSL/TLS screen appears. Select a discretionary mode, and click [Create]. The completion screen appears. Click [OK]. It will take you back to the SSL/TLS Information screen. bizhub PRO 1050/1050e 18-89...
Page 908 Browser Control Setting Removing a certificate 18-90 bizhub PRO 1050/1050e...
Page 909 Browser Control Setting Click [Settings]. The SSL/TLS Setting screen appears. Check [Remove a Certificate], and click [Next]. The Remove a Certificate screen appears. Click [Remove]. The removal confirmation screen appears. Click [OK]. It will take you back to the SSL/TLS Information screen. bizhub PRO 1050/1050e 18-91...
Page 910: Authentication
Browser Control Setting 18.12.10Authentication Auto Logout This screen appears when you click [Authentication] on the [Network] tab. The screen is used to enter and confirm settings concerning logout time. Enter for individual items. Admin Logout Time, User Logout Time. [Apply] button: Click the button to apply the new settings.
Page 911 Browser Control Setting AP I/F This screen appears when you click [AP I/F] on the [Network] tab. The screen is used to enter and confirm settings concerning the AP I/F. Enter for individual items. Port Number, Use SSL/TLS, Port Number (SSL/TLS). [Apply] button: Click the button to apply the new settings.
Page 912 Browser Control Setting 18-94 bizhub PRO 1050/1050e...
Page 913: Security
Security Security...
Page 915 (Ex: 10-0000) Please keep this in mind when checking the software version. Acknowledgements - KONICA MINOLTA, KONICA MINOLTA Logo, and The essentials of im- aging are registered trademarks or trademarks of KONICA MINOLTA HOLDINGS, INC. - PageScope and bizhub PRO are registered trademarks of KONICA MI- NOLTA BUSINESS TECHNOLOGIES, INC.
Page 916: Security Functions
Security 19.1 Security Functions The bizhub PRO 1050/1050e device has two security modes. Normal mode Use this mode if the machine is used by a single person and there is a low possibility of illicit access and operations. This is the default mode when shipped from the factory.
Page 917: Environments In Which Security Strengthen Mode Is Recommended
Security 19.1.1 Environments in which Security Strengthen mode is rec- ommended - The device is connected to an local network, the Internet through a fire- wall, or the external telephone line for maintenance. - The device is monitored by a telephone line or a network. 19.1.2 Creating a secure environment For security, we recommend that supervisors and a machine manager use Security Strengthen mode and establish an environment as follows.
Page 918: Security Strengthen Mode
Security 19.2 Security Strengthen Mode 19.2.1 Description of Security Strengthen mode The following items will have enhanced security. Protect and delete used data in memory and on the HDD - There are two kinds of image data that will be saved in memory and on the HDD: AHA compressed data and uncompressed data (TIFF and PDF formats).
Page 919: Data Protected By Security Strengthen Mode
Security Create, save and analyze an audit log - A history of security function operations will be created and saved. Date and time, information identifying the person who made the operation, de- tails of the operation, and results of the operation will be saved, enabling analysis of unauthorized access.
Page 920: Protect And Delete Data After Use
Security 19.3 Protect and Delete Data After Use Data from each mode (copy / scan / printer) will be temporarily saved in memory or on the HDD, and it will be deleted unless it is moved to a Box. Data is compressed using a special method, so it cannot be decompressed externally.
Page 921: User Authentication In Security Strengthen Mode
Security 19.4 User Authentication in Security Strengthen Mode In Security Strengthen mode, setting up password conditions will be tougher to improve security. The machine manager should set up a user name and password required for user authentication, as this is a machine manager op- eration.
Page 922: To Register A New User
Security 19.4.1 To register a new user Follow the procedure below to setup a user name and password to be re- quired for user authentication in Security Strengthen mode. Procedure Press [Utility/Counter] on the control panel to display the Utility Screen. Touch [06 Machine Manager Setting].
Page 923 Security Details Passwords are case sensitive. If a wrong password or fewer than 8 alphanumerical characters are en- tered and the [OK] key is touched, the warning message "Password does not match" will appear, and no key will work for five seconds. Enter the right password after five seconds.
Page 924 Security Touch [Add] to display the User Registration Screen. Touch [User No.], [User Name], [Password], or [Belong Section] to dis- play each subsequent screen, then make the desired setting. 19-12 bizhub PRO 1050/1050e...
Page 925 Security To enter the User No.: Touch [User No.] on the User Registration Screen. Use the touch panel keypad on the popup menu to enter the de- sired user number. Touch [OK] to return to the User Registration Screen. To enter the User Name: Touch [User Name] on the User Registration Screen.
Page 926 Security To enter the Password: Touch [Password] on the User Registration Screen. Enter the desired password from the touch panel keypad. Touch [OK] to return to the User Registration Screen. To enter the Section: Touch [Belong Section] on the User Registration Screen. Touch the desired section key to highlight it.
Page 927: To Change User Data
Security 19.4.2 To change user data Follow the procedure below to change a user name and password once reg- istered. Procedure Press [Utility/Counter] on the control panel to display the Utility Screen. Touch [06 Machine Manager Setting]. The Input Password Screen will be displayed.
Page 928 Security Details Passwords are case sensitive. If a wrong password or fewer than 8 alphanumerical characters are en- tered and the [OK] key is touched, the warning message "Password does not match" will appear, and no key will work for five seconds. Enter the right password after five seconds.
Page 929 Security Touch the user name to be changed, then touch [Change]. The Change Registered User Screen will be displayed. Touch [User Name], [Password], or [Belong Section] to display each subsequent screen, then make the desired setting change. bizhub PRO 1050/1050e 19-17...
Page 930 Security To change the User Name: Touch [User Name] on the User Registration Screen. Enter the desired user name from the touch panel keypad. Touch [OK] to return to the Change Registered User Screen. To change the Password: Touch [Password] on the User Registration Screen. Enter the desired password from the touch panel keypad.
Page 931 Security To change the Section: Touch [Belong Section] on the User Registration Screen. Touch the desired section key to highlight it. Touch [OK] to return to the Change Registered User Screen. Touch [OK]. When settings are completed, touch [OK] on the Change Registered User Screen.
Page 932: To Delete A User
Security 19.4.3 To delete a user Follow the procedure below to delete a user name, password, and also Per- sonal Folder. Procedure Press [Utility/Counter] on the control panel to display the Utility Screen. Touch [06 Machine Manager Setting]. The Input Password Screen will be displayed. Enter the password.
Page 933 Security Details Passwords are case sensitive. If a wrong password or fewer than 8 alphanumerical characters are en- tered and the [OK] key is touched, the warning message "Password does not match" will appear, and no key will work for five seconds. Enter the right password after five seconds.
Page 934 Security Touch the user name to be deleted. The selected key will be highlight- Touch [Delete]. The popup menu will be displayed to confirm that the selected user will be deleted. Touch [Yes] to delete the selected user name, password, and also the Personal Folder that belongs to the deleted user.
Page 935: To Change Password By User
Security 19.4.4 To change password by user General users can change the password that has already been set for user authentication. We recommend that a user himself/herself changes the password assigned by the machine manager for security. Procedure Press [Utility/Counter] on the control panel to display the Utility Screen. Touch [01 System Setting].
Page 936 Security Touch [07 Change User Password]. The User Authentication Screen will be displayed. Touch [User Name], then enter your user name. The entered name will be displayed on the screen. Touch [Password], then enter your current password. The entered password will appear as asterisks (********) on the screen. Details Passwords are case sensitive.
Page 937 Security Touch [New Password], enter your new password, then touch [OK]. Reminder Do not use your name, birthday, employee number, etc. for a password that others can easily figure out. Enter the new password again for confirmation. Touch [Check Input], then enter your new password once more. Touch [OK].
Page 938: Hdd Store Function In Security Strengthen Mode
Security 19.5 HDD Store Function in Security Strengthen Mode A Box built on the HDD is used to store the scanned data. To prevent the data from being accessed or tampered with, we recommend using the Box with a password specified. Never fail to use the Security Strengthen mode when storing any secret doc- ument.
Page 939 Security Touch [Password] to display the Input Password Screen. Enter the password, then touch [OK] to return to the User Authentica- tion Screen. Details Passwords are case sensitive. If a wrong password or fewer than 8 alphanumerical characters are en- tered and the [OK] key is touched, the warning message "Password does not match"...
Page 940 Security Touch [OK]. The Copy Screen will be displayed. Touch [Output Application] on the Copy Screen. Touch [HDD Store] on the Output Application Screen. The HDD Box List Screen will be displayed. 19-28 bizhub PRO 1050/1050e...
Page 941 Security Select the desired personal Box. Enter the password if selected Box requires one. The File Selection Screen will be displayed. Touch [Store]. The Input File Name Screen will be displayed. bizhub PRO 1050/1050e 19-29...
Page 942 Security Enter the file name, then touch [OK]. Press [Start] on the control panel to scan. After scanning all the originals, the machine automatically starts to print and store the data in a Box. When operation is completed, press [Access] on the control panel. The User Authentication Screen will be displayed to prohibit the ma- chine operation without entering a user name and password.
Page 943: Store Scanned Data In A Box
Security 19.5.2 Store scanned data in a box The following is a detailed explanation of how to save scanned data to a Box and also to output the data in Security Strengthen mode. Procedure On the User Authentication Screen, touch [User Name] and [Password] to enter your user name and password.
Page 944 Security Details Passwords are case sensitive. If a wrong password or fewer than 8 alphanumerical characters are en- tered and the [OK] key is touched, the warning message "Password does not match" will appear, and no key will work for five seconds. Enter the right password after five seconds.
Page 945 Security Touch [STORE] or [RECALL]. If you touch [STORE], then touch [Scanner to HDD]. The HDD Box List Screen will be displayed. Select the desired personal Box. Enter the password if selected Box requires one. The File Selection Screen will be displayed. bizhub PRO 1050/1050e 19-33...
Page 946 Security Touch [Store], then enter. Enter the file name, then touch [OK]. The Scanner Basic Screen will be displayed. 19-34 bizhub PRO 1050/1050e...
Page 947 Security Make the desired setting, then press [Start] on the control panel to scan and store the image data. When operation is competed, press [Access] on the control panel. The User Authentication Screen will be displayed to prohibit the ma- chine operations without entering a user name and password.
Page 948: Recall/Delete Data In A Box
Security 19.5.3 Recall/Delete data in a box The following is a detailed explanation of how to recall or delete the data stored in a box. Procedure On the User Authentication Screen, touch [User Name] and {Password] to enter your user name and password. Touch [User Name] to display the Input User Name Screen.
Page 949 Security Touch [Password] to display the Input Password Screen. Enter the password, then touch [OK] to return to the User Authen- tication Screen. Details Passwords are case sensitive. If a wrong password or fewer than 8 alphanumerical characters are en- tered and the [OK] key is touched, the warning message "Password does not match"...
Page 950 Security Touch [OK]. The Copy Screen will be displayed. Touch [RECALL]. The HDD Box List Screen will be displayed. Select the desired personal Box. Enter the password if selected Box requires one. The File Selection Screen will be displayed. 19-38 bizhub PRO 1050/1050e...
Page 951 Security Recall or Delete the image data. To recall the image data Touch the desired file key, then touch [>>>]. To output the image data, touch [Wait Output], [Proof Output], or [Auto Output], as desired, and then touch [OK]. Specify the output page. Touch [Output Page.] To output one desired page only, [Touch Page Select], press the control panel keypad, then touch [OK].
Page 952 Security Enter the desired print quantity from the touch panel keypad, then touch [OK]. To delete the image data Touch the desired file key, then touch [File Delete]. The popup menu to confirm will be displayed. Touch [Yes] The selected file will be deleted, and return to the File Selection Screen. When operation is completed, press [Access] on the control panel.
Page 953: Output Data In The Secure Box
Security 19.5.4 Output data in the Secure Box Secure printing using a PC: To set up data output using the secure printing function on PC, a secure fold- er with a specific password must be prepared. Enter the secure folder name made up of max.
Page 954 Security Touch [Password] to display the Input Password Screen. Enter the password, then touch [OK] to return to the User Authen- tication Screen. Details Passwords are case sensitive. If a wrong password or fewer than 8 alphanumerical characters are en- tered and the [OK] key is touched, the warning message "Password does not match"...
Page 955 Security Touch [OK]. The Copy Screen will be displayed. Touch [RECALL]. The HDD Box List Screen will be displayed. bizhub PRO 1050/1050e 19-43...
Page 956 Security Touch [Secure Folder] to display the Secure Box List Screen. Select the desired secure box. Enter the secure password setup in secure printing. Touch [OK]. The Secure File List Screen will be displayed. Select the desired secure file. 19-44 bizhub PRO 1050/1050e...
Page 957 Security Secure printing will start. Touch [Wait Output], [Proof Output], or [Auto Output] as desired. When operation is completed, press [Access] on the control panel. The User Authentication Screen will be displayed to prohibit the ma- chine operation without entering a user name and password. bizhub PRO 1050/1050e 19-45...
Page 958: Machine Manager Security Functions
Security 19.6 Machine Manager Security Functions The machine manager turns Security Strengthen mode ON/OFF. To do so, an 8-digit CE authentication password and Machine Manager password must be set for the machine. Ask your authorized service repre- sentative to set up a Machine Manager password. To change this password, the machine manager himself should operate the procedure.
Page 959 Security Enter the password. Use the touch panel keypad to enter the 8-digit Machine Manager password, then touch [OK]. The Machine Manager Setting Menu Screen will be displayed. Details Passwords are case sensitive. If a wrong password or fewer than 8 alphanumerical characters are en- tered and the [OK] key is touched, the warning message "Password does not match"...
Page 960 Security Touch [07 Security Setting]. Touch [03 Security Strengthen Mode]. 19-48 bizhub PRO 1050/1050e...
Page 961 Security Turn Security Strengthen mode ON or OFF. If you want to turn Security Strengthen mode ON, touch [On] to high- light it. If you want to turn it OFF, touch [Off] to highlight it. Touch [OK]. The Restart Confirmation popup screen will appear. Touch [Yes].
Page 962: Hdd Lock Password
Security 19.6.2 HDD lock password While the Security Strengthen mode is turned ON, a lock password (8 to 32 alphanumerical characters, case sensitive) can be set up on the HDD to pro- tect the data stored on it. If the HDD itself is externally accessed, the data readout will not be available until the correct lock password is entered.
Page 963 Security Enter the password. Use the touch panel keypad to enter the 8-digit Machine Manager password, then touch [OK]. The Machine Manager Setting Menu Screen will be displayed. Details Passwords are case sensitive. If a wrong password or fewer than 8 alphanumerical characters are en- tered and the [OK] key is touched, the warning message "Password does not match"...
Page 964 Security Touch [07 Security Setting]. Touch [02 HDD Management Setting]. The HDD Management Setting Menu Screen will be displayed. 19-52 bizhub PRO 1050/1050e...
Page 965 Security Touch [03 Change HDD Lock Password]. The Change HDD Lock Password Screen will be displayed. Touch [Current Password] to enter the password currently used, then touch [OK]. (The first password: 9-digit alphanumeric serial number of the main body) Details The main body serial number will be printed at the upper right corner of the audit log.
Page 966 Security If authentication is succeeded, touch [New Password] to enter the new password. The key will not be active until authentication is succeeded. Reminder Do not use your name, birthday, employee number, etc. for a password that others can easily figure out. Details If authentication fails, the information will be saved in the audit log.
Page 967: Print Audit Log
Security 19.6.3 Print audit log An audit log will be automatically created when the data saved in the ma- chine have been accessed. All the audit log data can be output as follows. Procedure Press [Utility/Counter] on the control panel to display the Utility Screen. Touch [06 Machine Manager Setting].
Page 968 Security Use the touch panel keypad to enter the 8-digit Machine Manager password, then touch [OK]. The Machine Manager Setting Menu Screen will be displayed. Details Passwords are case sensitive. If a wrong password or fewer than 8 alphanumerical characters are en- tered and the OK key is touched, the warning message "Password does not match"...
Page 969 Security Touch [04 Management List Print]. The Management List Print Screen will be displayed. Touch [Audit Log Report], then touch [COPY]. Press [Start] on the control panel. Details To stop printing, press [Stop] on the control panel, then touch [Cancel] on the confirmation popup screen.
Page 970: Analyze Audit Log
Security 19.6.4 Analyze audit log Audit logs need to be analyzed by the machine manager regularly (once per month) or when unauthorized access and tampering of data saved in the ma- chine in Security Strengthen mode is noticed. The machine is supposed to store up 750 logs per month. If more than 750 logs are assumed to be stored in a month, carry out the analysis in a shorter period before the unanalyzed logs reach that number.
Page 971 Security Audit Log Information The audit log contains the following information. date/time: date and time when an operation was made that results in the creation of a log entry. the person who made the operation or who is subject to security protec- tion can be specified.
Page 972: Table Of Items Saved In Audit Log
Security Table of items saved in audit log Operation Stored action Result CE authentication CE ID OK/NG Manager authentication Machine Manag- OK/NG er ID Set/change Security Machine Manag- Strengthen mode er ID Print audit log Machine Manag- er ID Change/register CE pass- CE ID word Change/register Machine...
Page 973 Security The purpose of analyzing the audit log is to understand the following and im- plement countermeasures: - Whether or not data was accessed or tampered with - Subject of attack - Details of attack - Results of attack For specific analysis methods, see the next page. Specify unauthorized actions: password authentication If logs have NG as the result of password authentication (action: 01, 02, 11, 16), items protected by passwords may have been attacked.
Page 974 Security Specify unauthorized actions: actions other than password authentica- tion under security All operation results other than password authentication will be indicated as successful (OK), so determine if there were any unauthorized actions by ID and action. - Since you cannot specify what was attacked only with an ID, you need to see the action and the table on the previous page to determine whether unauthorized actions were made on a personal box or secure box.
Page 975: Troubleshooting
Troubleshooting...
Page 977: If "Please Call Service" Message Is Displayed
Troubleshooting Troubleshooting 20.1 If “Please Call Service” Message Is Displayed A “Please Call Service” message indicates a machine condition that requires the attention of your service representative. The Call for Service Screen usually displays the telephone and facsimile numbers of your service representative. 7 CAUTION When the Call for Service Screen is displayed, be sure to contact your service representative immediately by following the procedure below.
Page 978 Troubleshooting Turn OFF the sub power switch and main power switch. Unplug the machine. Contact your service representative and report the condition and report code number. Details Limited Use of the Copier in Trouble If the message shown below is displayed on the Call for Service Screen, you may continue operating the copier on a limited function basis and uti- lize the trays and ADU that are not affected by the trouble.
Page 979: Clearing Mishandled Paper
Troubleshooting 20.2 Clearing Mishandled Paper When a paper misfeed occurs, the machine stops making copies and the Jam Position Screen displays to indicate misfeed area(s). The [Start] LED turns red on the control panel, and copying operation cannot be continued until all the misfeed locations are cleared. Part name Description Message area...
Page 980 Troubleshooting Touch Illustration on the screen. The screen illustrating the method for the disposal action will be dis- played. Details Touch [Next] to go to the next page of a series of illustrations, if provided. Touch [Jam Position] to return to the Jam Position Screen. If paper misfeed occurs in the Perfect Binder PB-501, the Illustration key is not displayed.
Page 981 Troubleshooting 7 CAUTION The internal fixing unit is very hot. To avoid getting burned, DO NOT TOUCH. Be especially careful not to put your hand into the fixing unit area when withdrawing the fixing conveyance unit to remove mishandled paper. Be careful of removing staples stuck inside the machine so as not to get injured.
Page 982: If Machine Tab Blinks In Orange
Troubleshooting 20.3 If MACHINE Tab Blinks in Orange If any trouble occurs in the machine, one of the following messages will be displayed in the message area and the [MACHINE] tab will blink in orange. - Paper Misfeed: “Mishandled paper” - Tray Empty: “Please load ## paper”...
Page 983: Tray Empty
Troubleshooting 20.3.2 Tray Empty If the popup screen shown below is displayed after touching [Detail Check], the selected tray has become empty. Follow the procedure below to change the tray selection for the current job, or supply the empty tray with copy paper. To change the tray selection Touch the desired tray key.
Page 984 Troubleshooting To supply the empty tray with paper Load paper in the empty tray. For details, refer to “Loading Paper” on page 4-3. Touch [Close] to restore the Machine Status Screen. Press [Start]. Printing operation will resume using the tray supplied with paper. 20-10 bizhub PRO 1050/1050e...
Page 985: Inconformity In Paper Presetting
Troubleshooting 20.3.3 Inconformity in Paper Presetting The machine automatically stops when copy paper in the selected tray should be replaced according to the paper presetting specified in reserve setting, and displays either of the following popup screens. Follow the procedure for each to continue the machine operation. Using Custom size/Wide size/Tabbed standard size paper of different size or in different condition Replace paper in the tray with that specified in the paper presetting, then...
Page 986 Troubleshooting Using Standard size paper of different size Replace paper in the tray with that specified in the paper presetting. Touch [Change], then press [Start] to start the printing operation. Details If wrong size is loaded in the tray, the above popup screen will be dis- played.
Page 987: If "Memory Full" Message Is Displayed (Memory Overflow)
Troubleshooting 20.4 If “Memory Full” Message Is Displayed (Memory Overflow) In certain modes, this machine uses memory to make operations convenient and smooth flowing. Occasional memory overflow may occur if the installed memory is inade- quate for the copy conditions selected, and the machine will stop its opera- tion with the following popup screen displayed.
Page 988: If Power Off/On Screen Is Displayed
Troubleshooting 20.5 If Power OFF/ON Screen Is Displayed When any trouble affects the electrical signal of the copier, “Please switch Off/On” will be displayed in the message area. Follow the procedure below to turn the machine power off then on. Turn OFF the sub power switch.
Page 989: Troubleshooting Tips
Troubleshooting 20.6 Troubleshooting Tips Copier does not operate when sub power switch is on - Check to be sure power plug is firmly inserted in electrical socket. - Check to be sure main power switch is ON. - Check to see if Weekly Timer function is activated. See “When Weekly Timer Is Activated”...
Page 990 Troubleshooting Copying does not begin after pressing [Start] - Close Front door and left side door of main body. - Insert or adjust the appropriate paper tray for paper size selected. - Be sure the print quantity is entered. - Close Finisher door/Folding unit door/Large capacity stacker door com- pletely.
Page 991 Troubleshooting APS selects the wrong paper size Paper guides must be adjusted exactly to the size of originals. In mixed original mode, a message to load a required paper size dis- plays, even though that size is loaded in one of the trays Paper sizes loaded in the trays must be consistent with the tray position size;...
Page 992 Troubleshooting Copies skew in the stapled sets - Check to see if copy paper is excessively curled in the tray. Reload the copy paper upside down. - Check to see if large-sized copies meet the secondary (sub) tray when fully output before being stapled. Release the lock of the secondary (sub) tray, then slightly lift it upward.
Page 993: Maintenance
Maintenance...
Page 995: Cleaning Image Scanning Section
Maintenance Maintenance 21.1 Cleaning Image Scanning Section In order to maintain optimum copy quality, always keep the following areas clean. 21.1.1 Cleaning the ADF Scanning Glass Keep the ADF scanning glass clean; otherwise soil marks may be copied, re- sulting in dark lines on the copies. Raise the document feeder, then clean the glass with a clean soft cloth.
Page 996: Cleaning The Adf Guide Cover
Maintenance 21.1.3 Cleaning the ADF Guide Cover The ADF guide cover should be kept clean; otherwise soil marks may be cop- ied or the original size cannot be detected correctly. Raise the document feeder, then clean the ADF guide cover with a clean soft cloth. Reminder Never use paint solvents, such as ben- zene or thinners, to clean the ADF...
Page 997: Precautions For Paste Pellets And The Perfect Binder
Maintenance 21.2 Precautions for Paste Pellets and the Perfect Binder To ensure safety and product reliability, observe the precautions for using paste pellets and the Perfect Binder. Read chapter “1 Safety Information” as well. Precautions for Paste Pellets - Paste pellets are not edible; do not put them in your mouth nor swallow them.
Page 998: Checking Copy Count
Maintenance 21.3 Checking Copy Count The Utility Menu Screen allows you to view the current indication of the fol- lowing items as a list. - Total count - Feed paper count - Output paper count - Printer total count - Copier total count - Scanner total count - PM count, cycle, counter start date - Developer count, cycle, counter start date...
Page 999 Maintenance Details The Utility Menu Screen can be displayed even when the job operation is in progress. The counter information will be displayed on the left side of the screen. Touching [Exit] will return to the previous screen. Touch [Detail]. The PM count, Developer count, and Drum count will be displayed.
Page 1000 Maintenance Details The Developer count and Drum count can be selected to indicate either the cycle count or runtime count. Contact your service representative, if desired. Print the counter list, if desired. Touch [COPY] tab to display the Copy Screen. Select the desired paper size, then press [Start].
Page 1001: Preventive Maintenance
Maintenance 21.4 Preventive Maintenance After a set number of copies (750,000 copies) have been made on your ma- chine, Preventive Maintenance (PM) will be required for maintaining optimal performance. When preventive maintenance is due, a message and the PM icon will prompt you to contact your service representative for maintenance.
Page 1002 Maintenance 21-10 bizhub PRO 1050/1050e...
Page 1003: Machine Specifications
Machine Specifications...
Page 1005: Main Body Specifications
Machine Specifications Machine Specifications These specifications are subject to change without notice. 22.1 Main Body Specifications 22.1.1 Main Body Specifications Name bizhub PRO 1050/1050e Type Console type Transfer method Indirect electrostatic method Original glass Fixed Light-sensitive unit Light source Xenon lamp Developing method Dry, 2-component magnetic brush developing Fixing method...
Page 1006 Machine Specifications Specifications Paper size • Standard size: A3 to B6R size (image cutoff width: leading and trailing ± ± ends 2 mm 2 mm, top and bottom 1.5 mm 1.5 mm) • Wide size and non-standard size: Max. 324 mm x 460 mm * Full-Image Area function is not provided on this machine.
Page 1007: Adf (Df-603)
Machine Specifications 22.1.2 ADF (DF-603) Specifications Function Feed 1- and 2-sided originals automatically Type of original 50 ~ 200 g/m Original size A3, B4, A4, A4R, B5, B5R, A5, B6R, 11"x17", 8"x13", 8.5"x11" Original capacity 100 sheets max. (80 g/m Original insertion Automatic feed at a time Dimensions...
Page 1008: Option Specifications
Machine Specifications 22.2 Option Specifications 22.2.1 Paper Feeder Unit PF-701 Specifications Function: Paper feed into main body (3 trays) Paper sizes A3, B4, A4, B5, B5R, F4, 12”x18”, 11"x17", 8.5"x14", 8.5"x11", and those wide sizes (max. 324 mm x 460 mm) Types of paper •...
Page 1009: In-Bin Stapler Finisher Fs-503
Machine Specifications 22.2.3 In-Bin Stapler Finisher FS-503 Specifications Type Offset catch tray Functions Staple, Straight delivery, Shift delivery, Output to secondary tray Paper sizes • Staple: A3, B4, A4, A4R, B5, A5, F4, 12"x18", 11"x17", 8.5"x14", 8.5"x11", 8.5"x11"R, 5.5"x8.5", 8K, 16K and those wide sizes (max.
Page 1010: Folding Unit Fd-501
Machine Specifications 22.2.4 Folding Unit FD-501 Specifications Functions Punch, Folding, Post inserting (PI), Straight delivery, Output to secondary tray Number of punch holes 2 or 4 ± ± Hole diameter 6.5 mm 0.5 mm (2 holes) / 8.0 mm 0.5 mm (4 holes) ±...
Page 1011: Saddle Stitcher Sd-501
Machine Specifications 22.2.5 Saddle Stitcher SD-501 Specifications Functions Multi-folding (Multi Centre, Multi Letter), Fold&Staple, Trim- ming, Straight delivery Processing capability 105 sheets per minute at maximum Types of paper • 50 to 244 g/m paper (Multi Centre, Fold&Staple, Trim- ming) •...
Page 1012: Perfect Binder Pb-501
Machine Specifications 22.2.6 Perfect Binder PB-501 Specifications Functions Hot-melt type binding, Trimming, Manual binding, Straight de- livery to secondary (sub) tray Processing capability: 105 sheets per minute at maximum Number of sheets (1 set) 10 to 300 sheets, or within 30 mm thick Paper sizes Perfect binding tray;...
Page 1013 Appendix...
Page 1015: How To Input Characters
Appendix Appendix 23.1 How to Input Characters As touching the item where you can input characters, the character input screen appears. You can input alphanumerics and symbols. A character array is the same with the computer keyboards. 23.1.1 About keys on the character input screen Keys on the character input screen are described here.
Page 1016: About Character Input
Appendix 23.1.2 About character input The followings describe basic steps to input characters on the character in- put screen. Touch the corresponding key to input the desired character. Touch [OK]. The character input screen closes. The input characters are displayed on the corresponding column.
Page 1017: Setting Data For Import/Export
Appendix 23.2 Setting Data for Import/Export [1] System Main menus Sub menus Target items Device Infor- Device Infor- Device Name Device Place Administrator Name mation mation Online Assist- Online Assist- Contact Name ance ance Contact Information Product Help URL Corporate URL Supplies and Accessories Online Help URL E-Mail Alert...
Page 1018 Appendix [2] Print Main menus Sub menus Target items Interface Interface Parallel Timeout Network Timeout Default Setting General Input Tray Output Tray Duplex Binding Staple Punch Center Staple/CenterFold/Trimming Offset Output Order Page Order Print Number Collate Paper Size Orientation Resolution Spool setting Banner Option Banner Page Tray...
Page 1019 Appendix [3] Network Main menus Sub menus Target items TCP/IP TCP/IP TCP/IP Speed Auto IP IP Adress Subnet Mask Default Gateway Host Name Domain Name DNS Server RAW Port Number1 RAW Port Number2 RAW Port Number3 RAW Port Number4 RAW Port Number5 RAW Port Number6 IP Address Fil- Access Permission Address...
Page 1020 Appendix Main menus Sub menus Target items IPP Print Printer Name Printer Location Printer Information Printer URI Operations Supported Print Job Accept Print Job Validate Job Cancel Job Get Job Attribute Get Jobs Get Printer Attribute Client FTP Client Proxy Server Address Proxy Server Port Number Server Timeout Port Number...
Page 1021 Appendix Main menus Sub menus Target items SSL/TLS SSL/TLS Infor- Encryption Strength mation Validity Period Organization Organization Unit Locality State/Province Country Authentication Auto Logout Admin Logout Time User Logout Time AP I/F AP I/F Port Number Use SSL/TLS Port Number(SSL/TLS) bizhub PRO 1050/1050e 23-9...
Page 1022: Configuration Setting
Appendix 23.3 Configuration Setting Print Sample 23-10 bizhub PRO 1050/1050e...
Page 1023 Appendix Print Sample bizhub PRO 1050/1050e 23-11...
Page 1024 Appendix Print Sample 23-12 bizhub PRO 1050/1050e...
