92/31/EEC, Amending Directive 89/336/EEC relating to EMC The EC Declaration of Conformity is available upon request for products with a CE mark. For copies of the EC Declaration of Conformity, contact: Eaton Power Quality Oy Koskelontie 13 FIN-02920 Espoo Finland...
Page 4
Special Symbols The following are examples of symbols used on the UPS or accessories to alert you to important information: RISK OF ELECTRIC SHOCK - Indicates that a risk of electric shock is present and the associated warning should be observed. CAUTION: REFER TO OPERATOR’S MANUAL - Refer to your operator’s manual for additional information, such as important operating and maintenance instructions.
Proper disposal of batteries is required. Refer to your local codes for disposal requirements. Never dispose of batteries in a fire. Batteries may explode when exposed to flame. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 10
Une mise au rebut réglementaire des batteries est obligatoire. Consulter les règlements en vigueur dans votre localité. Ne jamais jeter les batteries au feu. L’exposition aux flammes risque de les faire exploser. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Es necesario desechar las baterías de un modo adecuado. Consulte las normas locales para conocer los requisitos pertinentes. Nunca deseche las baterías en el fuego. Las baterías pueden explotar si se las expone a la llama. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
NOTE Check the battery recharge date on the packaging label. If the date has expired and the batteries were never recharged, do not use the UPS. Contact your service representative. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
The following clearances are recommended for the Powerware 9355 UPS: From Front of Cabinet 36” (91.4 cm) working space From Back of Cabinet 6” (15.2 cm) ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
To remove a three-high cabinet or a two-high EBM from the shipping pallet: Remove the two M10 bolts securing the stabilizing bracket to the pallet (see Figure 2). M10 Bolts Figure 2. Removing the Stabilizing Bracket Bolts ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 16
Remove the three M10 bolts securing the rear shipping pad to the pallet and remove the shipping pad. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 17
Reinstall the front cover removed in Step 3. Hang the top edge of the cover on the cabinet first, then lower the bottom edge and snap into place. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 18
With the cabinet supported, slowly pull the pallet away from the cabinet (see Figure 5). Figure 5. Removing the Pallet Roll the cabinet to the desired location. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
M10 Bolt Figure 6. Removing the Vertical Bracket Reinstall the M4 screws to the UPS (see Figure 7). M4 Screws Figure 7. Reinstalling the M4 Screws ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 20
If needed, adjust the leveling feet to release the bracket. Front Shipping Bracket M10 Bolts M10 Bolts Shipping Pad Figure 8. Removing the Front Shipping Bracket and Shipping Pad ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 21
(see Figure 9). If needed, adjust the leveling feet so that the cabinet will roll. Figure 9. Unloading the Cabinet ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 22
10. With the cabinet supported, slowly pull the pallet away from the cabinet (see Figure 10). Figure 10. Removing the Pallet 11. Roll the cabinet to the desired location. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
UPS cabinet. Switch off utility power to the distribution point where the parallel tie cabinet and UPSs will be connected. Be absolutely sure there is no power. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 24
Figure 11. Parallel Tie Cabinet Front Cover Remove the internal cover to gain access to the breakers (see Figure 12). Internal Cover Figure 12. Internal Cover ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 25
12. Punch two holes in the conduit landing plate for the input and output conduit using a Greenlee punch or similar device. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 27
Conduit sizes were chosen from NEC Table C1, type letters RHH, RHW, RHW-2, TW, THW, THHW, THW-2. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 28
14. Hardwire the output terminations from the UPS to the parallel tie cabinet (see Figure 16). Ground Neutral Line 1 Line 2 Line 3 Figure 16. UPS Output to Parallel Tie Cabinet Wiring ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 29
18. Repeat Steps 12 through 17 for each UPS. Maintenance Bypass Wiring to UPS TB2 Ground Neutral Line 1 Line 2 Line 3 Figure 17. Load Connections ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 30
21. Reinstall the internal cover removed in Step 6. 22. Reinstall the parallel tie cabinet front cover removed in Step 5. 23. Continue to “Installing Options” on page 27. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 31
Bypass Input 80A (4X) LOAD From UPS 1 Output From UPS 2 Output From UPS 3 Output From UPS 4 Output Figure 19. Parallel Wiring Diagram ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
X-Slot Communication Bay #2 Signal Input 2 REPO (normally open) REPO (normally closed) DB-9 Communication Port Relay Output Contacts Figure 21. Communication Options and Control Terminals ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Press and release the handle latch at the bottom of each cover and then lift the cover up and off the cabinet (see Figure 23). Figure 23. Removing the Front Covers ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 35
Verify all CAN Bridge Card wiring is correct for proper operation. NOTE Signal Input 2 can still be used for building alarms; it is automatically rerouted to the CAN Bridge Card. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 36
INSTALLING OPTIONS SHIELD CAN H CAN L ALM RTN ALARM UPS #1 UPS #2 UPS #3 UPS #4 Figure 24. CAN Bridge Card Wiring ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 37
With wire cutters, cut either side of the tab and twist down to remove the tab (see Figure 25). Figure 25. Removing Knockout Tabs Route the cable(s) to the approximate location of the cover access holes. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 38
Be sure the cables fit in the access holes in the covers. Figure 26. Reinstalling the Front Covers Continue to “Stabilizing the Cabinet” on page 33 to complete the parallel UPS installation. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Continue to one of the following sections: “Extended Battery Module Installation” on page 37 to install optional EBMs. “Operation” on page 41 to start up the parallel UPS system. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 40
STABILIZING THE CABINET M4 Screws Figure 28. Stabilizing Bracket with One Cabinet M4 Screws Figure 29. Stabilizing Bracket with Two Cabinets ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 41
STABILIZING THE CABINET M4 Screws Figure 30. Stabilizing Bracket with Three Cabinets ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 42
STABILIZING THE CABINET ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
If additional EBMs are installed, plug the EBM cable of the second cabinet into the battery connector on the first EBM. Repeat for each additional EBM. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 45
NOTE After UPS startup, ensure maximum battery runtime by configuring the UPS for the correct number of EBMs (see page 47). Front Ground Strap Figure 32. Front Ground Strap Installation (2-High Cabinets Shown) ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Power On Indicator (green) On Battery Indicator (yellow) Bypass Indicator (yellow) Alarm Indicator (red) Control Buttons for the LCD Menu Options Figure 33. Powerware 9355 Control Panel ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Display Functions As the default or after 15 minutes of inactivity, the LCD displays the selectable startup screen. The default is the Eaton Powerware logo and can be changed to the Mimic screen in the User Settings menu. The backlit LCD automatically dims after a long period of inactivity. Press any button to restore the screen.
Page 49
UPS Type / Part Number / Serial Number / Firmware / Display / CAN Bridge Turn UPS ON/OFF ON and OFF Options UPS Off / System On / System Off ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
<Not Installed> Set Modem Call Events Event #0 Call modem: no Set Modem Init String ATZ0 Set Modem Call Command None Set Modem Communication Password None ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 51
OPERATION Table 3. User Settings (continued) Description Available Settings Default Setting Start Screen Eaton Powerware logo Eaton Powerware logo Mimic screen User Password Enabled/Disabled Disabled If Enabled is selected, the password is USER. Audible Alarms Normal Sound/Disabled Normal Sound Battery Charging...
Initial Startup Startup and operational checks must be performed by an authorized Eaton Customer Service Engineer, or the warranty terms as specified in the Powerware 9355 UPS (10/15 kVA) User’s Guide become void. This service is offered as part of the sales contract for the UPS. Contact service in advance (usually a two-week notice is required) to reserve a preferred startup date.
UPS-64 models contain 4 strings; EBM-96 models contain 6 strings. Press the button to save the setting. Press the button until the Eaton Powerware logo appears. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
The UPS removes power to the parallel UPS system output. Press the button until the Eaton Powerware logo appears. If you want to completely remove power from the UPS, continue to the following section, “Individual UPS Shutdown,” to shut down each UPS.
Switch off utility power where the UPS is connected. If you are shutting down all the UPSs in a parallel system, repeat Steps 2 through 6 for each UPS then remove utility power. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
The UPS goes to Bypass mode for five seconds, and then the indicator illuminates. Each UPS should be in Normal mode. 10. Press the button until the Eaton Powerware logo appears. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide...
Switch the bypass breaker on the parallel tie cabinet to the ON position. Switch the UPS breakers on the parallel tie cabinet to the OFF position. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 58
On the same UPS front panel, set the UPS to Normal mode: Press the button to select the Go to Normal Mode option. Each UPS should go to Normal mode. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
UPS continues to operate, but may switch to nominal). Bypass mode if the load increases. The alarm resets when the condition becomes inactive. LED is on. 1 beep every second. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Page 60
If the condition persists, contact your backup time. service representative. Battery circuit breakers are in the OFF Switch all battery circuit breakers to the ON position. position. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Press any button on the front panel display to silence the alarm. If the alarm status changes, the alarm beeps again, overriding the previous alarm silencing. ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
Please have the following information ready when you call for service: Model number Serial number Firmware version number Date of failure or problem Symptoms of failure or problem Customer return address and contact information ® EATON Powerware 9355 Parallel UPS (10/15 kVA) User’s Guide 164201601 Rev A www.powerware.com...
