The bottom right side of the screen contains three buttons:
Help displays online help
Apply click this button to save your configuration changes to the displayed page
Cancel click this button to discard any configuration changes made to the current page

Web Management Interface Menus and Submenus

Table 3 describes the menus and submenus in the Web management interface.
Table 3. Web Management Interface Menus and Submenus
Note: Some menus and submenus described in this chapter may not apply to your
Gateway. Please check your Gateway's GUI to see which items are available.
Menu and Submenus
System
System > Password Settings
LAN
LAN > Ether Switch Control
LAN > Ether Access Control
QoS
QoS > Port
QoS > COS
QoS > DSCP
QoS > Queue
QoS > DSCP Remarking
Wireless
Wireless > Encryption
Wireless > WPS
Wireless > MAC Filtering
Wireless > Advanced Settings
Configuring Your Gateway
Description
Lets you enable or disable uPnP and HNAP. The submenu lets you:
Define the password for logging in to the Gateway's Web interface.
•
Lets you configure settings for your private LAN.
• Specify fixed speed and duplex settings, and disable individual LAN ports.
Allow all EtherLAN client stations to access the Internet through the Gateway,
•
allow certain trusted EtherLAN client stations to access the Internet through the
Gateway, or deny certain trusted EtherLAN client stations from accessing the
Internet through the Gateway.
Lets you enable Quality of Service (QoS) settings. If you enable QoS, the following
submenus become available for:
Prioritizing performance of the four Gateway LAN ports.
•
• Defining four queues to which the Class of Service (CoS) is mapped.
Defining the QoS class queue to which the customized DSCP is mapped.
•
Specifying whether QoS behavior runs with strict or weighted priority.
•
• Defining the DSCP remarking action and mode.
Lets you configure basic wireless settings, such as enabling or disabling wireless
operation, selecting wireless mode, and configuring the Service Set Identifier
(SSID) and channel settings. Submenus let you:
Use encryption to protect the data transmitted across your wireless network
•
Enable or disable Wi-Fi Protected Setup (WPS).
•
Allow all wireless client stations or only trusted PCs to connect over a wireless
•
connection.
Configure advanced wireless settings for the Gateway.
•
SMCD3GN2 Wireless Cable Modem User Manual
32
See Page
34
35
36
39
41
44
45
46
48
50
52
54
56
60
63
65
