Figure 35. WPS Setup Menu with WPS Config Enabled
Table 13. WPS Summary and WPS Progress Options
Option
WPS Config
WPS Current Status
WPS Configured
AP PIN
WPS mode
WPS PIN
Configuring Your Gateway
Enables or disables the Gateway's WPS setup.
ENABLE = Gateway's WPS setup is available. (default)
•
DISABLE = Gateway's WPS setup is unavailable.
•
WPS Summary
A read-only field that shows whether WPS is currently being used.
A read-only field that whether WPS has been configured.
A read-only field that shows the personal identification number (PIN) for the access point.
WPS Progress
Determines whether WPS can be configured using a PIN or the WPS button on the front panel of the
Gateway.
PIN = requires you to enter a PIN in the WPS Setup menu to configure WPS.
•
PBC = Push Button Configuration. Lets you use the WPS button on the front panel of the Gateway
•
to configure WPS.
If PIN was selected for WPS mode, enter the PIN required to enable WPS. The PIN must be 8 alpha-
numeric characters long.
