SMC Networks SMCD3GN2 User Manual page 107

Output Return Loss: > 6dB
WLAN
1T1R/1T2R/2T2R modes
300Mbps PHY data rate
Supports IRRR 802.e WiFi Multimedia (WMM)
Support 8 SSIDs
WMM-QoS
WPS, WPA, WEP (64/128-bit), TKIP,AES, MAC Filtering
WPS push button for WiFi Protected Setup with PIN
MAC address Access Control
ENVIRONMENT
Operating Temperature: 32 °F (0°C) to 104°F (40°C)
Operating Humidity: 10% to 90%
Storage Temperature: -40°F (-40°C) to 140°F (80°C)
REGULATORY /STANDARD COMPLIANCE
FCC Part 15B Class B
UL/Cul:609650-1
WiFi 802.11b /g/ n
DOCSIS 3.0
DIMENSIONS (L x W x H) without packaging
9.84x 6.30 x 1.65 in
25 x 16 x 4.2 cm
WEIGHT: 508g/1.12lb
LEDs: Power, DS ( Downstream), US ( Upstream), Online, ETH (4), Wireless, USB
POWER SUPPLY: AC on board; AC power: 90~120V
* Actual speeds will vary based on factors including networks configuration and service tiers.
Technical Specifications
107
SMCD3GN2 Wireless Cable Modem User Manual
