The bottom right side of the screen contains three buttons:
Help displays online help
Apply click this button to save your configuration changes to the displayed page
Cancel click this button to discard any configuration changes made to the current page

Web Management Interface Menus and Submenus

Table 3 describes the menus and submenus in the Web management interface.
Note: Some menus and submenus described in this chapter may not
apply to your Gateway. Please check your Gateway's GUI to see which
menus and submenus are available.
Table 3. Web Management Interface Menus and Submenus
Menus and Submenus
System
System > Password Settings
System > Remote Management
System > Customer UI Setup
WAN
WAN > MAC Spoofing
LAN
LAN > Ether Switch Control
LAN > Ether Access Control
LAN > Additional Public LAN
LAN > Public LAN IP Access
Control
QoS
QoS > Port
SMCD3GN2 Wireless Cable Modem Gateway Administrator Manual
錯誤! 尚未定義樣式。
Lets you disable all commercial Gateway functions, define a router name, use the
router name at command prompts, and enable or disable UPnP and HNAP.
Submenus let you:
Define user and admin password settings, RADIUS authentication, TACACS+
•
authentication, and TACACS authentication.
Allow users to manage the Gateway remotely using the Gateway's Web interface
•
and/or Telnet, and enable or disable remote management of the Gateway's
administrator interface.
Select which configuration options on the Gateway's user configuration menus are
•
shown to or hidden from users.
Lets you configure Wide Area Network (WAN) and Media Access Channel (MAC)
spoofing settings. The submenu lets you:
Clone ("spoof") the Gateway's MAC address if necessary.
•
Lets you configure settings for your public and private LAN, auto-negotiation, and
duplex mode. The submenu lets you:
Specify fixed speed and duplex settings, and disable individual LAN ports.
•
Allow all EtherLAN client stations to access the Internet through the Gateway,
•
allow certain trusted EtherLAN client stations to access the Internet through the
Gateway, or deny certain trusted EtherLAN client stations from accessing the
Internet through the Gateway.
Add more than one public subnet, except for 20.20.1, to the LAN interface.
•
Block specific pubic IP addresses from accessing the Internet.
•
Lets you configure Quality of Service (QoS) settings. If you enable QoS, the
following submenus become available for:
Prioritizing performance of the four Gateway LAN ports.
•
33
Description See Page
36
38
43
44
46
49
50
53
54
58
60
62
64
