Table 19. Customer Defined Access Rules Menu Options
Option
Name
Type
Remote IPs
Start IP
End IP
Local IPs
Start IP
End IP
From Port
To Port
Configuring Your Gateway
Name for identifying the custom service. The name is for reference purposes only.
The type of protocol you want to access rule. Choices are TCP, UDP, and TCP/UDP. Default
is TCP.
Lets you apply the access rule to any remote IP addresses, a single remote IP address, or a
range of remote IP addresses.
If you select one remote IP address, enter the IP address in the Start IP field.
•
If you select a range of remote IP addresses, enter the starting IP address in the Start IP
•
field and the ending IP address in the End IP field.
To specify:
• A single remote IP address, enter the remote IP address.
A range of remote IP addresses, enter the starting IP address here and the ending IP
•
address range in the next field.
This field is unavailable if the Gateway is configured for any remote IP addresses.
Ending IP address in the LAN IP address range to which the access rule will be applied. This
field is unavailable if the Gateway is configured for any LAN IP address or a single LAN IP
address.
Lets you specify any local IP addresses, a single local IP address, or a range of local IP
addresses to which the access rule is applied.
If you select one local IP address, enter the IP address in the Start IP field.
•
If you select a range of local IP addresses, enter the starting IP address in the Start IP field
•
and the ending IP address in the End IP field.
To apply the predefined access rule to:
• A single local IP address, enter the local IP address.
A range of local IP addresses, enter the starting IP address here and the ending IP address
•
range in the next field.
This field is unavailable if the Gateway is configured for any local IP addresses.
Ending IP address in the local IP address range to which the access rule will be applied. This
field is unavailable if the Gateway is configured for any local IP address or a single local IP
address.
Starting port number on which the access rule will be applied. If necessary, contact the
application vendor for this information.
Ending port number on which the access rule will be applied. If necessary, contact the
application vendor for this information.
81
SMCD3GN2 Wireless Cable Modem User Manual
Description
